Digitus DS-55580 User manual

4K All-in-one video bar –
Video conference system
Quick Installation Guide
DS-55580

2
1. Introduction
The DIGITUS® 4K video conferencing system combines camera, microphone
and speaker in one device and is suitable for small to medium-sized rooms.
The video bar connects easily to a notebook or computer via USB. Thanks to
Plug-and-Play, installation is extremely easy, no additional software is
required. Delivery includes an additional microphone which extends the
audio range if needed as well as a remote control for convenient control of
the range of functions.
2. Main Features
4K Ultra-HD ePTZ (electronic Pan-Tilt-Zoom) camera
Ultra wide angle lens – 120° diagonal, 110° horizontal, 78° vertical
4K Ultra HD video calls (up to 3840 x 2160 pixels / 30 frames per second)
2.8" Sensor (Sony IMX415), 8 MP
Auto-framing, Smart Zoom (4x digital zoom) & AI Face/Speaker Tracking –
The video bar uses AI (Artificial Intelligence) to automatically adjust the
camera position, focus and zoom in order to optimally capture the video
participants
Beamforming microphone array – 4 integrated beamforming microphones
for speech capture and 5m audio range (voice pick-up)
Digital noise reduction & acoustic echo cancellation – suppresses
undesirable background noise and eliminates echoes
Additional table microphone included – additional 3m voice pick-up (audio
range), connection to video bar via network cable (10m, incl.)
Hi-Fi speaker with 5W max.
Remote control included for convenient control of functions
3. Package Content
1x Video Bar

1x Additional microphone

1x USB connection cable (USB-C – USB-A 5 m)

1x network cable (10 m)

1x remote control

1x power adapter (12V/2A)

1x user manual

3
4. Technical Data
Campatibility
Windows 7 or higher, macOS 10.10 or higher,
ChromeOS, Android 5.0 or higher
Camera lens Ultra wide angle lens (120° diagonal,
110° horizontal, 78° vertical)
Auto framing
Smart Zoom (4x digital zoom) & AI Face/ Speaker
Tracking
Microphone
Beamforming microphone array (4 integrated
beamforming microphones for speech capture and
5m audio range (voice pick-up));
Additional table microphone included (3m voice
pick-up (audio range), connection to video bar via
network cable (10m, incl.));
Speaker
Hi-Fi speaker with 5W max.
Control Function
Remote control included for convenient control of
functions;
Automatic control - aperture, brightness, contrast,
white balance
Resolution
up to 4K Ultra-HD (up to 3840 x 2160 / 30 Hz)
Video bar connections
1x USB-C 3.0 – Host PC connection;
1x RJ45 – Additional table microphone connection;
1x power supply input (External power)
supply connection;
1x audio input (3.5 mm);
1x audio output (3.5 mm)
DSP Audio
AEC technology;
AGC (Automatic gain control);
Noise Reduction
Dimensions
(W x D x H)
40 x 7.5 x 9,2 cm
Color
Black/ Gray

4
5. Connection Overview
1.)
Type C-Port
2.)
Power Interface
3.)
RJ45 for Extension Microphone
4.)
Security lock slot
5.)
Line in
6.)
Line out
7.)
4K ePTZ Camera
8.)
Camera Indicator
9.)
Microphone
10.)
Mount
11.)
Speaker

5
6. Set Up
1.)
Connect the Video Bar to PC/ conference host via USB cable and
connect the PC/ conference host TV via HDMI cable.
Type-C
2.)
Mount
USB Port
HDMI Port
TV HDMI
Port

6
3.)
Connect the power supply
.
Power
4.)
In computer/ conference software settings, choose the source of
camera, microphone and speaker from the USB video bar.
7. Camera indicator light status
The camera indicator light will turn blue when the camera is pened or under running.
It will turn red when the microphone is muted. For other normal conditions, the light
will be green.

7
8. Camera preset settings
Adjust the camera view to the positions you want to present, then long press 1 (or 2/
3) button for 2 seconds. After a hint tone appears, camera preset 1 is successfully set.
Repeat the above steps, press 1/ 2/ 3 keys respectively. You can set 3 preset positions
in total. By repeating the same key, it will overwrite the previous preset and update it
to the latest preset.
9. Camera Remote Control
Mute
Preset
Tilt
Pan
Tilt
Zoom out
Volume -
Rotate
Recovery
Pan
AI on/ off
Zoom in
Volume +
Disclaimer
Hereby Assmann Electronic GmbH, declares that the Declaration of
Conformity is part of the shipping content. If the Declaration of Conformity is
missing, you can request it by post under the below mentioned manufacturer
address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
