Dimplex BRAVA DXBRVAP5 User manual

DXBRVAP5
08/54813/0 Issue 1
This product complies with all the required UK & European Product Safety, Electromagnetic Compatibility and Environmental
Standards. It is fully compliant with the LVD, EMC, RoHS and Eco Design Directives
5 Stage Desktop Air Purier
IMPORTANT - Please ensure the bag protecting the lter is removed before use
Make your air good again

This product should be used only in accordance with the
specications outlined in this manual. Usage other than as specied
in these instructions may result in serious injury, risk of re or
electric shock.
DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your guarantee. The inside
of the unit contains no user serviceable parts. All servicing should
be performed by qualied personnel only.
IMPORTANT - To reduce the risk of electric shock, the plug is
intended to t in a standard polarized 13Amp socket outlet, only
plug the appliance directly into a proper electrical outlet.
WARNING: To avoid danger of su󰀨ocation please remove all
packaging materials particularly plastic and EPS and keep these
away from vulnerable people, children and babies.
Use this product on a horizontal and stable surface with the feet
securely tted or x to the wall as applicable.
WARNING - To avoid the risk of accidental strangulation from the
supply cord all children and vulnerable people must be supervised
when in the vicinity of the product whether it is working or not.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
Children of less than 3 years should be kept away unless
continuously supervised.
Children aged from 3 years and less than 8 years shall only switch
on/o󰀨 the appliance provided that it has been placed or installed in
its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3
years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in order
to avoid a hazard.
Important Safety Advice

DO NOT place the product directly below a xed socket outlet.
DO NOT use this product if it has been dropped
DO NOT use this product in the immediate surroundings of a bath, a
shower or a swimming pool.
WARNING: UV radiation is dangerous for the eyes and skin.
This appliance contains a UV-C emitter/lamp.
Unintended use of the appliance or damage to the housing may
result in the escape of dangerous UV-C radiation. UV-C radiation
may, even in little doses, cause harm to the eyes and skin.
Appliances that are obviously damaged must not be operated.
Note that the UV-C lamp is designed to last for approximately 10000
hours of use. The air purier will continue to operate without the
UV-C function when the UV-C lamp burns out.
UV-C Lamp is non-replaceable by the user, the user must not
attempt to replace the UV-C lamp.
The UV-C emitter must only be replaced by a qualied service/
maintenance person.
DO NOT use if there are visible signs of damage to the product.
WARNING: Do not use this product in small rooms when they are
occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided.
WARNING: To reduce the risk of re, keep textiles, curtains or any
other ammable material a minimum distance of 1m from the air
outlet.
DO NOT pull, carry or move the appliance using the power cable.
WARNING - To avoid re hazard - keep the cord out of heavy tra󰀩c
areas, DO NOT cover cord with carpeting, throw rugs, runners, or
similar coverings, DO NOT route cord under furniture or appliances,
NEVER put the cord near heat registers, radiators, stoves or
heaters.
Take care to position the cord away from tra󰀩c areas where it will
not be a tripping hazard.
The socket-outlet must be accessible at all times to enable the
mains plug to be disconnected as quickly as possible.
WARNING - Risk of re - Do not use this appliance connected
through an extension lead or any external switching device such as
a plug in timer or remote control plug in adapter, any weakness in
the design, connections or components in these devices can easily
result in overheating of the connection points resulting in melting,
distortion and even the risk of re.

Improve your indoor air quality with your new Brava air purier. It features a 3 in 1
pre-lter, true HEPA lter, active carbon lter, ioniser and a UV-C Light.
PRE-FILTER: Captures big particles, initial dust and allergen particles.
TRUE HEPA FILTER: Captures micro particles, dust, smoke, pollen and other
allergens.
ACTIVE CARBON FILTER: Removes odours and bad smells
UV-C LIGHT: Destroys micro-organisms such as germs, viruses, bacteria and
fungi (such as mold toxins).
ION Fresh Technology: Generates negative ions that attach themselves to ‘dirty’
positively charged ions to help combat airborne impurities to help create fresher
cleaner air.
Main unit
UV-C device
Pre-filter with carbon, HEPA filter
Base
Touch panel
Air outlet
Screw
Air Quality Sensor
Operating Instructions
BEFORE OPERATING THE AIR PURIFIER:
1. Carefully remove your air purier from box and plastic bag.
5 Stage Air Purication System
Product Overview
DO NOT COVER or obstruct the air inlet and outlet openings in any
way.
NEVER drop or insert any object into any openings.
This instruction leaet belongs to the appliance and must be kept in
a safe place. If changing owners, the leaet must be surrendered to
the new owner.

Operating the Air Purier
2. You must remove the PE bag from the lter before use, please dispose of it
safely away from vulnerable people, children and babies.
IMPORTANT: When moving the air purier, always lift or carry the unit holding
rmly using both hands.
3. Plug-in power cord to AC power supply.
4. Select a rm, level and at location for the air purier.
*For proper air ow, locate the unit at least 1foot / 30cm from any wall or furniture.
*Make sure none of the air inlet grills are blocked.
1. “POWER” BUTTON:
Press this button to turn on or switch o󰀨 the unit.
Note: To reset / switch o󰀨 the “FILTER RESET” indicator, press and hold the
“POWER” button for at least 5 seconds.
2. “SPEED” BUTTON:
Press this button to change and select the fan operation mode. There are 4 speed
settings – Low , Medium , High and Turbo , and also, an AUTO
mode setting which when selected will automatically adjust the speed based on
the air quality detected by the air quality sensor in the product.
Low is ideal for night time use in the bedroom. Turbo function is very useful to
remove odours from your kitchen after cooking.
3. “LIGHTS OUT SLEEP” BUTTON:
Press this button to turn on sleep mode function, after the indicator ickers for
5 seconds, it enters into sleep mode, all lights are o󰀨, the SPEED automatically
ION
ION
UV- C

Filter Removal / Replacement
changes to L speed.
Press any button to exit sleep mode.
Note: If you unplug the air purier during sleep mode it will come out of Sleep
setting.
4. “TIMER” BUTTON:
Press this button one or more times, the numerical display indicates the operation
time you set (from 1 to 12 hours).
5. “UV-C” BUTTON:
Press this button to turn on or turn o󰀨 UV-C lamp.
6. “IONISER” BUTTON:
Press this button to turn on or turn o󰀨 Ioniser function.
7. PM 2.5 indicator and LED display:
This measures PM (Particle Matter) that are 2.5 microns in size. These particles
are microscopic and are the most dangerous to human health as they can enter
the lungs and blood stream. The LED indicator changes colour according to how
dirty/ polluted the air is:
Red: Heavily Polluted >150μg/m³
Orange: Lightly Polluted >100 - 149μg/m³
Yellow: Moderate >50 - 99.9μg/m³
Blue: Good >0 - 49μg/m³
Important note: When the unit is not in use, please switch it o󰀨 and unplug it.
FILTER REPLACEMENT INDICATOR
A continuous red FILTER RESET light indicates that it is time to replace the lter. Replace the lter
according to the directions below then press and hold the POWER button for 5 seconds to restart
the program system. The FILTER RESET light will turn o󰀨.
*The 3 in 1 lter will last approximately 6 months depending on how dirty the air is.
ION
Find the knob in the bottom Turn the knob to left, lift the upper shell
Filter
Change the filter Put back the upper shell Turn the knob to right
Turn right
Turn left
UV- C

1. Unplug the product.
2. Turn the product Upside down.
3. Slide the switch to unlock and remove the base.
4. Take out dirty lter and insert new lter into the unit.
5. Re-attach the base to the unit (making sure you align the inetrnal tabs) and slide the switch to re-
lock to secure the base.
FILTERS
HEPA and activated carbon lter should be cleaned once every month by vacuum cleaner.
Note: Filters should be replaced at least once every 6 months. More frequent cleaning and replacing
may be required depending on environmental conditions.
Technical Specication
DXBRVAP5 Symbol Value Unit
Clean Air Delivery Rate CADR 230 m³/hr
Fan Power Input P33 W
Standby Power Consumption PSB 0.5 W
UV Light Power P3W
Fan Sound Power Level LWA 60 dB(A)
Rated Voltage V230 V (AC)
Rated Frequency Hz 50 Hz
Standards application EN 60335-1; EN 60335-2-65
Mini Troubleshooting Guide
Before carrying out any of the following service checks, unplug the unit from the mains.
Insu󰀩cient air ow:
Unit will not start:
Excessive noise:
Check that the lters are clean/lter bag has been removed.
Check for any obstructions in the air inlet and outlet
Check the power supply and electric fuses
Check that the Front Cover is latched rmly in place and the lter is rmly in
place.
Check for any foreign objects in contact with the fan. The lter may be clogged
and ready for replacement.
The foam sealing gaskets have been installed incorrectly.
Uneven positioning.
WARNING ALWAYS DISCONNECT FROM THE POWER SUPPLY BEFORE CLEANING THE
APPLIANCE
The appliance should be cleaned at least once every month as dust may accumulate which would
a󰀨ect performance. Do not use detergents, abrasive cleaning products or polish of any kind on the
appliance. Wipe with a clean, dry, soft cloth to remove dust and a damp cloth (not wet) to clean o󰀨
stains. Be careful not to allow moisture into the appliance. Use a vaccum cleaner to remove any u󰀨
which does accumulate.
NOTE:
• Do NOT stick any foreign objects or your ngers inside of the unit.
• Do NOT use gasoline, benzine, thinner, harsh cleaners, etc. on and/or in the unit while cleaning
as they will damage the product.
• NEVER use alcohol or other solvents.
Cleaning and Maintenance

Service
The UV-C emitter must only be replaced by a qualied service/
maintenance person.
The appliance must be disconnected from the mains before any
service or maintenance is carried out.
Qualied Service/Maintenance personnel must read the service
instructions below before opening the appliance.
CAUTION: Do not operate the air-purier without the protective
UV-C bulb cover tted.
WARNING: Do not operate the UV-C emitter (lamp) outside the
appliance.
Note: The UV-C bulb contains mercury (Hg).
UV-C LAMP REPLACEMENT
1. Follow steps outlined above to remove 3 in 1 lter to obtain access to the UV-C lamp.
2. Remove the lamp cover screw with a small phillips screwdriver.
3. Carefully remove the lamp holder and unclip the attached wire.
4. Remove lamp from holder and replace with new lamp back in the holder. Please be gentle when
removing or replacing the lamp.
5. Reattach lamp wire to adjoining connector and place lamp holder back in position. Carefully place
the lamp cover over the lamp and twist clockwise and secure with screw.
6. Replace 3 in 1 lter, base and re fasten securely.
Note: Do not look into the UV-C lamp when it is ON.
Note: You can obtain replacement lters and UV-C lamps at www.dimplex.co.uk
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not be disposed of within
household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice in your country.
