Dimplex DXAPV3N User manual

DXAPV3N
Air Purifier
With
Enviro-neutralising Technology
WARNING:
Please read before use these instructions and keep them for
future reference.
DXAPV3N

SAFETY WARNINGS
ATTENTION!
• This unit is regarded as an “purifier for domestic environments”;
any other use is to be considered inappropriate and therefore
dangerous. The manufacturer cannot be held liable for any
damages caused by improper, erroneous or unreasonable use.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been provided supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children should not carry out cleaning or maintenance of the
product without supervision.
• In order to avoid a hazard, if the supply cord (6) is damaged, it
must be replaced by the manufacturer, its service agent or
similarly qualified persons.
• Only place the appliance on hard, flat and stable surfaces which
are inaccessible to children.
• When the product is working do not cover the back grill or air
output.
• Before cleaning or maintenance, unplug the product power cord
(6) from the power supply.

Fig. 1
1
4
7
8
3
6

DXAPV3N Air Purifier
WARNING:
Please read before use these instructions and keep them for future
reference.
The DXAPV3 Dimplex Air Purifier has been designed to improve the quality of
indoor air, reducing the presence of polluting agents such as dust, cigarette
smoke, unpleasant odours, spores, bacteria, pollen, dust mite residues, pet
dander etc.
Air passes through an active carbon filter which helps to eliminate dust and
odours such as cigarette smoke. The air is then passed through a HEPA filter,
able to retain 99.97% of polluting particles with a microscopic size of 0,3µm
upwards; such as pollen, dust mites, mould spores and bacteria.
Air purification is assisted with the built-in Dimplex Viro³ Enviro-neutralising
Technology.
Enviro-neutralising Technology
The Viro³ Enviro-neutralising Technology generates a balance of positive and
negative ions from water vapour in the air. These ions cluster around harmful
substances such as airborne mould, viruses and allergens, changing their
chemical make-up and rendering them inactive and harmless to the human
body. The negative ions produced by the Viro³ Enviro-neutralising Technology,
are similar to those which can be found in uncontaminated areas of nature
such as waterfalls, beaches and in the mountains. They enrich the air and
naturally give a sensation of clean air, reducing psychophysical stress.
The DXAPV3N has two airflow speeds with a max air flow rate of 44m³/H. It
has a low power consumption of 25W and is suitable for environments of a
size up to 55m².
KEY (Fig.1)
DXAPV3N
1. Feet
2. --
3. Back grill
4. Back grill hook

5. Filter
6. Supply cord
7. ON/OFF switch
8. Air output
WARNINGS
• This product is not a toy. Keep the appliance, the back grill (3) the filter (5),
the feet (1), and the power cable (6) out of the reach of children.
• Do not start the appliance work without the filter (5) or the back grill (3).
• Fix the filter (5) only by the use of the back grill (3).
• After having removed the appliance from its packaging, ensure that it is
intact and that there is no visible damage. When in doubt, do not use the
appliance and only contact technically competent personnel or retailers.
• Keep all components and packaging out of the reach of children.
• Before connecting the appliance, ensure that the information on the rating
label is compatible with your electricity distribution network. The rating label is
located on the bottom of the appliance.
• Only connect the appliance to a socket that is accessible to adults.
• Do not move, lift, tilt, or perform any cleaning or maintenance when the
purifier is in use or connected to the mains.
• Before cleaning or drying the appliance, remove the power cord (6) from the
socket.
• Never leave the power cable plug (6) inserted in the socket when the unit is
unattended or not in use.
•Do not use accessories, spare parts or components that have not been
provided/ supplied by the manufacturer.
• Any repairs should only be performed by competent technical personnel.
• The use of any electrical appliance requires compliance with certain basic
rules:
- Never touch the unit with wet or humid hands.
- Do not pull the power cord (6) or the appliance itself to remove the plug from
the socket.
- Never leave the appliance exposed to natural elements (rain, sun, etc.).
- Keep the appliance and the power cable away from sources of heat.
- Never immerse the appliance in water, other liquid or place it under running
water.

- Do not touch the appliance if it has accidentally dropped into water;
immediately turn the power off, turn off the power in your home and remove
the plug from the socket before touching the appliance. Do not reuse the
appliance but contact the retailer or an authorized service centre.
- This appliance contains no parts that can be serviced or reused by the user
and it can only be opened with special tools. In the event of failure and/or poor
operation of the unit, switch it off immediately and remove the plug from the
socket. Do not attempt to tamper with the unit and only contact the retailer or a
service centre authorized.
• If the unit is not used for an extended period of time, it must be stored as
detailed in the paragraph regarding Cleaning and Maintenance.
• Should the unit no longer be used, it is advisable to make it inoperative by
cutting the power cable, after removing the plug from the socket.
• Do not dispose of as household waste but recycle, as it is
electrical/electronic equipment (WEEE), as required by applicable laws and
EU directives.
• To avoid the risk of fire, do not pass the power cable (6) under rugs or near
radiators, stoves and heaters.
• Do not keep the purifier in environments with extreme temperatures.
• Product features may be subject to change without notice.
• If you have doubts about the interpretation of anything within this instruction
booklet, contact your retailer or the manufacturer.
INSTRUCTIONS FOR USE
PRELIMINARY OPERATIONS
1. Position the appliance in its selected position, observing the requirements
outlined in the Warnings paragraph.
2. Position the product so that the back grill (3) and the air output (8) are not
covered.
3. Verify that filter (5) and back grill (3) are inserted before switching the
product on.
4. Connect the power cable plug (6) to a socket that is inaccessible to
children.
SWITCHING THE APPLIANCE ON AND OFF
5. Move the ON/OFF switch (7) from “OFF/0” position to “●” in order to switch
on the appliance on speed 1, a light will indicate function.

Move the ON/OFF switch (7) to the “●●” position in order to switch to speed 2,
a light will indicate function
Move back the ON/OFF switch (7) to “OFF/0” position in order to switch off the
product.
CLEANING AND MAINTENANCE
Warning!
Before performing the following cleaning/ maintenance operations, always
switch off the appliance and unplug the power cable (6) from the socket.
HOW TO CLEAN THE EQUIPMENT
Always remember to disconnect the power cable plug from the mains socket
before carrying out any cleaning operations. It is recommended that you clean
the outer body of the product every 2 weeks, using a soft cloth dampened in
water. Do not use sprays, alcohol or other aggressive or abrasive substances.
Only clean the air outlet grill (3) with a soft brush to lift any dust. Do not insert
any objects into the openings of the product.
Warning!
1. Do not immerse the appliance in water or other liquid. Do not place the
appliance under water or use near jets of water; if electrical parts come into
contact with water, do not use the appliance and contact your retailer or a
service centre authorized by the distributor.
2. Keep water away from the power cord (6).
3. Any repairs must only be performed by a service centre authorized by the
distributor.
REPLACING THE FILTER
The DXAPV3N is supplied with a combined filter made up of an active
carbon pre-filter and HEPA 1 filter.
The filter cannot be washed and its life depends on the time of use and the
quality of air in the environment. (It is recommended to replace the filter at
least every 2000 hours of use). If the environment is particularly dusty, the
filter should be replaced more frequently. It is recommended to regularly check
the amount of dirt accumulated in the filter.

How to Replace the Filter:
•Keep the product and cable away from heat sources.
•Switch off the equipment and disconnect the power cable plug from the
mains socket.
•Raise the filter release catch located at the rear of the product and remove
the air inlet grill (4).
•Remove the old filter (5) and replace it with a new filter.
•Reassemble the equipment carrying out the above operations in the
reverse order.
WARNING! Ensure the active carbon filter (darker filter) is placed closest to
the air inlet grill when put back into the filter housing.
WARNING! Replace the filter with an original filter supplied by Dimplex or
the retailer/supplier only.
The use of filters not approved by the manufacturer could impair the safety
and operation of the equipment.
PURCHASING SPARE FILTERS
In the first instance spare HEPA and carbon filters should be purchased from
Dimplex by contacting tel: [phone] (Customer Services).
Alternatively spare filters may be available from the retailer/supplier.
GDC Group Ltd reserves the right to modify the content of these instructions,
at any time and without prior notice.
TECHNICAL FEATURES
MOD. DXAPV3N
Nominal voltage: 220-240V~ 50Hz
Absorbed power: 25W
Suitable air cleaning capacity: 55m³
Weight: 1.6Kg
Measurements: 240x130x330mm
Storage environmental conditions:
Ambient temperature: -10 ÷ +50 °C
Relative humidity: 10 ÷ 90%

CE Conformity:
This air purifier appliance complies with all the essential requirements and
other provisions indicated in the EC Directives 2014/30/EU (electromagnetic
compatibility) and 2014/35/EU (electrical safety). To request a copy of the EC
declaration, please contact the Manufacturer.
SYMBOLS KEY
Equipment in compliance with the essential requirements laid
down in the EC Directives in force
Warning!
Class II equipment
Users instructions
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this
product for environmental safe recycling.
AFTER SALES SERVICE
Your product is guaranteed for 1 year from the date of purchase. The 1 year
guarantee is extended for an additional 2 years when you register the product
with Dimplex within 28 days of purchase. If you do not register the product
with Dimplex within 28 days your product will remain guaranteed for 1 year
only.
Within the extended warranty period we undertake to repair or exchange this
product free of charge providing:
a) Proof of purchase such as sales receipt can be provided, showing that the
appliance was bought within the 12-months prior to registering the
defect/fault.

b) The appliance was correctly operated in accordance with the
manufacturer’s instructions and used solely for domestic purposes.
c) The defect/fault was not as a result of accident, misuse, unauthorised
modification or inexpert repair.
Your rights under this guarantee are additional to your statutory rights, which
in turn are not affected by this guarantee.
Validation of extended warranty
To validate your extended warranty, register with us online at
http://register.dimplex.co.uk
N.B. Each qualifying product needs to be registered with Dimplex individually.
Please note that the extended warranty is only available in the UK and
Ireland.
Should you require after sales information or assistance with this product in
the first instance please email us at:
Email: [e-mail]
DIMPLEX
MILLBROOK HOUSE
GRANGE DRIVE
HEDGE END
SOUTHAMPTON
SO30 2DF
Tel: [phone]
A division of GDC Group Ltd,
Website: www.dimplex.co.uk
This product complies to EU directive 2012/19/EU. The crossed bin symbol on the
appliance indicates that the product, at the end of its life, must be disposed of
separately from domestic waste, either by taking it to a separate waste disposal site for
electric and electronic appliances or by returning it to your dealer when you buy
another similar appliance. The user is responsible for taking the appliance to a special
waste disposal site at the end of its life. If the disused appliance is collected correctly
as separate waste, it can be recycled, treated and disposed of ecologically; this avoids
a negative impact on both the environment and health, and contributes towards the
recycling of the product’s materials. For further information regarding the waste
disposal services available, contact your local waste disposal agency or the shop
where you bought the appliance.
