DXAPV3
Air Purifier
with
Enviro-neutralising Technology
USER MANUAL
Issue 02 - 2011

GB Dimplex Air Purifier
Please read these instructions carefully before
use and keep them for future reference.
The DXAP 3 Dimplex Air Purifier has been designed to
improve the quality of air indoors, reducing the presence of
polluting agents, such as dust, cigarette smoke, unpleasant
odours, spores, bacteria, pollen, dust mite residues, pet
dander etc.
Air passes through an active carbon filter which helps to
eliminate dust and odours such as cigarette smoke. The air
is then passed through a HEPA filter, able to retain 99.97% of
polluting particles with a microscopic size of 0.3 µm
upwards; such as pollen, dust mites, mold spores and
bacteria.
Air purification is assisted even further with the built-in
Dimplex iro³ Enviro-neutralising Technology.
Enviro-neutralising Technology
The iro³ Enviro-neutralising Technology generates a
balance of positive and negative ions from water vapour in
the air. These ions cluster around harmful substances such
as airborne mold, viruses and allergens, changing their
chemical make-up and rendering them inactive and
harmless to the human body. The negative ions produced
by the iro³ Enviro-neutralising Technology, are like those
which can be found in large quantities in uncontaminated
areas in nature, near waterfalls, beaches and in the
mountains. They enrich the air and naturally give a
sensation of clean air, reducing psychophysical stress.
The DXAP 3 has two airflow speeds with a max air flow rate
of 72m³/h, has a low power consumption of 40W and is
suitable for environments of a size up to 28m².
KEY
1. Stabilising Feet
2. Foot Housings
3. Air Inlet
4. Filter Release Catch
5. Active Carbon and HEPA Filter
6. Power Cable
7. ON/OFF & Fan Speed Selection Switch
8. Air Outlet Grille
WARNINGS
•After removing any packaging materials, ensure that the
product has not been damaged during transportation. In
the case of doubt, do not use and return to the point of
purchase.
•Do not leave any packaging materials (plastic bags,
cardboard boxes, etc) within the reach of children.
•Before connecting the equipment, ensure that the rated
voltage corresponds to the mains’ voltage supply. The
voltage rating plate is located underneath the product
•Always disconnect the equipment from the mains when
it is not in use or left unattended.
•This product is not a toy and it should be kept out of the
reach of children
•Keep the product and cable away from heat sources.
•Before carrying out any cleaning or maintenance,
operations, disconnect the product from the mains.
•Do not use accessories, spare parts, or any component
not supplied or approved by the manufacturer, as they
may make the product unsafe.
•This equipment is only intended for the use it has been
specifically designed for (an Air Purifier for domestic use
only). Any other use is to be considered inappropriate
and therefore dangerous. GDC Group Ltd declines all
responsibility for any damage caused by the
inappropriate, incorrect or unreasonable use of the
equipment.
The use of any electrical equipment requires compliance
with some fundamental rules. In particular:
•Never touch the product with wet or damp hands.
•Never submerge the product in water or any other liquid.
•Do not touch the product if it accidentally falls into
water; unplug it immediately and do not use afterward.
Contact a qualified electrician or the manufacturer.
•Do not pull the power cable or the product to
disconnect it from the mains socket.
•Do not leave the product exposed to atmospheric
agents (rain, sun, etc).
•The parts and components of this product cannot be
repaired by the user. If the equipment is damaged
and/or not working correctly, switch it off by
disconnecting the power cable plug from the mains
socket, do not attempt to open the product, and
contact a qualified electrician or the manufacturer.
•When the product is no longer in use, it is recommended
to unplug it from the mains socket and remove the
power cable
•To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle this
product responsibly to promote the sustainable reuse of
material resources. DO NOT DIS OSE OF WITH GENERAL
HOUSEHOLD WASTE.
•This equipment is approved to EC directives.
•If the power cable is worn and/or damaged, it must only
be substituted with another power cable the some type
by a qualified electrician.
•The appliance is not intended for use by children or other
persons without assistance or supervision if their physical,
sensory or mental capabilities prevent them from using it
safely. Children should be supervised to ensure that they
do not play with the appliance.
HOW TO OSITION THE EQUI MENT
Insert the two feet into the appropriate housings located at
the rear of the equipment (diag. 1).
Position the product out of reach of children, on a flat,
stable surface. Ensure that the air inlet/outlet grilles are not
obstructed to allow suitable air circulation around the
product.
WARNING: Never place the DXAP 3 air purifier near or on
top of electrical, electronic or radio electrical equipment.
HOW TO SWITCH ON THE EQUI MENT
•Connect the power cable plug to a mains socket that is
easily accessible.
•Switch on the equipment by placing the ON/OFF switch
lever to the:
• (slow airflow) or
•• (fast airflow) position.

HOW TO CLEAN THE EQUI MENT
Always remember to disconnect the power cable plug
from the mains socket before carrying out any cleaning
operations. It is recommended that you clean the outer
body of the product every 2 weeks, using a soft cloth
dampened in water. Do not use sprays, alcohol or other
aggressive or abrasive substances. Only clean the air outlet
grille (diag.3) with a soft brush to lift any dust. Do not insert
any objects into the openings of the product.
RE LACING THE FILTER
The DXAP 3 is supplied with a combined filter made up of
an active carbon prefilter and HEPA 1 filter.
The filter cannot be washed and its life depends on the time
of use and the quality of air in the environment. (It is
recommended to replace the filter at least every 2000 hours
of use). If the environment is particularly dusty, the filter
should be replaced more frequently. It is recommended to
regularly check the amount of dirt accumulated in the filter.
How to Replace the Filter:
•Keep the product and cable away from heat sources.
•Switch off the equipment and disconnect the power
cable plug from the mains socket.
•Raise the filter release catch located at the rear of the
product and remove the air inlet grille (diag.2).
•Remove the old filter (diag.4) and replace it with a new
filter.
•Reassemble the equipment carrying out the above
operations in the reverse order.
WARNING! Ensure the active carbon filter (darker filter) is
placed closest to the air inlet grille when put back into the
filter housing.
WARNING! Replace the filter with an original filter supplied
by Dimplex or the retailer/supplier only.
The use of filters not approved by the manufacturer could
impair the safety and correct operation of the equipment.
URCHASING S ARE FILTERS
In the first instance spare HEPA and carbon filters should be
purchased from Dimplex by contacting tel: [phone]
(after sales).
Alternatively spare filters may be available from the
retailer/supplier.
GDC Group Ltd reserves the right to modify the content of
these instructions, at any time and without prior notice
AFTER SALES SERVICE
Your product is guaranteed for one year from the date of
purchase. Within this period, we undertake to repair or
exchange this product free of charge (subject to
availability), provided it has been operated in accordance
with these instructions.
Your rights under this guarantee are additional to your
statutory rights, which in turn are not affected by this
guarantee.
Should you require after sales information or assistance with
this product in the first instance please email us at:
Email: [e-mail]
DIM LEX
MILLBROOK HOUSE
GRANGE DRIVE
HEDGE END
SOUTHAM TON
SO30 2DF
Tel: [phone]
A division of GDC Group Ltd,
Website: www.dimplex.co.uk
This product complies with EU Directive
2002/96/EC.
The crossed bin symbol on the appliance
indicates that the product, at the end of its
life, must be disposed of separately from domestic waste,
either by taking it to a separate waste disposal site for
electric and electronic appliances or by returning it to your
dealer when you buy another similar appliance. The user is
responsible for taking the appliance to a special waste
disposal site at the end of its life. If the disused appliance is
collected correctly as separate waste, it can be recycled,
treated and disposed of ecologically; this avoids a
negative impact on both the environment and health, and
contributes towards the recycling of the product’s
materials.
For further information regarding the waste disposal services
available, contact your local waste disposal agency or
manufacturer.
