Dimplex DHCER24M User manual


2.4KWCERAMICHEATER
WITHMANUALCONTROLS

DHCER24M

UserManual



Pleasereadtheinstructionscarefullybeforeusingtheproductand
keepthisusermanualforfuturereference.

2
1.PRODUCTFEATURES
2.4kWheatoutput
Choiceofheatsettings
Doubleoverheatprotection
Tipoversafetyprotection
Oscillatingfunction
Manualcontrols
12monthwarranty

3
2.SAFETYWARNINGS
Pleaseoperatetheheateronadryevensurface.
Thisapplianceisnotintendedforusebypersons(includingchildren)with
reducedphysical,sensoryormentalcapabilities,orlackofexperienceand
knowledge,unlesstheyhavebeengivensupervisionorinstructions
concerningtheuseoftheappliancebyapersonresponsiblefortheirsafety.
Disconnecttheheaterfrommainswhennotinuseorcleaning.
Donotoperatetheappliancewithadamagedcordorplug.Ifthepower
supplycordisdamaged,itmustbereplacedbythemanufacturerorits
serviceagentorasimilarlyqualifiedpersoninordertoavoidahazard.
Itisnotrecommendedtouseanextensioncordorpowerboardonthis
appliance.
Donotimmersecord,plugoranypartoftheapplianceinwateroranyother
liquid.
Donotplacetheheateronornearanyothersourceofheat.
WARNING:donotcovertheheater.Thismaycausetheunittooverheat.
Afiremayoccuriftheheateriscoveredwithortouchesflammablematerial,
includingcurtains,drapes,beddingetc.WheninoperationKEEPTHEHEATER
AWAYFROMSUCHMATERIALS.
Donotusetheheaterintheimmediatesurroundingsofbathtubs,showers,
washingstandsorswimmingpools.
Donotusetheheateroutdoors.
Whentheheateristurnedonforthefirsttime,itmayreleaseaslight,
harmlessodor.Thisodorisanormaloccurrencecausedbytheinitialheating
oftheinternalheatingelementsandshouldnotoccuragain.
Donotoperatetheheaterinareaswhereflammableliquidsarestored.
Donotoperatetheheaterincloseproximitytocurtainsorothercombustible
materials.Keepanycombustiblematerialsatleast1.0mawayfromthe
heater.

4
3.ASSEMBLYINSTRUCTION

Openthepackaging,taketheunitoutandunscrewthebasefixingnut.
Insertthebaseintothebottomoftheunitandscrewonthebasefixingnut.
Turntheunituprightandplaceitonaflatorevensurfacebeforeuse.

5
4.PARTSDESCRIPTION


1. Base2.FrontCover
3. MeshCover4.LogoNameplate
5. ControlKnob6.KnobBezel
7. HandleCover8.Handle
9. HeadCover10.RightCover
11.BackCover12.BottomCover
13.LeftCover14.SwingBase

6
5.OPERATINGINSTRUCTIONS
First,connectthepowercordtothecorrectpowersupply(220‐240V~/50Hz/10
amps).



PowerSettingKnob
Rotatetheknobtothe“Off”positiontoturnofftheunit.
Rotatetheknobto“Low”toturntheunitonatlowheat.
Rotatetheknobto“LowSwing”toturntheunitonatlowheatwith
oscillation.
Rotatetheknobto“High”toturntheunitonathighheat.
Rotatetheknobto“HighSwing”toturntheunitonathighheatwith
oscillation.

TemperatureAdjustmentKnob
Rotatetheknobclockwisetosetyourdesiredtemperature.
Whentheunitreachesthesettemperature,theunitwillpoweroffandthe
indicatorlightwillalsobeswitchedoff.
Ifthetemperaturedrops,thedevicewillturnonautomaticallyandthe
indicatorlightwillbeswitchedbackon.


7
6.CLEANINGANDMAINTENANCE
Makesurethepowerswitchisturnedoffandtheplugisdisconnectedfromthe
socketbeforecleaningormaintenance.Otherwise,itmaycauseanelectricshock.

Cleaningtheunit’ssurface:
Cleanthesurfacewithadampcloth(oraddsomedetergent).Donotuse
corrosivedetergentorsolventtoclean,suchasPetrol/Turpentineetc.Donot
washtheunitdirectlywithwater.

8
7.SPECIFICATION
ModelNo.DHCER24M
Productname2.4kWCeramicHeaterw/Manual
Controls
Voltage/Frequency220‐240V~/50Hz
Power1400/2400W
Speed≥1.5m/s
Noise≤50dB（1m）
Tipoverprotectionangle45±5°
Productsize633hx221wx209d(mm)
N.W.3.25kg
G.W.…kg


DISPOSAL:Donotdisposethisproductasunsortedmunicipalwaste.
Collectionofsuchwasteisrequiredtobedisposedofseparately.


