Dimplex PLX075NN User manual

Convector Heater
PLX075NN/PLX100NN/PLX150NN/PLX200NN
1. Important Information
Please read carefully all the information provided in
these instructions. Keep the instructions in a safe place
and if necessary give them to any future owner.
-The device may only be installed by an authorized
and qualified technician.
-The unit may only be used for space heating in
enclosed rooms.
-Any examination of the heater or repair work may
only be carried out by a qualified electrician.
-Disconnect the heater from the power supply if it is
faulty or is not used for a long time. Disconnect or
shut off the power at the breaker.
-Do not cover the heater in any way (risk of fire).
- Warning: Outer surfaces become hot when heater
is switched on.
-The heater must not be operated by children or
other persons not capable of using the appliance in
a safe manner. Children must be prevented from
playing with the appliance.
-Do not insert any objects into the openings.
-Do not use the heater in rooms containing
flammable materials (e.g. solvents, etc.).
-Do not place the connecting lead on top of the
appliance.
WARNING:
If the heater is switched on automatically, there is a
danger of fire if it has been in any way covered or
blocked.
2. Positioning, Installation, Minimum Clearances
When installed, the heater must be aligned horizontally
on a vertical wall, as shown in the illustration.
The minimum clearances shown must be complied
with.
In addition, a minimum distance of at least 20” must be
maintained in front of the heater.
The heater must not be located directly beneath a wall
socket outlet.
Do not install the heater where the controls can be
reached by a person bathing or showering.
CAUTION:
Do not place near flammable objects.
Ensurethataircanenterandleavetheheaterfreely,at
the inlets below and the outlets above.
The recess box must be accessible for inspection after
theappliancehasbeenmounted.
Wall Mounting
IMPORTANT
Theoriginalwallbracketssuppliedattachedtotherear
of the unit must be used.
-Drill mounting holes for the wall brackets.
-Screw the brackets securely to the wall.
-Hang the heater from the wall brackets using the slits
in its rear wall.
-Secure the heater at the top on the wall brackets.
3. Electrical Connection
All wiring must comply with National Electrical codes
and local codes and utility requirements. This
installation should be entrusted to duly qualified
personnel where required by law.
Connect the supply wire into a properly rated recess
box. Consult your local electrical code for applicable
wire gauge. Connect L1 from the power supply to the
blue wire from the unit, connect the L2 wire from the
power supply to the brown wire from the unit, and
connectthegroundtotheyellow/greenwirefromthe
unit.
5 15/16”
5 15/16”
5 15/16”
16 15/16”
1-888-346-7539
7207930100r01

4. Anti-Overheat
Theheaterisprotectedwithasafetydevicetoprevent
overheating. Shouldthe heateroverheat due toimpeded
air circulation the automatic cutout will turn the heater off.
Theheater will reactivate once the heaterhascooled.
Keep the air inlets and outlets free of dust to ensure that
maximum heat output is available. Before the start of the
heatingseason, vacuum-clean theheater to remove any
dirt or dust.
5. Possible Faults
If the heater does not give out any warmth, check that
the thermostat is set to the correct temperature. Then
check the fuse or circuit breaker.
If the cause of the fault cannot be identified, contact the
nearestafter-salesservice center.
You must state the unit model number, as indicated on
the type plate (wiring compartment cover). Any
examination of the heater or repair work may only be
carried out by a qualified electrician or after-sales
service technician.
6. Cleaning
Before cleaning, ensure that the heater is disconnected
from the power supply and that it has cooled down. The
outer surface can be wiped with a soft damp cloth. Do
not use scouring powder or furniture polish, as these
can damage the surface.
Dust that collects within the unit can be removed from
the outside using a vacuum cleaner.
7. Technical Data
Power supply voltage 240/208volts
Protection class I Protective earth terminal
Protectionsystem IP 24
Drilling dimensions (front view)
8. Warranty
Two year limited warranty on complete unit, plus an
additional 10 year warranty on the elements. The
warranty is not valid without a sales receipt marked with
the date of purchase.
A5 15/16”
5 15/16”
16 15/16”
5 1/2”
7 1/4”
4 1/8”
2 1/2”
10”
4 5/8”
5 15/16”
8 7/16”
Cable entry
1367 Industrial Road
Cambridge, Ontario
Canada, N1R 7G8
1-888-DIMPLEX
1-888-346-7539
Type Voltage Output Weight Width Height Depth Dim A
PLX075NN 240/208 750/562W 6.2 kg 24 5/16” 16 15/16” 4 1/2” 11 1/4”
PLX100NN 240/208 1000/750 W 6.2 kg 24 5/16” 16 15/16” 4 1/2” 11 1/4”
PLX150NN 240/208 1500/1125W 6.6 kg 27” 16 15/16” 4 1/2” 13 15/16”
PLX200NN 240/208 2000/1500W 8.0 kg 33 3/4” 16 15/16” 4 1/2” 20 11/16”
