A world of expertise Operating Instructions
These instructions should be read carefully and
retained for future use. Note also the information
presented on the appliance.
Saletto
Low Profile Panel Heaters
Models: LPP050 LPP075
LPP100 LPP150
INDLUKP1RG ISSUE 0

IMPORTANT
These instructions should
be read carefully and
retained for future use.
Note also the information
presented on the
appliance.
IMPORTANT SAFETY ADVICE
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electrical shock,
and injury to persons, including the following:
IMPORTANT - The wall bracket supplied with the appliance must
be used.
WARNING - DO NOT USE THIS HEATER IN THE IMMEDIATE
SURROUNDINGS OF A BATH, A SHOWER OR A SWIMMING
POOL.
IMPORTANT - If the heater is installed in a room containing
a bath or shower, it must be installed that switches and other
controls cannot be touched by a person using a bath or shower.
Do not use outdoors.
Do not locate the heater immediately below a fixed socket outlet
or connection box.
Do not cover the heater. Do not place material or garments on
the heater, or obstruct the air circulation around the heater, for
instance by curtains or furniture, as this would cause overheating
and a fire risk.
The heater carries the Warning symbol indicating that it
must not be covered.
WARNING - THE SURFACES OF THIS HEATER CAN BE HOT.
Momentary contact with any part of the heater should not cause
injury.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Notethat duecare andconsiderationmustbetakenwhenusingthis
heater in series with a thermal control, a program controller, a timer
or any other device that switches on the heat automatically, since a
fire risk exists when the heater is accidentally covered or displaced.
If the supply cord is damaged is damaged it must be replaced
by the manufacturer, its service agent or a similarly qualified
persons in order to avoid a hazard.

Electrical
WARNING- THIS APPLIANCE MUST BE EARTHED
The electrical installation must be carried out by a competent
electrician, and be in strict accordance with the current I.E.E.
regulations for Electrical Equipment in Buildings.
The wires in this mains lead are coloured in accordance with the
following code:
GREEN AND YELLOW: EARTH
BLUE: NEUTRAL
BROWN: LIVE
BLACK: PILOT WIRE
- see also ‘Pilot Wire Connection’
The heater is fitted with a length of flexible cable type H05VV-F
size 4x1.0mm2for connection to the fixed wiring of the premises
through a suitable connection box positioned adjacent to the
heater.
A means of disconnection must be incorporated in the fixed wiring
of the premises in accordance with the wiring rules. The supply
circuit to the heater must incorporate a double pole isolating
switch having separation of at least 3mm.
Pilot Wire Connection
The BLACK wire is designed to carry a signal from slot in or wall
mounted Dimplex programmers. If, however a programmer is not
being used, the pilot wire should be isolated in accordance with
the current IEE Wiring Regulations.
IMPORTANT - DO NOT connect the BLACK pilot wire to earth.
Care should be taken with the installation of pilot wire(s) as when
switching to background (set back) they become energised at
240V although only at a current less than 100mA. In every case
a suitable means of isolation must be provided for the pilot wire
and marked to indicate that two sources of supply may be present
at the heater.
Where pilot wires are installed separately from the heater final
sub-circuit they should be protected, double insulated and carry
their own integral earth continuity conductor.
Supplementary Earth Bonding
Should Equipotential Earth Bonding be required the earthing
conductor in the supply cord is deemed to provide the
supplementary bonding connection (see Regulation 544.2.5,
17th Edition I.E.E. Wiring Regulations).

General
The heater is designed for wall mounting on the
wall bracket supplied. It should only be operated
when in the upright position. - see Fig.1 and
Fig.2.
All models are splashproof to IPX4 standard
and may be used in bathrooms, however not in
the immediate vicinity of baths, showers, water
connections, wash basins or swimming pools.
Before connecting the heater check that the supply
voltage is the same as that stated on the heater.
NOTE - Lit cigarettes, candles and oil burners,
combined with the convection effect of electric
heaters can cause soot deposits to build up on
the surface directly above and to the sides of the
heater. This is not a fault of the heater. Extensive
burning of candles or smoking in the operating
environment of this product can produce heavy
discolouration within a few months of use.
Dimensions
Model(s) Watt A (mm)
LPP050 0.5kW 746
LPP075 0.75kW 746
LPP100 1.0kW 877
LPP150 1.5kW 1142
Wall Mounting
IMPORTANT - The wall bracket supplied with
the appliance must be used. The heater should
be positioned observing the minimum clearances
stated around the heater - see Fig.1 and Fig.2.
DO NOT locate the heater immediately below a
fixed socket or connection box.
Re1. move wall mounting bracket from the back
of the heater by depressing the spring latch at
the top of each bracket - see Fig.3.
Fix2. the wall bracket securely to the wall through
the two screw holes provided.
Pre3. sent the heater to the wall bracket, and
engage lower slots in the back with the
bracket.
Rai4. se the heater to upright position and push
the heater onto bracket to engage top latch.
A
235
150
Min.
150 Min.
Fig. 1
Fig. 2
Fig. 3
100
170 Min.
50mm
50 Min.
Shelf
50mm
than
wider
Shelf
A
LPP050 672
LPP075 672
LPP100 803
LPP150 1068
250 Min.
A

Operation
Switching On the Heater (see Fig.4)
The controls are located on the right hand side
on the top of the appliance, lift flap to access the
controls - see Fig.4.
The buttons marked ‘ ‘ controls the electricity
supply to the electronic thermostat. An indicator
beside the ‘ ‘ button shows when the unit is
powered ‘ON’.
Setting Desired Temperature (see Fig.5)
The heater is fitted with an adjustable thermostat
enabling the room temperature to be controlled by
adjusting the slider accordingly.The min setting ‘ ’
represents a room temperature of approximately
5oC and may be used for protection against frost.
The ‘MAX’ setting represents a room temperature
of approximately 30oC.The ‘ ’ symbol glows when
the elements are actually heating.
Turn on the heater using the ‘ ’ button and move
the thermostat slider to the desired position.When
the room temperature has reached the desired
level, the power to the elements will be reduced,
the heater will then maintain the room temperature
at the chosen level.
NOTE - Should your heater fail to come on when
the thermostat slider is at a low setting, this may
be due to the room temperature being higher than
the thermostat setting.
Background Temperature
When used in conjunction with a remote
programming device supporting background/
setback setting, the heater will automatically
operate at a room temperature setting of 5oC less
than the thermostat setting when the programme
is in background/setback mode.
Limiting the thermostat setting
Before wall mounting the product the installer may
wish to limit the heat selection slider movement for
the operator. This may be achieved by removing
the two plastic pins (see ‘x’ in Fig.6) from the
rear of the thermostat moulding using pliers and
inserting them in the preferred holes to limit the
slider movement.
‘x’
Fig. 4
Fig. 5
Fig. 6

Fig. 6
Notes to the Installer
Test Mode
When the heater is connected via a pilot wire
system, the test mode allows the installer to check
whether the heater is responding correctly to the
incoming pilot wire signal.
Before switching the heater on at the mains, place
the thermostat slider to the ‘MAX’ position, then
press and hold the ‘ ’ button whilst switching on
the mains.
The unit will now enter a test state for 4 mins.
During this test state the ‘ ’ neon will indicate the
pilot wire status:
NEON PILOT WIRE
CONTROLLER MODE
Neon on - ON
Neon off - OFF
Neon flashing fast approx every 0.1 sec - FROST
Neonflashingslowapproxevery0.5sec-SETBACK
Accessory Modules
Optional accessory modules are available for use
with this range of heaters - see separate User
Instruction for details on the operation of each
module.
Before fitting a control module switch the heater
off at the mains supply.
To insert a module, the plug-in protective cover on
the right hand side of the thermostat unit at the
back of the heater must first be removed.
Insert a flat-head screwdriver into the side cover
and prise away from the heater - see Fig.7.
Lift the cover away from the heater to reveal the
slide in compartment.
Insert the accessory module into the slot ensuring
it is positively located in position - see Fig.7.
Switch the heater on at the mains supply.
Safety - Overheat Protection
For your safety this appliance is fitted with a
thermal cut-out. In the event that the product
overheats for some reason, the cut-out prevents
excessive temperatures on the product by cutting
power to the heater. Once the heater has cooled
down, it will reset automatically, it will continue to
cycle on and off automatically until the reason for
overheating is removed.
Fig. 7

Energy Saving Tips
The energy we use to heat, light and power our homes contributes over a quarter of
UK’s carbon emissions, the principle contributor to climate change.
Around half the energy used in the home is for heating and hot water, so using your
heating system efficiently will not only help the environment, but also save you money.
Energy efficiency tips for heating and hot water
1. Don’t set the temperature to high...
By reducing the thermostat setting by just 1oC can reduce your energy use by as much as
10%. And if you’re going away for the winter, leave the thermostat on the frost protection
setting to provide protection from freezing at a minimum cost.
2. Use it where you need it...
Set the appropriate temperature on your heaters for the room they are in; for example,
leave the thermostat on a heater in a spare bedroom on a lower setting.
3. Use it when you need it...
Use heaters fitted with timers or linked to central controllers to turn the heating on only
when you need it and automatically switch it off when you don’t.
4. Curtains...
Close your curtains at dusk to stop heat escaping through the windows.
5. Windows...
Nearly 25% of heat loss can occur through poorly insulated frames and single glazing.
If you can’t afford to double glaze all your windows, go for the rooms you heat most.
6. Treat your hot water tank...give it a jacket
An insulating jacket for hot water tanks costs only a few pounds and pays for itself within
months. Fit one that’s at least 75mm (3”) thick and you could save £10-15 a year.
7. Water
Use a shower if you have one to save time, money and water.
Don’t set the thermostat too high on your water heater- 60oC/ 140oF is usually adequate
for bathing and washing.
Put the plug in when running hot water in your sink - leaving hot taps running is both
wasteful and expensive.
Ensuring dripping taps are repaired quickly. In just one day, you could waste enough
water to fill a bath.
Other Energy Saving Tips for Around the Home
1. Lights
Turn off lights whenever you leave a room for more than ten minutes
Use low-energy bulbs wherever you can as they use less than a quarter of the electricity
used by ordinary light bulbs and last ten times longer!
2. Cooking
Use the right size pan for food and cooker hob.
Keep saucepan lids on - this enables you turn down the heat.
Boil water for cooking in a kettle.

This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
© GDC
Dimplex, a division of GDC Group Limited, Millbrook House, Grange Drive, Hedge End, Southampton SO30 2DF
Customer Help Line: 0845 600 5111 Fax: [phone] Email: [email protected].uk Website: www.dimplex.co.uk
This product is protected by intellectual propery rights owned by the GDC Group Ltd or members of the Glen Dimplex Group on an
international basis. The Glen Dimplex Group of Companies will actively protect these rights.
A world of expertise
Cleaning
WARNING - ALWAYS DISCONNECT FROM THE POWER SUPPLY BEFORE
CLEANING THE HEATER.
Before commencing cleaning, unplug the heater and allow it to cool. Disconnect the
electricity supply to the appliance.
The outside can be cleaned by wiping it over with a soft damp cloth and then dried. Do
not use abrasive cleaning powders or furniture polish, as this can damage the surface
finish.
To release the heater from the wall bracket for cleaning or redecoration, depress the
latch on both brackets (See Fig.3) and hinge forward.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not be disposed of with household
waste. Please recycle where facilities exist. Check with a Local Authority or retailer for
recycling advice in your country.
After Sales Service
Your product is guaranteed for two years from the date of purchase.
Within this period we undertake to repair of exchange this product free of charge provided
it has been installed and operated in accordance with these instructions.
Your rights under this guarantee are additional to your statutory rights, which in turn are
not affected by this guarantee.
Should you require after sales information or assistance with this product please go to
www.dimplex.co.uk where you will find our self help guide by clicking on “After Sales”
or ring our helpdesk on 0845 600 5111 (UK) or 01 842 4833 (R.O.I.).
Spare parts are also available on the website www.dimplex.co.uk
Please do not return a faulty product to us in the first instance.
Please retain your receipt as proof of purchase.
