Diode Dynamics DD6090 User manual

2018+ Jeep JL Wrangler
Hood Light Bar Kit Installation Guide
2018+ Jeep JL Wrangler
Hood Light Bar Kit Installation Guide
PAGE 3 [phone] WWW.DIODEDYNAMICS.COM
Scan the QR code to link to our installation video online!
NEED MORE HELP?
We’ve taken the time to test our products on your vehicle. We can
guarantee compatibility and tment the rst time – no guessing
game! If you need more help with installation, watch our step-by-step
video to walk you through the process.
DD6090 Jeep 2018 Hood Bracket Kit
DD6104 Jeep 2018 SS50 Hood LED Kit White Driving
DD6105 Jeep 2018 SS50 Hood LED Kit White Flood
DD6106 Jeep 2018 SS50 Hood LED Kit White Combo
This installation guide is for the following SKUs:
Please contact Diode Dynamics should you have any questions about the installation
or wiring process, at 314-205-3033 (10a-5p CST) or [email protected].
DD6107 Jeep 2018 SS50 Hood LED Kit Amber Driving
DD6108 Jeep 2018 SS50 Hood LED Kit Amber Flood
DD6109 Jeep 2018 SS50 Hood LED Kit Amber Combo
PP0077B
7. At the white connector, unplug the switch wires from the harness, and connect the extra
pigtail here instead. Using the butt connector at the end of the pigtail, crimp the yellow
wire to an OEM Auxiliary Switch wire lead.
NOTE: Power will be drawn from the battery, so any OEM Auxiliary Switch wires can be used,
regardless of amperage rating.
8. Route the output wire to the light bar, avoiding any moving parts or direct contact with
heat sources. Plug the output connector into the light bar.
9. Secure the wires and test thoroughly to complete your installation.
AUX
GUARANTEE
100% SATISFACTION
WARRANTY
3 YEAR

1. On either side of the vehicle, remove the
two factory bolts as indicated using a T40
Torx driver.
Tip: If you’re planning on running wires, you
can remove the bottom two bolts to remove
the panel completely. Route your wires out
next to the windshield hinge, then reinstall
the trim piece.
PAGE 1 PAGE 2
[phone] WWW.DIODEDYNAMICS.COM
WATCH THE INSTALLATION VIDEO ONLINE!
Scan the QR code on page 3
2018+ Jeep JL Wrangler
Hood Light Bar Kit Installation Guide
2018+ Jeep JL Wrangler
Hood Light Bar Kit Installation Guide
Tools Needed: T40 Torx driver, 10mm socket, wire strippers, and wire crimper
Thank you for your purchase of this custom-designed LED light bar kit for
your 2018+ Jeep JL Wrangler! This kit utilizes both factory mounting points
and included hardware to mount the bracket to the vehicle.
WARRANTY
3 YEAR
2. Place the included spacers over both
mounting points.
The following instructions are for Jeep JL Wranglers with an Auxiliary Switch Bank. If you
do not have the Auxiliary Switch Bank, use the included toggle switch adapter wire to route
a switch. All power sources must be fused.
Wiring Instructions
4. Mount your 50” light bar to the brackets
using the low prole hex bolts included in the
universal mounting bracket box. Secure using
a 10mm socket.
3. Align the bracket in place, and use the
included OEM-style extended hardware
to secure. Repeat for the other side of
the vehicle.
RELAY
Factory Grounding Point
Power Input Wire
G
V
SWITCH
AUX A
Output
5. Determine a suitable location to mount the relay, near the battery or main power
terminal.
6. Connect the red power input wire to the positive battery/power terminal. Connect the
black ground wire to the negative battery terminal or a factory grounding point.
A
G
V
NOT USED
See back for further instructions.
