RGBW™ Demon Eyes (Universal)
Installation Guide
Thank you for your purchase of this unique product for your
projector housing! With these modules, you will be able to add
full multicolor functionality to your projector housing. This guide
describes the installation process for installing the Demon Eyes
in a Mini H1 projector housing. The Demon Eyes can be custom
mounted with adhesive for any other size projectors.
1. To begin, attach the Demon Eye to the top of the
included bracket, using one of the included locking
screws and locknuts. Ensure the locknut is on the
bottom side of the Demon Eye. Be sure to thread the
locking screw and locknut rst and then tighten using
pliers and a small Philips screwdriver.
2. Next, mount the Demon Eye inside the projector
housing, ensuring the Demon Eye board is inside the
shroud. The bracket can be mounted on either the
front or the back side of the projector housing.
Using the mounting holes and included locking screws,
secure both sides of the bracket to the housing. Again,
thread the locking screws and locknuts and then
tighten using pliers and a small Philips screwdriver.
Tools Needed: Pliers, small Phillips Screwdriver
WARRANTY
3 YEAR
Please note: Headlights must be opened before proceeding with installation. Professional installation
is strongly recommended. Please contact Diode Dynamics if you need assistance locating an installer.
PAGE 1
See back for further instructions.

[phone] WWW.DIODEDYNAMICS.COM
4. Connect the remote control power to the Signal Wire. Next, tap the Signal Wire to any 12V
power source. The black wire must be grounded before any function will work.
5. Mount drivers and controllers, and tuck all wires. Drivers should be mounted outside of
headlight for serviceability, in a location away from the engine block to avoid excessive heat
buildup.
6. Test thoroughly, reseal headlight and reinstall onto vehicle.
3. Connect each Demon Eye connector to the RGBW
Drivers. Next, take the bare wires from the RGBW
Driver and connect them to the RGBW Controller. All
wires must be inserted into the corresponding slot on
the controller in order for the boards to work (i.e. all
white wires must be inserted into the white slot, etc.).
See wiring method diagram below.
PAGE 2
RGBW™ Demon Eyes (Universal)
Installation Guide
IMPORTANT: DO NOT plug the LED panel directly into the controller without the
driver. The LEDs must be plugged into the driver rst to control the power.
Please contact Diode Dynamics should you have any questions about the installation
or wiring process, at 314-205-3033 (9a-5p CST) or [email protected].
Scan the QR code to link to our installation video online!
NEED MORE HELP?
We’ve taken the time to test our products on your vehicle. We can
guarantee compatibility and tment the rst time – no guessing
game! If you need more help with installation, watch our step-by-step
video to walk you through the process.
GUARANTEE
100% SATISFACTION
Visit www.diodedynamics.com to nd more products for any vehicle.
