Introduction
This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a
digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on
the DIRECTLINK text in the header for additional information.
DS3/DS3+ and DS4/DS4+ modules provide an all-in-one solution for most modern vehicles, and include remote start, keyless entry, security,
and immobilizer bypass capabilities. T-harnesses may also be used in many applications for easy installation.
The following methods are available to configure modules:
• Web: www.directechs.com (DS3/DS3+ and DS4/DS4+)
• Desktop Application: Directlink DT (DS3/DS3+ and DS4/DS4+)
• Mobile Device: Directlink App (DS4/DS4+ only)
When Flashing via Directlink DT (Desktop app) or via the Web, an XKloader2 will be required.
To configure via Web or DirectLink DT (mobile app):
1. Disconnect the main module from any (+) 12V power source.
2. Connect the module to your computer using the XKLoader2.
3. Follow the steps in the pop-up window that will be displayed when the module is detected.
Notes:
•Flashing via web is only possible using Internet Explorer on Windows 8, 8.1, and 10.
•This method is not compatible with any other browser (Edge, Chrome, Firefox, etc.)
•When using Windows 11 or newer, Directlink DT is mandatory.
The DS4/DS4+ module is designed to be configured using the DirectLink application through mobile devices.
To download the DirectLink mobile application, visit the Google Play or Apple store. They can also be
configured via Web and DirectLink DT. The DS4/DS4+ features are built in Bluetooth® 4.0, allowing you to
configure and control your system. The DS3/DS3+ module is not equipped with Bluetooth®, therefore is not
compatible with the DirectLink app for mobile devices.
To configure via DirectLink DT (mobile app):
1. Follow and complete the wiring diagram(s) related to your installation through the app.
2. When installation is complete, select Configure DS4/DS4+.
3. Follow the on-screen instructions.
FLASH REQUIRED!
FLASH REQUIRED!
4 White

4933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
Fuel level/EV battery level
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
RAP Shut Down (Retained ACC Power)
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
E-Brake Status
Ignition Status

5933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible T-Harness is not compatible.
AUX
Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each wiring
diagram.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Refer to the "Vehicle connections" following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory
hood pin, or if not supported in data
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Security-Only installations: Refer to the "Locating components in the vehicle" section for the optional starter disable
connection.

6933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
Siren
Hood Pin
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
(+) Ignition Output: Lt. Green: 8
(-) Ground: Black: 10
(+) Parking Light Output: White: 5 & 11
HS CAN 1 Low: Tan: 1
(+) Starter Output: White: 7
(-) Auto Headlamp Shutoff Output: Lt. Green/Black: 1
(+) Accessory Output: Violet/Black: 8
HS CAN 1 High: Tan/Black: 2
HS CAN 2 High: Orange/Green: 4
HS CAN 2 Low: Orange/Brown: 3
(+) 12V Input: Red: 6 & 12
(+) 12V Input : Lt. Green/Red: 7
16
8
9
1
HS CAN 1 Low:
White or Violet, pin 14
HS CAN 1 High:
Yellow/Green or Pink, pin 6
OBDII Diagnostic
(connector side view)
C-309
(black 2-pin conn.
at ECU)
C-311
(white 20-pin conn. at ECU)
C-313
(brown 16-pin conn. at ECU)
12
1
8
3
10 12
2
9
4
11 13
5
14
6
15
7
16
C-313
C-309
C-311
ETACS/ECU
(at driver kick panel)
31 2
45 6
Ignition Connector
(white 6-pin conn.
left side of steering
column)
(+) Ignition:
White, pin 2
(+) Starter:
Orange or
Lt. Blue, pin 5
(+) Accessory:
Lt. Green, pin 6
1
83
10
12
2
94
11
1317
5
1418
6
1519
7
1620
(-) Driver Door Trigger:
Yellow, pin 16
(+) 12V:
White or Black/Red, pin 1
(-) Lock Output: Green/Black: 3
(+) Clutch:
Black/Red, pin 2
1
Clutch Pedal
2
OR
Manual Transmission Only
Automatic Transmission Only
(+) Parking Lights:
Brown, pin 13
(+) Parking Lights:
Yellow, pin 10
6 Amp
diodes
(-) GWA Output: Blue/White: 2
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
15
15
Connect to vehicle
only if ignition
controlled door
locks are activated.
Refer to the Starter
disable connection
section for relay and
connection details.
1
7
2
8
3
9
4
10
5
11
6
12
Immobilizer Connector
(black and white 12-pin conn. right side
of steering column)
HS CAN 2 High:
Yellow or White/Blue, pin 11
HS CAN 2 Low:
Lt. Green or Black/Blue, pin 10

7933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle
Optional starter disable connection
When using an external relay, use a 1N4002 diode or larger.
22 812
4 2442
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
(-) Ground When Armed (GWA) Output: Blue/White: 2
86 85
30
87a
87
Cut
Starter (conn. side)
Starter (veh. side)
(+) Ignition
Refer to the
Vehicle connections
section for wire and
connector details.
1A diode [1N4002+ ]

8933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2012 Mitsubishi Lancer Evolution. Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low 1 data link connector, black 16 pin plug, pin 14 data violet Mandatory
H1/2 Tan/Black (Data) HS CAN High 1 data link connector, black 16 pin plug, pin 6 data yellow/green Mandatory
H1/3 Orange/Brown (Data) HS CAN Low 2 Wireless Control Module on key switch, white 12 pin plug, pin 10 data lt. green Mandatory
H1/4 Orange/Green (Data) HS CAN High 2 Wireless Control Module on key switch, white 12 pin plug, pin 11 data yellow Mandatory
H1/5 Lt. Green No Connection No Connection
H1/6 Violet/Brown No Connection No Connection
H1/7 Orange/Black No Connection No Connection
H1/8 Yellow/Black No Connection No Connection
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Auto Headlight Shutoff Output dash fuse box, brown 16 pin plug, pin 16 - yellow Remote Start
Only
H2/2 Blue/White (-) Ground When Armed (GWA) Output [3] Starter:
ignition switch, white 6 pin plug, pin 5
Ignition:
ignition switch, white 6 pin plug, pin 2
Must use a relay.
Must use a 1N4002 diode or larger.
+
+
orange (Lancer) or lt. blue
(Lancer Evolution)
white
Security Only
H2/3 Dk. Green/Black (-) Lock Output driver kick, white 25 pin plug, pin 7 - red or yellow/red Mandatory
H2/4 Red/White (-) Trunk Release Output No Connection
H2/5 Brown/Black (-) Horn Output horn switch or dash fuse box, white 19 pin plug, pin 19 - green Optional
H2/6 Brown/White (-) AUX 1 Output No Connection
H2/7 White (+) Starter Output Starter:
ignition switch, white 6 pin plug, pin 5
Clutch for manual Transmission:
clutch switch, white 2 pin plug, pin 2
+
+
orange (Lancer) or lt. blue
(Lancer Evolution)
black/red
Remote Start
Only
H2/8 Violet/Black (+) Accessory Output ignition switch, white 6 pin plug, pin 6 + lt. green Remote Start
Only
H2/9 Dk. Blue/Black (-) Unlock Output No Connection
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output No Connection
H2/11 Brown/Red (+) Siren Output [2] Security Only
H2/12 Pink (+) Ignition Sense Input No Connection
H2/13 Violet (+) Door Trigger Input No Connection
H2/14 Brown (+) Brake Input No Connection
H2/15 White/Blue (-) Activation Input No Connection

9933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/16 Red/Blue (-) Headlight Detection Input No Connection
H2/17 Black/White (-) E-Brake Input No Connection
H2/18 Orange/Black (+) Knob Sense Input No Connection
H2/19 Blue (-) Trunk Trigger Input No Connection
H2/20 Green (-) Door Trigger Input No Connection
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White Relay N.C. Knob Sense Interrupt No Connection
H3/2 Blue/Red Relay N.O. No Connection No Connection
H3/3 Blue Relay COM Knob Sense Interrupt No Connection
H3/4 White/Brown Relay N.C. No Connection No Connection
H3/5 White Relay COM. (+) Pk Light Output dash fuse box, white 20 pin plug, pin 10, 13
Must use two 6A diodes.
+ yellow (L); brown (R) Mandatory
H3/6 Red (+) 12 Volt Input dash fuse box, black 2 pin plug, pin 1 + white or black/red (80A) Mandatory
H3/7 Lt. Green/Red Relay N.O. (+) 12 Volt Input dash fuse box, black 2 pin plug, pin 1 + white or black/red (80A) Remote Start
Only
H3/8 Lt. Green Relay COM (+) Ignition Output ignition switch, white 6 pin plug, pin 2 + white Remote Start
Only
H3/9 Lt. Green/White Relay N.C. No Connection No Connection
H3/10 Black (-) Ground (chassis ground) Mandatory
H3/11 White Relay COM (+) Pk Light Output dash fuse box, white 20 pin plug, pin 10, 13
Must use two 6A diodes.
+ yellow (L); brown (R) Mandatory
H3/12 Red (+) 12 Volt Input dash fuse box, black 2 pin plug, pin 1 + white or black/red (80A) Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black (+) 12 Volt Input No Connection
H4/3 Pink/Black Flex Relay (pin 87a) No Connection
H4/4 Pink/White (+) Flex Relay Output No Connection
H4/5 Red (+) 12 Volt Input No Connection
H4/6 Green Starter Input (conn. side) No Connection
H4/7 Violet (+) Starter Output (vehicle side) No Connection
H4/8 Orange (+) Accessory Output No Connection
H4/9 Red/White (+) 12 Volt Input No Connection

10 933.MIT3 2.11.195.3 2012 Mitsubishi Lancer Evolution
©2022 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/10 Pink (+) Ignition Input/Output No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
Temperature sensor harness, 2-pin black connector (H7)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
