Directed Directechs DB3 User manual

Designed by Installers for Installers
INSTALLATION GUIDE
DB3
2014 Toyota Avalon (Smart Key). 403.TL6 2.17
© 2018 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 4
Vehicle function compatibilities 4
Pre-installation and application warnings 5
OEM remote starter detection 5
Wiring diagram 7
Locating components in the vehicle 8
Vehicle connections 9
Connecting the module 11
Module programming 12
LED diagnostics and troubleshooting 13
Soft reset 15
Hard reset 15
Feature programming 16
Feature and option list 17
Limited one year consumer warranty 18
Quick reference guide 19
Contents

3403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote controls to assure that the system does not unintentionally remote start the vehicle.
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.

4403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Door Locks Status
E-Brake Status
Ignition Status

5403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys required for
programming 1Keys required for operation 0
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
No takeover feature is available.
To remote start the engine, the hood, hatch, and all doors must be closed.
By default, the tach is set to 1000 rpm on hybrid vehicles.
Keyless and Smart Key will remain functional during remote start on hybrid vehicles.
If the vehicle is already equipped with an OEM remote starter, the installer must disconnect it before installing the DB3
module, otherwise it will not program.(For more information see "OEM remote starter detection")
Refer to "Vehicle connections" following the wiring diagram.
General notes: This section highlights important information for this specific firmware.
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[2] Connection required ONLY if Pit-Stop/Idle mode is desired.

6403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
OEM remote starter detection
If the vehicle has an active OEM remote starter it will program into convenience only (no immobilizer bypass). The reason for this
is to allow aftermarket security to be installed while keeping the factory remote starter active. If you wish for the interface to control
the remote start sequence, perform one of the following:
How to determine if a vehicle is equipped with an OEM remote starter?
1An “ENGINE STARTER” sticker should be on the remote.
ENGINE
S
TARTER
2
Press the remote control’s lock button twice within 2 seconds, then press and hold the lock
button for 3 seconds.
The parking lights flash after 3 seconds. The engine starts and the parking lights flash
repeatedly for 20 seconds.
ENGINE
STARTER
x2 &Press & Hold
for 3 seconds
If the vehicle is equipped with an Add-On Lexus/Toyota OEM remote starter: The factory remote starter must be
permanently disconnected before programming the Directed interface as both modules cannot coexist. See "Physical OEM
remote start fuse location".
If the vehicle is equipped with a BCM Enabled Lexus/Toyota OEM remote starter: The vehicle does not have a physical
remote starter and only one module can be programed at a time. In this case temporally disable the OEM remote start system
using the following process:
1. Remove the fuse powering the OEM Remote Starter. See "OEM remote start fuse location"
2. Perform a "Soft reset" or "Hard reset".
3. Perform the "Module programming".
4. After programming is successful replace the fuse powering the OEM Remote Starter.
OEM remote start fuse location
Make Model Year Fuse Location Fuse
Name
Fuse
Value
Lexus ES 300h (Smart Key) 2013-2015 Engine room relay box, left side of engine compartment. Mayday 5A
Lexus ES 350 (Smart Key) 2013-2015 Engine room relay box, left side of engine compartment. Mayday 5A
Lexus GS 350 (Smart Key) 2013-2016 Engine room relay box, right side of engine compartment. DCM 7.5A
Lexus GS 450h (Smart Key) 2013-2015 Bottom of luggage room junction box, left rear quarter panel. DCM 7.5A
Physical OEM remote start fuse location
Make Model Year Fuse Location
Toyota Avalon (Smart Key) 2013-2016 Behind glovebox upper right hand side.
Toyota Avalon Hybrid 2013-2016 Behind glovebox upper right hand side.
Toyota Camry (Smart Key) 2013-2016 Behind glovebox upper left hand side.
Toyota Camry Hybrid 2013-2016 Behind glovebox upper left hand side.
Toyota RAV4 (Smart Key) 2013-2015 High above drivers kick panel.

7403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
D2D Port
OBDII
Diagnostic Connector
(+) Ignition Input/Output
(+) 12V
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
Autolight Interr. (conn. side): Yellow: 8
Autolight Interr. (veh. side): Orange/Yellow: 9
Immo Data 1: Yellow/Black: 10
Immo Data 2: Orange/Black: 11
1412
10 42
1 8
169
9: Pink: (+) Ignition Input
(-) Parking Lights Output
XKD2D65
(-) Ground
(-) SLP:
pin 4
Steering Lock
(black 7-pin connector)
HS CAN Low:
pin 14
HS CAN High:
pin 6
Body ECU
(white 30-pin connector)
BRX: pin 26
Cut
BTX: pin 25
(-) Autolights:
pin 28
(-) Parking Lights:
pin 30
(+) Ignition Status Output: Gray/Black: 7
(AC) Tach Output: Violet/White: 5
(-) SLP Output: Yellow/Red: 11
Ground: Brown/Red: 12
(AC) Tach Intput
Do not connect these wires:
accessory , ignition, starter from
the remote starter to the vehicle.
(-) Push-to-Start Output: Green/Black: 2
18
12
20
8
22 23 27 29
10 13 14 15 16 17
2 5
19 21
diode 1A
(-) PTS:
pin 1
Push-To-Start
(black 10-pin
connector)

8403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Locating components in the vehicle

9403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2014 Toyota Avalon (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN High OBD-Data Link Connector, white 16 pin plug, pin 6 Data Blue
H1/4 Tan (DATA) HS CAN Low OBD-Data Link Connector, white 16 pin plug, pin 14 Data White
H1/5 Orange/Green (DATA) HS CAN High Not Applicable
H1/6 Orange/Brown (DATA) HS CAN Low Not Applicable
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM Auto Light Interrupt (connector side) Body ECU on dash fuse box, white 30 pin plug, pin 28 Cut Tan
H1/9 Orange/Yellow Relay N.C. Auto Light Interrupt (vehicle side) Body ECU on dash fuse box, white 30 pin plug, pin 28 Cut Tan
H1/10 Orange/Red Relay N.C. No Connection No Connection
H1/11 Yellow/Red Relay COM SLP Steering Lock Actuator on steering column, black 7 pin plug,
pin 4 - Green
H1/12 Brown/Red Relay N.O. Ground (chassis ground)
H1/13 Red (+) W2W Only - 12 Volt Dash Fuse Box, white 36 pin plug (3C), pin 2 + Lt. Green (30A)
H1/14 Black (-) W2W Only - Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) PTS Engine Start Stop Switch, black 10 pin plug, pin 1 - Violet
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black (+) Ignition Output Remote Starter
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown (MUX) W2W Only - Hood Output Remote Starter
H2/10 Yellow/Black (Data) Immo Data Body ECU on dash fuse box, white 30 pin plug, pin 25 Data Brown (BTX)
H2/11 Orange/Black (Data) Immo Data Body ECU on dash fuse box, white 30 pin plug, pin 26 Data Lt. Green (BRX)
H2/12 Blue/Red (-) Lock Output Not Applicable
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.

10 403.TL6 2.17 2014 Toyota Avalon (Smart Key)
© 2018-02-23 Directed. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet (-) W2W Only - Pk Light Input Remote Starter
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White No Connection No Connection
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink (+) Ignition Input Output 12-pin red connector - Pin 7
Remote Starter
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue
H4/2 Black
H4/3 Green
H4/4 Red
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A
H5/2 N/A
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color Ref.
12 Volts Dash Fuse Box, white 36 pin plug (3C), pin 2 + Lt. Green (30A)
Factory Alarm Arm2 Not Applicable
Factory Alarm Disarm2 Not Applicable
Parking Lights - Body ECU on dash fuse box, white 30 pin plug, pin 30 - Red
Starter Certification ECU behind glove box, white 18 pin plug, pin
5+ pink
Trunk-Hatch Release2 Not Applicable
