Directed DS4+ User manual

FORD1
INSTALLATION GUIDE
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
2018-01-12
© 2018 Directed, Vista CA
DS4+
Designed by Installers for Installers

Contents
Warning! Safety first ....................................................................................................................... 3
Introduction .................................................................................................................................... 4
Pre-installation and application warnings ..................................................................................... 4
Vehicle application guide........................................................................................................... 5
Wiring connections ......................................................................................................................... 6
Main harness (H1), 12-pin black connector .................................................................................. 6
Relay harness (H2), 10-pin white connector.................................................................................. 6
Data harness (H3), 8-pin white connector..................................................................................... 6
Analog input/output harness (H4), 22-pin white connector............................................................. 7
RF Port harness (H5), 2-pin white connector.................................................................................. 7
D2D harness (H6), 4-pin white (1) and black (2) connectors ........................................................... 7
Temperature sensor harness (H7), 2-pin black connector (optional, 8556T)....................................... 7
Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)........................................ 8
Type 1 ..................................................................................................................................... 8
Type 2 ................................................................................................................................... 28
Configuring the system................................................................................................................... 57
Important! .............................................................................................................................. 57
Vehicles equipped with a manual transmission............................................................................ 57
RF Systems ............................................................................................................................. 57
8504D Combo Sensor............................................................................................................. 57
When used in conjunction with SmartStart.................................................................................. 57
D2D port configuration ............................................................................................................ 58
Module programming.............................................................................................................. 58
1-Key programming using Key2GO........................................................................................... 59
LED diagnostics and troubleshooting.......................................................................................... 60
Soft reset................................................................................................................................ 62
Hard reset .............................................................................................................................. 62
Learning the Tach (not needed with Virtual Tach) ............................................................................... 63
Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 63
Limited lifetime consumer warranty .................................................................................................. 64
Quick Reference Guide.................................................................................................................. 65

3DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.

4DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Introduction
The FORD1 firmware for DS4+ is compatible with specific Ford, Lincoln and Mercury vehicles. It is a complete
solution for remote start, security (when security features are enabled), bypass, and features built in Bluetooth
4.0 allowing you to configure and control your system. This guide provides information on the installation of the
module using FORD1. Please refer to the DirectLink application or www.directechs.com for more information
about which configuration is best for your application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices, however it can also
be configured using the web tool located at www.directechs.com. To download the DirectLink mobile application, please visit the
Google Play or Apple store.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys required for
programming 2Keys required for operation 0
Compatible with FORD1 4.13+
Key2GO is required if only one key is available. You can program the interface without the need for Key2GO if two keys
are present.
Keys required to program: 40-Bit Encryption transponder: Programming can be completed with two (2) keys or with one (1)
key if using Key2GO.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
It is important to check that the fuses are positioned correctly in the module. Refer to the "Fuse selection" section following
each installation type for more information.
Refer to the "Vehicle wiring reference chart" following each installation type.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] The Green wire is ONLY required for starter disable and anti-grind connections.
[4] Keysense or Factory Disarm Output is required ONLY if the vehicle is equipped with an OEM Alarm. Refer to the "Vehicle
wiring reference chart" following each installation type.
[5] CAN connections are only required if using in conjunction with SmartStart.
[6] Required ONLY when enabling the security features during module flashing.
[7] Vehicles built after July 24, 2000.
Additional parts required (maximum required):
Diode 6A
0 x 1A Diodes 86 85
30
87a
87
0 x Relay
Resistor 100Ω
0 x Resistor
Fuse 7.5A
0 x Fuse

5DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Vehicle application guide
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
Vehicles
2014 2013 2012 2011 2010 2009 2008 2007 2006 2005 2004 2003 2002 2001 2000 PK-Immobilizer Bypass-Data No Key Req'd DL-Disarm Factory Security DS4+ Only Key2GO RS-Accessory Activation RS-Ignition Activation RS-RAP Shut Down (Retained ACC Power) RS-SmartStart RS-Start (Crank) Activation
Ford
Crown Victoria 1 1 1111111
•••••••••
Ed
g
e 22222 •••••••••
Esca
p
e 2 22222111 1
•••••••••
Esca
p
e H
y
brid 2 22222
•••••••••
E-Series 1 1 1 1 1 1 1
•••••••••
Ex
p
edition 2 2 2222222
•••••••••
Ex
p
lorer 2 2 22222222
1 [7]
•••••••••
Ex
p
lorer S
p
ort Trac 1111 1
•••••••••
F-150 2 2 211111
•••••••••
F-250 2 2 2 2
•••••••••
F-350 2 2 2 2
•••••••••
F-450 2 2 2 2
•••••••••
Fiesta 2 2 2
•••••••••
Five Hundred 2 2 2
•••••••••
Flex 2 2 2
•••••••••
Focus 2 2 22111111 1 1
•••••••••
Freestar 2222
•••••••••
Freest
y
le 222 •••••••••
Fusion 2 2 2 2222
•••••••••
GT 11 •••••••••
Mustan
g
2 2 2 22222
•••••••••
Mustan
g
(
SA Ke
y)
22 •••••••••
Ran
g
er 1 1 11111111 1
•••••••••
S
p
ort Trac 2 2 2 2
•••••••••
Taurus 2 2 2 22111111 1 1
•••••••••
Taurus X 2 2
•••••••••
Thunderbird 2222
•••••••••
Transit Connect 1 or 2 1 or 2 1 or 2
•••••••••
Windstar 1 1 1
•••••••••
Lincoln 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Aviator 2 2 2
•••••••••
LS 22222 1 1
•••••••••
Mark LT 1 1 1
•••••••••
MKS 2222 •••••••••
MK
X
2222 •••••••••
MKZ 222222 •••••••••
Navi
g
ator 2 2 2 2 22222221
•••••••••
Town Ca
r
1 1 1111111
•••••••••
Ze
p
h
yr
2 •••••••••
Mercur
y
14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Grand Mar
q
uis 1 1 1111111
•••••••••
Marauder 1 1
•••••••••
Marine
r
2 22222
•••••••••
Mariner H
y
brid 2 2222
•••••••••
Milan 2 2222
•••••••••
Monte
g
o 222 •••••••••
Montere
y
2222
•••••••••
Mountainee
r
2 22222222
1 [7]
•••••••••
M
y
sti
q
ue
1•••••••••
Sable 2 2 1111 1 1
•••••••••
Le
g
end:
AV: Horn & Li
g
ht Controls PK: Trans
p
onder & Immobilizer Override
CC: Comfort & Convenience Control
s
RS: Remote Start & En
g
ine Controls
DL: OE Door Lock & Alarm Controls SS: Inte
g
rated Securit
y
& Monitorin
g
FOB: S
y
nc CAN Interface w/ FOB Remote ST: Function/Feature Status

6DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wiring connections
The wiring connections listed below are specific to this firmware.
Main harness (H1), 12-pin black connector
Conn./Pin Color Description
H1/1 Blue/White Relay 1 N.C. – No Connection 1
H1/2 Blue/Red Relay 1 N.O. – No Connection 1
H1/3 Blue Relay 1 COM – No Connection1
H1/4 White/Brown Relay 3 N.C. – No Connection 1
H1/5 White Relay 3 COM – (+) or (-) Parking Light Output 1
H1/6 Red (+) 12 Volt (Battery)
H1/7 Lt. Green/Red Relay 2 N.O. – (-) Ground 1
H1/8 Lt. Green Relay 2 COM – RAP Off Output 1
H1/9 Lt. Green/White Relay 2 N.C. – RAP Off Output 1
H1/10 Black (-) Ground
H1/11 White Relay 3 COM – (+) or (-) Parking Light Output 1
H1/12 Red (+) 12 Volt (Battery)
Relay harness (H2), 10-pin white connector
Conn./Pin Color Description
H2/1 N/A No Connection
H2/2 Red/Black (+) 12 Volt Input (Accessory/Starter relay)
H2/3 Pink/Black Relay N.C. – Flex Relay Isolation 1
H2/4 Pink/White Relay COM – Flex Relay Output 1
H2/5 Red (+) 12 Volt Input (Ignition relay)
H2/6 Green Relay COM – (+) Starter (key side)1
H2/7 Violet Relay N.C. – (+) Starter Output (vehicle side)1
H2/8 Orange Relay COM – (+) Accessory Output1
H2/9 Red/White (+) 12 Volt Input (Flex) relay
H2/10 Pink Relay COM – (+) Ignition Output
Data harness (H3), 8-pin white connector
Conn./Pin Color Description
H3/1 Tan No Connection
H3/2 Tan/Black No Connection
H3/3 Orange/Brown HS CAN Low
H3/4 Orange/Green HS CAN High
H3/5 Lt. Green No Connection
H3/6 Violet/Brown No Connection
H3/7 Orange/Black Data RX
H3/8 Yellow/Black Data TX
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.

7DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Analog input/output harness (H4), 22-pin white connector
Conn./Pin Color Description
H4/1 Lt. Green/Black (-) FAA Output 1
H4/2 Blue/White (-) Ground When Running (Status) Output 1
H4/3 Dk. Green/Black (-) Lock Output 1
H4/4 Red/White (-) Trunk Release Output 1
H4/5 Brown/Black (-) Horn Output 1
H4/6 Brown/White N/A
H4/7 White (+) Keysense Output 1
H4/8 Violet/Black (+) AUX 4 Output 1
H4/9 Dk. Blue/Black (-) Unlock Output 1
H4/10 Lt. Blue/Black (-) Factory Alarm Disarm Output 1
H4/11 Brown/Red (+) Siren Output 1
H4/12 Pink (+) Ignition Sense Input
H4/13 Violet (+) Door Sense Input 2
H4/14 Brown (+) Brake Input 2
H4/15 White/Blue (-) Activation Input 2
H4/16 Red/Blue (-) Valet Switch 2
H4/17 Black/White (-) E-Brake Input 2
H4/18 Orange/Black (-) Instant Alarm Trigger Input 2
H4/19 Blue (-) Trunk Sense Input 2
H4/20 Green (-) Door Sense Input 2
H4/21 Gray (-) Hood Pin Input 2
H4/22 Violet/White (AC) Tach Input
RF Port harness (H5), 2-pin white connector
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness (H6), 4-pin white (1) and black (2) connectors
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
Temperature sensor harness (H7), 2-pin black connector (optional, 8556T)
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they
are low current and a relay may be necessary.

8DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)
Type 1
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is IMPORTANT to check that
the fuses are positioned
correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
15
15
30
20
20
Siren
Hood Pin
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
HS CAN High: Orange/Green: 4
HS CAN Low: Orange/Brown: 3
TX: Yellow/Black: 8
RX: Orange/Black: 7
(-) Ground: Black: 10
(-) RAP Off Output: Lt. Green: 8
(-) Ground: Lt. Green/Red: 7
(+) or (-) Parking Lights: White: 5 & 11
(AC) Tach Input: Violet/White: 22
(-) Unlock Output: Blue/Black: 9
(-) Lock Output: Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(+) Brake Input: Brown: 14
(+) 12V Input: Red: 6 & 12
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Input: Red: 5
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/Black: 2
(+) Starter Output (Car Side): Violet: 7
Starter Input (Key Side): Green: 6
16
8
9
1
HS CAN Low, pin 14
(-) Driver Door
Trigger
HS CAN High, pin 6
OBDII Diagnostic Connector,
under Driver Dash
(connector side view)
Passive Anti-Theft Security System (PATS) connectors
See the Vehicle Wiring Charts for more wire and connector details
Ignition
RX
TX Ground
43
2
1
4 3 2 1
Ignition
RX
TX
Ground
4
1
2
3
4
1
2
3
Ground
TX
RX
Ignition
31
3
2
1
4
2
4
RX
4
TX
3
Ground2
Ignition1
4
3
2
1
(-) Door Input: Green: 20
(+) 12V Input: Red/White: 9
(+) Ignition 2/Flex Relay Output: Pink/White: 4
Conn. type 1 Conn. type 2 Conn. type 3 Conn. type 4
Refer to Vehicle wiring
reference chart section or go to
www.directechs.com for more
information on vehicle-specific
wiring connections.

9DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Vehicle wiring reference chart
This section provides vehicle wiring information
to guide you through the various stages of your
installation. Refer to www.directechs.com for
additional information.
Under hood
Rear running board harness to rear
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Crown Victoria 2003-2004
Brake Lt. Green 2 (+) Brake pedal switch. Black 2 D
RX Gray/Orange 3 Data (PATS) connector Type 4. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 4. Green 4 A
Keysense Black/Pink 4 or 5 (-) Bottom of steering column. Gray 4 or 8 K
12V Lt. Green or Brown B3 (+) Ignition switch. Black 15 B
Ignition White/Yellow I1 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow A2 (+) Ignition switch. Black 15 B
Accessory 2 Black/Lt. Green A1 (+) Ignition switch. Black 15 B
Accessory 3 Pink/Black A4 (+) Ignition switch. Black 15 B
Parking Lights Brown 4 (+) LCM (Lighting Control Module) right of steering column. Black 16 E
Driver Door Trigger Dk. Blue 11 (-) LCM to the right of the steering column. Gray 22 E
Lock (with keyless/factory
alarm entry)
Pink/Yellow N/A (+) Drivers kick panel door harness. N/A N/A C
Unlock (with keyless/factory
alarm entry)
Pink/Lt. Green N/A (+) Drivers kick panel door harness. N/A N/A C
Lock (w/o keyless entry) Pink/Yellow N/A 5-wire Drivers kick panel door harness. N/A N/A C
Unlock (w/o keyless entry) Pink/Lt. Green N/A 5-wire Drivers kick panel door harness. N/A N/A C
Trunk Release Violet/Yellow N/A 5-wire Drivers kick panel harness to rear. N/A N/A C
Passenger Door Triggers Black/Orange 11 (-) LCM to the right of the steering column.
Required ONLY when enabling the security features during module
flashing.
Gray 16 E
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A

10 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Crown Victoria 2005-2007
RX Gray/Orange 4 Data (PATS) connector Type 4. Black 4 A
TX White/Lt. Green 3 Data (PATS) connector Type 4. Black 4 A
Brake Lt. Green/Red 2 (+) Brake pedal switch. Black or Brown 5 D
12V Lt. Green/Violet 9 (+) Ignition switch. Gray 10 B
Ignition Violet/Orange 1 (+) Ignition switch. Gray 10 B
Starter Dark Green 10 (+) Ignition switch. Gray 10 B
Accessory 1 Gray/Yellow or
Black/Lt. Green
7 (+) Ignition switch. Gray 10 B
Accessory 2 White/Lt. Blue or
White/Violet
5 (+) Ignition switch. Gray 10 B
Keysense Gray/Yellow or
Black/Pink
3 or
10
(+) Ignition switch. Gray 10 B
Parking Lights Brown 10 (+) LCM right of steering column or drivers kick. Black 13 E
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green 14 Data OBDII. Black 16 L
Hood Trigger Violet/Orange 2 (-) LCM right of the steering column or hood pin. N/A 16 E
Driver Door Trigger Dk. Blue N/A (-) Drivers kick panel junction block. Gray 20 C
Lock (with keyless/factory
alarm entry)
Pink/Yellow N/A (+) Drivers kick panel door harness. N/A N/A C
Unlock (with keyless/factory
alarm entry)
Pink/Lt. Green N/A (+) Drivers kick panel door harness. N/A N/A C
Lock (w/o keyless entry) Pink/Yellow N/A 5-wire Drivers kick panel door harness. N/A N/A C
Unlock (w/o keyless entry) Pink/Lt. Green N/A 5-wire Drivers kick panel door harness. N/A N/A C
Trunk Release Violet/Yellow N/A 5-wire Drivers kick panel harness to rear. N/A N/A C
Passenger Door Triggers Black/Orange N/A (-) Drivers kick panel harness to rear. Required ONLY when enabling
the security features during module flashing.
N/A N/A C
Ford Crown Victoria 2008-2009
RX Gray/Orange 4 Data (PATS) connector Type 4. Black 4 A
TX White/Lt. Green 3 Data (PATS) connector Type 4. Black 4 A
Brake Lt. Green/Red 2 (+) Brake pedal switch. Brown 5 D
12V Lt. Green/Violet 9 (+) Ignition switch. Gray 10 B
Ignition Violet/Orange 1 (+) Ignition switch. Gray 10 B
Starter Dark Green 10 (+) Ignition switch. Gray 10 B
Accessory 1 Gray/Yellow or
Black/Lt. Green
7 (+) Ignition switch. Gray 10 B
Accessory 2 White/Violet 5 (+) Ignition switch. Gray 10 B
Keysense Gray/Yellow or
Black/Pink
3 or
10
(+) Ignition switch. Gray 10 B
Parking Lights Brown 10 (+) LCM right of steering column or drivers kick. Black 13 E
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green 14 Data OBDII. Black 16 L
Driver Door Trigger Dk. Blue 22 (-) DDM (Drivers Door Module) in drivers door. Black 26 M
Trunk Release White/Violet 12 (+) DDM in drivers door or trunk release switch. Black 26 M
Lock Pink/Yellow N/A (+) Drivers kick panel door harness. N/A N/A C
Unlock Pink/Lt. Green N/A (+) Drivers kick panel door harness. N/A N/A C
Passenger Door Triggers Black/Orange 7 (-) DDM in drivers door or drivers kick panel. Required ONLY when
enabling the security features during module flashing.
Gray 24 M

11 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Crown Victoria 2008-2011
RX Gray/Orange 4 Data (PATS) connector. Black 4 A
TX White/Lt. Green 3 Data (PATS) connector. Black 4 A
Brake Lt. Green/Red 2 (+) Brake pedal switch. Brown 5 D
12V Lt. Green/Violet 9 (+) Ignition switch. Gray 10 B
Ignition Violet/Orange 1 (+) Ignition switch. Gray 10 B
Starter Dark Green 10 (+) Ignition switch. Gray 10 B
Accessory Gray/Yellow or
Black/Lt. Green
7 (+) Ignition switch. Gray 10 B
Accessory 1 Gray/Yellow 7 (+) Ignition switch. Gray 10 B
Accessory 2 White/Violet 5 (+) Ignition switch. Gray 10 B
Keysense Gray/Yellow or
Black/Pink
3 or
10
(+) Ignition switch. Gray 10 B
Parking Lights Brown 10 (+) Drivers kick or LCM (Lighting Control Module) right of steering
column.
Black 13 E
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green 14 Data OBDII. Black 16 L
Passenger Door Triggers Black/Orange 7 (+) Drivers kick or DDM in drivers door. Gray 24 M
Driver Door Trigger Dk. Blue 22 (-) DDM (Drivers Door Module) in drivers door. Black 26 M
Trunk Release White/Violet 12 (+) Trunk release switch or DDM in drivers door. Black 26 M
Lock Pink/Yellow N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock Pink/Lt. Green N/A (-) Drivers kick panel door harness. N/A N/A C
Ford Escape 2001-2004
RX Red/Black 4 Data (PATS) connector Type 2. Green 4 A
TX Brown/Orange 3 Data (PATS) connector Type 2. Green 4 A
12V Red/ Lt. Blue or
Green/Red 4 (+) Ignition switch. Black 7 B
Ignition Lt. Green/Violet 1 (+) Ignition switch. Black 7 B
Starter Tan/Blue 7 (+) Ignition switch. Black 7 B
Accessory Black/Lt. Green 6 (+) Ignition switch. Black 7 B
Keysense Black/Pink 5 (+) Ignition switch. Black 7 B
Hood Trigger Violet/Orange 16 (-) GEM (General Electronic Module) right of gas pedal. Gray 22 E
Driver Door Trigger Violet/Lt. Green 10 (-) GEM right of gas pedal. Gray 22 E
Lock
Pink/White 23
MUX GEM right of gas pedal or driver kick panel, (-) trigger thru
1000Ωresistor. Gray 26 E
Unlock (-) GEM right of gas pedal or driver kick panel.
Parking Lights Brown N/A (+) Drivers kick panel harness to rear. N/A N/A C
Brake Lt. Green N/A (+) Drivers kick panel. N/A N/A C
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A

12 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford E-Series 2008
Brake Dk. Green to Lt.
Green
2 (+) Brake switch or drivers kick panel harness to rear. Black 2 D
RX Gray/Orange 3 Data (PATS) connector Type 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 3. Green 4 A
Keysense Black/Pink 1 (-) Bottom of steering column. Brown 6 K
12V Lt. Green/Violet 2 (+) Ignition switch. Gray or Black 13 B
Ignition Pink/Lt. Green 1 (+) Ignition switch. Gray or Black 13 B
Starter White/Pink 5 (+) Ignition switch. Gray or Black 13 B
Accessory 1 Gray/Yellow 8 (+) Ignition switch. Gray or Black 13 B
Accessory 2 Black/Lt. Green 3 (+) Ignition switch. Gray or Black 13 B
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green 14 Data OBDII. Black 16 L
Driver Door Trigger Red/Pink N/A (-) Drivers kick panel. N/A N/A C
Passenger Door Triggers Black/White N/A (-) Drivers kick panel. N/A N/A C
Sliding Door White N/A (-) Passenger kick panel harness to rear. N/A N/A O
Parking Lights Brown N/A (+) Drivers kick panel harness to rear. N/A N/A C
Lock (with keyless entry) Orange/Black or Red N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock (with keyless entry) Yellow/Red
or Brown
N/A (-) Drivers kick panel door harness. N/A N/A C
Lock (w/o keyless entry) Pink/Yellow N/A 5-wire Drivers kick panel door harness. N/A N/A C
Unlock (w/o keyless entry) Pink/Lt. Green N/A 5-wire Drivers kick panel door harness. N/A N/A C
Ford E-Series 2009-2014
RX Violet/Gray 3 Data (PATS) connector Type 3. Green 4 A
TX Yellow/Orange 4 Data (PATS) connector Type 3. Green 4 A
Keysense Blue/Gray 10 (-) Ignition switch. Gray 10 B
12V Blue/Red 2 (+) Ignition switch. Gray or Black 13 B
Ignition White/Orange 1 (+) Ignition switch. Gray or Black 13 B
Starter Blue/White 5 (+) Ignition switch. Gray or Black 13 B
Accessory 1 Brown/Yellow 8 (+) Ignition switch. Gray or Black 13 B
Accessory 2 Violet/Green 3 (+) Ignition switch. Gray or Black 13 B
Parking Lights Violet/White 6 (+) Driver kick panel or SJB (Smart Junction Box) under drivers dash. Gray 13 H
HS CAN High White/Blue 6 Data OBDII. Black 16 L
HS CAN Low White 14 Data OBDII. Black 16 L
Driver Door Trigger Green/Violet 14 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Passenger Front Door Trigger White 2 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Passenger Rear Door Trigger Yellow 15 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Rear Door Trigger Green or Lt. Green 3 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Lock Gray/Yellow 17 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Unlock Violet/Gray 4 (-) Driver kick panel or SJB under drivers dash. Gray 26 H
Brake Violet/White 40 (+) Brake switch or SJB under drivers dash. Black 52 H

13 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Excursion 2002-2005
RX Gray/Orange 3 Data (PATS) connector Type 1 or 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 1 or 3. Green 4 A
Brake Lt. Green 4 (+) Brake pedal switch or driver kick panel. Tan 5 D
Keysense Black/Pink 8 (-) Bottom of steering column. Gray 8 K
Parking Lights Brown 12 (+) Headlight switch. Gray 12 F
Driver Door Trigger Yellow/Black 4 (-) VSM (Vehicle Security Module), behind the center of dash. Gray 14 N
Lock White/Red 3 (-) VSM, behind the center of dash. Gray 14 N
Unlock Black/White 2 (-) VSM, behind the center of dash. Gray 14 N
Rear Door/Hatch Release Tan/Lt. Green 12 (-) VSM, behind the center of dash. Gray 14 N
12V Yellow B3 (+) Ignition switch. Black 15 B
Ignition Red/Lt Green
(Gasoline) or
White/Yellow (Diesel)
I1 (+) Ignition switch. Black 15 B
Starter Dk. Green STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow or
Brown
A4 (+) Ignition switch. Black 15 B
Accessory 2 Dk. Blue/Lt. Green A1 (+) Ignition switch. Black 15 B
Accessory 3 Red/Black A3 (+) Ignition switch. Black 15 B
HS CAN High White/Lt. Green
(Gasoline) or
Pink/Yellow (Diesel)
6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green
(Gasoline) or
Red/White (Diesel)
14 Data OBDII. Black 16 L
Passenger Front Door Trigger Gray/Red 5 (-)
VSM, behind the center of dash.
Required ONLY when enabling the security features during module
flashing.
Gray 14 N
Driver Rear Door Trigger Lt. Green/Yellow 11 (-) Gray 14 N
Passenger Rear Door Trigger Black/White 6 (-) Gray 14 N
Rear Hatch trigger. Tan/Lt. Green 12 (-) Gray 14 N
Ford Explorer 2001
RX Gray/Orange 3 Data (PATS) connector Type 1. N/A 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 1. N/A 4 A
Brake Lt. Green 4 (+) Brake pedal switch or driver kick panel. Tan 5 D
Parking Lights White/Black or
Brown
12 (+) Headlight switch or drivers kick panel. Gray 13 F
12V Yellow B2 (+) Ignition switch. Black 15 B
Ignition Lt. Green/Violet I1 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow or
Brown
A4 (+) Ignition switch. Black 15 B
Accessory 2 Black/Green A1 (+) Ignition switch. Black 15 B
Hood Trigger Tan/Lt. Green N/A (-) Drivers kick panel. N/A N/A C
Driver Door Trigger Yellow/Black N/A (-) Drivers kick panel. N/A N/A C
Lock (with keyless entry) Pink/Yellow N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock (with keyless entry) Pink/Lt. Green N/A (-) Drivers kick panel door harness. N/A N/A C
Lock (w/o keyless entry) Pink/Yellow N/A 5-wire Drivers kick panel door harness. N/A N/A C
Unlock (w/o keyless entry) Pink/Lt. Green N/A 5-wire Drivers kick panel door harness. N/A N/A C
Driver Rear Door Trigger Lt. Green/Yellow N/A (-) Drivers kick panel harness to rear.
Required ONLYwhen enabling the security features during module
flashing.
N/A N/A C
Passenger Front Door Trigger Gray/Red N/A (-) Passenger kick panel door harness.
Required ONLYwhen enabling the security features during module
flashing.
N/A N/A O
Passenger Rear Door Trigger Pink/Lt. Blue N/A (-) N/A N/A O
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A

14 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Explorer Sport Trac 2001-2003
RX Gray/Orange 3 Data (PATS) connector Type 2. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 2. Green 4 A
Brake Lt. Green 2 (+) Brake pedal switch or driver kick panel. Tan 5 D
Keysense Black/Pink 6 (-) Bottom of steering column. Brown 6 K
12V Yellow B2 (+) Ignition switch. Black 15 B
Ignition Lt. Green/Violet I1 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow or
Brown
A4 (+) Ignition switch. Black 15 B
Accessory 2 Black/Green A1 (+) Ignition switch. Black 15 B
Accessory 3 Black/Pink A2 (+) Ignition switch. Black 15 B
Parking Lights White/Black or
Brown
N/A (+) Drivers kick panel. N/A N/A C
Hood Trigger Tan/ N/A (-) Drivers kick panel. N/A N/A C
Driver Door Trigger Yellow/Black N/A (-) Drivers kick panel door harness. N/A N/A C
Lock (with keyless entry) Pink/Yellow N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock (with keyless entry) Pink/Lt. Green N/A (-) Drivers kick panel door harness. N/A N/A C
Lock (w/o keyless entry) Pink/Yellow N/A 5-wire Drivers kick panel door harness. N/A N/A C
Unlock (w/o keyless entry) Pink/Lt. Green N/A 5-wire Drivers kick panel door harness. N/A N/A C
Driver Rear Door Trigger Lt. Green/Yellow N/A (-) Drivers kick panel harness to rear.
Required ONLY when enabling the security features during module
flashing.
N/A N/A C
Passenger Front Door Trigger Gray/Red N/A (-) Passenger kick panel door harness.
Required ONLY when enabling the security features during module
flashing.
N/A N/A O
Passenger Rear Door Trigger Pink/Lt. Blue N/A (-) N/A N/A O
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A
Ford Explorer Sport Trac 2004-2005
RX Gray/Orange 3 Data (PATS) connector Type 2. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 2. Green 4 A
Brake Lt. Green 2 (+) Brake pedal switch or driver kick panel. Tan 5 D
Parking Lights Brown 12 (+) Headlight switch. Gray 12 F
Ignition Lt. Green/Violet I1 (+) Ignition switch. Black 15 B
12V Red B2 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Brown A4 (+) Ignition switch. Black 15 B
Accessory 2 Black/Green A1 (+) Ignition switch. Black 15 B
Accessory 3 Black/Pink A2 (+) Ignition switch. Black 15 B
Driver Door Trigger Yellow/Black N/A (-) Drivers kick panel door harness. N/A N/A C
Lock Pink/Yellow N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock Pink/Lt. Green N/A (-) Drivers kick panel door harness. N/A N/A C
Passenger Front Door Trigger Gray/Red N/A (-) Drivers kick panel harness to rear.
Required ONLY when enabling the security features during module
flashing.
N/A N/A C
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A

15 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford F150 2004-2008
RX Gray/Orange 3 Data (PATS) connector Type 2. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 2. Green 4 A
Brake Lt. Green 2 (+) Trailer brake connector above gas pedal. Gray 6 E
12V Lt. Green/Violet 4 (+) Ignition switch. Black 7 B
Ignition Dk. Blue/Lt. Green 1 (+) Ignition switch. Black 7 B
Starter Red/Lt. Blue 7 (+) Ignition switch. Black 7 B
Accessory Black/Lt. Green 6 (+) Ignition switch. Black 7 B
Keysense Black/Pink 5 (+) Ignition switch. Black 7 B
Parking Lights Brown 5 (+) Headlight switch. Gray 10 F
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/Lt. Green 14 Data OBDII. Black 16 L
Driver Door Trigger Black/Yellow N/A (-) Drivers kick panel harness to rear. N/A N/A C
Lock Pink/Yellow N/A (-) Drivers kick panel harness to rear. N/A N/A C
Unlock Pink/ Lt. Green N/A (-) Drivers kick panel harness to rear. N/A N/A C
Passenger Front Door Trigger Black/Pink N/A (-) Drivers kick panel harness to rear.
Required ONLY when enabling the security features during module
flashing.
N/A N/A C
Driver Rear Door Trigger Black/Lt. Blue N/A (-) N/A N/A C
Passenger Rear Door Trigger Black/White N/A (-) N/A N/A C
Ford Focus 2000-2007
Brake Green/Red 1 (+) Brake pedal switch. Black 3 D
RX White/Green 4 Data (PATS) connector Type 2. Green 4 A
TX Gray/Orange 3 Data (PATS) connector Type 2. Green 4 A
12V Red 4 (+) Ignition switch. Black 7 B
Ignition Green/Yellow 1 (+) Ignition switch. Black 7 B
Starter Gray/Black 7 (+) Ignition switch. Black 7 B
Accessory Yellow 6 (+) Ignition switch. Black 7 B
Keysense Red/Black 5 (+) Ignition switch. Black 7 B
Parking Lights Orange/Yellow 13 (+) Headlight switch. Black 16 F
HS CAN High - (2002-2007) Gray/Red 6 Data OBDII. Black 16 L
HS CAN Low - (2002-2007) Blue/Red 14 Data OBDII. Black 16 L
Trunk Release - (2000-2001) Black/Yellow 3 (-) GEM (Generic Electronic Module) behind glovebox. Blue or Gray 16 P
Hood Trigger Black/Yellow 21 (-) GEM behind glovebox. Blue or Gray 23 P
Driver Door Trigger Black/Yellow 22 (-) GEM behind glovebox or drivers kick panel. Tan 23 P
Trunk Release - (2002-2004) White 71 (-) Drivers kick panel junction block. Black 71 C
Trunk Release - (2005-2007) Black/Yellow 49 (-) Drivers kick panel junction block. Black 71 C
Lock Black/Red N/A (-) Drivers kick panel door harness. N/A N/A C
Unlock Black/Yellow N/A (-) Drivers kick panel door harness. N/A N/A C
Passenger Door Trigger Black/Blue 21 (-) GEM behind glovebox.
Required ONLY when enabling the security features during module
flashing.
Tan 23 P
Driver Rear Door Trigger Black/Orange 15 (-) Green 23 P
Passenger Rear Door Trigger Black/Green 18 (-) Gray 23 P

16 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford GT 2005-2006
Starter Pink 1 (+) Starter switch. Black 2 R
RX Brown/Orange 4 Data (PATS) connector Type 2. Green 4 A
TX White/Orange 3 Data (PATS) connector Type 2. Green 4 A
12V Red 4 (+) Ignition switch. Black 7 B
Ignition Lt. Green/Violet 1 (+) Ignition switch. Black 7 B
Accessory Black/Lt. Green 6 (+) Ignition switch. Black 7 B
Keysense Black/Pink 5 (-) Ignition switch. Black 7 B
Parking Lights Brown 19 (-) SJB (Smart Junction Box) passenger side foot well. Black 32 O
Hood Trigger Violet/Orange 5 (+) SJB passenger side foot well. Black 32 O
Brake Red/Lt. Green 14 (+) SJB passenger side foot well or brake pedal switch. Black 32 O
Trunk Release (Hood Release) Red 16 (+) SJB passenger side foot well. Black 32 O
Driver Door Trigger Lt. Green/Black 21 (-) SJB passenger side foot well or drivers kick panel. Gray 32 O
Lock Pink/Blue 4 (-) SJB passenger side foot well. Gray 32 O
Unlock Pink/White 5 (-) SJB passenger side foot well. Gray 32 O
Passenger Door Triggers Yellow/Lt. Green 20 (-) SJB passenger side foot well or drivers kick panel.
Required ONLY when enabling the security features during module
flashing.
Gray 32 O
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A
Ford Ranger 2001-2004
RX Gray/Orange 3 Data (PATS) connector Type 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 3. Green 4 A
Brake Lt. Green 4 (+) Brake pedal switch. Brown 5 D
Keysense Black/Pink 1 (+) Bottom of steering column. Brown 6 K
12V Yellow B2 (+) Ignition switch. Gray or Black 16 B
Ignition Lt. Green/Violet I1 (+) Ignition switch. Gray or Black 16 B
Ignition Red/Lt. Blue STA (+) Ignition switch. Gray or Black 16 B
Accessory 1 Gray/Yellow A4 (+) Ignition switch. Gray or Black 16 B
Accessory 2 Black/Pink A1 (+) Ignition switch. Gray or Black 16 B
HS CAN High - (2004 Only) White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low - (2004 Only) Pink/ Lt. Green 14 Data OBDII. Black 16 L
Driver Door Trigger Yellow/Black 6 (-) SJB passenger kick panel. Black 32 O
Lock Pink/Yellow 5 (-) SJB passenger kick panel. Black 32 O
Unlock Pink/Green 9 (-) SJB passenger kick panel. Black 32 O
Parking Lights Brown 8 (+) SJB passenger kick panel. Brown 32 O
Passenger Door Triggers Gray/Red 3 (-) SJB (Smart Junction Box) passenger kick panel.
Required ONLY when enabling the security features during module
flashing.
Black 22 O

17 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Ranger 2005-2006
RX Gray/Orange 3 Data (PATS) connector Type 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 3. Green 4 A
Brake Lt. Green 4 (+) Brake pedal switch. Brown 5 D
Keysense Black/Pink 1 (-) Bottom of steering column. Brown 6 K
12V Yellow 2 (+) Ignition switch. Gray or Black 13 B
Ignition Lt. Green/Violet 1 (+) Ignition switch. Gray or Black 13 B
Starter Red/Lt. Blue 5 (+) Ignition switch. Gray or Black 13 B
Accessory 1 Gray/Yellow 8 (+) Ignition switch. Gray or Black 13 B
Accessory 2 Black/Green 3 (+) Ignition switch. Gray or Black 13 B
HS CAN High White/Lt. Green 6 Data OBDII. Black 16 L
HS CAN Low Pink/ Lt. Green 14 Data OBDII. Black 16 L
Driver Door Trigger Yellow/Black 6 (-) SJB (Smart Junction Box) passenger kick panel. Black 32 O
Parking Lights Brown 8 (+) SJB passenger kick panel. Black 32 O
Lock Pink/Yellow 5 (-) SJB passenger kick panel. Black 32 O
Unlock Pink/Green 9 (-) SJB passenger kick panel. Black 32 O
Passenger Door Triggers Gray/Red 3 (-) SJB passenger kick panel.
Required ONLY when enabling the security features during module
flashing.
Black 22 O
Ford Ranger 2007-2011
RX Blue/Gray 3 Data (PATS) connector Type 3. Green 4 A
TX Violet/Brown 4 Data (PATS) connector Type 3. Green 4 A
Brake Violet/White 2 (+) Brake pedal switch. Tan 5 D
Keysense Black/Pink to Blue/
Gray
10 (+) Bottom of steering column. Gray 10 K
12V Red 2 (+) Ignition switch. Gray 13 B
Ignition White/Orange 1 (+) Ignition switch. Gray 13 B
Starter Blue/White 5 (+) Ignition switch. Gray 13 B
Accessory 1 Brown/Yellow 8 (+) Ignition switch. Gray 13 B
Accessory 2 Violet/Yellow 3 (+) Ignition switch. Gray 13 B
HS CAN High White/Blue 6 Data OBDII. Black 16 L
HS CAN Low White 14 Data OBDII. Black 16 L
Parking Lights Violet/White 5 (+) SJB (Smart Junction Box) passenger kick panel. Black 32 O
Driver Door Trigger Green/Violet 6 (-) SJB passenger kick panel or drivers kick panel. Black 32 O
Lock Gray/Yellow 5 (-) SJB passenger kick panel or drivers kick panel. Black 32 O
Unlock Violet/Gray 9 (-) SJB passenger kick panel or drivers kick panel. Black 32 O
Passenger Door Triggers White 3 (-) SJB passenger kick panel.
Required ONLY when enabling the security features during module
flashing.
Black 32 O
Passenger Rear Door Trigger Yellow 6 (-) Black 32 O
Driver Rear Door Trigger Green 4 (-) Black 32 O

18 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Taurus 2000-2001
RX Red/Black 3 Data (PATS) connector Type 3. N/A 4 A
TX Brown/Orange 4 Data (PATS) connector Type 3. N/A 4 A
Parking Lights Brown 12 (-) Headlight switch or fuse box. Gray 12 F
12V Lt. Green/Violet A4 (+) Ignition switch. Black 15 B
Ignition Red/Lt. Green A2 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow A4 (+) Ignition switch. Black 15 B
Accessory 2 Black/Lt. Green A2 (+) Ignition switch. Black 15 B
Keysense Black/Pink (-) Ignition switch. Black 15 B
Hood Trigger Tan/Lt. Green 17 (-) GEM (Generic Electronic Module) left of steering column. White 26 J
Driver Door Trigger Yellow/Black 5 (-) GEM left of steering column. White 26 J
Lock Pink/Yellow 18 (-) GEM left of steering column. White 26 J
Unlock Pink/Lt. Green 6 (-) GEM left of steering column. White 26 J
Trunk Release (with Keyless) Violet/Yellow 26 (-) GEM left of steering column or trunk release switch. White 26 J
Trunk Release (w/o Keyless) Gray/Red 26 (+) Trunk release switch. N/A N/A I
Brake Red/Lt. Green 1 or 2 (+) Brake pedal switch. Black N/A D
Passenger Door Triggers Gray/Red 19 (-)
GEM left of steering column. Required ONLY when enabling the
security features during module flashing.
White 26 J
Driver Rear Door Trigger Lt. Green/Yellow 20 (-) White 26 J
Passenger Rear Door Trigger Pink/Lt. Blue 7 (-) White 26 J
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A
Ford Taurus 2002-2005
RX Gray/Orange or
Brown/Yellow
3 Data (PATS) connector Type 3. N/A 4 A
TX White/Lt. Green or
Gray/Red
4 Data (PATS) connector Type 3. N/A 4 A
Parking Lights Brown 12 (+) Headlight switch or fuse box. Gray 12 F
12V Lt. Green/Violet B3 (+) Ignition switch. Black 15 B
Ignition Red/Lt. Green I1 (+) Ignition switch. Black 15 B
Starter Red/Lt. Blue STA (+) Ignition switch. Black 15 B
Accessory 1 Gray/Yellow A4 (+) Ignition switch. Black 15 B
Accessory 2 Black/Lt. Green A2 (+) Ignition switch. Black 15 B
HS CAN High - (2004-2005) White/Orange 6 Data OBDII. Black 16 L
HS CAN Low - (2004-2005) Pink/Orange 14 Data OBDII. Black 16 L
Keysense Black/Pink 17 (-)
GEM (Generic Electronic Module) left of steering column.
Black 20 J
Hood Trigger Tan/Lt. Green 17 (-) White 26 J
Driver Door Trigger Yellow/Black 5 (-) White 26 J
Lock Pink/Yellow 18 (-) White 26 J
Unlock Pink/Lt. Green 6 (-) White 26 J
Trunk Release Violet/Yellow 3 (-) White 26 J
Brake Red/Lt. Green 1 or 2 (+) Brake pedal switch. Black N/A D
Passenger Door Triggers Gray/Red 19 (-)
GEM left of steering column. Required ONLY when enabling the
security features during module flashing.
White 26 J
Driver Rear Door Trigger Lt. Green/Yellow 20 (-) White 26 J
Passenger Rear Door Trigger Pink/Lt. Blue 7 (-) White 26 J

19 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Taurus 2006-2007
Brake Red/Lt. Green 2 (+) Brake pedal switch. Black 2 D
RX Gray/Orange 3 Data (PATS) connector Type 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 3. Green 4 A
Parking Lights Brown 12 (+) Headlight switch or fuse box. Gray 12 F
12V Lt. Green/Violet B3 (+) Ignition switch. Gray or Black 13 B
Ignition Red/Lt. Green I1 (+) Ignition switch. Gray or Black 13 B
Starter Red/Lt. Blue STA (+) Ignition switch. Gray or Black 13 B
Accessory 1 Gray/Yellow A4 (+) Ignition switch. Gray or Black 13 B
Accessory 2 Black/Lt. Green A2 (+) Ignition switch. Gray or Black 13 B
HS CAN High White/Orange 6 Data OBDII. Black 16 L
HS CAN Low Pink/Orange 14 Data OBDII. Black 16 L
Keysense Black/Pink 17 (-) GEM (Generic Electronic Module) left of steering column. Black 20 J
Hood Trigger Tan/Lt. Green 17 (-) GEM left of steering column. White 26 J
Driver Door Trigger Yellow/Black 5 (-) GEM left of steering column. White 26 J
Lock Pink/Yellow 18 (-) GEM left of steering column. White 26 J
Unlock Pink/Lt. Green 6 (-) GEM left of steering column. White 26 J
Trunk Release Violet/Yellow 3 (-) GEM left of steering column. White 26 J
Passenger Door Triggers Gray/Red 19 (-) GEM left of steering column.
Required ONLY when enabling the security features during module
flashing.
White 26 J
Driver Rear Door Trigger Lt. Green/Yellow 20 (-) White 26 J
Passenger Rear Door Trigger Pink/Lt. Blue 7 (-) White 26 J
Ford Transit Connect 2010-2013
Brake Green/White to
Green/Red
4 (+) Brake switch. Black 4 D
RX White/Green 4 Data (PATS) connector Type 4. Black 4 A
TX Gray/Orange 3 Data (PATS) connector Type 4. Black 4 A
12V Red 4 (+) Ignition switch. Black 7 B
Ignition Green/Yellow 1 (+) Ignition switch. Black 7 B
Starter Gray/black or
Orange/Black
7 (+) Ignition switch. Black 7 B
Accessory Yellow 6 (+) Ignition switch. Black 7 B
Keysense Black/Red 5 (+) Ignition switch. Black 7 B
HS CAN High Gray/Red or Gray/
Violet
6 Data OBDII. Black 16 L
HS CAN Low Blue/Red or
Blue/White
14 Data OBDII. Black 16 L
Parking Lights Orange/Yellow 13 (+) GEM (Generic Electronic Module) behind dash fuse box. Black 16 J
Driver Door Trigger (w/manual
door locks)
Black/Yellow 18 (-) GEM behind dash fuse box. Gray 23 J
Rear Door Unlock White/Green 5 (+) GEM behind dash fuse box. Green 23 J
Lock Black/Orange 10 (+) GEM behind dash fuse box. Green 23 J
Unlock Black/Green 11 (+) GEM behind dash fuse box. Gray 23 J
Passenger Door Triggers (w/
manual door locks)
Black/Blue 19 (-) GEM behind dash fuse box.
Required ONLY when enabling the security features during module
flashing."
Gray 23 J
Sliding Door Trigger
(w/manual door locks)
Black/White 8 (-) Gray 23 J

20 DS4+ FORD1
© 2018-01-12 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Thunderbird 2002-2005
Brake Orange/Blue or
Orange/Yellow
2 (+) Brake pedal switch. Green 2 D
RX Gray/Red 4 Data (PATS) connector Type 2. Green 4 A
TX White/Red 3 Data (PATS) connector Type 2. Green 4 A
12V Red 7 (+) Ignition switch . Black 8 B
Ignition Green/Black 5 (+) Ignition switch. Black 8 B
Starter Gray/Black 3 (+) Ignition switch. Black 8 B
Accessory 1 Pink/Yellow 6 (+) Ignition switch. Black 8 B
Accessory 2 Pink/White 2 (+) Ignition switch. Black 8 B
Accessory 3 Yellow 4 (+) Ignition switch. Black 8 B
Keysense Red/White 8 (+) Ignition switch. Black 8 B
Parking Lights White/Green 1 MUX Headlight switch, (-) trigger thru a 1780Ωresistor. Gray 10 F
Hood Trigger White 3 N.
Closed
FEM (Front Electronic Module) driver kick panel. Black 12 C
HS CAN High - (2003-2005) Gray/Red 6 Data OBDII. Black 16 L
HS CAN Low - (2003-2005) Blue/Red 14 Data OBDII. Black 16 L
Driver Door Trigger - (2004-
2005)
Black/Red 12 (-) FEM driver kick panel. Black 20 C
Trunk Release White 6 (-) FEM driver kick panel or trunk release switch. Black 20 C
Unlock White/Black 17 (-) REM (Rear Electronic Module) behind rear seats drivers side or
drivers kick panel.
Black 20 N/A
Lock White/Violet 16 (-) White 26 C
Driver Door Trigger - (2002-
2003)
Orange/White N/A (+) Under dash light. N/A N/A S
Ford Windstar 2001-2003
RX Gray/Orange 3 Data (PATS) connector Type 3. Green 4 A
TX White/Lt. Green 4 Data (PATS) connector Type 3. Green 4 A
Hood Trigger Violet/Orange 3 (-) FEM (Front Electronic Module) driver under dash on firewall. White 12 G
12V Lt. Green/Violet &
Red
B3 (+) Ignition switch. Black 15 B
Ignition White/Yellow I1 (+) Ignition switch. Black 15 B
Starter Green STA (+) Ignition switch. Black 15 B
Accessory 1 Yellow A3 (+) Ignition switch. Black 15 B
Accessory 2 Black/Lt. Green A2 (+) Ignition switch. Black 15 B
Keysense Black./Red 5 (+) Ignition switch. Black 15 B
Lock Lt. Blue/Orange 6 (-) FEM driver under dash on firewall. White 20 G
Unlock Lt. Green/Yellow 4 (-) FEM driver under dash on firewall. White 20 G
Parking Lights Headlight switch. See Tech Tip 1072 at www.directechs.com. F
Door Trigger Brown/Pink N/A (-) Passenger "D" Pillar. N/A N/A N/A
Brake Red/Lt. Green N/A (+) Brake switch. N/A N/A D
HS CAN High N/A N/A N/A N/A N/A N/A N/A
HS CAN Low N/A N/A N/A N/A N/A N/A N/A
