Directed Directechs DB3 User manual

DB3 403.NISS4HT
v2.36
2023 Nissan Armada (Smart Key)
THNISS3D Compatible
(Sold Separately)

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Installation 6
Wiring diagram with T-Harness (THNISS3D) 6
Wiring diagram 7
Locating components in the vehicle 8
Vehicle connections 9
Module programming 11
Key2GO 12
Connecting the module 12
LED diagnostics and troubleshooting 13
Soft reset 15
Hard reset 15
Feature programming 16
Feature and option list 17
Limited one year consumer warranty 18
Quick Reference Guide (customer copy) 19
Contents

3403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
Fuel level/EV battery level
Key2GO
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
E-Brake Status
Ignition Status

5403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible THNISS3D
AUX
Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Aftermarket alarm: When armed, the aftermarket alarm (if available) will sound, if the trunk is opened, by using the OEM passive
entry request button near the trunk. To avoid this, open the trunk using the OEM fob button, aftermarket transmitter or SmartStart
application. Alternatively, you can disarm the aftermarket alarm before opening the trunk.
T-Harness (THNISS3D):
•All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness"
•for more information on connections and installation instructions.
•The optional Plug & Play THNISS3D T-Harness is sold separately.
•The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
•All T-Harness wires not listed in the diagram are not required for the installation.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Refer to the "Vehicle connections" following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory
hood pin, or if not supported in data.
[2] Tach: The tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.

6403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
D2D Port
Wiring diagram with T-Harness (THNISS3D)
1412
10 42
(-) Push-to-Start Output: Green/Black
(-) RAP Off Output: Red/Black
(+) Ignition Status Input: Violet/Green
(+) Ignition Status Output: Violet/Brown
(+) Ignition Input
(+) 12V Input
(-) Ground
D2D
only
XKD2D65
Clock & Data Wire
at NATS Connector
(behind Push-to-Start
button)
(-) Unlock Output
(+) Parking Light Output
(-) Lock Output
Do NOT
Connect
White/Black: N.C.
(+) Starter Output
T-02
T-02
NOT USED
T-01
T-01
NOT USED
B-01 B-02
Brake Switch T-Harness
THNISS3D
(optional T-Harness)
Extend Wires HS CAN High: Tan/Black
HS CAN Low: Tan
Diagnostic Connector OBDII
(-) Hood Input
Hood Pin
4
1
5678
23
PTS Switch
(brown 8- pin conn.)
(-) PTS:
Lt. Blue, pin 4
(-) Driver Door Trigger:
Gray/Red, pin 7
1
15
14
13
12
11
10
568
4
3
2
BCM
(black 15-pin conn.)
7
(+) Brake:
Red, pin 2
3
1
4
2
White 4-pin conn.
(brake switch)
This is a mandatory connection. Refer to
the Vehicle connections section for the
corresponding connector, pin and
wire color of your vehicle.
Refer to the
Additional mandatory connections
section for connection details.
(+)12V:
Yellow, pin 15
14
13
12
11
10
5 6 7 8 94321
15
BCM
(white 15-pin conn.)
HS CAN Low:
Pink, pin 40
HS CAN High:
Blue, pin 39
BCM
(black 40-pin conn.
behind instrument cluster)
40
39
38
37
36
35
34
33
32
31
30
2928
27
26
25
24
23
22
21
20
191817
16
15
14
13
12
1110
89
7
6
5
4
3
2
1
BCM
(behind instrument cluster)
Cut the Tan and Tan/Black
and extend the wire coming
from the module side and
connect them to the CAN
wires at the vehicles BCM.

7403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
D2D Port
(-) Ground (-) Ground
(+) Starter Output
(+) Ignition Input
(+) 12V Input
HS CAN High: Tan/Black: 3
HS CAN Low: Tan : 4
Immo. Data Interrupt (vehicle side): Yellow: 8
Immo. Data Interrupt (conn. side): Orange/Yellow: 9
(-) Push-to-Start Output: Green/Black: 2
(-) RAP Off Output: Red/Black: 4
(+) Ignition Status Input: Violet/Green: 8
(+) Ignition Status Output: Violet/Brown: 9
Immo. Clock Output: Yellow/Black: 10
Immo. Data Output (veh. side): Orange/Black: 11
1412
10 42
(+) Parking Lights Output
(-) Unlock Output
(-) Lock Output
XKD2D65
(AC) Tach Output: Violet/White: 5
CUT
Brake Switch
(white 4-pin conn.)
3
1
4
2
Refer to the
Additional mandatory connections
section for connection details.
This is a mandatory connection. Refer to
the Vehicle connections section for the
corresponding connector, pin and
wire color of your vehicle.
(-) Hood Input Hood Pin
(AC) Tach Input
(+) 12V:
Yellow, pin 15
BCM
(white 15-pin conn.)
15
14
13
12
11
10
5 6 7 8 94321
NATS Antenna Connector
(white 4-pin conn.
behind Push-to-Start button)
7
1
15
14
13
12
11
10
5689
4
3
2
(-) Driver Door Trigger:
Gray/Red, pin 7
BCM
(black 15-pin conn.)
Data:
Lt. Green/Red, pin 3
Clock: Pink, pin 2
(+) Brake:
Red, pin 2
40
39
38
37
36
35
34
33
32
31
30
2928
27
26
25
24
23
22
21
20
191817
16
15
14
13
12
1110
89 7
6
5
4
3
2
1
BCM
(black 40-pin conn.
behind instrument cluster)
HS CAN Low:
Pink, pin 40
HS CAN High:
Blue, pin 39
4
1
5678
23
PTS Switch
(brown 8- pin conn.)
(-) PTS:
Lt. Blue, pin 4
BCM
(behind instrument cluster)

8403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Locating components in the vehicle

9403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2023 Nissan Armada (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN High BCM behind instrument cluster, black 40 pin plug, pin 39 Data Blue
H1/4 Tan (DATA) HS CAN Low BCM behind instrument cluster, black 40 pin plug, pin 40 Data Pink
H1/5 Orange/Green No Connection No Connection
H1/6 Orange/Brown No Connection No Connection
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM. Immo. Data Interrupt (veh. side) NATS Antenna Amp on push button ignition switch, white 4 pin plug, pin 3 Data Lt. Green/Red
H1/9 Orange/Yellow Relay N.C. Immo. Data Interrupt (conn. side) NATS Antenna Amp on push button ignition switch, white 4 pin plug, pin 3 Data Lt. Green/Red
H1/10 Orange/Red Relay N.C. No Connection No Connection
H1/11 Yellow/Red Relay COM No Connection No Connection
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - 12 Volt BCM behind instrument cluster, white 15 pin plug, pin 15 + Yellow (50A)
H1/14 Black (-) W2W Only - Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) PTS Output Push Button Ignition Switch, brown 8 pin plug, pin 4 - Lt. Blue
H2/3 Green/White (-) W2W Only - Door / Trunk Output Remote Starter
H2/4 Red/Black (-) RAP Off Output BCM behind instrument cluster, black 15 pin plug, pin 7 - Gray/Red
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green (+) Ignition Status Input Remote Starter
H2/9 Violet/Brown (+) Ignition Status Output Remote Starter
H2/10 Yellow/Black Immo. Clock Output NATS Antenna Amp on push button ignition switch, white 4 pin plug, pin 2 Data Pink
H2/11 Orange/Black Immo. Data Output (veh. side) NATS Antenna Amp on push button ignition switch, white 4 pin plug, pin 3 Data Lt. Green/Red
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color

10 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet (-) W2W Only - Aux1 Input Remote Starter
H3/5 Violet/Black (-) W2W Only - Aux2 Input Remote Starter
H3/6 White/Black No Connection No Connection
H3/7 Pink/White (+) W2W Only - Pk Light Input Remote Starter
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink (+) W2W Only - Ignition Input Remote Starter
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue (Data) TX
H4/2 Black (-) Ground
H4/3 Green (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts BCM behind instrument cluster, white 15 pin plug, pin 15 + Yellow (50A)
Brake Wire Brake Switch, white 4 pin plug, pin 2 + Red
Factory Alarm Arm [3] Power Window Main Switch, white 16 pin plug, pin 15 - Red (key lock)
Factory Alarm Disarm [3] Power Window Main Switch, white 16 pin plug, pin 16 Double - White (key unlock)
Ground (chassis ground)
Hood Pin [2] Hood Switch --or-- Underhood Fuse Box, white 12 pin plug, pin 10 - Lt. Green
Parking Lights [3] Dash Fuse Box, white 10 pin plug, pin 8 + Blue/Orange
Starter BCM behind instrument cluster, white 40 pin plug, pin 27 - Red/White
Tachometer [1] Power Steering Control Unit behind glove box, white 12 pin plug, pin
10
AC Black/Lt. Blue

11 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
1
Wait until the LED turns ON solid red.
Note: To skip the transponder programming and use convenience features only, press the
programming button 5 times.
2Important! Ensure that all keyfobs except one is located a minimum of 10 feet (3 meters)
away from the vehicle BEFORE proceeding with the next step.
3Note: This step is required for programming only.
Remove the backup key from the transmitter. Open the transmitter, and remove the battery.
4Place and hold the keyfob in front of Push-to-Start (PTS) button.
Important! Hold it there for steps6 to 8.
5Press the PTS button twice to turn the ignition ON, and wait for the key light to start flashing.
6Press and hold the brake pedal until the LED starts flashing orange slowly, then release the
pedal slowly.
7Press the PTS button oncemore to turn the ignition OFF.
8Remove the module from the vehicle and reconnect it to your computer. The web site will
automatically recognize that you are moving onto the second phase of the programming
sequence.
9Click on Submit Key2GO Request.
10 Once the configuration is completed, reconnect the module. The LED turns ON solid green for
3 seconds, then turns OFF.
You have successfully completed the module programming sequence.

12 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Key2GO
This feature is mandatory to control the immobilizer override in this firmware.
Key2GO has been designed and developed to bypass the advanced encryption layers found in modern vehicles. It uses an array of servers
to generate a duplicate of the original key, allowing the installation of a remote starter without having to give up a key.
The advantage is that this feature allows you to use one original key and the server to configure the bypass in the vehicle.
All Key2GO-compatible firmware are clearly indicated in the function list of each vehicle search result page and will also appear on the
flash page. Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the
registration process, such as your Directed account number and store name.
Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application.
Refer to the Module Programming section of this guide for instructions on how to program features using Key2GO.
Connecting the module
Important!
Make all the required connections to the vehicle, as described in this guide, and double-check to ensure everything is in order before
moving onto the programming.
Warning! To take advantage of advanced features, you must use DirectLink 4.5 (and higher) or the Directechs Mobile application.
To flash a module using your computer:
1. Connect the interface module to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and select Flash Module.
3. Follow the instructions to select your vehicle, installation type, and configure your options.
4. When you have configured the firmware options, click FLASH.
To flash a module using your smartphone or tablet:
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs mobile app on your smartphone or tablet.
3. Select FLASH YOUR MODULE and follow the onscreen instructions.
When the flashing operation is successful, you can proceed with the instructions below.
D2D installation
Recommended: Connect the 10-pin, 12-pin and 14-pin harnesses to the module, then connect the
4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
4th
(D2D)
2nd
(12-pin)
OR
W2W installation
If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin
harness to the module. 3rd
(14-pin)
1st
(10-pin)
2nd
(12-pin)

13 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
LED diagnostics and troubleshooting
This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation.
Module Programming
LED Description Troubleshooting
Off Module has no power. Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If
12 Volt is present, the module may be defective.
Solid red
Waiting to begin the programming
sequence. Ensure the correct programming procedure is being followed.
Flashes green & red Initialization failed. Reset the module and complete the programming again. If the issue persists, please contact Technical
Support.
Solid orange Transponder functions were skipped. (If compatible) when RXT mode is not desired or convenience features are needed, please reset the and
reprogram the module.
Flashes green
All required CAN networks has been
detected. Normal operation.
Flashes orange 1 of 2 CAN networks has been detected. Normal operation.
Flashes orange
slowly
Key2GO initiated. Please follow the steps indicated in “Module programming” to complete the Key2GO programming.
Solid green x 3 secs
Module was successfully programmed with
all functions. Normal operation.
Solid orange x 3 secs
Module was successfully programmed
without transponder functions. Normal operation.
Module Programming - Error codes
LED Description Troubleshooting
Flashes red x 1 CAN2 not detected.
Check the CAN2 Orange/Green and Orange/Brown wire connections. Wake up the data bus by
turning the ignition on and try again. If your installation does not require this connection, skip this step by
pressing the programming button 5 times.
Flashes red x 1 J1850 not detected. Check the J1850 wire connection. Wake up the data bus by turning the ignition on and try again.
Flashes red x 2 CAN1 not detected.
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the ignition on
and try again. If your installation does not require this connection, skip this step by pressing the
programming button 5 times.
Flashes red x 3 Bypass data not detected. Check the bypass line connection. If more than one wire is used, make sure they are not inverted. Ensure
the vehicle still operates correctly using the factory key.
Flashes red x 4 Bypass processing error. The bypass calculation failed. Reset the module and try again. If the condition persists, please contact
Technical Support.
Flashes red x 5 ISO 1 not detected. The Yellow/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams &
vehicle wiring reference charts)” to check the connections.
Flashes red x 6 ISO 2 not detected. The Orange/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams &
vehicle wiring reference charts)” to check the connections.
Flashes red x 7 MUX not detected. The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to “Installation
(wiring diagrams & vehicle wiring reference charts)” to check the connections.
External Module Synchronization
LED Description Troubleshooting
(Flashes red, red,
then orange) x 10
OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited.

14 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.

Active Ground When Running (Status)
LED Description Troubleshooting
Flashes green
Ground When Running (Status) command
received. The module has initialized the remote start sequence.
Flashes red & orange Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence.
Flashes green quickly Start ON command received. The module has received the Start ON command and is processing the remote start sequence.
Flashes red x 10 PTS shutdown error. The PTS output from the module was not activated due to safety protection.
Flashes red x 21 CAN bus incorrectly detected. Verify the CAN1 and CAN2 connections. Refer to “Installation (wiring diagrams & vehicle wiring
reference charts)” to check the connections.
Commands
LED Description Troubleshooting
Flashes orange x 1 LOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 2 UNLOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 3 TRUNK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 4 AUX1 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 5 AUX2 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Flashes orange x 6 AUX3 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or D2D.
Shutdown Codes
LED Description Troubleshooting
Flashes green x 1 Takeover successful. Normal operation.
Flashes red x 1 Runsafe was not disabled. No UNLOCK command was received prior to opening the door, or the 45 second timer expired in
takeover mode.
Flashes red x 2 Brake was not detected. The brakes were not detected, which prevents the system from shutting down the vehicle.
Flashes red x 3 Smart key was not detected. The smart key was not detected, which prevents the system from shutting down the vehicle.
Flashes red x 4 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down.

15 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Soft reset
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange then release the programming button.
The LED turns ON solid red. &&
Solid SolidRelease
A module reset will only erase the steps perfomed in “Module programming”. The firmware and settings flashed to the module
will not be affected.
Hard reset
Warning Against Executing a Hard Reset!
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the
LED starts to flash orange and red. Solid Flashes
&
3Release the programming button. The LED turns ON solid red. &
Release Solid
A hard reset will revert the flashed firmware back to its default factory settings. Depending on the installation, some settings (such
as RFTD and D2D options) may have to be reconfigured. Refer to “Feature and option list”.

16 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Feature programming
To enter feature programming routine:
1. Turn the ignition ON, then OFF.
2. Within 5 seconds, press and hold the programming button until the LED turns ON orange (after 3 seconds).
3. Release the programming button.
The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to indicate the
current option of feature 1 (e.g. 1 x green followed by 1 x red indicates feature 1 is set to option 1). The flashing sequence will repeat
until a new command is entered.
Changing feature options:
4. Press the lock/arm or unlock/disarm button on the aftermarket transmitter to change the option of the selected feature.
The LED flashes red rapidly the number of times equal to the current option number. After a short delay, the LED flashes green slowly the
number of times to indicate the current feature. The flashing sequence will repeat until a new command is entered.
Accessing another feature:
4. Press and release the programming button a number of times to advance from the current feature to the next desired feature.
The LED flashes green slowly the number of times equal to the feature number. After a short delay, the LED flashes red rapidly to indicate
the current option of the current feature. The flashing sequence will repeat until a new command is entered. When the maximum number
of features or options is reached, the LED will start flashing again from the first feature or option.
Exiting feature programming:
4. To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30
seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence.

17 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Feature and option list
Depending on your vehicle, some of the features and options listed below may need to be configured using the configuration tool found on
the module flashing page at www.directechs.com. The web offers more options; however, manual configuration of the features is possible
using the information on this page.
* Default option
Feat
.Operation Flashes / Option Description
1 RFTD Output Type 1. No RF Output* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (when available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
2 Trunk 1. Trunk* Will pop the trunk if available.
2. Right Sliding Door When available, will operate the right sliding door.
3. Left Sliding Door When available, will operate the left sliding door.
3 Aux1 1. Trunk Will pop the trunk if available.
2. Right Sliding
Door* When available, will operate the right sliding door.
3. Left Sliding Door When available, will operate the left sliding door.
4 Aux2 1. Trunk Will pop the trunk if available.
2. Right Sliding Door When available, will operate the right sliding door.
3. Left Sliding
Door* When available, will operate the left sliding door.
5 Parking Light Control
On Data
1. Disabled The remote starter parking lights wire must be connected in the vehicle.
2. Enabled* The parking lights will be controlled by CAN wires.
6 OEM Security
Disarm On Data
1. Disabled The vehicle is not equipped with an OEM alarm.
2. Enabled* This feature must be enabled when the vehicle is equipped with an OEM security alarm. The alarm original to the
vehicle is disarmed using the bypass and Push-to-Start (PTS) button.
7 Door Lock Control
On Data
1. Disabled The remote starter door lock wires must be connected in the vehicle.
2. Enabled - Type1 (EU) Works for most European vehicles.
3. Enabled - Type2
(US)*
Works for most North American vehicles. (We've noticed that some North American vehicles need to be set to
"Type 1 (EU)" to work properly.)

18 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Limited 12 Months Consumer Warranty
VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part
thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date
of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s
option) without charge for parts or repair labor. A transmitter for a vehicle security or remote start system is warranted for
12 months from he date of original purchase.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty
coverage (e.g. dated bill of sale), authorization number, specication of defect(s), transportation prepaid, to an approved
warranty station. This warranty is not transferable.
This Warranty does not cover damage to the vehicle’s electrical system or costs incurred for the installation, removal or
reinstallation of the product. This Warranty does not cover batteries, broken LCD transmitter display screens, nor apply
to any product or part thereof which, in the opinion of the Company, has su󰀨ered or been damaged through alteration,
improper installation, mishandling, misuse, abuse, neglect, accident, or by removal or defacement of the factory serial
number/bar code label(s).
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 24 MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No person or representative is
authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
The company does not warrant that this product cannot be compromised or circumvented. THE EXTENT OF THE
COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY
PURCHASER FOR THE PRODUCT WITHOUT INSTALLATION LABOR.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specic legal
rights and you may also have other rights which vary from state to state.
VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824

19 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Quick Reference Guide (customer copy)
Pit stop/idle mode
1Stop the vehicle in a safe parking spot and put the gear
in Park (P).
Put
gear in Park
2
Press the Remote Start button on the transmitter.*
The parking lights will flash once to indicate the vehicle is
now in Pit Stop Mode.
Parking lights
flash x1
14:36
Press
Remote
Start
button*
&
3
It is safe to leave the engine running and exit the vehicle
with the factory remote in hand.
Note: We recommend that you always lock the doors of
your vehicle when leaving it unattended.
14:36
Exit
vehicle
with
remote
* Icon and remote appearance may differ depending on the model purchased.
List of available commands
Note that the information below is for many Viper, Clifford, Python, Avital, Automate,
Autostart and AstroStart models. Icons and commands may differ depending on the model
and options purchased. Refer to your authorized installation center for more specific
information.
Button(s) Actions
Press & hold for 1 second to lock.
Press & hold for 1 second to unlock.
* Press & hold for 1 second to remote start.
* Press & hold for 5 seconds to activate the trunk release (optional).
* Icon and remote appearance may differ depending on the model purchased.
Sending commands to your vehicle
Whether you want to remote start the engine, lock/unlock the doors or pop the trunk, there
are 3 possible ways you can send commands to your vehicle, using the:
• Factory remote.
• Aftermarket remote.
• Directed SmartStart application via your smartphone.
If applicable, you can also start the engine remotely by pressing the Lock button 3 times
quickly on your factory remote.
Vehicle takeover with Get In and Go
1Close the vehicle doors, hood and trunk, then press the
Remote Start button on the transmitter to start the vehicle.*
14:36
Press Remote
Start button*
2Press the Unlock button on the factory or aftermarket
remote.*
14:36
Press Unlock on
either remote*
Complete the following steps within 45 seconds or the vehicle will shut down.
3Enter the vehicle, while making sure the factory remote is
inside with you.
14:36
Enter
vehicle
with
remote
4Depress the brake pedal, put the car in gear and drive off.
Ready
to drive
off
* Icon and remote appearance may differ depending on the model purchased.
Get In and Go
Get In and Go is designed to provide users with easy takeover when entering their Push-to-Start
(PTS) equipped vehicle, once it has been remote started.
Typically, users would have to remote start their vehicle, then get inside and press the PTS button
to perform a takeover. There is therefore a physical action required to drive away. With Get In
and Go, you simply remote start the vehicle, unlock the doors, get in and go... All that's left to do
is put the gear in drive and drive off.

20 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key)
©2023 Directed. All rights reserved.
Notes
