Directed Directechs DB3 User manual

Designed by Installers for Installers
INSTALLATION GUIDE
DB3
2012 Mitsubishi Galant. 403.MIT4 2.07
© 2022 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Wiring diagram 6
Locating components in the vehicle 7
Adding wires to an empty pin 8
Vehicle connections 9
Module programming 12
Module programming for convenience only (skip transponder) 13
Connecting the module 13
LED diagnostics and troubleshooting 15
Soft reset 17
Hard reset 17
Feature programming 18
Feature and option list 19
Limited one year consumer warranty 20
Quick Reference Guide (customer copy) 21
Contents

3403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Immobilizer Bypass-Data No Key Req'd
RAP Shut Down (Retained ACC Power)
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
Ignition Status

5403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible T-Harness is not compatible. Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Refer to the "Vehicle connections" section following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Tach wire: An optional connection required on some remote starters, which do not support a tach signal in D2D.
[3] Lock/Unlock wires: If there are no Lock/Unlock wires, you can insert them directly as shown on the "Adding wires to an empty pin"
section.

6403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
D2D Port
1412
10 42
Wiring diagram
(+) Parking Lights Output
(-) Hood Input (-) Hood
(-) Unock Output
(+) Ignition Output
(+) 12V Input
(+) Accessory 1 Output
(+) Starter Output
(-) Starter Output
(-) Lock Output
XKD2D65
16
8
9
1
HS CAN Low: Black, pin 14
HS CAN High: Red, pin 6
OBDII
Diagnostic Connector
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 3
(-) Ground
31 2
4 5 6
(+) Ignition: Black/White, pin 2
(+) 12V: Blue/Yellow, pin 1
(+) Starter: Black/Yellow, pin 5
(+) Accessory 1: Blue/Red, pin 4
(+) Accessory 2:
Blue/Black, pin 6
Ignition Switch
(white connector at ignition switch)
(+) Accessory 2 Output
(-) RAP Off Output: Green/Black, pin 2
(-) Driver Door Trigger:
Lt. Green, pin 6
Driver’s Fuse/Junction Block
(white connector front of fuse box)
Junction Block
front view
765
131415 12
4 3 2 1
891011
C-204
(-) Unlock: Lt.Green/Red, pin 14
(-) Lock: Violet, pin 13
Junction Block
rear view
ETACS-ECU
(white connector, left rear of dash fuse box)
5
4321
10 11 12 15
14
13 16 17 18
22 23 2419 20 21
7
68 9
Clutch:
Brown/Black,
pin 2
(+) 12V
For Manual Transmission ONLY
Clutch
Pedal
21
Relay pin 30 Relay pin 87a
30
86
85
87
87a
Cut
(-) Trunk Release Output
(-) Trunk Release:
Black/Yellow, pin 21
Keysense Interr. Output (conn. side): Yellow/Red: 11
Keysense Interr. Output (veh. side): Orange/Red: 10
Keysense:
Blue/Red,
pin 10 CUT
1 2 3 4 5 6 7
89 10 11 12 13 14 15
(+) Turn Signal
(left):
Green/Red,
pin 8
(+) Turn Signal
(right):
Green/Yellow,
pin 13
Signal Lights
(white connector in dash fuse box)
6 Amp
Diodes
(AC) Tach Input (AC) Tach Output: Violet/White, pin 5
(-) Hood Pin Input
Hood Pin
(+) 12V Input: Brown: 7
(+) Ignition Output: Yellow: 8

7403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle

8403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Adding wires to an empty pin
Solder onto a diode, cut away the rest of the wire.
Empty pin
Diode
Solder the wire to secure it on the metal pin.
This part can be removed because only
the metal pin is needed to secure the
contact in the empty pin.
Unlock* wire from the Remote Starter.
*Lock: The same procedure has to be done for the missing Lock wire.

9403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2012 Mitsubishi Galant. Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN High data link connector, 16 pin plug, pin 6 data red
H1/4 Tan (DATA) HS CAN Low data link connector, 16 pin plug, pin 14 data black
H1/5 Orange/Green No Connection No Connection
H1/6 Orange/Brown No Connection No Connection
H1/7 Brown Relay N.O. (+) 12 Volt Input ignition switch, white 6 pin plug, pin 1 + blue/yellow (40A)
H1/8 Yellow Relay COM. (+) Ignition Input ignition switch, white 6 pin plug, pin 2 + black/white
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. Keysense Interrupt (Vehicle side) key switch or ETACS-ECU on left rear of dash fuse box, white 24 pin
plug, pin 10
open blue/red
H1/11 Yellow/Red Relay COM. Keysense Interrupt (Connector side) key switch or ETACS-ECU on left rear of dash fuse box, white 24 pin
plug, pin 10
open blue/red
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - 12 Volt Remote Starter
H1/14 Black (-) W2W Only - Ground Remote Starter
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) RAP Off Output dash fuse box, top, white 15 pin plug, pin 6 - lt. green
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red No Connection No Connection

10 403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green No Connection No Connection
H3/2 Blue No Connection No Connection
H3/3 Red/White No Connection [2] No Connection
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection [3] No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White No Connection No Connection
H3/8 Violet No Connection No Connection
H3/9 Pink No Connection No Connection
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Green (Data) TX
H4/2 Black (-) Ground
H4/3 Blue (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
