dixell IC200CX Series User manual

F
IC200CX Series
Quick reference guide

INDEX
1GENERAL ADVICE 6
2IC200 CX TABLE OF THE FEATURES 7
3USER INTERFACE 8
3.1 DISPLAY CONFIGURATION 8
3.2 Icons Meaning 8
3.3 Meaning / Functionning of the bottom display led 10
4DISPLAY LAYOUT 10
4.1 How to read the measurement list 10
4.2 Read Probe values of circuit 1 or 2 10
5DISPLAY INFORMATION 11
5.1 Read the Set Point value 11
5.2 Modify the Set Point 11
5.3 Read the active SetPoint during Energy Saving or Dynamic Setpoint
11
5.4 KEY FUNCTION 12
5.5 KEY COMBINANTION 13

6REMOTE TERMINAL 13
7FIRST INSTALLING 14
7.1 On Board Clock (Optional) 14
7.2 RTC Setup 14
8ANALOG AND DIGITAL OUTPUT CONFIGURATION 15
8.1 Analog input Pb1 - Pb2 – Pb5 – Pb6 15
8.2 Analog input Configuration Pb3 - Pb4 15
8.3 Digital Input Configuration Id1 – Id18 16
8.4 Digital Output (relay) Configuration RL1- RL8 17
8.5 Analog output configuration 0 ÷ 10 Volt (OUT1 e OUT2) 18
8.6 Configurazione N° 2 Uscite Analogiche 0 ÷ 10 Volt / Taglio di Fase (OUT3 e
OUT4) 18
9PROGRAMMING WITH THE “HOT KEY 64” 18
9.1 Download: how to program an instrument with a programmed “Hot Key”
18
9.2 Upload: How to program a “Hot Key” with the parameters of the instrument
19
10 PROGRAMMING USING THE KEYBOARD 19
10.1 Password default values 19
10.2 Enter the Pr1 - Pr2 - Pr3 programming levels 19
10.3 How to change a parameter value 20

10.4 Change the Password value 20
10.5 Enter the programming level Pr1 21
10.6 Enter the programming level Pr2 21
10.7 Enter the programming level Pr3 22
11 FUNCTION MENU “ M” KEY 23
11.1 Alarm list: show and reset 23
11.2 Compressor overload alarm reset 24
11.3 Compressor overload password. 24
11.4 Alarm log list 24
11.5 Erase the Alarm log list 25
11.6 Password value of the alarm list 25
11.7 Disable – enable a single circuit 25
12 TABLE OF THE OUTPUT STATUS IN ALARM CONDITION
26
12.1 ALARM: “A” type and status of the loads in case of alarm 26
12.2 ALARM: “b” type and status of the loads in case of alarm 28
12.3 ALARM: “C” type and status of the loads in case of alarm 29
13 TABLE OF THE PARAMETERS 30
14 BLACK-OUT 53

15 WIRING CONNECTIONS 54
15.1 Hardware Resources for IC206CX model 54
15.2 Hardware Resources for 208CX Models 54
16 INSTALLING AND MOUNTING 55
16.1 Panel cut- out 55
16.2 Vertical boards Vi620CX panel cut-out 55
17 ELECTRICAL CONNECTIONS 56
18 TECHNICAL DATA 57

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Pag. 6/58
1 GENERAL ADVICE
PLEASE READ BEFORE USING THIS MANUAL
•This manual is part of the product and should be kept near the instrument for easy and quick
reference.
•The instrument shall not be used for purposes different from those described hereunder. It cannot
be used as a safety device.
•Check the application limits before proceeding.
SAFETY PRECAUTIONS
•Check the supply voltage is correct before connecting the instrument.
•Do not expose to water or moisture: use the controller only within the operating limits avoiding
sudden temperature changes with high atmospheric humidity to prevent formation of condensation
•Warning: disconnect all electrical connections before any kind of maintenance.
•The instrument must not be opened.
•In case of failure or faulty operation send the instrument back to the distributor or to “Dixell s.r.l.”
(see address) with a detailed description of the fault.
•Consider the maximum current which can be applied to each relay (see thechnical Data).
•Ensure that the wires for probes, loads and the power supply are separated and far enough from
each other, without crossing or intertwining.
•Fit the probe where it is not accessible by the end user.
•In case of applications in industrial environments, the use of mains filters (our mod. FT1) in parallel
with inductive loads could be useful.

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
2 IC200 CX TABLE OF THE FEATURES
CHARACTERISTICS IC206CX
IC208CX
N°KEYS
6 nn
RELAYS
6 n
8 n
DIGITAL INPUTS
11 Config Config
ANALOG INPUTS
4 NTC – PTC
2 NTC - PTC - 4÷20mA - 0 ÷ 5Volt Config Config
PROPORTIONAL OUTPUTS
2 configurables (signal 0÷10V) Config Config
2 configurables (signal 0÷10V, PWM) Config Config
SERIAL OUTPUTS
TTL with Mod-BusRtu protocol nn
Remote Keyboard VICX620 (up to 2 remote keyboards with probe on board)
nn
POWER SUPPLY
12 Vac/dc (+15%;-10%) nn
24 Vac/dc (± 10%) Opt Opt
MAIN DISPLAY (UPPER DISPLAY)
± 4 digits with decimal point nn
SECONDARY DISPLAY (LOWER DISPLAY)
± 4 digits with decimal point nn
OTHER
Clock on board Opt Opt
Buzzer Opt Opt
configurable = configurable through parameter
opt = optional
n= default

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Pag. 8/58
3 USER INTERFACE
3.1 DISPLAY CONFIGURATION
3.2 ICONS MEANING
ICON MEANING / FUNCTIONNING
°C -°F
BAR-PSI Lighted when the display shows a temperature or pressure
Lighted when a compressor is activated
Blinking = when the delay of activation is running
Alarm: blinking in case of alarm
Lighted if anti freeze heaters/ integration heating / boiler are activated
Flow alarm/ (differential) pressure switch / supply fan thermal (air / air unit): is
blinking if the configuration of the digital input is active

1592022750 Quick reference guide IC 200CX Rel. 1.1 25/05/2009
Lighted when the bottom display shows the RTC
Lighted during the programming parameters if it is time based
Lighted in function menu when the display shows the defrost delay
Water pump: lighted if at least one pump is activated
Condenser fan: lighted if at least one fan is active
Lighted if Dynamic set point or Energy saving are active
Lighted during menu navigation
Lighted if auxiliary ouput is active
Lighted when the controller is ON
Lighted when the display shows probes values of circuit 1 or circuit 2
Lighted when the defrost is activated
Blinking during the counting of the interval between defrost
