dj power DSK-1500VS User manual

Fog machine DSK-1500VS
User’s Manual

Fog machine DSK-1500VS Art.No.: 115 54
2 / 21
Table of contents
1. Safety instructions ............................................................................................... 3
1.1. For safe and efficient operation................................................................... 3
2. Intended use of the device .............................................................................. 4
2.1. Overhead installation ..................................................................................... 5
2.2. Connections ....................................................................................................
2.2.1. Electrical connections .............................................................................
2.2.2. DMX connections ..................................................................................... 7
2.3. DMX connection with terminator ................................................................. 7
3. Introduction ......................................................................................................... 8
3.1. Features ............................................................................................................ 8
3.2. Item delivered ................................................................................................. 8
3.3. Product description ........................................................................................ 9
3.4. Overhead installation of the device ......................................................... 10
4. Start-up .............................................................................................................. 11
4.1. Operation ....................................................................................................... 11
4.1.1. Structure of the menu ........................................................................... 12
4.1.2. DMX chart ............................................................................................... 13
4.1.3. Remote .................................................................................................... 13
4.2. Fluid sensor ..................................................................................................... 15
5. Technical data ................................................................................................. 1

Fog machine DSK-1500VS Art.No.: 115 54
3 / 21
1. Safety instructions
•This device is suitable for indoor use (not outdoors) only.
•Unauthorized modifications will invalidate the warranty.
•Repairs are to carry out by skilled workers only.
•Use only fuses of the same type and original parts as spare parts.
•To avoid fire and electric shocks protect the unit from rain and humidity.
1.1.For safe and efficient operation
Be careful with heat and e treme temperatures!
Do not place the device in a location where it is exposed to extreme
temperatures.
Operate the device only in an ambient temperature between 0°C (32°F) -
40°C (104°F). Do not expose the device to direct sunlight or heat sources.
Keep away from humidity, water and dust!
Avoid placing the device in a location with high humidity or excessive
dust. Place no liquids on or near the system.
Place the device on a firm ground!
To avoid vibrations always place the device on a firm ground.
Do not use chemicals for cleaning!
Use a clean and dry cleaning rag to remove dust. Metal parts can be
cleaned with a damped cleaning rag. Before cleaning always unplug the
device from the power supply.
If the device is not working properly!
If problems occur unplug the device from the power supply. The user should
not try to service the device independently. All repairs and service must be
performed by a qualified technician.
Take proper care with the power cord!
Never pull the power cord to disconnect the device from the power
supply, but remove the plug with plug housing in the hand. If you do not
use the device for an extended period, unplug the device from the power
supply.
ATTENTION!
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any consequent secondary
failures. Only skilled workers are allowed to carry out the electrical
connections. All electrical and mechanical connections have to be carried
out according to the European safety standards.

Fog machine DSK-1500VS Art.No.: 115 54
4 / 21
2. Intended use of the device
This device was developed for professional use on stages, in discos, theatres
etc. The device is only approved for a connection up to 230 V 50/ 0 Hz
alternating current and only for indoor use.
Regular breaks during operation increase the lifetime of your device.
Avoid convulsions or any form of forceful impact during the installation or the
startup of the device.
Take care that no cables are lying around. You would endanger your own
safety and also the safety of a third party.
It is not allowed to operate or store the device in an environment in which
spray water or rain is expected. Humidity or very high atmospheric humidity
could reduce the isolation of the device and could cause deathly electric
shocks.
If using fog machine you have to ensure that the fog saturation of the room
must allow a good visibility of at least 10m.
Operate the device not during thunderstorms. Surge voltages could destroy
the device. Unplug the power supply during thunderstorms.
Surrounding objects or surfaces should not be in contact with the device.
Make sure that during the installation and removal of the device the area
below the place of installation is basically cordoned off. This also applies to
implementation of service.
Make familiar yourself with the functions of the device before start-up. People
without the experience should not handle with the device. The most cause of
functional disorder is inappropriate handling.
Keep the device away from children and never operate it unattended.
Never aim the nozzle on people a keep a distance from 50 cm to the nozzle.
ATTENTION. The ejected fog is very hot!
Keep a minimum distance of 50 cm to other objects.
Use only the recommended, high quality water-based fluid from your dealer.
Other fluids may cause damages. Do not use flammable additives, such as
oil, gas, perfumes, etc. in your fluid.
Never aim the nozzle on open fire or flammable objects.
Make sure to top off the fluid in time. If the machine operated without fluid it
can cause damages to the pump or the heating block. Before top off the
fluid please unplug the device from the power supply.
Never drink the fluid. I fit does happen, please contact a doctor. If the fluid
had contact with the eyes or mucous membranes, rinse immediately with
water bodies.
Operate the unit only in a horizontal position.

Fog machine DSK-1500VS Art.No.: 115 54
5 / 21
Never use solvents or aggressive detergents for cleaning. Use instead of this a
damped cleaning rag.
To prevent damages during transport use for transport the original packing or
provided accessories.
For reasons of safety unauthorized changes are forbidden!
A usage of the device which differs from usages which are described in this
manual can cause damages of the device. In this case the warranty expires.
Additional you should notice that every different usage is related with
dangers and can cause e.g. an electrical short, fire, electric shock or crash.
2.1. Overhead installation
Danger of life!
You have to observe the regulations of BGV C1 (formerly VBG
70) and EN60598-2-17 Installations are to carry out by skilled
personnel only.
The suspension devices have to be build and measured so they can
withstand for an hour the tenfold of the payload without suffering a
permanent detrimental deformation.
Basically installation has to be made by using a second separate suspension.
This can be e.g. a suitable net. The second suspension must be designed and
attached so no part of the installation can fall down in case of failure.
During construction, reconstruction and deconstruction unnecessary stay in
the range of moving areas, on lightning bridges, under elevated work stations
or any other danger zones is forbidden.
The operator is obliged to following safety-related and mechanical facilities:
•Before the first start-up or after critical changes before restarting it has
to be checked by an expert.
•Review in the frame of the inspection test at least all four years by an
expert. .
•Review by a qualified person at least once a year.
How to carry out the overhead installation:
Ideally the device should be installed outside lounge areas of people.
IMPORTANT! Overhead installation requires a high level of experience. This
includes knowledge of calculating the payload, used installation material
and safety inspections of the used material and the projector whereas the
required experience is not limited to this. Do not try to carry out installation
yourself under any circumstances if you are not qualified. Contact a
professional installer. An inappropriate installation can lead to injuries and/or
damaged properties.
