EN
1. Forward Vision System**
2. Propellers
3. Motors
4. Gimbal and Camera
5. Front LEDs
6. Landing Gears (Built-in antennas)
7. Power Button
8. Battery Level LEDs
9. Intelligent Flight Battery
10. Battery Buckles
11. Downward Vision System**
12. GPS Antennas
13. Vents
14. USB -C Port
15. Camera Micro SD Card Slot
16. Aircraft Status Indicator/Function Button
17. Backward Vision System**
* Maximumighttimewastestedin0windataconsistent15.5mph(25kph).Thisvalueshouldbetakenfor
reference only.
**TheForward,DownwardandBackwardVisionSystemsareaffectedbysurroundingconditions.Readthe
DisclaimerandSafetyGuidelinesandwatchthetutorialintheDJIGO4apporontheOfcialDJIwebsite
to learn more. http://www.dji.com/mavic-air
Aircraft
TheDJITM MAVICTM Air features a new folding design and a fully stabilized 3-axis
gimbal camera capable of shooting 4K video and 12 megapixel photos. DJI
signature technologies such as Obstacle Avoidance and Intelligent Flight Modes
likeSmartCapture,8KPanorama,AdvancedPilotAssistanceSystems,QuickShot,
ActiveTrackTM,andTapFlyTM,makecapturingcomplexshotseffortlessandeasy.The
MavicAirboastsamaximumightspeedof42.5mph(68.4kph)andamaximumight
time* of 21 minutes.
1
2
109
3
7
8
6
4
5
11
12
13
14
15
16
17

3
EN
Remote Controller
BuiltintotheRemoteControlleristheDJIenhancedWi-Fitechnology,offeringamaximum
transmission range of 2.49 mi (4 km) and video from the aircraft to the DJI GOTM4 app on your
mobiledeviceatupto1080patcloserange,and720patlongerranges.Thedetachable
controlsticksmaketheremotecontrollereasiertostore.TheMavicAiralsosupportsyingon
your phone with Virtual Joysticks.
Maximum run time: 2.5 hours*
1. Antennas
2. Status LED
3.RTHButton
4. Charging / Main Video
Link Port (Micro USB)
5. Control Sticks
6. Flight Pause Button
7. Flight Mode Switch
8. USB / Assistant Video
Link Port
9. Battery Level LEDs
10. Power Button
11. Function Button
12. Mobile Device Clamp
Folded
13. Gimbal Dial
14.RecordButton
15. Customizable Button
16. Shutter Button
* Theremotecontrollerisabletoreachitsmaximumtransmissiondistance(FCC)inawideopenareawith
noElectro-MagneticInterference,andatanaltitudeofabout400feet(120meters).
 Themaximumruntimeistestedunderlaboratoryenvironment,onlyforyourreference.
1
3
4
5
6
7
8
9
10
11
12
2
13
14
15
16

4
EN
1. Downloading the DJI GO 4 App and Watching
Tutorial Videos
2. Preparing the Aircraft
Searchfor‘DJIGO4’intheAppStoreorGooglePlay,or
scantheQRcodetodownloadtheapponyourmobile
device.
Watchthetutorialvideosatwww.dji.com/mavic-airorintheDJI
GO 4 app by tapping the icon in the top right corner of your
screen.
Removethe
gimbal protector
from the camera.
It is recommended to mount the propeller guards
whenyinginBeginnerModeorindoorstoensure
bettersafety.RefertotheMavicAirPropellerGuards
User Guide to learn more.
Unfold the rear
arms.
Unfolded
DJI GO 4 supports iOS 9.0 (or later) or Android 4.4 (or later).
It is recommended to have the gimbal protector attached when the aircraft is not in use. Make
sure the gimbal is horizontal when mounting or removing the gimbal protector.
Ensurethelandinggearisproperlyunfoldedbeforeuse.Otherwise,thebuilt-inantennamaybe
affectedcausingseriousproblemstothevideolink.Makesureyoufoldthelandinggearsrst
before folding the aircraft arms.
2
1 1
DJI GO 4
TutorialVideos
Unfold the front arms
and landing gears.

5
EN
3. Charging the Batteries
RemovetheIntelligentFlightBattery
from the aircraft.
Attach the Intelligent Flight Battery to the battery charger via the port as shown above.
Intelligent Flight Battery Charging time:
53 minutes in environments at temperatures between 15° to 40° C;
1 hour and 40 minutes in environments at temperatures between 5° to 15° C.
Remote Controller Charging time: 2.5 hours
Use the provided charger to fully charge the
IntelligentFlightBatterybeforersttimeuse.
Low Battery Level High Low Battery Level High
Press the Power button once to
check the current battery level. Press
once,thenagainandholdtoturnon/
off the remote controller.
Press once to check the battery level.
Pressonce,thenagainandholdto
turn on/off.
B
A
A
B
USB-C Cable
USB Adapter
Power Outlet
100 - 240V
B
A
A
B
Whenfullycharged,inserttheIntelligentFlightBatteryintotheaircraftuntilyouhearaclick,
ensuringthatthebatteryismountedrmlyinplace.
TheoptionalBatteryChargingHubcanchargeuptofourbatteriessimultaneously.Pleasevisit
theofcialDJIOnlineStoretolearnmore.
Removetheremotecontrollercablebeforecharging.Connecttheprovidedcommunication
cable with the USB Adapter to the Charger.
B
A
A
B
Check the Battery Levels and Power On/O

6
EN
Use your DJI account to activate the aircraft. Activation requires an internet connection.
4. Preparing the Remote Controller
5. Preparing for Takeoff
Internet
1
3
2
DJI GO 4
App
Set the antennas parallel to each other
Power on the remote
controller
Power on the aircraft Launch the DJI GO 4 app
OptimalTransmissionRange
Strong Weak
Place one end of the remote
controller cable to the end
of the slot on the side of the
remote controller.
Unfold the antennas and
mobiledeviceclamps,
then attach the control sticks.
Attach your mobile
device within the clamps.
Ensurethecontrolsticksarermlymounted.
TheremotecontrollercablewiththeLightningConnectorismountedbydefault.Usethe
appropriate cable for your mobile devide to connect to the remote controller.
WhenusinganiPadortablet,usetheUSBportontheremotecontroller.
Do not use the Micro USB and the USB ports simultaneously for linking video. Disconnect one
port from the video-linking device if the other port is in use.

7
EN
6. Flight
PresstheFlightPausebuttonforemergencybrakingduringight.
Ready to Go (GPS)
OR
Left Stick Up
Down
Turn RightTurn Left
Right Stick Forward
Backward
RightLeft
AutoTakeoff
Left stick up (slowly)
to take off
Left stick down (slowly) until you touch
the ground
Holdafewsecondstostopthemotors
Auto Landing
Beforetakingoff,makesuretheAircraftStatus
BarintheDJIGO4appdisplays‘ReadytoGo’.
ThedefaultightcontrolisknownasMode2.Theleftstickcontrolstheaircraft's
altitudeandheading,whiletherightstickcontrolsitsforward,backward,leftandright
movements.Thegimbaldialcontrolsthecamera'stilt.
Combination stick command
to start/stop the motors
Auto Takeo / Landing
Manual Takeo / Landing
Themotorscanonlybestoppedmid-ightwhentheightcontrollerdetectscriticalerror.
Remote Controller Operation

8
EN
Turnonyourmobiledevice'sWi-FiandentertheWi-Fipasswordshownontheaircrafttoconnect
totheMavicAirnetworkifforanyreasonyoucannotscantheQRcode.
WhenusingWi-FiinawideopenareawithnoElectro-MagneticInterference,transmission
distance is approximately 262 ft (80 m) at an altitude of 164 ft (50 m).
LinkingisrequiredwhenswitchingbacktoRemoteControlmode.TheWi-Fifrequencyofyour
mobiledevicecanbesetto2.4GHzor5GHz.SetyourWi-Fito5GHzforlessinterference.Once
connectedtotheMavicAir,youcanchangeyourWi-FipasswordorresetyourWi-Ficonnection.
(RefertotheUserManualformoreinformation)
WatchthetutorialintheDJIGO4apporontheOfcialDJIwebsitetolearnmore.
AlwayssetanappropriateRTHaltitudebeforetakeoff.WhentheaircraftisreturningtotheHome
Point,youshouldguideitwiththecontrolsticks.
Mavic_XXX
DJI GO 4
App
Normal
TapFly
QuickShot
Tripod
ActiveTrack
SmartCapture
1. Power on the aircraft.
2. Press and hold the Function Button on the aircraft for four seconds until you hear a
doublebeep,switchingtoWi-Ficontrolmode.
3.LaunchtheDJIGO4appandtaptheiconinthetoprightcornerofyourscreen.Next,
scantheWi-FiQRCodeonthefrontarmtostarttheconnection.
4.TapAutoTakeoff.
5.NowyoucanytheaircraftwithtouchcontrolviaVirtualJoysticks.
Controlling ight with Virtual Joysticks on your mobile device via Wi-Fi
In the DJI GO 4 App

9
EN
It’simportanttounderstandbasicightguidelines,forthesafetyofbothyouand
thosearoundyou.Don'tforgettoreadtheDisclaimer and Safety Guidelines.
7. Fly Safe
Fly in Open
Areas
Strong GPS
Signal
Maintain Line
of Sight
Avoid flying over or near obstacles, crowds, high voltage power lines, trees
or bodies of water.
DO NOT fly near strong electromagnetic sources such as power lines and
base stations as it may affect the onboard compass.
DO NOT use the aircraft in adverse weather conditions such as rain, snow,
fog and wind speeds exceeding 10 m/s or 22 mph.
Fly Below 400 Feet
(120 m)
Learn more at:
http://flysafe.dji.com/no-fly
Stay away from the rotating propellers
and motors.
No Fly Zone
120m
≥10 m/s
