DMP Electronics 464-263H Assembly instructions

InstallatIon sheet
464-263H HSPA+ Cellular Communicator
Description
The 464-263H HSPA+ Cellular Communicator provides a fully supervised alarm communication path over the HSPA+
network for XR100/XR500 Series panels. The 464-263H is installed in the panel enclosure and powered by the panel, so no
additional enclosure, power supply or battery back-up is needed.
What is Included
The 464-263H includes the following:
• One Model 464-263H Cellular Communicator
• One Model 381-2, 18-inch Coax cable with SMA connector
• One 4-Wire LX-Bus harness
• One SIM Card
• One Model 383 Rubber Duck Antenna
• One PCB standoff
Compatibility
The 464-263H is compatible with XR100 and XR500 Series control panels when
using version 212 or higher.
Installation Safety
Ground Yourself Before Handling the Panel! To discharge
static, touch any grounded metal, such as the enclosure,
before touching the panel.
Remove All Power From the Panel! Remove all AC
and Battery power from the panel before installing or
connecting any modules, cards, or wires to the panel.
Installing the 464-263H
Align the 464-263H card 50 pin connector with the J6 connector and
press the card onto the connector while applying even pressure to
both sides of the board. See Figure 2.
Installing the SIM Card
Insert the SIM card into the 263H as pictured in Figure 1.
Connecting the Antenna
1. Position one of the supplied washers onto the 381-2 SMA
connector and push the threaded end through an enclosure
knockout.
2. Position the second washer onto the threaded end extending
through the knockout and secure the nut.
3. Attach the included 383C Antenna to the SMA connector.
See Figure 2.
4. Attach the opposite end of the 381-2 Coax to the SMA connector
on the
464-263H. See Figure 2.
Note: As an alternative, the antenna coax can be connected directly to the
464-263H SMA connector when the coax enters the enclosure via conduit.
LX-Bus™ Expansion Capability
The 464-263H card also provides a 4-wire LX-Bus™ for the addition of
any combination of 100 protection zones and 100 relay outputs. Insert
the harness connector into the 4-pin LX-Bus header on the bottom of
the 464-263H Interface Card.
Note: Do not use shielded wire when using the LX-Bus. Do not connect
the wires from the 464-263H to panel terminals or the panel J22
header. All devices installed on the 464 LX-Bus must be included in the
panel standby battery calculations.
Programming/Activation
Cellular Service is required before using the 464-263H for signal
transmission. In Remote Link panel communication programming,
select Cellular as one of the Communication types. The module comes
with a SIM card ready for activation with SecureCom Wireless, LLC.
More information is available at www.securecomwireless.com or refer
to the Remote Link Users Guide (LT-0565). Or, use a SIM card provided by
the carrier of your choice. If you are activating the unit with an
alternate carrier, program the APN provided by your carrier during panel programming.
65555
SIM
CARD
Bottom View
Figure 1: 263H SIM Card Installation
Model 381-2
Coax Cable
from 263H
Nut
Washers
SMA
Connector
SMA
Connector
Antenna
Connector
J6 Interface Card
Connector
18 19 20 21 22 23 24 25 26 27 28
Z5 Z6 Z7 Z8 Z9+ Z9- Z10+ Z10-
GND
GND
Red—Auxiliary Power
Yellow—Data In
Green—Data Out
Zone Expansion
Harness Connector
To LX-Bus
Modules
XR100/XR500
Panel
Black—Ground
263H
Cell Module
464-263H
263H
SIM
Card
Figure 2: 464-263H HSPA+ Wiring
Figure 3: Remote Link Activation
Figure 4: Remote Link Activation

LT-1314 1.01 © 2014 Digital Monitoring Products, Inc.
INTRUSION •FIRE • ACCESS • NETWORKS
2500 North Partnership Boulevard
800-641-4282
www.dmp.com
Designed, Engineered and
Assembled in U.S.A. Springeld, Missouri 65803-8877
14033
Diagnostics
The XR100/XR500 Series panels provide a Diagnostics function to test the Communication integrity and Cellular Signal
strength of the 464-263H. To use Diagnostics, reset the panel, enter the Diagnostics code 2313 (DIAG), and press COMMAND
until COMM STATUS displays.
Communication Status
Select COMM STATUS from the Diagnostics menu. The panel tests the 464-263H for the following items.
• Modem Operating • Cellular Tower Detected • NOC Success
• Identied • Registered • Communication Path Integrity
Cellular Signal
Select CELL SIGNAL from the Diagnostics menu. The panel tests and indicates the strength of the
signal using a bar display. One bar indicates a weak signal and seven bars indicate a strong signal.
Wiring Specications for LX-Bus
When planning an LX-Bus installation, keep in mind the following specications:
1. DMP recommends using 18 or 22-gauge unshielded wire for all keypad and LX-Bus circuits. Do Not use twisted pair or
shielded wire for LX-Bus and keypad bus data circuits. To maintain auxiliary power integrity when using 22-gauge wire do
not exceed 500 feet. When using 18-gauge wire do not exceed 1,000 feet. Install an additional power supply to increase
the wire length or add devices.
2. Maximum distance for any one circuit (length of wire) is 2,500 feet regardless of the wire gauge. This distance can be in
the form of one long wire run or multiple branches with all wiring totaling no more than 2,500 feet. As wire distance from
the panel increases, DC voltage on the wire decreases.
3. Maximum number of devices per 2,500 feet circuit is 40.
Note: Each panel allows a specic number of supervised keypads. Add additional keypads in the unsupervised mode. Refer
to the panel installation guide for specic number of supervised keypads allowed.
4.
Maximum voltage drop between the panel (or auxiliary power supply) and any device is 2.0 VDC. If the voltage at any device
is less than the required level, add an auxiliary power supply at the end of the circuit. When voltage is too low, the devices
cannot operate properly. For additional information refer to the LX-Bus/Keypad Bus Wiring Application Note (LT-2031).
FCC Information
This device complies with Part 15 of the FCC Rules. Afx the included FCC label to the exterior of the panel enclosure in plain
sight. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modications made by the user and not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
-xx dbm
SIGNAL: ▐▐▐▐▐▐▐
Specications
Primary Power 12 VDC from panel
Current Draw
Standby: 15mA
Alarm (Nominal):
48mA
Peak (~150mS): 85mA
Accessories
380-400 Level 400 SecureCom SIM Card
380-400R Level 400 Rogers SIM Card
381-2 18” Coax Cable
381-12 12’ Coax Extension
381-25 25’ Coax Extension
383 Antenna
386 Wall Mount Antenna Bracket
Ordering Information
464-263H Cellular Communicator
464-263HCAN Canadian Cellular Communicator
Listings and Approvals
Cellular FCC ID: R17HE910NA
Cellular Industry Canada: 5131A-HE910NA
Underwriters Laboratories (UL) Listed
ANSI/UL 1076 Proprietary Burglar
ANSI/UL 1610 Central Station Burglar
Underwriters Laboratories Canada (ULC) Listed
ULC/ORD-C1076 Proprietary Burglar
ULC S304-06 Central Station Burglar
