DMP Electronics 263LTE-FN User manual

DESCRIPTION
Figure 1: 263LTE-FN
The 263LTE-FN Cellular
Communicator provides
a fully-supervised alarm
communication path over a
reserved AT&T network. The
module installs on the panel
inside the enclosure and is
powered by the panel so no
additional enclosure, power
supply, or battery back-up is
needed.
The 263LTE-FN is
FirstNet Ready™.
Compatibility
• XR150/XR550 Series
panels with Version 202 or
higher
• XT30/XT50 Series Panels
with Version 202 or higher
What is Included
• 263LTE-FN Cellular
Communicator
• 383 antenna
• PCB stando
• Hardware pack
1INSTALL THE 263LTE-FN
Caution: Touch grounded metal to discharge
static before handling the panel.
XT30/XT50 Series Panels
1. Open the panel enclosure, set the reset
jumper, and remove power from the panel.
2. Insert the included stando into the
panel stando hole.
3. Align the 263LTE-FN SMA antenna connector
with the antenna hole in the top of the panel
enclosure, place one washer around the
connector, and secure it on the 12-pin cell
module connector. See Figure 2.
Note: For XT50 panels, install the included
washers between the antenna and the panel.
4. Align the 263LTE-FN stando hole with the
stando already placed in the panel and
snap it into place.
1
2
3
4
Figure 2: 263LTE-FN on an XT30/XT50 Panel
Back of the
263LTE-FN
Stando and
Stando Hole SMA Connector
Figure 3: 263LTE-FN on an XR150/XR550 Panel
Stando and
Stando Hole
Back of the
263LTE-FN
XR150/XR550 Series Panels
1. Open the panel enclosure, set the reset
jumper, and remove power from the panel.
2. Insert the included stando into the
XR150/XR550 Series panel stando hole.
3. Secure the 263LTE-FN on the 12-pin cell
module connector. See Figure 3.
4. Align the 263LTE-FN stando hole with the
stando already placed in the panel and
snap it into place.
Washer (XT50 only)
263LTE-FN CELLULAR
COMMUNICATOR
Installation Guide

2 263LTE SERIES INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS
1. Navigate to the Dealer Admin site (dealer.securecomwireless.com).
2. Click Customers in the right-side menu and select a customer.
3. Click Add System.
4. Enter a System Name.
5. Select either Cellular or EASYconnect + Cell Backup in the Connection Type field.
6. Enter the SIM number found on the 263LTE-FN label and click Get Status.
7. Enter the Account Number.
8. Select a Rate Plan for the 263LTE-FN.
9. Click Activate Cellular Device.
Dealer Admin Activation
3ACTIVATE THE 263LTE-FN
Cellular service is required before you can use the 263LTE-FN for signal transmission.
The 263LTE-FN comes ready for activation with SecureComTM Wireless, LLC. Use Remote
LinkTM, the Dealer AdminTM site (dealer.securecomwireless.com), the Tech APPTM, or call DMP
Customer Service (1-866-266-2826) to activate the 263LTE-FN.
2CONNECT THE ANTENNA
Be sure to only use the included 383 antenna when installing the 263LTE-FN.
XT30/XT50 Series Panel
1. If installing an XT50, place the second washer around the 263LTE-FN SMA
connector and connect it to the included antenna at the hole in the top of the panel.
2. Connect the 263LTE-FN SMA connector to the included antenna at the hole in the
top of the panel. See Figure 4.
XR150/XR550 Series Panel
1. Attach one end of the included 381-2 coax cable to the 263LTE-FN SMA connector.
2. Position one washer onto the other end of the coax cable and push the threaded
end through the antenna knockout hole.
3. Position the second washer onto the threaded end that extends through the
antenna knockout hole and secure the nut.
4. Attach the included LTE antenna to the coax cable SMA connector. See Figure 5.
CONNECT THE ANTENNA
LTE Antenna
Figure 4: XT30/XT50 Series Panel
1
2
3
4
Figure 5: XR150/XR550 Series Panel
SMA
Connector
LTE Antenna
Coax Cable
SMA Connector
263LTE-FN
SMA
Connector
Coax
Cable
Antenna
Knockout Hole
Brass Washers

263LTE SERIES INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS 3
TEST THE 263LTE-FN
1. Navigate to the Tech APP.
2. Tap Find a Customer then search for a customer.
3. Tap Add a System.
4. Enter a System Name.
5. Scan or enter the Serial #.
6. Select either Cellular or EASYconnect + Cell Backup in the Connection Type field.
7. Enter the Account Number.
8. Enter the SIM Number found on the 263LTE-FN label then tap Get SIM Status.
9. Select a Rate Plan for the 263LTE-FN.
10. Tap Activate Cellular Device.
Tech APP Activation
The panel provides a diagnostic function to test the communication integrity and cellular
signal strength of the 263LTE-FN to the nearest tower for the cellular carrier. To use the
diagnostic function, reset the panel, enter 2313 (DIAG), and press CMD.
Communication Status
This option tests the individual components of cellular or wireless network
communication.
1. Select CELL STATUS from the Diagnostic menu. Possible test results are shown
in Table 1.
2. Select YES to continue through the remaining component tests or select NO to
stop testing and return to CELL STATUS.
Confirmed Faulty
MODEM OPERATING NO MODEM FOUND
IDENTIFIED NO SIM CARD
TOWER DETECTED NO TOWER
REGISTERED NOT REGISTERED
CONNECT SUCCESS CONNECT ERROR
NOT ACTIVATED
CELL PATH GOOD NO ACK RECEIVED
Remote Link Activation
1. Navigate to Remote Link and select a panel.
2. Select Program in the top menu and select Communications from the drop-down
menu.
3. Select Cellular Network as the Communication Type and click Activate.
4. Select SIM as the SIM Type.
5. Enter the SIM number found on the 263LTE-FN label and press the Tab key.
6. Select a Rate Plan for the 263LTE-FN and click Activate.
4
Table 1: Cell Status Test Results

Designed, engineered, and
manufactured in Springfield, Missouri
using U.S. and global components.
INTRUSION • FIRE • ACCESS • NETWORKS
2500 North Partnership Boulevard
Springfield, Missouri 65803-8877
888.436.7832 | DMP.com
© 2021 Digital Monitoring Products, Inc.
LT-2184 1.01 21174
Specifications
Primary Power 12 VDC from panel
Current Draw
Standby 6 mA
Alarm 7 mA
Ordering Information
263LTE-FN Cellular Communicator for AT&T LTE
Accessories
381-2 18” Coax Cable
381-12 12’ Coax Extension
381-25 25’ Coax Extension
383 Dual Band Antenna (included)
386 Antenna Mounting Bracket
Compatibility
XR150/XR550 Series Version 202 or higher
XT30/XT50 Series Version 202 or higher
Certifications
FCC Part 15: XMR201909EC25AFX
Industry Canada: 10224A-201909EC25AFX
Underwriters Laboratory (UL) Listed
• ANSI/UL 294 Access Control System Units
• ANSI/UL 636 Holdup Alarm Units and System
Accessory
• ANSI/UL 1023 Household Burglar
• ANSI/UL 1076 Proprietary Burglar
• ANSI/UL 1610 Central Station Burglar
• ANSI/UL 1635 Digital Burglar
• ANSI/UL 985 Household Fire Warning
• ANSI/UL 864 Fire Protective Signaling 9th Edition.
• ANSI/UL 365 Police Sta. Connected Burg Alarm
Units & Systems
• ANSI/UL 609 Local Burg Alarm Units & Systems
Underwriters Laboratory of Canada (ULC) Listed
• ULC S304 Central Station Burglar
• ULC - Subject - C1023 Household Burglar
• ULC/ORD - C1076 Proprietary Burglar
• ULC - S545 Household Fire
• ULC - S559 Equipment for Fire Receiving
Centers and Systems
