Dockin D FINE User manual

BLUETOOTH SPEAKER
User manual

2
CONTENT
GENERAL
Welcome to the Dockin family!...........................................................................3
Speaker arrangement.............................................................................................4
Connections....................................................................................................................4
Controls.............................................................................................................................5
SAFETY
Reading and storing the user manual..........................................................6
Explanation of symbols and terms..................................................................6
Proper use.......................................................................................................................7
Safety Notes...................................................................................................................8
OPERATION
Checking the package contents.....................................................................12
Turning the D FINE on............................................................................................12
Pairing...............................................................................................................................12
Changing the source device/disconnecting ..........................................13
Turning the D FINE o............................................................................................13
AUX mode.......................................................................................................................14
Charging the DFINE...............................................................................................14
Power-saving function...........................................................................................14
Power bank function...............................................................................................14
Micro-USB service port.......................................................................................15
Care and storage......................................................................................................15
Troubleshooting..........................................................................................................16
Technical Specications........................................................................................16
Declaration of conformity ...................................................................................17
Manufacturer information and service .....................................................17
Disposal............................................................................................................................18
EN

3
Spotify:
dockin_de
Instagram:
dockin_de
Facebook:
DOCKIN
WELCOME TO THE DOCKIN FAMILY!
About DOCKIN
Honesty and authenticity are at the core of what we believe in. Both
are incorporated into our daily work and are therefore an integral
part of DOCKIN as a brand and our products.
We meet the challenge of a new, young brand in the rather conserv-
ative audio market head on. Being on the frontier of technology,
delivering products for a better life and better sound for our entire
community — whether it is through our products, our customer
service or through reaching out to you in other ways.
OUR MISSION
We put our passion into audio concepts that enhance your expe-
rience of unique sound in your exible and mobile life – anytime and
anywhere! First-class workmanship and a captivating sound are
always in the centre of our focus.
PASSION FOR SOUND
… is more than just akey marketing speak. Our team consists of
people with strong backgrounds in audio and a passion for sound
and aesthetics. The love for music, sound and technology unites our
team and makes our products unique in the audio landscape.
You can learn even more about us at www.dockin.de/about! Here
are some curated playlists for you, which you can listen to there and
on Spotify. Just come over and take a look!
EN

4
SPEAKER ARRANGEMENT
CONNECTIONS
USB charging port
(power bank function)
AUX Input
Charging port
(device)
Micro-USB service port
Tweeter
(right)
Tweeter
(left)
2 subwoofers
2 passive bass
radiators
EN

5
NFC logo
Bluetooth® status LED
Push and hold:
Turn the device on/o
Push: Play/Pause
Push and hold: Disconnect Bluetooth®
Push: Increase the volume
Push and hold: Next track
Push: Reduce the volume
Push and hold: Previous track
Rechargeable battery
status LED
CONTROLS
EN

6
READING AND STORING THE USER MANUAL
This user manual for your DFINE Bluetooth® speaker
(hereinafter referred to only as “DFINE”) contains
important information about safety and handling.
Therefore, read the user manual carefully before using
the DFINE and also store it in a safe place for future reference. If
you do not observe the information in the user manual, in
particular the safety notes, this may result in damage to property
and, in the worst case, even injury to persons. If you pass your
DFINE on to someone, make sure to also include this user manual.
This user manual is based on the standards and rules in force in
the European Union. When abroad, also be sure to observe the
country-specic guidelines and laws.
You can download this user manual as a PDF le at www.dockin.
de under Support.
EXPLANATION OF SYMBOLS AND TERMS
Here, you will nd a list of the safety-relevant symbols and terms,
which are used in this user manual, on the DFINE or on its
packaging.
WARNING
This combination of a warning symbol and term indicates a moderate
risk, which, if not avoided, may result in death or severe injury.
NOTICE
This signal term warns you of potential damage to property.
The GS symbol on the mains adapter stands for
tested safety. Products labelled with this symbol meet
the requirements of the German Product Safety Act
(ProdSG).
EN

7
This symbol indicates that the wall adapter is a device
belonging to protection class II.
Declaration of conformity (see chapter “Declaration of
conformity”): This symbol indicates products that full
all applicable Community regulations in the European
Economic Area.
This symbol certies that the radiated electromagnetic
interference of the device is under the limit approved by
the US Federal Communications Commission.
ETL Listed test seal: Products labelled with this symbol
meet the requirements of electrical product safety of
the United States of America.
The wall adapter may only be used indoors.
PROPER USE
The DFINE is designed as a speaker for private use. It is not suit-
able for commercial use. You can connect to a source device of your
choice in the following ways: You can connect the source device to
the DFINE via Bluetooth®4.0, EDR, NFC or using an AUX cable.
The D FINE also has a power bank function, that is, you can also
connect suitable external devices to the DFINE and charge them
using the integrated rechargeable battery of the DFINE.
The power cable contained in the package contents is designed for
charging the DFINE. If you want to charge an external device on
the DFINE using the power bank function, you may, depending on
the respective external device, need an additional cable that is not
included in the package contents.
Only use the DFINE as described in this user manual. Any other use
is deemed improper and may result in damage to property or even
injury to persons. The DFINE is not a children’s toy.
The manufacturer or vendor accepts no liability for damage caused
by improper or incorrect use.
EN

8
SAFETY NOTES
WARNING
Risk of electrical shock!
Improper handling, incorrect electrical installation or excessive
mains voltage may result in an electrical shock.
-Make sure that the mains voltage of the socket corresponds to
the specication on the rating plate if you connect the DFINE to
it for charging purposes.
-Make sure that the socket that you connect the DFINE to is
readily accessible so that you can quickly disconnect the DFINE
from the mains supply in the event of a fault.
-Only use the power cable contained in the package contents to
charge the DFINE.
-Stop using the D FINE if it exhibits visible damages or if the
power cable or its connector plug is defective.
-Do not in any case open the housing of the D FINE. Instead,
contact a qualied workshop for repairs. Liability and warranty
claims are excluded in the event of repairs performed by your-
self, improper connection or incorrect operation.
-Only parts that comply with the original device data may be
used for repairs. There are electrical and mechanical parts in
the device which are necessary in order to avoid exposure to
sources of danger.
-Do not in any case submerge the DFINE and the power cable in
water or other liquids.
-Do not use the DFINE in the rain or in wet rooms.
-Make sure that the DFINE and the power cable do not come
into contact with open ames and hot surfaces.
-Make sure that the power cable is not kinked and do not lay it
over sharp edges.
-Disconnect the DFINE from the power supply once it is fully
charged, before you clean the DFINE or if a fault occurs.
-Immediately disconnect any external devices connected to the
DFINE if a fault occurs.
EN

9
WARNING
Risk of explosion and re!
Improper handling of the DFINE can cause the integrated recharge-
able battery to explode or cause a re.
-Do not subject the DFINE to excessive warmth or heat such as
direct sunshine, re or similar.
Only use the power cable contained in the package contents to
charge the DFINE.
WARNING
Danger of chemical burns!
Leaked battery uid can cause chemical burns if it comes into con-
tact with the skin or other parts of the body.
-If you notice that battery uid is leaked, be absolutely sure that
it does not come into contact with your skin, eyes or mucous
membranes. If you have accidentally come into contact with
battery uid, immediately rinse the aected areas with plenty of
clean water and promptly contact a physician.
-Be absolutely sure to use protective gloves in the event of a
leaked rechargeable battery and remove any battery uid that
has leaked with a dry, absorbent cloth.
WARNING
Risks to certain groups of persons!
-The DFINE may be used by children ages eight and over as well
as persons with impaired physical, sensory or mental capacities
or those lacking experience and knowledge if they are super-
vised or have been instructed in how to safely use the DFINE
and have understood the risks associated with operating it.
Children must not play with the DFINE. Cleaning and user main-
tenance must not be performed by unsupervised children.
-Make sure that children do not play with the packaging material
or the DFINE.
EN

10
-Keep children under the age of 8 away from the DFINE and the
power cable.
-Keep the DFINE out of the reach of children.
-Do not leave the DFINE unattended while charging an external
device.
WARNING
Health hazard!
During operation, the DFINE generates magnetic elds, which can
interfere with the functioning of medical devices such as pacemak-
ers. Using the DFINE in certain locations can also result in faults or
accidents.
-Always keep a distance of at least 10cm between the medical
device and the DFINE. If necessary, consult your physician if you
have any questions.
-Do not use the DFINE in environments where there is a risk of
explosion.
-Make sure that you only use the DFINE where wireless trans-
missions are permitted.
WARNING
Risk of hearing loss!
Listening at a high volume for prolonged periods poses a risk of
hearing loss.
-Avoid listening at a high volume for a prolonged period of time.
-Make sure that you maintain adequate distance to the DFINE
and never hold your ear up to one of the speakers.
-Set the volume on the source device to a low level before start-
ing playback on the DFINE. If you set the source device to full
volume, very high noise pressure may result, which may not only
inict organic damage, but also have psychological eects. Chil-
dren and pets are particularly at risk in this respect.
EN

11
NOTICE
Risk of damage!
Improper handling can cause damage to the DFINE.
-Do not place the DFINE on or near hot surfaces (stovetops,
heaters etc.).
-Do not allow the power cable to come into contact with hot
parts.
-Fully recharge the DFINE approximately every six months, even
if you are not using the DFINE at all or only irregularly.
EN

12
CHECKING THE PACKAGE CONTENTS
Make sure that the package contents are complete and that all
parts are undamaged before you commission the DFINE.
1. Take the DFINE and all accessories out of the packaging.
2. Use the following list to check whether the package contents
are complete.
The package contents contain the following individual parts:
• DFINE speaker
• Power cable with wall adapter
• AUX cable (3.5mm plug cable)
• User manual
3. Check whether the DFINE or the accessories are damaged.
If this is the case, do not use the DFINE. Instead, contact the
manufacturer at the service address.
TURNING THE DFINE ON
• Hold the button on the top of your DFINE down for 3
seconds to switch the DFINE on.
The DFINE automatically connects with the last Bluetooth®
source (blue LED illuminates continuously) or switches to pairing
mode if the last source is not available (blue LED blinks quickly).
PAIRING
Connecting via Bluetooth® function:
1. Activate Bluetooth® on the source device (Bluetooth®
settings).
2. Go to the Bluetooth® settings and scan for discoverable
devices.
3. Select “DOCKIN DFINE” from the Bluetooth® device list.
EN

13
After successful pairing, the blue LED on your DFINE stays lit and
you will hear a conrmation sound.
Connecting via NFC function:
This function is only available if your device supports NFC (
Near Field
Communication ).
1. Activate Bluetooth® on the source device (Bluetooth®
settings).
2. Activate NFC on the source device.
3. Hold your source device close to the NFC logo on top of the
DFINE. First time connection via NFC needs to be conrmed on
your source device.
After successful NFC pairing, the blue LED on the DFINE stays lit
and you will hear a conrmation sound.
CHANGING THE SOURCE DEVICE/DISCONNECTING
To select a new playback device while still paired, the current
Bluetooth® connection needs to be disengaged.
• Disconnect the current Bluetooth® connection on the source
device.
or
• Push and hold the button on your DFINE for approx. 3
seconds.
TURNING THE DFINE OFF
• Hold the button on the top of your DFINE down for 3
seconds to switch the DFINE off.
EN

14
AUX MODE
You can connect your DFINE to a source device using the provided
AUX cable (3.5mm plug cable).
The DFINE power-saving mode is disengaged when the AUX
cable is connected. If the AUX cable and the mains adapter are
connected, this permits stationary use, for example as a PC
speaker or a TV soundbar.
1. Connect the source device to the AUX input of your DFINE
using the provided 3.5mm plug cable.
2. Start playback on the source device.
CHARGING THE DFINE
• Charge your DFINE by using the provided power cable. The
charging port is located behind the cover on the side.
During charging, the rechargeable battery status LED is
green.
Once the device is completely charged, the LED turns o.
If the rechargeable battery has less than 15 minutes of charge
remaining, the rechargeable battery status LED will be red.
POWER-SAVING FUNCTION
If there hasn’t been any signal transmission or charging via the USB
output for 15 minutes, your DFINE turns o automatically. If the AUX
cable is connected, the power saving function is disabled. This allows
stationary use.
POWER BANK FUNCTION
The power bank function enables you to charge the source device
with your DFINE.
EN

15
• To do so, connect the source device to the USB output of your
DFINE using a USB cable.
MICRO-USB SERVICE PORT
The micro-USB service port on the side of your DFINE is used
exclusively designed for technical service. Do not plug anything into
this port.
CARE AND STORAGE
Care and cleaning:
• Use a dry, lint-free cloth to clean your DFINE. Make sure that
no liquids penetrate the device!
• Do not in any case use brushes with metal or nylon bristles
and do not use any sharp or metallic cleaning utensils for
cleaning as they could damage the surface.
Storage:
• Store your DFINE at room temperature (approx. 5–20°C) in a
dry location where it is protected against direct sunlight.
• Make sure that your DFINE is not accessible for children.
• Always store the DFINE in a charged state.
• Charge your DFINE at regular intervals (approx. every
2–3months) even if you do not use it at all or only irregularly.
As with all lithium ion rechargeable batteries, this is necessary
in order to maintain the battery power in the long term.
EN

16
TROUBLESHOOTING
Bluetooth® connection failed:
• Make sure that your DFINE is not already connected with
another device (if so, disconnect).
• Ensure that the source device is within a few meters to your
DFINE.
• Ensure that Bluetooth® is activated on the source device.
• Deactivate & reactivate Bluetooth® on the source device.
• Turn your DFINE off and on again.
TECHNICAL SPECIFICATIONS
Article: DFINE Bluetooth® speaker
Article number: 15231
Rechargeable battery: Lithium ion (6,600 mAh)
Music playback time: up to 10 hours
Protection type: IP55
(protected against dust and
splashing water)
Nominal output: 50 W
Power consumption in standby:
< 0.5 W
USB port (power bank
function): USB-A; 5V; 1A
Dimensions: 285 × 100 × 103 mm
Weight: 1930g
Connection options for
external source devices: Bluetooth® 4.0 + EDR, NFC, AUX
Connections present on the
DFINE:
DC 5V, DC 15V, 3.5mm jack plug
(AUX), micro-USB
EN

17
Information about the wall adapter:
Model: DYS40-150240W-K
Nominal output for input: 100–240V~; 50/60Hz; 1.0A Max.
Nominal output for output: 15.0V 2.4A
Protection class: II
Information about the Bluetooth® function:
Frequency range: 2.402–2.480GHz
Transmission power: 8dBm at 3.3V
DECLARATION OF CONFORMITY
Ströer Products GmbH hereby declares that the D FINE radio
system described in this user manual complies with the Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the
following Internet address:
https://support.dockin.de/hc/de/articles/115003938889-Spezi-
kation
MANUFACTURER INFORMATION AND SERVICE
If you have questions regarding the DFine or if any problems occur
during operation or similar, rst contact the following body via
e-mail:
[email protected]
DOCKIN is a trademark of Ströer Products GmbH | Torstr. 49 |
10119 Berlin
EN

18
DISPOSAL
Disposing of the packaging
Dispose of the packaging sorted into single-type
materials:
• Paperboard and cardboard for recycled paper
• Films in the recyclable material collection service
Disposing of the device
(Applicable in the European Union and other European states with
systems for the separate collection of reusable waste materials)
Old devices must not be disposed of with
household waste!
If the DFINE is no longer operational, every consumer
is required by law to dispose of used devices
separately from household waste, e.g. at a collection
point run by the communal authority/borough. This
ensures that old devices are recycled in a professional
manner and also rules out negative consequences for
the environment. For this reason, electrical equipment
is marked with the symbol shown here.
Batteries and rechargeable batteries do not
belong in the household garbage!
As the end user you are required by law to bring all
batteries and rechargeable batteries, regardless
whether they contain harmful substances* or not, to
a collection point run by the communal authority or
borough or to a retailer, so that they can be disposed of
in an environmentally friendly manner.
Bring the DFINE (together with the rechargeable
battery) to your collection point and make sure that it
is in an uncharged state!
* labelled with: Cd = cadmium, Hg = mercury, Pb = lead
EN

19
EN

20
CONTENU
INFORMATIONS GÉNÉRALES
Welcome to the Dockin family!.........................................................................21
Conguration des haut-parleurs ..................................................................22
Connexions...................................................................................................................22
Éléments de commande......................................................................................23
SÉCURITÉ
Lire le mode d’emploi et le conserver....................................................... 24
Explication des symboles et des termes................................................ 24
Utilisation conforme à l’usage prévu..........................................................25
Consignes de sécurité..........................................................................................26
UTILISATION
Contrôler la livraison ............................................................................................ 30
Mettre en marche le DFINE........................................................................... 30
Pairing...............................................................................................................................31
Changer d’appareil source/déconnexion.................................................31
Arrêter le DFINE......................................................................................................32
Mode AUX .....................................................................................................................32
Charger DFINE.........................................................................................................32
Fonction économie d’énergie...........................................................................32
Fonction power bank............................................................................................ 33
Port de service micro-USB ............................................................................. 33
Entretien et rangement..................................................................................... 33
Dépannage................................................................................................................... 34
Spécications techniques................................................................................. 34
Déclaration de conformité................................................................................ 35
Informations fabricant et service................................................................ 36
Élimination.....................................................................................................................37
FR
