DOGA XS-38D User manual

Instructions manual / XS-38D
1
XS-38D
SERVICE MANUAL

Instructions manual / XS-38D
2
I
IM MP PO OR RT TA AN NT T
The tool delivered with this manual may have been modified for specific needs.
In that case, please give us the tool code number written on our shipping note or the approximate tool delivery date when
you place an order for a new similar tool or for spare parts.
In that way, you will be sure to get the required tool and/or spare part.
W
WA AR RN NI IN NG G
This information has to be kept in a location known by all users.
Each operator has to read carefully this manual before installing, using, and
mending the product.
Be sure that the operator has understood using recommendations and the meaning of signs put on the product.
Most accidents could be avoided respecting this Manual Instructions. As a matter of fact, they were created according to
European laws and norms regarding products.
In each case, please respect and follow safety national norms. Do not take off nor damage the stickers or advise put on the
product and above all the details imposed by the law.

Instructions manual / XS-38D
3
INDEX
1. General safety rules………………………………………………………………………………………. p.4
1.1 Work Area…………………………………………………………………………………………………p.4
1.2 Electrical safety…………………………………………………………………………………………...p.4
1.3 Personal safety…………………………………………………………………………………………...p.4
1.4 Tool use and care………………………………………………………………………………………...p.5
1.5 Service……………………………………………………………………………………………………..p.5
2. Specific safety rules………………………………………………………………………………………. p.5
3. Electrical specification……………………………………………………………………………………..p.6
4. Mechanical specification…………………………………………………………………………………..p.6
5. Selectable INPUT VOLTAGE…………………………………………………………………………….p.6
6. Pin configuration of output……………………………………………………………………………….. p.6
7. Selectable OUTPUT……………………………………………………………………………………….p.7
8. Soft start and Double hit…………………………………………………………………………………..p.7
9. Over Current Protection (Overload), over heat protection and reset…………………………………p.8
10. Connections……………………………………………………………………………………………….p.9
11. Interface with XS-38D controller………………………………………………………………………..p.10
11.1 Connector and cables…………………………………………………………………………………..p.10
11.2 Input/Output signals interface………………………………………………………………………….p.10
11.3 Timing chart of start / Stop signal……………………………………………………………………..p.10
11.4 Interface converter (Option)……………………………………………………………………………p.11

Instructions manual / XS-38D
4
1. General safety rules
WARNING ! Read and understand all instructions. Failure to follow all instructions listed below, may
result in electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
1.1 Work Area
- Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
- Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the dust or fumes.
- Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose
control.
1.2 Electrical Safety
- Grounded tools must be plugged into an outlet properly installed and grounded in accordance with all codes and
ordinances. Never remove the grounding prong or modify the plug in any way. Do not use any plugs. Check with a
qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the tools should electrically
malfunction or break down, grounding provides a low resistance path to carry electricity away from the user.
- Avoid body contact with grounded surface ad pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is grounded.
- Don't expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
- Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from
heat, oil, sharp edges or moving parts. Replace damaged cords immediately. Damaged cords increase the risk of
electric shock.
- When operating a power tool outside, use an outdoor extension cord marked W-A or W. These cords are rated for
outdoor use and reduce the risk of electric shock.
1.3 Personal Safety
- Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use tool while
tired or under the influence of drugs, alcohol, or medication. A moment of inflation while operating power tools may
result in serious personal injury.
- Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
- Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your finger on the switch or
plugging in tools may result in personal injury.
- Remove adjusting keys or switches before turning the tool on. A wrench or a key that is left attached to a rotating part
of the tool may result in personal injury.
- Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of
the tool in unexpected situations.
- Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes, hard hat, or hearing protection
must be used for appropriate conditions.

Instructions manual / XS-38D
5
1.4 Tool use and Care
- Use clamps or other practical way to secure and support the workplace to a stable platform. Holding the work by
hand or against your body is unstable and may lead to loss of control.
- Do not force tool. Use the correct tool for your application. The correct tool will do the job better and safer at the rate
for which it is designed.
- Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled with the switch is dangerous and
must be repaired.
- Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the
tool. Such preventive safety.
- Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the hands of untrained
users.
- Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools, with sharp cutting edges are
less likely to bind and are easier to control.
- Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the
tools operation. If damaged, have the tool serviced before using. Many accidents are caused by poorly maintained
tools.
- Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable
for one tool, may become hazardous when used on another tool.
1.5 Service
- Tool service must be performed only by qualified personnel. Service or maintenance performed by unqualified
personnel could result in a risk of injury.
- When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section of this
manual. Use of unauthorized parts or failure to follow. Maintenance instructions may create a risk of electric shock or injury.
2. Specific safety rules
2.1 Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden
wiring or its own cord. Contact with a "live" wire will make exposed metal parts of the tool "live" and shock the operator.
2.2 Never lubricate aerosol oil on to the electrical part.

Instructions manual / XS-38D
6
3. Electric specification
Model XS-38D Ver. 4.0
Input 110 / 230 VAC (selectable)
Output 20/30, 30/38 VDC (selectable)
Rated power 2.5 A 95W
Maximum output current 6 A
Intermittent operation 10s On / 30s Off
Safety system CE certified (Class I)
4. Mechanical specification
Size : 98 x 158 x 55H (mm)
Weight : 850 gr
Power cord : 1.5 m
Fuse : 6.3 A 250 V
5. Selectable INPUT VOLTAGE
6. Pin configuration of output

Instructions manual / XS-38D
7
7. Selectable OUTPUT
8. Soft start and Double hit
Push
sT Button Function LED light
0 Standard Green
1st Soft Start during 0.2 sec. Yellow Blink once
2nd Soft Start during 0.3 sec. Yellow Blink twice
3rd Soft Start during 0.5 sec. Yellow Blink three times
4th Soft Start during 0.6 sec. Yellow Blink once four times
5th Soft Start during 0.8 sec. Yellow Blink once 5 times
6th Soft Start during 1.0 sec. Yellow Blink once four times
7th Double hit Red

Instructions manual / XS-38D
8
9. Over Current Protection (Overload), Over heat protection and reset
Description
Primary OCP Secondary OCP
Limit current
12-13A Condition ‘’A’’ Condition ‘’B’’
Detection
Time duration
Immediately 3 sec 0,5 sec
Protection
Whole power shut
down permanently
Output power disappear for 5 sec.
LED
No
Protection
Signal
Buzzer
No
Normal frequent
Beep ON / OFF
Higher frequent
Beep ON / OFF
Recovery
Turn off the power
switch and on after
1 min.
Auto recovery after 5 sec

Instructions manual / XS-38D
9
10. Connections

Instructions manual / XS-38D
10
11. Interface with XS-38D controller
11.1 Connector and cables
11.2 Input/Output signals interface
11.3 Timing chart of Start / Stop signal

Instructions manual / XS-38D
11
11.4 Interface converter (Option)
Interface converter converts the electronic signal by opto coupler to opposite direction as below.
Also it provides additional dry contact signals in both Normal Closed and Normal Open by the built-in relay.

06.17.60155.11/12
