Dometic PERFECTROOF User manual

PR2000, PR2500
Awning
Installation Manual. . . . . . . . . . . . . . . . . . . . 10
Markise
Montageanleitung. . . . . . . . . . . . . . . . . . . .22
Store extérieur
Instructions de montage . . . . . . . . . . . . . . .34
Told o
Instrucciones de montaje . . . . . . . . . . . . . .46
Told o
Instruções de montagem . . . . . . . . . . . . . .58
Tend a da sole
Indicazioni di montaggio . . . . . . . . . . . . . .70
Zonnescherm
Montagehandleiding . . . . . . . . . . . . . . . . .82
Markise
Monteringsvejledning. . . . . . . . . . . . . . . . .94
Markis
Monteringsanvisning. . . . . . . . . . . . . . . . .106
Markise
Monteringsanvisning. . . . . . . . . . . . . . . . . 117
Markiisi
Asennusohje . . . . . . . . . . . . . . . . . . . . . . .128
Маркиза
Инструкция по монтажу. . . . . . . . . . . . . . 139
Markiza
Instrukcja montażu . . . . . . . . . . . . . . . . . . 151
Markíza
Návod na montáž . . . . . . . . . . . . . . . . . . . 163
Markýza
Návod k montáži . . . . . . . . . . . . . . . . . . . . 175
Előtető
Szerelési útmutató . . . . . . . . . . . . . . . . . . 187
Markiza
Navodilo za montažo . . . . . . . . . . . . . . . . 199
Τέντα
Οδηγίες τοποθέτησης . . . . . . . . . . . . . . . 210
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SL
EL
AWNINGS
PERFECTROOF
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 1 Mittwoch, 24. Februar 2021 9:55 09

© 2021 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 2 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
3
2 3 4
5 6 7 8
9
12
13
1110
14
PR
2500
15
1
1
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 3 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
4
2
15 – 25 Nm
3

4
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 4 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
5
1.
2.
Ø 3 mm
5
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 5 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
6
AB
A
PR
2000
PR
2500
B
6
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 6 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
7
1.
2.
7
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 7 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
8
4.
1.
2.
3.
8
on
rd
bk
rd
bk
bu
T15A
bn
T3A
D+
bu
bn
bu
bn
2
43
5
6
7
8
810 11
1
9
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 8 Mittwoch, 24. Februar 2021 9:55 09

PR2000, PR2500
9
1
1
2
0
1
2
3
a
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 9 Mittwoch, 24. Februar 2021 9:55 09

EN
Explanation of symbols PR2000, PR2500
10
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit docu-
ments.dometic.com, dometic.com.
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6 Installing the awning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
7 Connecting the awning (PR2500 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
8 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
1 Explanation of symbols
!
A
I
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 10 Mittwoch, 24. Februar 2021 9:55 09

EN
PR2000, PR2500 Safety instructions
11
2 Safety instructions
Pleaseobserve the prescribed safety instructionsand stipulations from the
vehicle manufacturer and service workshops.
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Ensure that the awning has been installed by a qualified technician in
accordance with the Dometic installation manual.
•Only motor version: If connection cable of the awning is damaged,
it must be replaced by the manufacturer, service agent or a similarly
qualified person in order to prevent safety hazards.
Health hazard
• Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles.
• If the installation position is not predefined by the mounting rail,
ensure the roof of the motorhome can safely take the weight of the
awning before installation. Otherwise, the awning may become
unstable and bend or break.
ANOTICE!
• If the vehicle-specific installation manual specifies through bolting,
ensure the inner screw joints are accessible.
• If there is insufficient space above the door after the awning is
mounted, the door must remained closed when retracting or
extending to avoid the door making contact with the arms or the front
panel.
The required space depends on the design of the door (door width,
swing or sliding door) as well as the set awning angle of inclination
(fig. 2, page 4).
• The cables and cabinets in the interior of the vehicle may not be
damaged by drilling the holes.
INOTE
• Ensure the user of the vehicle is aware that the screws on the rear hinge
(fig. 3, page 4) must be tightened up (see operating manual). The
arms must not bear any load. This must be done by a service agent.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 11 Mittwoch, 24. Februar 2021 9:55 09

EN
Scope of delivery PR2000, PR2500
12
3Scopeofdelivery
3.1 PR2000
3.2 PR2500
No. in
fig. 1,
page 3
Awning width
Description
2.6 m, 3 m,
3.25 m, 3.5 m,
3.75 m
4m
1 1x 1x Awning
2 6x 6x Self-tapping screw
3 2x 2x Mounting bracket (lower section)
4 2x 2x Mounting bracket (upper section)
5 1x 1x Crank bracket (lower section)
6 — — Crank bracket (upper section)
74x4xRivets
84x4xPegs
9 1x 1x Crank
10 — 1x Latch for tension rafter
11 — 1x Hexagon head bolt
12 — 1x Tension rafter
13 — 1x Hexagon nut
No. in
fig. 1,
page 3
Awning width
Description
2.6 m, 3 m,
3.5 m, 3.75 m
4 m, 4.5 m,
5 m, 5.5 m,
6m
11x 1xAwning
2 8x 8x Self-tapping screw
3 2x 2x Mounting bracket (lower section)
4 2x 2x Mounting bracket (upper section)
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 12 Mittwoch, 24. Februar 2021 9:55 09

EN
PR2000, PR2500 Accessories
13
4Accessories
Available as accessories (not included in the scope of delivery):
5 1x 1x Crank bracket (lower section)
6 1x 1x Crank bracket (upper section)
74x 4xRivets
84x 4xPegs
9 1x 1x Crank
10 – 1x Latch for tension rafter
11 – 1x Hexagon head bolt
12 – 1x Tension rafter
13 – 1x Hexagon nut
14 1x 1x Remote control with connection material
(optional)
15 1x 1x Switch (optional)
Description
TieDown Kit
Straps for anchoring the awning
CampRoom
Awning tent front wall and sides for various models with support legs in different sizes
RainProtect
Front wall and sides available in different sizes
SunProtect
Front wall and sides available in different sizes
Dometic Light LK120
LED light kit with remote control for installation on the awning arms
No. in
fig. 1,
page 3
Awning width
Description
2.6 m, 3 m,
3.5 m, 3.75 m
4 m, 4.5 m,
5 m, 5.5 m,
6m
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 13 Mittwoch, 24. Februar 2021 9:55 09

EN
Accessories PR2000, PR2500
14
!
Dometic awnings PR2000 and PR2500 are installed using a vehicle-specific,
universal mounting rail that is not included in the scope of delivery.
Mounting rail including fastening material for Fiat Ducato, Citroën Jumper,
Peugeot Boxer (average height, built from 2006)
A list of all available mounting rails can be found on the accessories sheet. Ask your
local service agent for an up-to-date, comprehensive overview of available adapters
or visit dometic.com.
If you have questions regarding the accessories, please contact your local service
agent.
LED LightStrip
LED strip available in different lengths for installation on the underside of the awning
Awning cleaner
Special awning cleaner
Repair Kit
Awning repair patch
WARNING!
Only use mounting rails recommended by Dometic fitting both to your
vehicle and to your awning. Using the wrong mounting rails leads to
danger while operating the awning. If you need support in choosing the
correct mounting rails fitting to you vehicle, please ask your local service
agent or visit dometic.com.
Vehicle length Awning width
5.41 m 3.1 m
5.99 m 3.5 m
6.36 m 4.0 m
Description
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 14 Mittwoch, 24. Februar 2021 9:55 09

EN
PR2000, PR2500 Intended use
15
5 Intended use
The PerfectRoof PR2000 and PR2500 awnings are suitable for installation on
motorhomes or caravans.
The awnings may be only be used while the vehicle is stationary. Please observe the
operating manual.
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
6 Installing the awning
6.1 Required installation material
For the installation of the rain gutter, you will need:
• Mounting rail (not in the scope of delivery, must be ordered suitable to the
vehicle)
• Various tools, e.g. screwdriver
• A suitable flexible adhesive/sealant, e.g. Sikaflex®-252
• A cleaning agent that is recommended for use with the adhesive
• A primer that is recommended for use with the adhesive
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 15 Mittwoch, 24. Februar 2021 9:55 09

EN
Installing the awning PR2000, PR2500
16
6.2 Installing the awning
During installation, observe the following general information:
• The mounting rails are bolted to the vehicles in the area of the rear hinge. In
addition, they are glued with installation adhesive (e.g. Sikaflex®-252 or a similar
product) to ensure the load is evenly spread and an optimal level of protection
from moisture is maintained.
• Observe the sealant manufacturer's instructions.
• An illustrated instruction manual that covers each type of installation is enclosed
with every vehicle-specific installation kit. As with the installation instruction
manual, this manual must be observed closely and complied with.
• Before installation, check the access to the screw joints. Make sure no cables or
cabinets are damaged when drilling.
• Contact your local service agent if you wish to have an angle of inclination
different to the default setting.
• If you wish to use an awning tent with the awning at a later date, when choosing
the awning size and installation position ensure that vent windows and hatches
remain accessible with erected tent (fig. 4, page 4).
• Clean the adhesive surfaces on the mounting rail and the wall.
• Prepare the adhesive surfaces with the primer.
• After gluing, wait until the adhesive has set. For further details, please refer to the
information provided by the sealant manufacturer.
• Seal the bore holes carefully to ensure no moisture can enter.
• Do not open the awning or leave it unattended, before the awning has been
fastened to the mounting rail.
• As part of the regular maintenance procedure, the screws on the rear hinge must
be tightened up by a service agent. Ensure the users of the vehicle are aware of
this.
➤Install the awning using the instructions in the operating manual enclosed with
your mounting rail.
Installing the mounting bracket
The mounting bracket must be installed if the awning is to be attached to the side of
the vehicle when extended.
1. Select the location of the installation.
2. Mark where the holes are to be drilled.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 16 Mittwoch, 24. Februar 2021 9:55 09

EN
PR2000, PR2500 Installing the awning
17
3. At the marked points, drill holes with a diameter of 3 mm from the outside into
the external wall (fig. 5, page 5).
4. Put the upper and lower sections of the mounting bracket together.
5. Clean the outer sides of the lower section and the installation surface in the
vehicle.
I
6. To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example,
to the back of the mounting bracket.
7. Fasten the mounting bracket with drill screws or rivet the mounting bracket in
place (fig. 5, page 5).
Installing the crank bracket
➤Install the mounting bracket for the crank at a suitable location inside the vehicle
(fig. 6, page 6).
Adjusting the awning arm‘s inclination angle (PR2000 only)
A
➤Proceed as shown (fig. 7, page 7).
NOTE
Make sure that no glue gets on to the movable upper section of the
mounting bracket.
NOTICE!
Changing the inclination angle effects the closing of the awning. Make
sure the awning is still working properly. If necessary, readjust the
inclination angle.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 17 Mittwoch, 24. Februar 2021 9:55 09

EN
Connecting the awning (PR2500 only) PR2000, PR2500
18
7 Connecting the awning (PR2500 only)
!
A
There are two options for the electrical connection of the awning:
• Awning switch with an integrated main switch
• Main switch and receiver for the remote control
Observe the following installation instructions:
• Fit the supplied main switch and fuse (15 A) to the positive line of the power sup-
ply. The main switch is required to switch off the awning when side walls are fitted
to the awning, for example, or if the vehicle is taken out of service for an extended
period of time (otherwise the standby consumption may drain the battery).
• Install the receiver on the inside of the vehicle to protect it from moisture.
• Observe the length of the cable between the awning motor and receiver when
choosing a place to install it.
•Donot shorten the antenna cable.
• When installing the supplied plug, use a suitable tool (crimping tool) to ensure
that the connection is secure and durable.
• If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is cor-
rect.
WARNING!
• Disconnect the power supply before starting the assembly.
• Only permit a qualified electrician to connect the awning to the
electrical power.
•Connecttheignition(D+ signal) to the orange line of the receiver.
This is the only way to ensure that the awning cannot be opened
while driving.
• Only use the original remote control supplied and optional original
wall switch.The use of original parts is the only way to ensure that
with connected D+ signal the power supply is disconnected and the
awning cannot be opened while driving.
NOTICE!
The cables and cabinets in the interior of the vehicle must not be
damaged through drilling the holes.
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 18 Mittwoch, 24. Februar 2021 9:55 09

EN
PR2000, PR2500 Connecting the awning (PR2500 only)
19
• Observe the required cable cross section when connecting to thepower supply:
Legend for fig. 9, page 8:
Installing the wall switch
➤Find a suitable location inside the motor home, out of direct sunlight, to install the
switch.
Installing the receiver of the remote control and connecting the electrical
connections
1. Find a suitable location inside the motor home, out of direct sunlight, to install
the mounting bracket for the remote control.
2. Connect the motor with the remote control in accordance with the applicable
electrical engineering regulations and the circuit diagram (fig. 9, page 8).
Cable length Required cable cross section
2 m 1.5 mm²
4 m 2.5 mm²
6 m 4.0 mm²
8 m 6.0 mm²
No. Description
1 Receiver
2 3 A fuse for LED awning light (optional)
3 on Orange line for D+ connection
4 rd Red line for LED awning light (optional)
5 bk Black line for LED awning light (optional)
6 bu Blue line for motor connection
7 bn Brown line for motor connection
8 bk Black line for power supply
9 rd Red line for power supply
10 Main switch
11 15 A fuse for main switch
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 19 Mittwoch, 24. Februar 2021 9:55 09

EN
Warranty PR2000, PR2500
20
Programming the remote control and the wall switch
1. Place the battery (see fig. 01, page 9).
2. Switch on the power supply.
✔The receiver beeps once briefly.
3. Press the programming button (fig. 02, page 9) or the buttons and on
the wall switch simultaneously (fig. a1 and 2, page 9) within 4 seconds.
✔The receiver beeps once briefly.
4. Press the programming button (fig. 02, page 9) or the buttons and on
the wall switch simultaneously (fig. a1 and 2, page 9) again briefly.
✔The receiver beeps once briefly.
5. Briefly press the button (fig. a3, page 9).
✔The receiver beeps four times briefly.
✔The awning moves briefly.
Proceed as follows to pair the wall switch:
1. Press the programming button (fig. 02, page 9) twice.
✔The receiver beeps twice briefly.
2. Press the buttons and on the wall switch simultaneously (fig. a1 and 2,
page 9).
✔The receiver beeps five times briefly.
✔The remote control or wall switch and awning are now set to one another.
8Warranty
The statutory warranty period applies. If the product is defective, please contact your
retailer or the manufacturer's branch in your country (see dometic.com/dealer).
For repair and warranty processing, please include the following documents when
you send in the product:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
DometicPR2000-PR2500_INM_4445101844_EMEA18_20xx-xx-xx.book Seite 20 Mittwoch, 24. Februar 2021 9:55 09
