Dometic COOLAIR SP950T User manual

AIR CONDITIONERS
COOLAIR
SP950T
Assembly kit for Renault Trucks Sleeper
and High Sleeper driver cab
Installation Manual . . . . . . . . . . . . . . . . . . 11
Montagesatz für Renault Trucks Sleeper
und High Sleeper Fahrerhaus
Montageanleitung . . . . . . . . . . . . . . . . . 29
Kit de montage pour Renault Trucks
cabine Sleeper et High Sleeper
Instructions de montage. . . . . . . . . . . . . 47
Juego de montaje para Renault Trucks
con cabina Sleeper y High Sleeper
Instrucciones de montaje . . . . . . . . . . . . 65
Kit de montagem para Renault Trucks
cabina Sleeper e High Sleeper
Instruções de montagem . . . . . . . . . . . . 83
Set di montaggio per cabina di guida
Renault Trucks Sleeper e High Sleeper
Indicazioni di montaggio . . . . . . . . . . . .101
Montageset voor Renault Trucks Sleeper
en High Sleeper bestuurderscabine
Montagehandleiding . . . . . . . . . . . . . . .119
Monteringssæt til Renault-lastbiler med
Sleeper og High Sleeper-førerhus
Monteringsvejledning . . . . . . . . . . . . . 137
Monteringssats för Renault Trucks
Sleeper- och High Sleeper-hytt
Monteringsanvisning . . . . . . . . . . . . . . . 154
Monteringssett for Renault Trucks
Sleeper og High Sleeper førerhus
Monteringsanvisning . . . . . . . . . . . . . . . 171
Asennussarja Renault-kuorma-autot
Sleeper ja High Sleeper -ohjaamolla
Asennusohje . . . . . . . . . . . . . . . . . . . . . . 188
Монтажный комплект для Renault
Trucks с кабиной Sleeper и High Sleeper
Инструкция по монтажу . . . . . . . . . . . 205
Zestaw montażowy do Samochody
ciężarowe Renault z kabiną kierowcy
Sleeper i High Sleeper
Instrukcja montażu . . . . . . . . . . . . . . . . 223
Montážna súprava pre Renault Trucks
Sleeper a High Sleeper kabína vodiča
Návod na montáž . . . . . . . . . . . . . . . . . . 241
Montážní sada pro vozidla tahač Renault
s kabinou typu Sleeper a High Sleeper
Návod k montáži. . . . . . . . . . . . . . . . . . 258
Szerelőkészletakövetkezőkhöz:Renault
Trucks Sleeper és High Sleeper
vezetőfülke
Szerelési útmutató . . . . . . . . . . . . . . . . .275
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SP950T-Renault-H2--I-16s.book Seite 1 Dienstag, 5. September 2017 5:03 17

SP950T-Renault-H2--I-16s.book Seite 2 Dienstag, 5. September 2017 5:03 17

3
CoolAir SP950T
75
291286
1
779
2
3
2
1
3
SP950T-Renault-H2--I-16s.book Seite 3 Dienstag, 5. September 2017 5:03 17

CoolAir SP950T
4
4
9
1
2
3
4
5
SP950T-Renault-H2--I-16s.book Seite 4 Dienstag, 5. September 2017 5:03 17

5
CoolAir SP950T
≤4,2 m
6
1
2
3
4
7
SP950T-Renault-H2--I-16s.book Seite 5 Dienstag, 5. September 2017 5:03 17

CoolAir SP950T
6
1
2
3
4
8
SP950T-Renault-H2--I-16s.book Seite 6 Dienstag, 5. September 2017 5:03 17

7
CoolAir SP950T
8
1
2
3
4
5
9
7
6
9
SP950T-Renault-H2--I-16s.book Seite 7 Dienstag, 5. September 2017 5:03 17

CoolAir SP950T
8
134567
89
2
0
SP950T-Renault-H2--I-16s.book Seite 8 Dienstag, 5. September 2017 5:03 17

9
CoolAir SP950T
+ 24 V –/ 0 V
ro sw
sw
sw br
gr
w
br
gr
gl
gr br w gr/gl wbr wbr grbr
M
M
1
2
3
4
5
6
7
89
10 11
gr/gl
12
w
gr
sw
br
wbrgr gl
br gr/gl gr
a
SP950T-Renault-H2--I-16s.book Seite 9 Dienstag, 5. September 2017 5:03 17

CoolAir SP950T
10
bl br gl gr ro sw w
DE Blau Braun Gelb Grün Rot Schwarz Weiß
EN Blue Brown Yellow Green Red Black White
FR Bleu Marron Jaune Vert Rouge Noir Blanc
ES Azul Marrón Amarillo Verde Rojo Negro Blanco
IT Blu Marrone Giallo Verde Rosso Nero Bianco
NL Blauw Bruin Geel Groen Rood Zwart Wit
DA Blå Brun Gul Grøn Rød Sort Hvid
SV Blå Brun Gul Grön Röd Svart Vit
NO Blå Brun Gul Grønn Rød Svart Hvit
FI Sininen Ruskea Keltainen Vihreä Punainen Musta Valkoinen
PT Azul Castanho Amarelo Verde Cinzento Vermelho Preto
RU Синий Коричневый Желтый Зеленый Красный Черный Белый
PL Niebieski Brązowy Żółty Zielony Czerwony Czarny Biały
CS Modrá Hněda Žlutá Zelená Červená Černá Bílá
SK Modrá Hnedá Žltá Zelená Červená Čierna Biela
HU Kék Barna Sárga Zöld Piros Fekete Fehér
SP950T-Renault-H2--I-16s.book Seite 10 Dienstag, 5. September 2017 5:03 17

11
EN
CoolAir SP950T
Contents
1 Symbols and formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 Using the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Handling electrical cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Conventions in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 General information on the installation manual. . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Target group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.1 Notes on installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.2 Removing the sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.3 Preparing the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.4 Attaching the seal for the cab roof. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.5 Installing the unit in the sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.6 Installing the electrical supply lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.7 Installing supply lines to the condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.8 Preparing the cover frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.9 Fastening the cover frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Configuration of unit software . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8.1 Starting and ending configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8.2 Menu level 1: Set temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8.3 Menu level 2: Low voltage cut-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8.4 Menu level 3: Operating mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.5 Menu level 4: Default setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.6 Menu level 5: Temperature unit display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
SP950T-Renault-H2--I-16s.book Seite 11 Dienstag, 5. September 2017 5:03 17

EN
Symbols and formats CoolAir SP950T
12
1 Symbols and formats
!
!
A
I
2 Safety instructions
You must read the entire manual thoroughly and carefully.
We can only guarantee the reliability of the air conditioning roof unit if the
instructions are adhered to. The same applies to the prevention of injury and
damage to property.
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess
voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair the
function of the product.
NOTE
Supplementary information for operating the product.
SP950T-Renault-H2--I-16s.book Seite 12 Dienstag, 5. September 2017 5:03 17

13
EN
CoolAir SP950T Safety instructions
2.1 Using the device
•The freedom of movement of semi-trailers (of the outer edges of the semi-
trailer when turning or jackknifing) and other vehicle attachments must not be
restricted.
•Only use the air conditioning roof unit for the purpose specified by the
manufacturer and do not make any alterations or structural changes to the
device.
•Do not use the air conditioning roof unit if it is visibly damaged.
•The air conditioning roof unit must be installed safely so that it cannot tip over
or fall down.
•Installation, maintenance and repair work may only be carried out by
qualified personnel from a specialist company who are familiar with the
risks involved and the relevant regulations.
•Do not use the air conditioning roof unit near flammable fluids and gases.
•Do not operate the air conditioning roof unit if the ambient temperature is
below 0 °C.
•Do not undo the upper cover of the air conditioning roof unit in the event of
a fire. Use approved extinguishing agents instead. Do not use water to
extinguish fires.
•Please inquire from your vehicle manufacturer whether the height entered in
your vehicle documentation needs to be altered due to the installation of the
air conditioning roof unit (height: 75 mm).
•Disconnect all power supply lines when working on the air conditioning roof
unit (cleaning, maintenance, etc).
2.2 Handling electrical cables
•Use cable ducts to lay cables through walls with sharp edges.
•Do not lay loose or bent cables next to electrically conductive materials
(metal).
•Do not pull on the cables.
•Attach and lay the cables in such a manner that they cannot be tripped over
or damaged.
•The electrical power supply may only be connected by a specialist work-
shop.
•Fit a fuse of 25 A to the connection to the vehicle's power supply.
•Never lay power supply lines (battery leads) in the vicinity of signal or control
cables.
SP950T-Renault-H2--I-16s.book Seite 13 Dienstag, 5. September 2017 5:03 17

EN
Conventions in this manual CoolAir SP950T
14
3 Conventions in this manual
3.1 General information on the installation manual
This installation manual contains the essential information and instructions for
installing the air conditioning roof unit. The information contained is orientated
towards the company installing the air conditioning roof unit.
The following instructions are intended to help you properly use the installation
manual:
•The installation manual is part of the scope of delivery and should be stored
carefully.
•The installation manual provides you with important information on the
installation of the device and can also be used as a reference material in the
event of repairs.
•The manufacturer assumes no liability for non-observance of this installation
manual. Any claims are excluded in this case.
3.2 Target group
The installation and configuration information in this manual is intended for
qualified installation personnel who are familiar with the guidelines and safety
precautions to be applied during the installation of lorry accessory parts.
SP950T-Renault-H2--I-16s.book Seite 14 Dienstag, 5. September 2017 5:03 17

15
EN
CoolAir SP950T Intended use
4 Intended use
The installation kit (ref. no. 9100300067) enables the installation of a CoolAir
SP950T roof evaporator unit (ref. no. 9105305549) in a roof opening
(ventilation hatch) provided at the plant in a Renault Trucks with a Sleeper or
High Sleeper driver cab.
The CoolAir SP950T roof evaporator unit can only be operated in combination
with a CoolAir SP950C condenser unit. Both components together form the
CoolAir SP950 parking cooler.
A
I
NOTICE!
•The SP950 unit is not suitable for installation in construction machines,
agricultural machines or similar equipment. It will not work properly if
exposed to strong vibrations.
•Operating the SP950 unit with voltages other than those specified can
result in damage to the device.
NOTE
The SP950 unit is only designed for ambient temperatures of up to 43 °C.
SP950T-Renault-H2--I-16s.book Seite 15 Dienstag, 5. September 2017 5:03 17

EN
Scope of delivery CoolAir SP950T
16
5 Scope of delivery
CoolAir SP950T installation kit for
Renault Trucks Sleeper and High Sleeper driver cab,
ref. no. 9100300067
6 Accessories
Available as accessories (not included in the scope of delivery):
Part designation Quantity Ref. no.
Installation manual 1 4445102180
2.5 m insulating tape (profile: 10 x 20 mm) 1 4443300055
Spacer sleeve L = 18 mm, ∅14 mm 8 4443900236
Hex screw M8 x 45 8 4445200107
Spring washer M8 8 4445200091
Washer 8,5 x 20 x 1,25 8 4445200113
Washer M8 8 4445200117
Connection cable 6 mm² x 4 m 1 4441300149
Cable binder 1 4445900256
Adapter for cover frame 2 4442500796
Rounded head screw M8 x 16 6 4445200048
Cap for cover frame 1 4443000357
Allen screw with cylindrical head M4 x 12 4 4445200119
Washer M4 4 4445200120
Nut M4 4 4445200055
Cover frame 1 4443000356
Washer M6 4 4445200115
Allen screw with cylindrical head M6 x 110 4 4445200123
Spacer sleeve L = 48 mm, ∅10 mm 4 4443900241
Part designation Ref. no.
Connection cable 8 mm² x 11 m 9100300027
SP950T-Renault-H2--I-16s.book Seite 16 Dienstag, 5. September 2017 5:03 17

17
EN
CoolAir SP950T Installation
7 Installation
A
7.1 Notes on installation
These installation instructions must be read completely prior to the installation of
the air conditioning roof unit.
The following tips and instructions must be observed wile installing the air
conditioning roof unit:
!
•Always check whether any vehicle components could be damaged or their
operation impaired by the unit before installing the air conditioning roof unit.
You can use fig. 1, page 3 and fig. 2, page 3 to check the dimensions of
the installed unit. The dotted line indicates the middle of the sunroof open-
ing.
•Before installation, find out (by consulting the manufacturer of the vehicle)
whether the construction is designed for the static weight and the loads of
the parking cooler when the vehicle is in motion. The manufacturer of the air
conditioning roof unit assumes no liability whatsoever.
•The roof inclination of the mounting surface may not exceed 8° in the
direction of travel.
•The supplied assembly parts must not be modified during installation.
•The ventilation slots (grill) may not be covered (minimum distance from other
attachment parts: 10 cm).
•You can connect the unit to the battery via the lorry's terminal block or
directly. The terminal block is to be preferred for the connection. On some
vehicles, larger consumers connected to the terminal block are switched off
after a short while if the power requirement is too high. Ask your vehicle man-
ufacturer for the specifications of the terminal block.
NOTICE!
•The air conditioning roof unit may only be installed by qualified personnel
from a specialist company. The following information is intended for
technicians who are familiar with the guidelines and safety precautions to
be applied.
•The manufacturer only assumes liability for parts included in the scope of
delivery. The validity of the warranty expires if the device is installed
together with third-party parts.
•Check whether the roof of the vehicle is able to support the weight of a
person before climbing onto it. Ask the vehicle manufacturer about the
permitted roof loads.
WARNING!
Make sure that all electrical components are electrically discharged before
carrying out work on them!
SP950T-Renault-H2--I-16s.book Seite 17 Dienstag, 5. September 2017 5:03 17

EN
Installation CoolAir SP950T
18
•When installing the system and making the electrical connections, observe
the guidelines from the body manufacturer.
•Pay attention to the connection plan for the device:
!
!
I
No. in
fig. a, page 9 Designation
1Condensatepump
2Evaporatorfan
3 Operating circuit board
4 Temperature sensor
5 Level sensor
6Controlunit
725Afuse
8 4 A fuse vaporiser fan
9 4 A fuse condenser fan
10 Condenser fan
11 Compressor
12 Klickson (compressor)
WARNING!
Before installing the air conditioning roof unit, all connections to the battery of
the vehicle must be disconnected.
Non-observance of this regulation can result in danger of electrocution.
CAUTION!
Improper installation of the air conditioning roof unit can result in irreparable
damage to the device and put the safety of the user at risk.
The manufacturer will not be held liable for claims if the air conditioning roof
unit is not installed according to this installation manual. That applies to mal-
functions and the safety of the air conditioning roof unit, in particular to injuries
and damage to property.
NOTE
After installing the unit, the specified parameters of the unit software must be
checked (chapter “Configuration of unit software” on page 23).
SP950T-Renault-H2--I-16s.book Seite 18 Dienstag, 5. September 2017 5:03 17

19
EN
CoolAir SP950T Installation
7.2 Removing the sunroof
➤Remove all screws and fixtures of the existing sunroof.
➤Take out the sunroof.
➤Remove the sealant around the opening, so that the surface is clean and free
of grease.
I
7.3 Preparing the unit
A
➤Place the air conditioning roof unit on a work surface with the housing facing
down.
➤Fix the two sheet metals (fig. 32, page 3) with 3 rounded head screws
M8x16mm(fig.31, page 3) each in the thread inserts (fig. 33, page 3).
A
➤Tighten the screws with a torque of 10 Nm.
7.4 Attaching the seal for the cab roof
A
➤Stick the 2.5 m insulating tape (10 x 20 mm) to the cab roof, following the
outline of the sunroof opening (fig. 4, page 4).
➤Provide the abutting edge and the top edge of the insulating tape with an
unhardened plastic butyl sealing compound (e.g. SikaLastomer-710).
NOTE
Dispose of all waste material, glue, silicone and seals separately. Observe the
local disposal guidelines.
NOTICE!
During preparatory work on the surfaces, secure the unit from falling down.
Make sure that the work surface is clean and level to ensure that the unit is not
damaged.
NOTICE!
Do not exceed the specified torque under any circumstances. This is the only
way to ensure that the thread inserts are not torn out.
NOTICE!
Ensure that the adhesive surface for the seal between the unit and the cab roof
is clean (free of dust, oil, etc.).
SP950T-Renault-H2--I-16s.book Seite 19 Dienstag, 5. September 2017 5:03 17

EN
Installation CoolAir SP950T
20
7.5 Installing the unit in the sunroof
➤Set the unit down centrally aligned and in the direction of travel (fig. 1,
page 3) on the sunroof opening.
I
➤Place the spacer sleeve L = 18 mm (fig. 51, page 4) and the washer M8
(fig. 59, page 4) on the fastening drill holes as shown in fig. 5, page 4.
➤Screw one hex screw M8 x 40 (fig. 54, page 4) with a washer (fig. 52,
page 4) and spring washer (fig. 53, page 4) in the 8 thread inserts on the
bottom of the unit.
A
➤Tighten the screws with a torque of 8 Nm.
7.6 Installing the electrical supply lines
!
A
I
NOTE
Make sure the air conditioning roof unit is centred perfectly. The seal must be
applied continuously around the air conditioning roof unit after being placed
on the roof of the vehicle. This is the only way to ensure a tight seal.
NOTICE!
Do not exceed the specified torque under any circumstances. This is the only
way to ensure that the thread inserts are not torn out.
WARNING!
•The electrical power supply may only be performed by qualified personnel
with specialist knowledge.
•Make sure there is no voltage present on electrically operated components
before carrying out work on them!
NOTICE!
•Fit a fuse of 25 A to the connection to the vehicle's power supply.
•The battery must be able to supply the required current and voltage
(chapter “Technical data” on page 28).
NOTE
The unit is equipped as standard with a 4 m long cable with a cross-section of
6mm
2. If longer cable lengths are required, then the cable cross-section must
be increased by an authorised specialist workshop:
In this case cut off the cable as closely as possible to the unit (max. 0.5 m) and
then establish a suitable connection with a larger cable cross-section.
When the cable is extended by 4 m to 6 m in length, the manufacturer
recommends using a cross-section of at least 8 mm2.
SP950T-Renault-H2--I-16s.book Seite 20 Dienstag, 5. September 2017 5:03 17
