Dometic MaCave S17G User manual

Wine cellar
Operating manual . . . . . . . . . . . . . . 35
EN
MaCave
S17G, S24G, S46G,
S118G, ST198D

MaCave
2
S17G S46G S118G
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
S24G ST198D
1
1
3
2
4
5
2
2

MaCave
3
1 2 3 4 5 6 7 8
S17G, S46G, S118G
3
S24G, ST198D
123 4 5
4
5
S17G, S46G
S17G, S46G
7
S17G, S46G
6

MaCave
4
S17G, S46G
9
S17G, S46G
8
S17G, S46G
a
S17G, S46G
0
S118G, ST198D
c
S118G, ST198D
b
S118G, ST198D
e
S118G, ST198D
d

MaCave
5
S24G
g
S24G
f
ih
SG17, SG46
≥575
50
110
460
A
B
715
822-892
820-890
100-
170
j

MaCave
6
S24G
min. 38
545
min. 560
455
450
545
min. 550
441
590
min. 200 cm2
k
l

MaCave
7
S17G
AB
m
S24G
AB
n
S46G
AB
o

MaCave
8
S118G
AB
p
ST198D
q

MaCave
9
1
2
r
1
s
1
t

EN
MaCave
10
Please read this instruction manual carefully before first use, and store
it in a safe place. If you pass on the product to another person, hand
over this instruction manual along with it.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3 Contents of product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4 Optional extras. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7 Setting up and connecting the appliance . . . . . . . . . . . . . . . . . . . . . 43
8 Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10 Maintaining and cleaning the appliance. . . . . . . . . . . . . . . . . . . . . . 55
11 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

EN
Explanation of symbols MaCave
11
1 Explanation of symbols
!
!
A
I
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
Fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
zFaulty assembly or connection
zDamage to the product resulting from mechanical influences and excess
voltage
zAlterations to the product without express permission from the manu-
facturer
zUse for purposes other than those described in the operating manual
WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE
Supplementary information for operating the product.

EN
MaCave Safety instructions
12
2.1 General safety
!WARNING!
zBefore you start up the device for the first time, verify that the
operating voltage matches the line voltage (see type plate).
zDo not operate the device if it is visibly damaged.
zThis device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
Should your device need to be repaired, please contact cus-
tomer services.
zThis device can be used by children aged 8 years or over, as
well as by persons with diminished physical, sensory or mental
capacities or a lack of experience and/or knowledge, providing
they are supervised or have been taught how to use the device
safely and are aware of the resulting risks.
zElectrical devices are not toys.
Always keep the device out of the reach of children.
zChildren must be supervised to ensure that they do not play with
the device.
zKeep the keys out of the reach of children.
zIf this device's power cord is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified
person in order to prevent safety hazards.
zDo not store any explosive substances, such as spray cans with
propellants in the device.
!CAUTION!
zDisconnect the device from the power supply
– before cleaning and maintenance
– if you don‘t use it for a longer period
zThe appliance should be moved and set up by at least two
people. Otherwise this could lead to back or other injuries.
zDo not place the device in direct sunlight or near any heat
producing appliances (heating, stoves).
ANOTICE!
zNever pull the plug out of the electrical outlet by the cord.
zDo not use accessories that have not been recommended by
the manufacturer. This can lead to injury and damage to mate-
rial.

EN
Contents of product MaCave
13
2.2 Operating the device safely
!WARNING!
zNever use the device in rooms where flammable materials are
stored or flammable gases have built up. Sparks from the motor
could ignite them.
!CAUTION!
zDo not use the device with wet hands.
ANOTICE!
zOnly use the device in indoors, never outside.
zNever expose the device to moisture.
zKeep children and pets at a safe distance when operating the
device.
zDo not place any electrical devices inside the refrigerator.
3 Contents of product
zWine cellar
zWater tank (S17G, S24G, S46G, S118G only)
zKey (S17G, S46G, S118G, ST198D only)
zLabel set (S17G, S46G, S118G, ST198D only)
zDoor hinge (left side)
zOperating manual

EN
MaCave Optional extras
14
4 Optional extras
5 Intended use
The device is a wine cellar. It is only intended for storing wine.
6 Technical description
The wine cellar is available in five models:
zS17G:
with capacity for up to 17 Bordeaux standard bottles
zS24G:
with capacity for up to 24 Bordeaux standard bottles
zS46G:
with capacity for up to 46 Bordeaux standard bottles
Description Item number
S17G S24G S46G
Storage base 9103540117 – 9103540118
Presentation shelves
(tilted)
– – 9103540121
Label set 9103540116 – 9103540116
Active carbon filter 9103500156 – 9103500156
Description Item number
S118G ST198D
Storage base 9103540119 9103540120
Presentation shelves
(tilted)
9103540121 –
Label set 9103540116 9103540116
Active carbon filter 9103500156 9103500156
Service tray 9103540068 9103540068

EN
Technical description MaCave
15
zS118G:
with capacity for up to 118 Bordeaux standard bottles
zST198D:
with capacity for up to 198 Bordeaux standard bottles
S17G, S24G, S46G and S118G: Factory fitted with shelves.
S17G, S46G and S118G: You can increase the capacity by using the
optional accessory of reinforced storage shelves.
ST198D: Factory fitted with reinforced storage shelves.
You can find information on storage of bottles in chapter “Storing bottles” on
page 46.
S24G has an adjustable temperature zone.
S17G, S46G, S118G and ST198D have two separate adjustable tempera-
ture zones. The temperature zones are chilled or heated automatically to
reach or maintain the temperature that is set.
The temperature can be set in 1°C or 1°F increments using sensor buttons.
The appliance has:
zSensor buttons: Just touch slightly to select the required function.
zautomatic defrosting
za UV impervious door
zS17G, S46G, S118G and ST198D: an active carbon filter for improving
the inner climate
za fan for maintaining a constant inner climate, such as in a cellar (dynamic
cooling mode)
zS17G, S46G and S118G: a lockable glass door with a reversible door
hinge
S24G: glass door with a reversible door hinge
ST198D: a lockable door with a reversible door hinge
zS17G, S46G and S118G: a replaceable decorative film for the glass door
zdetachable shelves for storing the bottles
za Sabbath mode
zLED interior lighting with two operating modes
za temperature memory function: The set temperature is also saved when
the unit is switched off.

EN
MaCave Technical description
16
za temperature monitor: A warning signal sounds and the temperature dis-
play flashes if the interior temperature noticeably deviates from the one
set.
Overview (S17G, S46G, S118G, ST198D)
Overview (S24G)
No. in
fig. 1,
page 3
Designation
1 Upper temperature zone
2 Control panel
3 Cooling area divider
4 Lower temperature zone
5Lock
6 Ventilation slots
7 Adjustable feet
No. in
fig. 2,
page 3
Designation
1 Control panel
2 Cooling area
3ST198D: Lock
4ST198D: Ventilation slots
5ST198D: Adjustable feet

EN
Technical description MaCave
17
Control elements (S17G, S46G, S118G, ST198D)
Control elements (S24G)
No. in
fig. 3,
page 4
Symbol Description
1 On/off switch
2 Increases the set temperature of the upper temperature
zone by 1 °C or 1 °F
3 Decreases the set temperature of the upper temperature
zone by 1 °C or 1 °F
4 Display indicates the current temperature of the upper
temperature zone
5 Display indicates the current temperature of the lower
temperature zone
6 Increases the set temperature of the lower temperature
zone by 1 °C or 1 °F
7 Decreases the set temperature of the lower temperature
zone by 1 °C or 1 °F
8 Switches the interior light on or off
No. in
fig. 4,
page 4
Symbol Description
1 On/off switch
2 Switches the interior light on or off
3 – Display indicates the current temperature
4 Increases the set temperature of the upper temperature
zone by 1 °C or 1 °F
5 Decreases the set temperature of the upper temperature
zone by 1 °C or 1 °F

EN
MaCave Setting up and connecting the appliance
18
7 Setting up and connecting the
appliance
7.1 Notes on setting up the appliance
S17G, S46G, S118G and ST198D can be placed free-standing.
When selecting the location, observe the following instructions:
zThe ambient temperature should be in accordance with the climate class
mentioned for your country in the supplementary brochure. Otherwise, it
is possible that the inner temperature you set cannot be reached or main-
tained. This could also be the case if there are extreme fluctuations in the
ambient temperature.
zThe appliance should stand in the coldest part of the room, away from
heat sources (ovens, heating devices or radiators).
zThe location must not be damp or wet.
zThe appliance must not be exposed to direct sunlight. This can damage
the acrylic coating and lead to higher power consumption.
zThe ground must be level and sufficiently stable to support the wine cellar
at full capacity.
zThe appliance must be sufficiently ventilated. The ventilation slots on the
front of the appliance must not be obstructed.
zNote the information on the electrical connection, see chapter “Notes on
the electrical connections” on page 45.
zRemove all the inner and outer packaging material before setting up.
zMake sure the appliance is level by adjusting the feet.
7.2 Notes on installing the appliance
ANOTICE!
zWhen mounting ensure that the ventilation openings are kept
free. Covered ventilation openings result in an increase of
electricity consumption and can damage the device.
zWhen pushing the appliance into place, ensure that the mains
cable does not get pinched.

EN
Setting up and connecting the appliance MaCave
19
S17G and S46G can be mounted into a kitchen plinth beneath the kitchen
counter.
S24G, S118G and ST198D can be mounted into a kitchen cabinet .
S17G and S46G installation (fig. j, page 6)
➤Check the dimensions (in mm):
➤If using a plinth:
Ensure that the ventilation openings in the plinth have a cross-section of
at least 300 cm2.
S118G and ST198D installation
➤Check the dimensions (in mm):
S24G installation (fig. k, page 7)
➤Check the dimensions (in mm):
zWarmed air must be dissipated via a ventilation shaft at the rear side.
zThe ventilation shaft must have a cross-section of at least 200 cm2.
zThe plastic seals included are mounted to seal right and left between the
device and the kitchen unit.
Width Depth Height
S17G 300 min. 575 822 – 892
S46G 600 min. 575 822 – 892
Width Depth Height
S118G 600 min. 575 1815
ST198D 600 min. 575 1815
Width Depth Height
S24G 560 550 450

EN
MaCave Setting up and connecting the appliance
20
7.3 Reversing the door
You can also change the hinge of the door, so that it opens to the left rather
than the right.
S17G and S46G
➤Change the door as described in fig. 5, page 4 to fig. a, page 5.
➤Fit the door handle on the other side as described in fig. h, page 6 to
fig. i, page 6.
S118G
➤Change the door as described in fig. b, page 5 to fig. e, page 5.
➤Fit the door handle on the other side as described in fig. h, page 6 to
fig. i, page 6.
ST 198D
➤Change the door as described in fig. b, page 5 to fig. e, page 5.
Turn the door by 180°.
➤Move the closing solenoid to the opposite position.
S24G
➤Change the door as described in fig. f, page 6 to fig. g, page 6.
Turn the door by 180°.
7.4 Notes on the electrical connections
A
Observe the following when connecting the appliance:
zConnect this appliance to a 15 A circuit.
zCheck that the voltage specification on the type plate is the same as that
of the power supply.
zIf you are using an extension cord, it must be suitable for the values which
correspond to the device, see chapter “Technical data” on page 57.
NOTICE!
Leave the appliance to stand upright for about 2 hours after trans-
porting, before you connect it to the power supply.
Otherwise this could cause faults in the cooling system.
