EN 3
EN
DEAR DR. FREI COMPRESSOR NEBULIZER OWNER
Thank you for choosing Dr. Frei
®
Compressor Nebulizer model TURBO LEX. We are sure that having
appraised worthily the high quality and reliability of this device you will become a regular user of the products of
trademark Dr. Frei
®
.
Your nebulizer is intended for use in treatment of asthma, COPD and other respiratory ailments in which an
aerosolized medication is required during therapy. Aerosol easily and quickly comes to both upper and lower
respiratory tracts.
Before starting to use the compressor nebulizer, please, study the user manual carefully. Following the rules stated
in the user manual will provide the faultless operation of the compressor nebulizer for a long period of time. For all
questions concerning the unit, please, contact service centre of distributor of trademark Dr. Frei
®
in your country.
TABLE OF CONTENTS
INTRODUCTION..................................................................................................................................................................3
What Is a Nebulizer and How Does It Work? .......................................................................................................................3
What Is Nebulizing Therapy Used For? ................................................................................................................................3
What Are the Advantages of Nebulizing Therapy? ...............................................................................................................3
BEFORE STARTING TO USE THE UNIT............................................................................................................................4
Important Safety Information ................................................................................................................................................4
Unit Accessories ...................................................................................................................................................................4
CARRYING OUT NEBULIZING THERAPY.........................................................................................................................5
Operating the Unit ................................................................................................................................................................5
Changing the Air Filter ..........................................................................................................................................................5
UNIT MAINTENANCE..........................................................................................................................................................5
Cleaning the Unit ..................................................................................................................................................................5
Troubleshooting ....................................................................................................................................................................6
TECHNICAL SPECIFICATIONS .......................................................................................................................................6
SYMBOL DESCRIPTION ..................................................................................................................................................7
WARRANTY........................................................................................................................................................................7
ELECTROMAGNETIC COMPATIBILITY INFORMATION..............................................................................................8
INTRODUCTION
What Is a Nebulizer and How Does It Work?
The compressor nebulizer system is a device that turns a liquid drug into a ne aerosol under the inuence of the com-
pressed air. Aerosol contains large and small particles. When breathing the gravity makes the larger particles accumulate
on the walls of the upper respiratory passages while the smaller particles have enough time to reach the lower bronchial
branches. Therefore the drug comes to all parts of the patient’s bronchial tree, including the smallest bronchi and alveoli,
and gets into the blood vessels on the walls of the alveoli in big therapeutic dozes with tiny or none side e󰀨ects.
What Is Nebulizing Therapy Used For?
Nebulizer systems are used by the patients with:
• acute respiratory diseases,
• obstructive pulmonary disease,
• chronic inammatory processes in respiratory passages such as chronic bronchitis, bronchial asthma (incl.
chronic or unstable ones, exacerbation of asthma), chronic pharyngitis,
• respiratory passages infections,
• abnormalities in secretion quality and secreting in bronchi,
• di󰀨erent types of coughing.
What Are the Advantages of Nebulizing Therapy?
Nebulizing therapy gives a possibility to quickly e󰀨ect the inammatory zone by big drug dozes which increases the
inuence of the treatment and reduces the risk of side e󰀨ects to other organs. Nebulizing therapy is the easiest way of
inhalation treatment and it is also an economical means of treatments from the point of view of purposeful use of drug.
Aerosol treatment with the help of nebulizing systems can be used for children, elderly and inrm patients.

4
BEFORE STARTING TO USE THE UNIT
Important Safety Information
• Carefully read the instructions before use. Keep this instruction manual for future references.
• Use the device only as an inhalator for therapeutic purposes. Medicine type, mode and time of application should be
prescribed by your doctor. Installation operations have to be done according to the instruction in this handbook and
only for the uses declared by the constructor.
• This device is unsuitable for use with inammable anaesthetic mixtures containing air, oxygen or nitrogen protoxide.
• Always disconnect the device from the main socket after use and before cleaning operations.
• Do not touch the device if it accidentally falls into the water. Unplug it immediately and do not use afterward. Contact
one of authorized service centers.
• Do not touch the device with wet hands.
• During use, make sure that the unit is placed on a at and stable surface.
• Do not use the device when patient is sleeping.
• Contact the service center for any maintenance, do not open the device. If the device does not work properly turn it
o󰀨 and consult the user manual.
• Do not leave any packaging materials (plastic bags, cardboard boxes, and so on) within reach of children to prevent
dangers.
• Keep accessories out of reach of children. Children and people with reduced physical or mental capacities need to use
the device only under close surveillance of an adult who has read this instruction manual. Keep the medicine cup out
of reach of children under 36 months because it contains small parts that could be ingested.
• Always disconnect the device from the main socket when it is not used.
• It is recommended to use one personal medication set of accessories.
• Do not leave pharmaceutical residual in the medicine cup and/or in the accessories at the end of the therapy.
• Cleaning and / or maintenance must be done only after turning o󰀨 the device and unplugging power cord from the
outlet.
• Do not pull thr cable or appliance in order to remove the plug.
• This is a medical device for home use and should be used on medical prescription. Must be run as indicated in this
user instructions. It’s important that patients read and understand the information for use and maintenance of the unit.
Contact your dealer or service centre for any questions.
• If the equipment’s plug does not t the socket, contact a qualied technician to substitute the plug. Do not use multiple
sockets and/or extensions.
• Do not obstruct the air intake.
• The installation must be done according to the instructions and use declared by the manufacturer. Improper installation
and / or improper use may cause damage to people, animals or things. The manufacturer can not be held responsible.
• Do not use the device while bathing and showering.
• Do not expose the device to the action of dust, heat (that could deform the housings), sunlight or other atmospheric
agents that could compromise the safety of the device itself.
• Do not use the device nearby sources of potential interference (example: heat sources like replaces, electric or gas
heaters; steam sources like boilers or kettles, electromagnetic radiation sources like microwave ovens, Wi-Fi devices).
• Keep away from pets that could contaminate the surface in contact with the patient or in general hinder the right
performance of the therapy.
• The appliance generates compressed air. Side e󰀨ects could come from the intolerance to the medicine used.
Electric devices must be disposed of in accordance with the locally applicable regulations, not with domestic
waste.
KEEP THIS INSTRUCTION MANUAL DURING THE WHOLE SERVICE LIFE OF THE UNIT
Unit Accessories
1
Mouthpiece
2
Adult mask
3
Pediatric mask
4
Medicine cup
5
Air tube
6
Spare air lters (5 pcs)
7
AC adapter
2
23
3
9
6
8
5
4
1
9
7

EN 5
CARRYING OUT NEBULIZING THERAPY
The appliance is a medical device of class IIa, which converts medicine from the uid form to vapour in order to inject it
directly into the respiratory tracts. The appliance nebulizes medicines both in suspension and in solution. The therapeutic
e󰀨ect could be reduced with oily and/or pasty medicines.
The appliance is NOT a nebulizer for essential oil. Don’t preheat liquid and/or alcohol solutions. Medicine cup and all
accessories have NOT been sterilized. Read “Unit maintenance” paragraph before use.
Operating the Unit
1. Put the device on a at, stable surface.
2. Ensure that the rated voltage corresponds to the
utility voltage supply.
3. Connect the device into the main socket.
4. Open the medicine cup unscrewing the two parts
(gure A).
5. Fill the medicine cup with a pharmaceutical pre-
scribed by your doctor (gure B). Note: The notch-
es on the lower part of the medicine cup are only
indicative.
6. Close the medicine cup screwing two parts back (gure C).
7. Connect one end of the air tube (9) to the medication cup and the other
end to the connector on the device (Figure D).
8. Install the needed accessory on the medicine cup: adult or pediatric
mask, or mouthpiece (gure E).
9. Turn on the device moving the switch to ON position.
10. After the application, turn o󰀨 the device and unplug. Before restarting the
appliance make sure it has been cooled to room temperature.
Changing the Air Filter
The lter should be replaced after 100 hours of use or when it turns grey.
Spare air lter and its container are on the gure H. For lter replacing, care-
fully raise the lid using a at screwdriver as shown in the picture I. Remove
the lter and t in a new lter (9). Install the lter holder in its housing, making
sure that it is securely xed.
Use the lter supplied by the manufacture only.
UNIT MAINTENANCE
Cleaning the Unit
After each therapy remove the device from the socket and clean the device and the accessories. Attention: use only the
accessories supplied with the product, other accessories can lead to ine󰀨ective therapy.
CLEANING OF THE MOUTHPIECE
Use drinking water to clean carefully these accessories. They can be sterilized by immersion in a chemical disinfectant
(oxidizing electrolytic chloride), following disinfectant manufacturer’s instructions and rinsed o󰀨 with drinking water. Leave
to dry naturally in a clean place.
CLEANING OF THE MEDICINE CUP
After use, open two parts, wash with soap and hot water and rinse it carefully. Remove excess of water with a soft, clean
HI
A B C
DE
A B C
DE
RECOMMENDATIONS FOR CARRYING OUT NEBULIZING THERAPY:
• Sit down in a comfortable and upright position.
• If a mask (adult or pediatric) is used, be sure that it securely adheres to the face. Mask has holes for the
air ow during the expiration.
• Breathe easy and have a short pause at the end of each breath.
• Therapeutic application ends when the medicine comes out in a discontinuous mode (spluttering).
• When using the mouthpiece, do not tilt the medicine cup over 45°.
