NEBULIZER AEROSOL THERAPY SYSTEM
model CHU-CHU-TRAIN
INSTRUCTION MANUAL
Thank you for choosing Dr. Frei®Nebulizer. We are sure that having appraised worthily the
high quality and reliability of this device you will become a regular user of the products
of Dr. Frei®Trade Mark.
Before starting to use the Nebulizer please study the instruction book carefully.
Following the rules stated in the instruction book will provide for the faultless operation of the
Nebulizer for a long period of time.
ATTENTION
Please use only those medicines that were prescribed to you by your doctor, DO NOT ex-
ecute self-treatment and DO NOT change the methods prescribed without consulting your
doctor.
CONTENT
1. Components and description of your nebulizer system model CHU-CHU-TRAIN
2. Getting ready for usage
2.1. Assembling the device
2.2. Replacement of lter
3. Carrying out aerosol therapy
4. Cleaning and disinfection
5. Possible problems and how to solve them
6. Technical specications
7. Warranty
8. What is nebulizing therapy

3
1. COMPONENTS AND DESCRIPTION OF YOUR NEBULIZER MODEL CHU-CHU-
TRAIN
Your nebulizer sytem includes compressor unit Chu-Chu-Train, power cord, PVC tubing,
mouthpiece, jet nebulizer, 3 air lters, adult mask, pediatric mask, instruction book, guaran-
tee card, packing.
The picture shows nebulizer model Chu-Chu-Train.
Pediatric
mask
Adult mask
Mouth piece
Jet
nebulizer
PVC tubing
Air outlet Filter Chamber
ON/OFF Switch
Power cord
Air lter

4
ATTENTION:
Read the manual carefully before using the device and keep it in case you need further
information in the future.
This nebulizer must be used only for the specic cause it was created for: the aerosoltherapy.
Any other use will be considered unsuitable and thus dangerous; the manufacturer can not
be considered responsible for the damages caused by unsuitable, incorrect or irrational use,
or if the unit has been used in electrical installations not in accordance with the standing
safety standards.
When using any electrical appliance certain important safety measures must always be ob-
served, including the following:
• The unit is not protected from liquid penetration.
• The nebulizer system must not be touched with wet or soaked hands.
• Do not use the device in presence of inammable anesthetic mix in contact with the air,
oxygen or nitrogen protoxide.
• Do not block the air ventilation holes.
• Unplug the unit before cleaning or maintaining it.
• Disconnect the nebulizer system when it is not in use.
• Do not untwist the jet nebulizer when the unit is operating.
• Do not leave medication inside the jet nebulizer when it is not in use.
• Do not pour more than 10 ml in the jet nebulizer.
• Use the unit on stable surfaces. Never use it while sleepy or drowsy.
• Use the unit intermittently. Maximum operating period: 30 minutes. It must stand unused
for 30 minutes.
• The mask and the mouth piece are for personal use, and they have not to be shared in
order to avoid any infection or contagion.
• Stop the nebulization if you feel any indisposition.
• Children will use this unit only under adult supervision.
• This unit have to be repaired only by authorized service centres.
NOTE: this unit employs a thermal limiter that will shut off the entire product
should the motor overheat.

5
2. GETTING READY FOR USAGE
2.1. ASSEMBLING THE DEVICE
1. Take the unit out of the box.
2. Open the jet nebulizer (Fig. A) and pour the
medication to nebulize into it.
Do not pour more than 10 ml (Fig. B).
Then twist both parts and close again. (Fig. C).
3. Connect the tubing to the jet nebulizer and
the other end to the nebulizer outlet. (Fig. D).
4. Put the mask or the mouth piece to be used
into the jet nebulizer (Fig. E).
5. Connect the unit to a suitable power recep-
tacle.
Your nebulizer system is ready for work.
2.2. REPLACEMENT OF THE FILTER
1. Filter should be changed every month or
sooner if the lter turns completely
gray in color.
2. Remove lter cap by grasping it rmly and
pulling out the unit.
3. Change the dirty lter of the cap with small, pointed object.
4. Insert a clean San Up lter. Extra lters are available.

6
5. Push the lter cap with new lter into position.
Caution:
Do not use cotton or any other material. Do not wash or clean the lter. Use only original
lters. Do not operate without a lter.
3. CARRYING OUT AEROSOL THERAPY
1. Turn the unit on by pressing the ON/OFF switch to start the treatment.
ATTENTION:
This device is for intermittent use: 30 min. ON/30 min. OFF.
2. Inhale the aerosol solution using the prescribed accessory in calm way. One should sit at
the table with one’s back upright, relaxed; otherwise you will constrict your respiratory pas-
sages and impair the effect of inhalation.
3. Turn the unit off and unplug it once the treatment has nished.
4. Clean the jet nebulizer and the devices as indicated in Cleaning and disinfection section.
Store the jet nebulizer and the devices into the unit’s lodging.
4. CLEANING AND DISINFECTION
Important:
1. Wash all the pieces, except for the air lter, with warm water and detergent. Rinse with
warm tap water to remove the detergent.
2. Dip the pieces into a clean bowl containing 3 parts of warm water and 1 part of vinegar
during 30 minutes, disinfectant can also be used.
3. Wash your hands and take out the pieces from the disinfectant solution, rinse them with
warm tap water and leave them on an absorbent piece of paper.
4. Keep the pieces into a hermetic bag. Do not dry them with a towel.
5. Clean the outer surface with a dry piece of cloth.
• Do not use any volatile uid like alcohol or benzene.
• The jet nebulizer and the devices must NOT be boiled.
• The jet nebulizer has to be replaced if it is stuck by medication or other substances.
• Under no circumstances will the unit be opened.

7
5. POSSIBLE PROBLEMS AND HOW TO SOLVE THEM
If something wrong happens while the device is working, please check and correct the fol-
lowing points:
Symptom Possible cause Suggested solutions
Although the de-
vice is on, it does
not work
1. Incorrectly plugged.
2. No power.
1. Check the plug is properly
connected.
2. Check the power is not gone
out.
The mist does not
come out
1.There is no solution in the jet
nebulizer.
2.There is too much solution in the
jet nebulizer.
3.PVC tubing is disconnected.
1. Add medication, maximum
10 ml.
2. Remove excess medication
from cup.
3. Connect the PVC tubing.
Aerosol output re-
duced (low) 1. Air lter is clogged. 2.The jet nebulizer is dirty. 1. Replace for a clean air lter. 2. Replace for new one.
Should the device not start working properly again, please contact the Service Centre; the
address is stated in the Guarantee Card.
6. TECHNICAL SPECIFICATIONS
Method of nebulization Dry piston compressor
Operating Voltage 220V-230V, 50Hz
Class
Power consumption 0.6A

8
Jet nebulizer maximum capacity 10 ml
Sound noise level (at 1m distance) 60 dB
Mean Mass Aerodynamic Diameter
(microns)
less than 5 microns
Medication outlet* 0.33 ml/min. or greater; value measured with
0.9% NaCl solution.
Weight 1.732 kg
Unit dimensions 240x140x124 mm
Operation Humidity and Temperature -5 to +400C, 30% to 95%
Storage Humidity and Temperature -10 to +600C, 10% to 95%
Atmospheric pressure range for
carriage and storage
50 - 106 kPa (500-1060 mbar)
*This specication may very with the kind of the medication being used and its viscousity.
The specications and the outer design are subject to change for improvement reasons
without previous notice.
SYMBOLS KEY
ON
OFF
Тype B
Read the instruction
AC
Class II
!

9
7. WARRANTY
The nebulizer system Chu-Chu-Train is covered by a 3-year warranty from date of purchase
for any defects in the design or in the materials used. The warranty does not cover the acces-
sories supplied with the device and those parts subject to normal wear and tear.
The warranty does not apply to damage caused by improper handling, accidents, not follow-
ing the operating instructions or self-maintained alterations made to the device.
The manufacturer shall not be liable for any damages to people, property or pets, either
directly or indirectly, caused by the non-compliance with the instruction book.
The warranty is only valid upon presentation of the warranty card which was correctly lled
in and sealed.
8. WHAT IS NEBULIZING THERAPY
What is a nebulizer?
The name of the device comes from the Latin word nebula that means fog, cloud. The nebu-
lizer system is a device that turns a liquid drug into a ne aerosol under the inuence of
the compressed air. Aerosol is a drug suspension. So, nebulizing therapy is an inhalation
therapy with the help of aerosols.
Inhalation therapy has been used for treatment of lung diseases for a long time. The ancient
civilizations of Egypt, India, Chine, the Middle East, Greece are know to have used inhala-
tions of evaporations from menthol, eucalyptus, different plants.
For patients with lung diseases nebulizing therapy seems to be the most rational one since
big drug doses come very fast to the respiratory tract directly.
How does the nebulizer system work?
Nebulizer directs an aerosol containing larger and smaller particles to the respiratory tract.
The gravity makes the larger particles accumulate on the walls of the upper respiratory pas-
sages while the smaller particles have enough time to reach the lower bronchial branches.
Therefore the drug comes to all parts of the patient’s bronhial tree, including the smallest
bronchi and alveole, and gets into the blood vessels on the walls of the alveole in big thera-
peutic dozes with tiny or none side effects. Some drugs are very slow to be absorbed from

10
the alimentary canal or are affected dramatically by the rst passage through the liver. In
such cases the way out is to use inhalation therapy. Nebulizing therapy can be used by pa-
tients of any age, it’s suitable for small children and inrms.
What is nebulizing therapy used for?
Nebulizer systems are used by the patients with:
• acute respiratory diseases
• obstructive pulmonary disease
• chronic inammatory processes in respiratory passages such as chronic bronchitis,
bronchial asthma (incl. chronic or unstable ones, exacerbation of asthma), chronic
pharyngitis;
• respiratory passages infections
• abnormalities in secretion quality and secreting in bronchi
• different types of coughing
Nebulizing therapy helps to decrease the level of inammation activity, to improve respira-
tory passage drain function, to lessen the bronchismus, to make the edema smaller and to
protect the mucous membrane, etc.
What are the advantages of nebulizing therapy compared to other means of drug delivery?
Nebulizing therapy gives a possibility to quickly effect the inammatory zone by big drug
dozes which increases the inuence of the treatment and reduces the risk of side effects to
other organs. Nebulizing therapy is the easiest way of inhalation treatment and it is also an
economical means of treatments from the point of view of purposeful use of drug. Aerosol
treatment with the help of nebulizing systems can be used for children, elderly and inrm
patients.
Please use only those drugs that were prescribed to you by your doctor, DO NOT ex-
ecute self-treatment and DO NOT change the methods/frequency prescribed without
consulting your doctor.
