Dreame DreameBot D10s User manual

User Manual
Robot Vacuum and Mop
The illustrations in this manual are for reference only. Please refer to the actual product.
D10s

Contents
User Manual
Benutzerhandbuch
1
24
EN
DE

1
EN
Usage Restrictions
Safety Information

·This product should not be used by children younger than 8 years old
nor persons with physical, sensory, intellectual deficiencies, or limited
experience or knowledge without the supervision of a parent or guardian
to ensure safe operation and to avoid any risks. Cleaning and maintenance
shall not be performed by children without supervision.

·Children shall not play with this product. Ensure children and pets are kept
at a safe distance from the robot while it is operating.

·This product is for floor cleaning in a home environment only. Do not use it
outdoors, on non-floor surfaces, or in a commercial or industrial setting.

·If the power cord becomes damaged or broken, stop using it immediately
and contact after-sales service.

·Do not use the robot in an area suspended above ground level without a
protective barrier.

·Do not place the robot upside down. Do not use the LDS cover, robot cover,
or bumper as a handle for the robot.

·Do not use the robot at an ambient temperature above 40° C or below 0° C or
on a floor with liquids or sticky substances.

·Pick up any cables from the floor before using the robot to prevent it from
To avoid electric shock, re or injury caused by improper use of the appliance, please read the user
manual carefully before using the appliance and keep it for future reference.

2
EN
dragging them while cleaning.

·Remove fragile or small items from the floor to prevent the robot from
bumping into and damaging them.

·To prevent damage or harm from dragging, clear any loose objects from
the floor, and remove cables or power cords on the cleaning path before
operating the appliance.

·Keep hair, fingers, and other body parts away from the suction opening of
the robot.

·Keep the brush cleaning tool out of reach of children.

·Do not place children, pets, or any item on top of the robot regardless of
whether it is stationary or moving.

·Do not use the robot to clean any burning objects. Do not use the robot to
pick up flammable or combustible liquids, corrosive gases, or undiluted
acids or solvents.

·Do not vacuum hard or sharp objects. Do not use the appliance to pick up
objects such as stones, large pieces of paper or any item that may clog the
appliance.

·Make sure the robot is turned off and the charging dock is unplugged
before cleaning or performing maintenance.

·Do not use a wet cloth to wipe or any liquid to rinse the robot and charging
Usage Restrictions
Safety Information

3
EN
Usage Restrictions
Safety Information
dock. Washable parts must be dried completely before installing and using
them.

·Make sure the robot is turned off when being transported and kept in its
original packaging if possible.

·Please use this product in accordance with the instructions in the User
Manual. Users are responsible for any loss or damage that arise from
improper use of this product.
Batteries and
Charging

·Do not use any third-party battery, power cord, or charging dock. Use only
with RCS0 supply unit.

·Do not attempt to disassemble, repair, or modify the battery or charging
dock on your own.

·Do not place the charging dock near a heat source.

·Do not use a wet cloth or wet hands to wipe or clean the dock's charging
contacts.

·Do not improperly dispose of old batteries. Unneeded batteries should be
discarded at an appropriate recycling facility.

·If the robot will not be used for an extended period, fully charge it, then turn
it off and store in a cool, dry place. Recharge the robot at least once every 3
months to avoid over-discharging the battery.

·This product contains batteries that can only be replaced by qualified
technicians or after-sales service.

4
EN
Hereby, Dreame Trading（Tianjin）Co., Ltd. declares that the radio equipment type RLS3L is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address: https://global.dreametech.com
For detailed e-manual, please go to https://global.dreametech.com/pages/user-manuals-and-faqs
Safety Information
Laser Safety
Information

·The laser sensor in this product meets the IEC 60825-1: 2014 Standard for
Class 1 laser products. Please avoid direct eye contact with it during use.

5
EN
Accessories
Pre-Installed Accessories
Other Accessories
Product Overview
Water Tank Side Brush
Cleaning Tool
Main Brush Dust Bin
Power Cord Charging Dock
Mop Pad

6
EN
Robot
Product Overview
Power/Clean Button
·Press and hold for 3 seconds to turn on or off
·Press briefly to start cleaning after the robot is turned on
Dock/Spot Clean Button
·Press to send the robot back to the charging dock
·Press and hold for 3 seconds to start Spot Clean Mode
Status Indicator
·Solid White: Cleaning or cleanup is completed
·Blinking Orange: Error
·Breathing White: Robot is charging when the battery
power is not low
Cover

7
EN
Reset Button
• Press and hold for 3
seconds to restore the
robot to factory settings
Wi-Fi Indicator
Cleaning Tool
Air Outlet/Speaker
Robot
Robot Sensors
Product Overview
Laser Distance Sensor (LDS)
Bumper
Returning-to-Dock Sensor
Cli Sensors
Main Wheel
Cli Sensors
Cli Sensors
Main Wheel
Main Brush
Charging Contacts
Brush Guard Clips
Universal Wheel
Side Brush
Charging Contacts
Dust Bin
Filter
Bin Cover
Bin Clip

8
EN
Charging Dock
Product Overview
Signaling Area
Charging Contacts
Power Port
Mopping Module
Water Tank
Water Inlet
Attaching Area
Slot
Water Tank Release Clip
Mop Pad
