Drill Master 68341 User manual

2 HP Fixed Base Router
68341 Router
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-800-444-3353 as soon as possible.
Visit our website at: http://www.harborfreight.com
Copyright©2011 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

Page 2 For technical questions, please call 1-800-444-3353. SKU 68341
Specications
Power 2 HP
Electrical Input 120 V~ / 60 Hz / 11 A (Rated)
Motor Speed 28,000 RPM (No Load)
Accepts Collet Sizes 1/4”, 3/8”, 1/2"
Maximum
Cutting Depth 2-3/8”
Depth Measurements 1/64” increments
Accessories
1/4", 3/8" Collet Chucks
Carbon Brushes
Straight Trimmer Guide
Two Wrenches
E194601
Save This Manual
Keep this manual for the safety warnings and
precautions, assembly, operating, inspection,
maintenance and cleaning procedures. Write the
product’s serial number in the back of the manual near
the assembly diagram (or month and year of purchase
if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference.
Important Safety Information
In this manual, on the labeling, and all other
information provided with this product:
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
DANGER indicates a hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol,
indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices
not related to personal injury.
CAUTION, without the safety alert symbol, is used
to address practices not related to personal injury.
General Power Tool
Safety Warnings
WARNING Read all safety warnings and
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/
or serious injury.
Save all warnings and instructions for
future reference.
The term ″power tool″ in the warnings refers
to your mains-operated (corded) power tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with grounded
power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with grounded surfaces
such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f. If operating a power tool in a damp location
is unavoidable, use a Ground Fault Circuit
Interrupter (GFCI) protected supply.
Use of a GFCI reduces the risk of electric shock.

Page 3For technical questions, please call 1-800-444-3353.SKU 68341
3. Personal safety
a. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power
tool while you are tired or under the
inuence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b. Use personal protective equipment.
Always wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your nger on the switch or energizing power
tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench
before turning the power tool on.
A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry
or long hair can be caught in moving parts.
g. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
these devices can reduce dust-related hazards.
h. Only use safety equipment that has been
approved by an appropriate standards
agency. Unapproved safety equipment
may not provide adequate protection.
Eye protection must be ANSI-approved and
breathing protection must be NIOSH-approved
for the specic hazards in the work area.
4. Power tool use and care
a. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer
at the rate for which it was designed.
b. Do not use the power tool if the
switch does not turn it on and off.
Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
5. Service
Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
Router Safety Warnings
1. Hold power tool by insulated gripping surfaces
when performing an operation where cutting
tool may contact hidden wiring or its own cord.
Contact with a ″live″ wire will make exposed metal
parts of the tool ″live″ and shock the operator.
2. Use clamps or another practical way to secure
and support the work piece to a stable platform.
Holding the work by hand or against your body
leaves it unstable and may lead to loss of control.
3. Use only accessories rated at least equal
to maximum speed marked on Router.
4. Only use router bits with a shank diameter
equal to the size of the tool’s collet. The collet
size is adjustable for 1/4", 3/8" or 1/2".
5. Make sure the collet nut is securely tightened before
use to prevent the router bit from slipping during use.
6. Do not use with base removed.
7. Hold router with both hands.
8. Keep hands away from the cutting area. Do
not place hands beneath the workpiece for
any reason. Keep the base of the router in rm
contact with the workpiece while cutting.
9. Keep Handles dry, clean, and free of oil or grease.
This will permit better control of the tool.
10. Do not use damaged bits.

Page 4 For technical questions, please call 1-800-444-3353. SKU 68341
11. Do not lay the Router down until it has
stopped rotating completely.
12. Hold the Router rmly when starting, as
startup rotation creates signicant torque.
13. Hold the Router rmly while cutting. The action of the
bit against the workpiece can cause it to “kick out”,
jumping rapidly away from the workpiece. This can
be caused by an improper type of bit, or a dull bit.
14. Do not handle the Router bit immediately
after cutting. It may be very hot,
potentially causing burns or injury.
15. Avoid overloading the tool. If the speed
drops abnormally, decrease the pressure on
the bit immediately. Do not apply excessive
pressure to the router while cutting.
16. Always use sharpened bits. If the bit stops
abruptly, or the bit becomes blocked, remove
the Router from the workpiece and shut it off.
17. Do not start the Router while the bit is in
contact with the workpiece. Allow the tool
to reach its normal operating speed before
applying the bit to the workpiece.
18. Use caution when setting the Locking Trigger
Switch. Be aware that the router will continue to
operate while the locking mechanism is engaged.
Do not lay the router down or hand it to another
person while the locking mechanism is engaged.
19. Before Routing, run the tool for about 10 seconds
to ensure that all moving parts are running
smoothly and there are no loose parts, rattles,
or sparking that would indicate damage.
20. Maintain labels and nameplates on the tool.
These carry important safety information. If
unreadable or missing, contact Harbor
Freight Tools for a replacement.
21. Avoid unintentional starting. Prepare to
begin work before turning on the tool.
22. When using a handheld power tool,
maintain a rm grip on the tool with both
hands to resist starting torque.
23. Do not leave the tool unattended when it is plugged
into an electrical outlet. Turn off the tool, and
unplug it from its electrical outlet before leaving.
24. Only use accessories rated to the speed
of the tool. Other accessories may y
apart, causing severe personal injury.
25. This product is not a toy.
Keep it out of reach of children.
26. People with pacemakers should consult their
physician(s) before use. Electromagnetic elds in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure. In
addition, people with pacemakers should:
• Avoid operating alone.
• Do not use with power switch locked on.
• Properly maintain and inspect to avoid
electrical shock.
• Any power cord must be properly
grounded. Ground Fault Circuit Interrupter
(GFCI) should also be implemented –
it prevents sustained electrical shock.
27. WARNING: Some dust created by power sanding,
sawing, grinding, drilling, and other construction
activities, contains chemicals known [to the State
of California] to cause cancer, birth defects or
other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement or
other masonry products
• Arsenic and chromium from
chemically treated lumber
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to
lter out microscopic particles.
(California Health & Safety Code § 25249.5, et seq.)
28. WARNING: Handling the cord on this product will
expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.
(California Health & Safety Code § 25249.5, et seq.)
29. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
Vibration Safety
This tool vibrates during use.
Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should rst be examined by a
doctor and then have regular medical check-ups to
ensure medical problems are not being caused or
worsened from use. Pregnant women or people who
have impaired blood circulation to the hand, past
hand injuries, nervous system disorders, diabetes,
or Raynaud’s Disease should not use this tool.
If you feel any symptoms related to vibration (such
as tingling, numbness, and white or blue ngers),
seek medical advice as soon as possible.

Page 5For technical questions, please call 1-800-444-3353.SKU 68341
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and ngers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration
when there is a choice.
5. Include vibration-free periods each day of work.
6. Grip tool as lightly as possible (while still keeping
safe control of it). Let the tool do the work.
7. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
SAVE THESE
INSTRUCTIONS.
Grounding
TO PREVENT ELECTRIC SHOCK AND
DEATH FROM INCORRECT GROUNDING
WIRE CONNECTION:
Check with a qualied electrician if you are
in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug
provided with the tool. Never remove the grounding
prong from the plug. Do not use the tool if the power
cord or plug is damaged. If damaged, have it
repaired by a service facility before use. If the plug
will not t the outlet, have a proper outlet installed by
a qualied electrician.
Grounded Tools:
Tools with Three Prong Plugs
3-Prong Plug and Outlet
1. Tools marked with “Grounding Required” have a three
wire cord and three prong grounding plug. The plug
must be connected to a properly grounded outlet.
If the tool should electrically malfunction or break
down, grounding provides a low resistance path to
carry electricity away from the user, reducing the risk
of electric shock. (See 3-Prong Plug and Outlet.)
2. The grounding prong in the plug is connected through
the green wire inside the cord to the grounding
system in the tool. The green wire in the cord must
be the only wire connected to the tool’s grounding
system and must never be attached to an electrically
“live” terminal. (See 3-Prong Plug and Outlet.)
3. The tool must be plugged into an appropriate outlet,
properly installed and grounded in accordance with
all codes and ordinances. The plug and outlet should
look like those in the preceding illustration.
(See 3-Prong Plug and Outlet.)
Double Insulated Tools:
Tools with Two Prong Plugs
Outlets for 2-Prong Plug
1. Tools marked “Double Insulated” do not
require grounding. They have a special
double insulation system which satises
OSHA requirements and complies with
the applicable standards of Underwriters
Laboratories, Inc., the Canadian Standard
Association, and the National Electrical Code.
2. Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration.
(See Outlets for 2-Prong Plug.)
Extension Cords
1. Grounded tools require a three wire extension
cord. Double Insulated tools can use either
a two or three wire extension cord.
2. As the distance from the supply outlet increases,
you must use a heavier gauge extension
cord. Using extension cords with inadequately
sized wire causes a serious drop in voltage,
resulting in loss of power and possible tool
damage. (See Table A on page 6.)
3. The smaller the gauge number of the wire, the
greater the capacity of the cord. For example,
a 14 gauge cord can carry a higher current
than a 16 gauge cord. (See Table A.)

Page 6 For technical questions, please call 1-800-444-3353. SKU 68341
4. When using more than one extension cord to make
up the total length, make sure each cord contains at
least the minimum wire size required. (See Table A.)
5. If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size. (See Table A.)
6. If you are using an extension cord outdoors, make
sure it is marked with the sufx “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use.
7. Make sure the extension cord is properly wired
and in good electrical condition. Always replace
a damaged extension cord or have it repaired
by a qualied electrician before using it.
8. Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas.
TABLE A: RECOMMENDED MINIMUM
WIRE GAUGE FOR EXTENSION CORDS*
(120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop to ve volts at
150% of the rated amperes.
Symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~ Volts Alternating Current
AAmperes
n0xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking concerning
Risk of Hearing Loss.
Wear hearing protection.
WARNING marking
concerning Risk of Fire.
Do not cover ventilation ducts.
Keep ammable objects away.
WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.

Page 7For technical questions, please call 1-800-444-3353.SKU 68341
Note: For additional information regarding the parts listed in the following pages, refer to Parts List on page 12.
Components
Collet Nut (1)
HandleHandle
Power Switch (23)
Scale
Ring (46)
Figure 1
Instructions for Putting into Use
TO PREVENT SERIOUS
INJURY FROM
ACCIDENTAL OPERATION:
Turn the Power Switch off and unplug the Router
before adjusting or installing accessories.
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the
beginning of this manual including
all text under subheadings therein
before set up or use of this product.

Page 8 For technical questions, please call 1-800-444-3353. SKU 68341
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the
beginning of this manual including
all text under subheadings therein
before set up or use of this product.
TO PREVENT SERIOUS
INJURY FROM
ACCIDENTAL OPERATION:
Turn the Power Switch off and unplug the Router
before adjusting or installing accessories.
Operating Instructions
Spindle
Main
Housing
(5)
Collet Nut
Wrench (51)
Spindle
Wrench (50) Spindle
Collet
Nut (1)
Bit
(sold separately)
Collet Nut
Wrench (51)
Spindle
Wrench (50) Spindle
Collet
Nut (1)
Unlock the Lock Lever (30). Rotate the Main Housing to raise or
lower the Spindle so you can access the
Spindle and Collet Nut with the Wrenches.
Remove or insert a Collet Chuck as needed
to t the bit size, then insert the bit (sold
separately)
and tighten the
Collet Nut with
the Wrenches.
1 2
Turn the Router upside down and hold the
Spindle in place with the Spindle Wrench
while turning the Collet Nut counterclockwise with
the Collet Nut Wrench to loosen the Collet Nut.
3 4
Tool Set Up
Installing Bits
Lock Lever
(30)

Page 9For technical questions, please call 1-800-444-3353.SKU 68341
Guide (24)
Guide Poles (28)
Wing Nuts (27)
Wing
Nuts (37)
Base
(45)
Spindle
Main
Housing
(5)
Adjusting the Cutting Depth
Attaching Guide
To attach the Guide (24) when making straight cuts:
1. Loosen the four Wing Nuts (27 and 37).
2. Slide the Guide Poles (28) on the Guide (24)
into the slots on the Base of the Router
with the Guide facing the workpiece.
3. Adjust the distance between the router bit
and the Guide to the desired setting.
4. Tighten the Wing Nuts (27 and 37).
Slide the Scale Ring until the “0” aligns with
the index line (vertical mark) on the Main
Housing. Unlock the Lock Lever. Each line on
the scale raises or lowers the bit by 1/64".
Rotate the Main Housing until the
tip of the bit touches the workpiece
surface. Lock the Lock Lever.
2
3
Scale Ring
Index Line
(vertical mark on
Main Housing)
Place the router on a at wood
surface. Unlock the Lock Lever (30).
1
While holding the Base up from the
surface, rotate the Main Housing to
raise or lower the bit until the index line on
the housing aligns with the desired depth
on the scale ring. Lock the Lock Lever.
4
Lock Lever
(30)
Lock Lever
(30)

Page 10 For technical questions, please call 1-800-444-3353. SKU 68341
Work Piece and Work
Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route to reach
the work area without creating a tripping hazard or
exposing the power cord to possible damage. The
power cord must reach the work area with enough
extra length to allow free movement while working.
3. Secure loose work pieces using a vise or clamps
(not included) to prevent movement while working.
4. Make sure there are no metal objects in the wood
which might make contact with the router bit.
General Operating Instructions
Note: Use two or more passes for deep cuts, especially
in the case of hardwood. Do not attempt to cut deeper
than 5/8” in a single pass. Adjust the cutting depth so
that the rst pass will be less than 5/8” deep, then follow
the procedures for Adjusting the Cutting Depth for each
progressive pass, until the nal depth is achieved.
Note: Feed the Router bit into the workpiece
against the bit’s direction of rotation.
Feed direction
Feed direction
Bit revolving direction
Bit revolving direction
View from cutting edge of piece
View from top of piece
When cutting outside edges, guide the router
counterclockwise around the workpiece.
Move it clockwise when cutting inside edges.
Router
Direction
WARNING! Moving the router against
the recommended direction can cause
serious injury from kickback.
Note: Make practice cuts at different speeds in scrap
material until you are able to produce a smooth
cut with no burnishing or burn marks. Burn marks
are caused by moving too slowly through the
wood. Feeding the Router too quickly, or trying to
remove too much material in a single pass creates
a rough cut and can overload the motor.
WARNING! When rst turning on the Router,
grip the Handles rmly as the tool may try
to twist from the strong initial torque.
1. Hold the Router handles rmly with both hands.
2. Place the Router directly above the point
you plan to cut. Verify that there are no
obstructions in the cutting path.
3. Turn on the Router.
4. Before cutting material, watch and feel for
vibration which could indicate an improperly
installed bit. Turn off and re-install bit, if needed.
5. Allow the bit to come to full speed,
slowly engage material. DO NOT force
the Router down into the material.
6. When nished, raise the Router so the bit is clear
of the material, then turn the Power Switch off.
Do not set the Router down until the
bit has come to a complete stop.
7. Do not touch the bit right after cutting. It becomes
very hot. Allow to cool before changing bits.
8. Do not leave the router running when not
actually cutting. Turn power off between cuts.
9. To prevent accidents, disconnect the power
supply after use. Clean, then store the
tool indoors out of children’s reach.

Page 11For technical questions, please call 1-800-444-3353.SKU 68341
TO PREVENT SERIOUS
INJURY FROM
ACCIDENTAL OPERATION:
Turn the Power Switch off and unplug the
Router before performing any inspection,
maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal
noise or vibration occurs, have the
problem corrected before further use.
Cleaning, Maintenance,
and Lubrication
1. BEFORE EACH USE, inspect the general condition
of the tool. Check for loose hardware, misalignment
or binding of moving parts, cracked or broken
parts, damaged electrical wiring, and any other
condition that may affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Regularly clean all ventilation openings by
periodically brushing with a soft brush and/
or blowing clear with compressed air.
4. WARNING! If the supply cord of this power
tool is damaged, it must be replaced only by a
qualied service technician.
Replacing Carbon Brushes
Remove and check the Carbon Brushes regularly.
Replace when they wear down to the limit mark on
the carbon. Replace both
brushes at the same time.
To replace: Remove the Brush
Caps and old brushes, then
insert the new brushes and
secure the caps in place. Carbon
Brush
(18)Limit mark
Brush
Cap
(15)
Maintenance and Servicing
Procedures not specically explained
in this manual must be performed
only by a qualied technician.
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. 1. Cord not connected.
2. No power at outlet.
3. Tool’s thermal reset breaker
tripped (if equipped).
4. Internal damage or wear. (Carbon
brushes or switch, for example.)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered, turn off tool
and check circuit breaker. If breaker is tripped, make sure
circuit is right capacity for tool and circuit has no other loads.
3. Turn off tool and allow to cool. Press reset button on tool.
4. Have technician service tool.
Tool operates slowly. Extension cord too long or
wire size too small.
Eliminate use of extension cord. If an extension cord is
needed, use shorter/heavier gauge cord. See Extension
Cords in Grounding section on page 5.
Performance
decreases over time.
1. Accessory dull or damaged.
2. Carbon brushes worn or damaged.
1. Keep cutting accessories sharp. Replace as needed.
2. Have qualied technician replace brushes.
Excessive noise
or rattling.
Internal damage or wear. (Carbon
brushes or bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Accessory misaligned.
3. Accessory dull or damaged.
4. Blocked motor housing vents.
5. Motor being strained by long or
small diameter extension cord.
1. Allow tool to work at its own rate.
2. Check and correct accessory to fence and/or table alignment.
3. Keep cutting accessories sharp. Replace as needed.
4. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while blowing
dust out of motor using compressed air.
5. Eliminate use of extension cord. If an extension cord is needed,
use one with the proper diameter for its length and load. See
Extension Cords in Grounding section on page 5.
Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power
supply before service.

Page 12 For technical questions, please call 1-800-444-3353. SKU 68341
Part Description Qty
1 Collet Nut 1
2 Bolt 2
3 Bearing Support 1
4 Bearing 1
5 Main Housing 1
6 Screw 2
7 Cover 1
8 Stator 1
9 Rotor 1
10 Washer 1
11 Bearing 1
12 Motor Housing 1
13 Power Cord 1
14 Cable Guard 1
15 Brush Cap 2
16 Brush Holder 2
17 Spring 2
18 Carbon Brush (installed) 2
18a Carbon Brush (replacement) 2
19 Cable Clamp 1
20 Screw 2
21 Rear Housing 1
22 Screw 4
23 Power Switch 1
24 Guide 1
25 Nut 2
Part Description Qty
26 Spring 2
27 Wing Nut 2
28 Guide Pole 2
29 Pin 1
30 Lock Lever 1
31 Nut 1
32 Block 1
33 Bolt 1
34 Screw 4
35 Right Handle (a) 1
36 Spring 2
37 Wing Nut 2
38 Right Handle (b) 1
39 Flat Cap Screw 3
40 Base Slider 1
41 Screw 4
42 Left Handle (a) 1
43 Left Handle (b) 1
44 Clinch Bolt 3
45 Base 1
46 Scale Ring 1
47 1/4" Collet Chuck (not shown) 1
48 3/8" Collet Chuck (not shown) 1
50 Spindle Wrench (not shown) 1
51 Collet Nut Wrench (not shown) 1
Parts List
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 13For technical questions, please call 1-800-444-3353.SKU 68341
Assembly Diagram

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship
for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity,
improper installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages arising from the use
of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection veries the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specic legal rights and you may also have other rights which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
