Triton TMNRTR Assembly instructions

Version date: 07.11.22
tritontools.com
TMNRTR
880W Trimmer Router
1/4"/ 8mm
Operating & Safety Instructions
Bedienings- en
veiligheidsvoorschriften
Instructions d’utilisation
et consignes de sécurité
Instrucciones de
uso y de seguridad
Instrukcja obsługi
i bezpieczeństwa
Sicherheits- und
Bedienungsanleitung
Instruções de
Operação e Segurança
Инструкции по эксплуатации и
правила техники безопасности
Istruzioni per l’uso
e la sicurezza
817698_OwnerManual.indd 1817698_OwnerManual.indd 1 11/11/2022 10:2211/11/2022 10:22

2
7
8
9 1
2
3
4
5
6
10
11
12 13 14
16
17
18
12
15
UK
EU
817698_OwnerManual.indd 2817698_OwnerManual.indd 2 11/11/2022 10:2311/11/2022 10:23

3
10 11
22
9 19 20
21
22
23 24
2525 2627
12
16
17
18
12
817698_OwnerManual.indd 3817698_OwnerManual.indd 3 11/11/2022 10:2311/11/2022 10:23

4
EN
25
29
31
33 34 3532
30 28
817698_OwnerManual.indd 4817698_OwnerManual.indd 4 11/11/2022 10:2311/11/2022 10:23

5
EN
43
44 45 36
37
8
8
37
38
38
39
46
7
42
41
40
817698_OwnerManual.indd 5817698_OwnerManual.indd 5 11/11/2022 10:2311/11/2022 10:23

6
EN
Fig. II
Fig. I
Fig. III
47
36
45
43
48
28 9 18
48
17 32
16 1617
52
817698_OwnerManual.indd 6817698_OwnerManual.indd 6 11/11/2022 10:2311/11/2022 10:23

7
EN
0
1
2
3
4
5
Fig. IV
Fig. V
A
33
5
33
6
49
50 51 4
B
Fig. VI
817698_OwnerManual.indd 7817698_OwnerManual.indd 7 11/11/2022 10:2311/11/2022 10:23

8
Fig. X
Fig. XI
Fig. IX
2
3
41
Fig. VII
130mm
0mm
130mm
Fig. VIII
47
7
43
44
817698_OwnerManual.indd 8817698_OwnerManual.indd 8 11/11/2022 10:2311/11/2022 10:23

9
!
Fig. XIII
Fig. XIV Fig. XV
Fig. XII
AB C D
817698_OwnerManual.indd 9817698_OwnerManual.indd 9 11/11/2022 10:2411/11/2022 10:24

10
Fig. XVI
Fig. XVIII
Fig. XIX Fig. XX
Fig. XVII
7
43
42
41
40
817698_OwnerManual.indd 10817698_OwnerManual.indd 10 11/11/2022 10:2411/11/2022 10:24

11
49mm
59mm
49mm
66mm
100mm
53mm
83mm
120m
m
Fig. XXV
Fig. XXIV
Fig. XXIII
Fig. XXI Fig. XXII
43
a
b
c
49
48
a
b
817698_OwnerManual.indd 11817698_OwnerManual.indd 11 11/11/2022 10:2411/11/2022 10:24

12
EN
VVolts
~, a.c. Alternating current
A, mA Ampere, milli-Amp
n0No load speed
nRated speed
°Degrees
ØDiameter
Hz Hertz
W, kW Watt, kilowatt
/min or min-1 Operations per minute
dB(A) Decibel sound level (A weighted)
m/s² Metres per second squared
(vibration magnitude)
Technical Abbreviations Key
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction manual
DO NOTuse in rain or damp environments!
WARNING: Moving parts can cause crush and cut
injuries.
Toxic fumes or gases!
WARNING: Sharp blades or teeth!
Class II construction (double insulated for additional
protection)
Environmental Protection
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
Conforms to relevant legislation and safety standards.
Caution!
Description of Symbols
The rating plate on your tool may show symbols. These represent
important information about the product or instructions on its use.
Specication
Model no: TMNRTR
Voltage: 220-240 V, 50/60 Hz
Power: 880W
No load speed: 11,500-31,000min-1
6 speed setting (1-6): 1) 11,500min-1
2) 16,500min-1
3) 21,000min-1
4) 25,000min-1
5) 29,000min-1
6) 31,000min-1
Collets: 1⁄4"& 8mm
Thank you for purchasing this Triton tool.This manual contains
information necessary for safe and effective operation of this
product.This product has unique features and, even if you are
familiar with similar products, it is necessary to read this manual
carefully to ensure you fully understand the instructions.Ensure all
users of the tool read and fully understand this manual.
Original Instructions
Introduction Be aware of kickback!
Always disconnect from the power supply when
adjusting, changing accessories, cleaning, carrying out
maintenance and when not in use!
Do not touch the blades before the tool is disconnected
from the supply and the blades have come to complete
stop
817698_OwnerManual.indd 12817698_OwnerManual.indd 12 11/11/2022 10:2411/11/2022 10:24

13
EN
WARNING: Always wear ear protection where the sound level
exceeds 85dB(A) and limit the time of exposure if necessary. If
sound levels are uncomfortable, even with ear protection, stop
using the tool immediately and check the ear protection is correctly
tted and provides the correct level of sound attenuation for the
level of sound produced by your tool.
WARNING: User exposure to tool vibration can result in loss
of sense of touch, numbness,tingling and reduced ability to grip.
Long-term exposure can lead to a chronic condition.If necessary,
limit the length of time exposed to vibration and use anti-vibration
gloves. Do not operate the tool with hands below a normal
comfortable temperature, as vibration will have a greater effect.
Use the gures provided in the specication relating to vibration to
calculate the duration and frequency of operating the tool.
Sound and vibration levels in the specication are determined
according to international standards. The gures represent normal
use for the tool in normal working conditions. A poorly maintained,
incorrectly assembled,or misused tool, may produce increased
levels of noise and vibration. www.osha.europa.eu provides
information on sound and vibration levels in the workplace that
may be useful to domestic users who use tools for long periods
of time.
The declared vibration total value has been measured in
accordance with a standard test method and may be used for
comparing one tool with another. The declared vibration total value
may also be used in a preliminary assessment of exposure.
WARNING: The vibration emission during actual use of the
power tool can differ from the declared total value depending on
the ways in which the tool is used. There is the need to identify
safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the times when
the tool is switched off and when it is running idle in addition to
the trigger time).
Carefully read and understand this manual and any label attached
to the tool before use. Keep these instructions with the product for
future reference. Ensure all persons who use this product are fully
acquainted with this manual.
Even when used as prescribed it is not possible to eliminate all
residual risk factors. Use with caution. If you are at all unsure of the
correct and safe manner in which to use this tool, do not attempt
to use it.
General Power Tool Safety Warnings
WARNING: Read all safety warnings, instructions,
illustrations and specications provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless) power
tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres, such
as in the presence of ammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
Max cutter diameter: 30mm
Max cutter shank: 8mm
Plunge adjustment: 1) Free plunge
2) Table height winder
3) Micro winder
Plunge range: 0-40mm
Parallel fence range: 0-130mm
Fence rod diameter: 8mm
Dust extraction port
dimensions:
Inner:
Outer: 35mm
40mm
Insulation class:
Cord length: 3m
Ingress protection: IP20
Dimensions (L x W x H):
with plunge base: 290 x 280 x 150mm
with trimmer base: 260 x 150 x 96mm
no base: 245 x 80 x 125mm
Weight: 2.9kg
As part of our ongoing product development, specications of
Triton products
may alter without notice.
Sound & vibration information
Sound pressure LPA 85dB(A)
Sound power LWA 96dB(A)
Uncertainty K 3dB
Weighted vibration ah6.167m/s²
Uncertainty K 1.5m/s²
The sound intensity level for the operator may exceed 85dB(A)
and sound protection measures are necessary.
817698_OwnerManual.indd 13817698_OwnerManual.indd 13 11/11/2022 10:2511/11/2022 10:25

14
EN
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
g) Use proper extension cord. Make sure your extension cord
is in good condition. When using an extension cord, be
sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.
3) Personal safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
OFF-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your nger on the switch or energising power tools
that have the switch ON invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool ON. A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it ON
and OFF. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove
the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power
tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g) Use the power tool, accessories and tool bits, etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed. Use
of the power tool for operations different from those intended
could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces
do not allow for safe handling and control of the tool in
unexpected situations.
5) Service
a) Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
Additional Safety for Routers
WARNING:
• Hold the power tool by insulated gripping surfaces only,
because the cutter may contact its own cord. Cutting a “live”
wire may make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
• Use clamps or another practical way to secure and support
the workpiece to a stable platform. Holding the work by your
hand or against the body leaves it unstable and may lead to loss
of control.
• If the replacement of the supply cord is necessary, this has
to be done by the manufacturer or his agent in order to
avoid a safety hazard.
• It is strongly recommended that the tool always be
supplied via a residual current device with a rated residual
current of 30 mA or less.
817698_OwnerManual.indd 14817698_OwnerManual.indd 14 11/11/2022 10:2511/11/2022 10:25

15
EN
a) Use safety equipment including safety goggles or shield,
ear protection, dust mask and protective clothing including
safety gloves
b) Cloths, cord, string etc should never be left around the
work area
c) Ensure the mains supply voltage is the same as the tool
rating plate voltage
d) Ensure any cable extensions used with this tool are in
a safe electrical condition, and have the correct ampere
rating for the tool
e) Completely unwind cable drum extensions to avoid
potential overheating
f) Use appropriate detectors to determine if utility cables or
pipes are below the surface of the work area. Consult utility
companies for assistance if necessary. Contact with electric
cables can lead to electric shock and re. Damaging a gas pipe
can lead to explosion. Contact with water lines can lead to major
property damage
g) Ensure embedded objects such as nails and screws have
been removed from the workpiece before commencing
operation
h) Handle router bits with care as they can be extremely sharp
i) Before use, check the bit carefully for signs of damage or
cracks. Replace damaged or cracked bits immediately
j) Ensure router cutters/bits are sharp and maintained
correctly. Dull cutting edges can lead to uncontrolled situations
including stalling, increased heat and possible injury
k) ALWAYS use both handles and maintain a rm grip on the
router before proceeding with any work
l) Keep handles and gripping surfaces dry, clean and free of
oil and grease to ensure the tool can be securely held in
use
m) Before using the tool to make a cut, switch on and let it run
for a while. Vibration could indicate an improperly installed bit
n) Take notice of the direction of rotation of the bit and the
direction of feed
o) Keep your hands away from the routing area and router
bit cutter. Hold the auxiliary handle or an insulated gripping
surface with your second hand
p) NEVER start the router while the cutter is touching the
workpiece
q) Ensure the plunge spring is always tted when using hand-
held
r) Ensure the cutter has completely stopped before plunging
to the collet lock position
s) The maximum speed of the router bit/cutter must be at
least as high as the maximum speed of the power tool
t) Parts of the router bits may become hot during operation.
Do not handle immediately after use to avoid risk of burns
u) Do not allow parts to come into contact with combustible
materials
v) The shank size of the router cutter/bit must be matched
to the exact same size collet tted to the router. Incorrectly
tted router cutter/bits will rotate irregularly and have increased
vibration that could lead to loss of control
w) DO NOT press the spindle lock button, or attempt to switch
the tool into bit change mode while the router is operating
x) Keep pressure constant while cutting into the workpiece,
allowing the router bit cutter to dictate the speed of cut. DO
NOTforce the tool and overload the motor
y) Ensure rating labels and safety warnings on the tool
remain clear to read and are replaced if marked or
damaged
z) When operating the router, be prepared for the router bit
cutter stalling in the workpiece and causing loss of control.
Always ensure the router is rmly held and the on/off switch is
immediately released in such circumstances
• After switching on the router, check the router bit is
rotating evenly (not ‘wobbling’) and there is no additional
vibration due to the router bit being incorrectly tted.
Operating the router with an incorrectly tted router bit can lead
to loss of control and severe injury
• EXTREME care must be taken when using cutters with a
diameter greater than 2"(50mm). Use very slow feed rates
and/or multiple shallow cuts to avoid overloading the motor
• ALWAYS switch off and wait until the bit has come to a
complete standstill before removing the machine from the
workpiece
• Disconnect from the power supply before carrying out any
adjustment, servicing or maintenance
WARNING: Dust generated by using power tools can be toxic.
Some materials may be chemically treated or coated and be a
toxic hazard.Some natural and composite materials may contain
toxic chemicals. Some older paints may contain lead and other
chemicals.Avoid prolonged exposure to dust generated from
operating a router. DO NOT allow dust to get onto skin or eyes and
do not allow the dust to enter your mouth to prevent absorption
of harmful chemicals. Where possible, work in a well-ventilated
area. Use a suitable dust mask and dust extraction system where
possible.Where there is a higher frequency of exposure, it is more
critical that all safety precautions are followed and a higher level of
personal protection is used.
Product Familiarisation
1. Router
2. Spanner
3. Collet
4. Hex Key
5. Guide Rails
6. Guide Fence
7. Roller Guide
8. Trimmer Base
9. Plunge Base
10. ON/OFF Switch
11. Speed Dial
12. Brush Access Covers
13. Motor Vents
14. Power Cord
15. Power Plug
16. Spindle Lock Button
17. Collet Nut
18. Securing Hole
19. Dust Extraction Spout
20. Micro Winder
21. Micro Adjustment Guide
22. Handle
817698_OwnerManual.indd 15817698_OwnerManual.indd 15 11/11/2022 10:2511/11/2022 10:25

16
EN
23. Guide Rail Slot
24. Plunge Lock Lever
25. Guide Rail Locking Knob
26. Base of Plunge Base
27. Plunge Base Plate
28. Plunge Base Locking Knob
29. Depth Stop Lock
30. Depth Stop
31. Depth Turret
32. Table Height Micro Winder Connector
33. Guide Bush Locking Screw
34. Dust Extraction Spout Connection Screw
35. Plunge Base Plate Screw
36. Trimmer Base Locking Knob
37. Trimmer Depth Locking Knob
38. Trimmer Base Plate
39. Trimmer Base Plate Screw
40. Guide Bearing
41. Roller Guide Adjustment Locking Knob
42. Roller Guide Adjustment Knob
43. Roller Guide Locking Knob
44. Washer
45. Trimmer Base Guard
46. Trimmer Depth MicroAdjustment Dial
47. Roller Guide Alignment Channel
48. Router Bit (not supplied)
49. Guide Bush (not supplied)
50. Spring Washer
51. Hex Screw
52. Table Height Winder
Figures XII and XIII
a Template
b Workpiece
c Offset
Intended Use
A mains-powered mini router intended for routing proles, edges,
grooves, holes and for copy routing in plastic, light building
materials, and wood. Predominantly for hand held use.
Note: Not intended for commercial use.
Unpacking Your Product
• Carefully unpack and inspect your product. Fully familiarise
yourself with all its features and functions
• Ensure all parts of the product are present and in good
condition
• If any parts are missing or damaged, have such parts replaced
before attempting to use this product
Before Use
WARNING: Ensure the tool is disconnected from the power
supply before attaching/changing any accessories or making any
adjustments.
Collet & router bit installation
WARNING: Wear protective gloves when inserting and
removing router bits due to the sharp edges of the cutters.
WARNING: Always use cutters and bits with the correct size
shank for the chosen collet size.
Note: It is easiest to install a cutter prior to tting the router to a
base; however, it is possible to change the Router Bit (not supplied)
(48) when attached to a base.
See Fig. I
1. Press the Spindle Lock Button (16) then rotate the Collet Nut
(17) until the spindle lock engages
2. Slacken the Collet Nut, using the supplied Spanner (2) if
required,and remove the Collet Nut
3. Ensure the correct size Collet is chosen to match the required
Router Bit (48) then place the Collet into the spindle, then
reapply the Collet Nut
4. With the correct Collet in place and Collet Nut attached but
slackened,insert the Router Bit into the Collet, ensuring that at
least half of the Router Bit’s shaft is inserted
5. Tighten the Collet Nut with the Spanner, ensuring that the
Router Bit cutter has 1-2mm clearance from the Collet and is not
butted tight against the Collet or the Collet Nut; vibration from
the cutter could vibrate the Collet Nut and cause it to loosen
during use
WARNING: DO NOTover-tighten the Collet Nut! This could
cause damage to the Collet,Collet Nut, external thread and Spindle
Lock.
Note: Do not tighten the Collet Nut with no Router Bit tted. This
can bend and damage the Collet.Keep the Collet Nut partially
screwed in until a Router Bit is tted. Be aware of the spring in the
spindle that keeps pressure on the Collet up against the Collet Nut.
When installing the Collet,a small amount of pressure is required
when applying the Collet Nut to the spindle drive thread.
6. To remove a Router Bit,engage the Spindle Lock by pressing
the Spindle Lock Button then slacken the Collet Nut with the
Spanner
7. With the Collet Nut sufciently slackened, the Router Bit can be
removed
WARNING: ALWAYS keep the Collet, Collet Nut, spindle drive
thread and Router Bit shank clean and free of oil and grease to
ensure a reliable and secure tting.
Fitting to plunge base
Note: If the Router (1) is attached to the Trimmer Base (8), remove
the Trimmer Base before attempting to t the router to the Plunge
Base (9).
1. Ensure the Plunge Base Locking Knob (28) is wound out so the
screw is not protruding into the base
2. Align the Router (1) so the Securing Hole (18) is directly above
the Plunge Base Locking Knob (Fig. II)
817698_OwnerManual.indd 16817698_OwnerManual.indd 16 11/11/2022 10:2511/11/2022 10:25

17
EN
3. Place the Router into the cradle of the Plunge Base
4. Tighten the Plunge Base Locking Knob (Fig. II) to secure the
Router in the Plunge Base
Dust extraction
IMPORTANT: Dust from certain materials can be toxic. Before using
the Router (1), attach a dust extraction system or vacuum cleaner to
the Dust Extraction Spout (19) (Fig. III), which is tted to the Plunge
Base (9), and ALWAYS wear respiratory protection. If no workshop
dust extraction system is available when using the Plunge Base,
clean and vacuum frequently to prevent the build-up of dust and
chippings.
Note: The Dust Extraction Spout can be removed,if required, by
unscrewing the two Dust Extraction Spout Connection Screws (34).
This will allow better access to cleaning hard-to-get-at places on the
Plunge Base when cleaning.
Adjusting the depth of cut
There are two ways to adjust the depth of cut:
• Free Plunge, for conventional and fast depth adjustment
• Micro Adjuster, for precise depth setting throughout the full
plunge range
Free plunge
1. With a chosen Router Bit (48) tted and the Router (1) attached
to the Plunge Base (9), disengage the Plunge Lock Lever (24)
(Fig. IV)
2. Using the Handles (22), plunge the router down to the required
plunge depth
3. Engage the Plunge Lock Lever to lock the router at the required
depth
Micro adjuster
1. With a chosen Router Bit (48) tted and the Router (1) attached
to the Plunge Base (9), disengage the Plunge Lock Lever (24)
(Fig. IV)
2. Turn the Micro Winder (20) until the router bit is at the depth
required
Note: Turn clockwise to increase cut depth and anti-clockwise to
reduce cut depth.A full revolution of the Micro Winder is a depth
adjustment of 1.5mm (1⁄16"). The Micro Adjustment Guide (21) can
be used to set a point of reference when gauging a full revolution.
3. Engage the Plunge Lock Lever when the router is at the required
depth, particularly for heavy cuts
Depth stop & turret
• The Depth Stop Lock (29) and Depth Turret (31) enable accurate
pre-setting of three different cut depths,each stepped at 5mm
(3⁄64") (Fig. IV)
Zeroing the router:
1. With a chosen Router Bit (48) tted and the Router (1) attached
to the Plunge Base (9), place the Router on a at surface then
disengage the Plunge Lock Lever (24) (Fig. IV)
2. Rotate the Depth Turret (31) until the 0 step is beneath the
Depth Stop (30)
3. Disengage the Depth Stop Lock (29) to release the Depth Stop
4. Plunge the Router down until the tip of the Router Bit touches
the at surface
5. Engage the Depth Stop Lock so the Depth Stop is locked in its
current position
Adjusting the depth turret:
• The Depth Turret (31) allows 3 different plunge depths to be
congured for fast switching during use: 5mm, 10mm and
15mm (3⁄64 x 25⁄64 x 19⁄32")
• This can speed up operations or allow a 3-cut approach to
reaching the nal required depth of cut
• Using the Depth Turret is particularly important when the
workpiece is more difcult to cut, i.e. harder wood or when a
better nish is required
• If the Depth Turret becomes loose, tighten the screw in the
centre
1. After zeroing the router (see “Zeroing the router”), the secured
Depth Stop (30) now provides an accurate datum and the depth
of cut can be set by reference to the graduations etched into the
face of each depth on the Depth Turret (31) (Fig. IV)
2. Rotate the Depth Turret to the required depth
Custom depth using the depth stop
• The scale on the face of the Depth Stop (30) can be used to
make adjustments to the Depth Stop after the router has been
zeroed (see “Zeroing the router”)
1. After zeroing the router on one of the turret stops, plunge the
router to the zero depth and ensure the Plunge Lock Lever (24)
is engaged
2. Loosen the Depth Stop Lock and raise the Depth Stop to
required depth then retighten the Depth Stop Lock to set the
new plunge depth
Notes:
• The exact depth required for a particular task, such as a hinge
leaf, can be achieved by placing the object/material of required
plunge depth between the Depth Stop and the Depth Turret
before locking the Depth Stop Lock. The plunge will now be the
precise depth required for the object/material
• The gap between the end of the Depth Stop and the Turret Stop
(31) will be the plunge depth
• The scale on the Depth Stop can be used to check changes in
depth setting,but the actual cutting depth is best measured by
making a trial cut on scrap material.The scale should be used as
an approximate guide
Fitting a guide bush for use with templates & jigs
See Fig.V
• An optional template guide bush kit is available for purchase
from your Triton stockist
1. To install a Guide Bush (not supplied) (49), loosen the Guide
Bush Locking Screws (33) and ensure the rotating tabs are
rotated away from the guide bush
2. Line the notches on the Guide Bush with the Guide Bush
Locking Screws so that the guide bush sits centre and ush
against the Plunge Base Plate (27)
3. Rotate the tabs on the Guide Bush Locking Screws over the
notches on the Guide Bush then tighten the screws to secure
the Guide Bush
4. To remove the Guide Bush, loosen the screws, rotate the tabs
then remove the Guide Bush before retightening the Guide
Bush Locking Screws
817698_OwnerManual.indd 17817698_OwnerManual.indd 17 11/11/2022 10:2511/11/2022 10:25

18
EN
Fitting & adjusting the guide fence
See Fig.VI,VII,VIII
Note: The Guide Fence (6) is for use with the Plunge Base (9) only
• The Guide Fence (6) can be assembled according to ‘A’ or ‘B’
(Fig. VI)
• Ensure the scale on one of the Guide Rails (5) is facing up when
tightening the Hex Screws (51)
1. To t the Guide Fence, loosen the Guide Rail Locking Knobs
(25) and insert the Guide Rails of the assembled fence into the
Guide Rail Slots (23) (Fig. VII)
2. Adjust the Guide Fence to the required distance from the cutter
(Fig. VII), using the scale as an approximate guide (Fig. VIII) if
used in conguration A, and measured if used in
conguration B
3. Ensure all Guide Rail Locking Knobs are tightened to secure the
Guide Fence
• If required, faces on the Guide Fence can be removed and a
batten can be attached to ensure a completely straight Guide
Fence. Always measure to the centre point of the cutter to
ensure an accurate cut
Beam trammel
• The diameter of the Guide Rail (5) is 8mm (5⁄16")
• A compatible 8mm beam trammel (not supplied) could be tted
to one of the rails and the rail could then be tted into one of
the Guide Rail Slots (23)
Table use
• When the Router (1) is tted to the Plunge Base (9) it can be
used in a compatible router table
• See Fig. XXIV for the dimensions of the Plunge Base Plate
Screws (35) for securing to a compatible table
• The Plunge Base Plate (27) can be removed to allow tment
to a compatible template or bracket.Consult the router table
manufacturer’s installation instructions
• The Plunge Base has a Table Height Micro Winder Connector
(32) that will allow above-table cutter height adjustment with a
Triton Table Height Winder (52), if the table has an access hole
Fitting to trimmer base
See Fig. IX
Note: If the Router (1) is attached to the Plunge Base (9), remove
the Plunge Base before attempting to t the router to the Trimmer
Base (8).
1. Ensure the Timmer Base Locking Knob (36) is wound out so the
screw is not protruding into the base
2. Align the Router (1) so the Securing Hole (18) is directly above
the Trimmer Base Locking Knob (Fig. IX)
3. Place the Router into the cradle of the Trimmer Base
4. Tighten the Trimmer Base Locking Knob (Fig. IX) to secure the
Router in the Trimmer Base
Setting the depth of cut with the trimmer base
See Fig.X
1. Loosen the Trimmer Depth Locking Knob (37)
2. Turn the Trimmer Depth Micro Adjustment Dial (46) to adjust
the cutter height to the required depth
3. Lock the Trimmer Depth Locking Knob to secure the depth
Fitting & adjusting the roller guide
Notes:
• Lateral clearance: to adjust the amount of material removed
by the cutter, adjust the horizontal clearance between the
workpiece and the Guide Bearing
• Height: adjust the vertical height of the cutter depending on the
thickness of the material to be cut and the router bit to be used
See Fig.XI and XII
1. To t the Roller Guide (7) to the Trimmer Base (8), loosen the
Roller Guide Locking Knob (43)
2. Slide the Roller Guide onto the Trimmer Base, ensuring the
guide is aligned with the Roller Guide Alignment Channel (47)
(Fig. XI) and the Washer (44) is on the outside of the Roller
Guide
3. Adjust the Roller Guide to the required height then tighten the
Roller Guide Locking Knob to secure the roller guide (Fig. XII)
4. To adjust the Guide Bearing’s (40) horizontal position, loosen
the Roller Guide Adjustment Locking Knob (41) then adjust with
the Roller Guide Adjustment Knob (42) (Fig. XII)
5. Tighten the Roller Guide Adjustment Locking Knob to secure the
Guide Bearing in place
Operation
WARNING: Ensure the tool is disconnected from the power
supply before attaching/changing any accessories or making any
adjustments.
WARNING: ALWAYS wear eye protection, adequate respiratory
and hearing protection, as well as suitable gloves when working
with this tool.
IMPORTANT: Ensure the Motor Vents (13) and other vents of the
tool are kept clean. Metallic swarf, breglass, plaster and other
particles and dust can damage the tool if allowed to enter the
Motor Vents. Use a vacuum cleaner to ensure the vents are clean. If
necessary, blow out with compressed air.
Switching ON & OFF
1. To power the Router (1) ON, press the ON/OFF Switch (10) to the
‘I’ position
2. To power the Router OFF, press the ON/OFF Switch to the ‘O’
position
3. Always allow the tool to reach full speed before making a cut
Variable speed control
WARNING: NEVER operate router bits at speeds higher than
their maximum rated speed. If bits are used at higher speeds
than their rated speed, they can break and y apart, potentially
damaging the tool, workpiece and causing serious personal injury.
• Control the rotation speed of the cutter by adjusting the Speed
Dial (11)
• The highest speed is achieved when the number is set to 6
• The lowest speed is achieved when the number is set to 1
• Set the ideal speed for the material; consider the material and
bit diameter
• Too slow a speed can result in the cutter leaving burn marks on
the material
817698_OwnerManual.indd 18817698_OwnerManual.indd 18 11/11/2022 10:2511/11/2022 10:25

19
EN
• See table below for the number to speed relationship on the
dial and usage information
Number RPM Usage
111,500 Bits and cutters
with a larger
diameter
216,500
321,000
425,000 Bits and cutters
with a smaller
diameter.
Laminates, plastics
and softwoods
529,000
631,000
IMPORTANT: Operating at reduced speed increases the risk of
damage to the Router (1) as a result of overload. Use very slow feed
rates and/or multiple shallow cuts.
Hand-held operation
WARNING: To minimise the risk of kickback, the direction of
routing must always be in opposition to the cutter’s rotational
direction.
Notes:
• Ensure all PPE/safety equipment is used when operating this
tool
• Ensure the workpiece is securely clamped to prevent any
movement during operation
• Hold the Router (1) rmly using both hands to control the
Router and keep an even pressure and movement when cutting
• The cutter rotates in a clockwise direction (A on Fig. XIII)
• When edge routing or trimming on the outside edge,ensure
the workpiece is to the left of the cutter (B and C on Fig. XIII) and
work in an anticlockwise direction
(Figs XIV, XV, XVI, XVIII, XIX, XX)
• When routing internal edges,ensure the edge to be cut is to the
left of the cutter and work around the internal shape
(D on Fig. XIII) in a clockwise direction
• If cutting all the way through the material, x a sacricial board
to the underside of the workpiece
• When edge cutting natural timbers, always pass along the end
grain rst, then by the long grain. If splintering or breakout
occurs, this will be remedied when passing down the long grain
• Do not operate the Router upside down unless securely
mounted in a well-guarded router table
• If a deep cut is required for a plunge cut, do not make the
full depth for the rst pass. Instead, make more passes with a
shallower depth of cut and adjust the cutting depth gradually
in smaller increments. The Depth Stop (30) and Depth Turret
(31) can be used for changing depths to pre-set 5mm (3⁄64")
increments
Routing with the roller guide
• Use the Timmer Base (8) and Roller Guide (7) for routing edges
with router bits without a guide bearing or pilot
• Ensure the Router (1) is installed in the Trimmer Base with
the Roller Guide (see ‘Fitting to trimmer base’ and ‘Fitting &
adjusting the roller guide’)
• Ensure the depth of cut is set as required (see ‘Setting the depth
of cut with the trimmer base’)
1. Power the Router ON then guide the Router from the side
toward the workpiece until the Guide Bearing (40) contacts the
edge of the workpiece (Figs XVI  XVII)
2. Guide the Router along the workpiece’s edge, ensuring the base
rests on the workpiece at the correct angle
IMPORTANT: When using the Trimmer Base (8) with the Roller
Guide (7), adjust the Guide Bearing (40) (Fig. XVII) with enough
vertical clearance from the cutter and consider cutter’s diameter
when setting the horizontal axis so the Guide Bearing can guide
the cutter along the edge of the workpiece.
Shaping or moulding
• If shaping or moulding without a parallel guide (Guide Fence
(6) or batten), a router bit with a guide bearing or pilot must be
used (Figs XIV  XV)
• Ensure the depth of cut is set as required (see ‘Before Use’
sections pertaining to setting the depth of cut)
1. Power the Router (1) ON then guide the Router from the side
toward the workpiece until the guide bearing on the Router Bit
(not supplied) (48) contacts the edge of the workpiece
2. Guide the Router along the workpiece’s edge, ensuring the base
rests on the workpiece at the correct angle
IMPORTANT: Excessive pressure could damage the workpiece.
Note: To prevent edge burn, clamp a sacricial piece of material
of the same thickness as the workpiece before and after the
workpiece. Start the cutting on the rst sacricial piece, guide
along onto the workpiece then beyond to nish on the other
sacricial piece. Doing this will prevent beginning burn and end
burn on the workpiece.
Routing with a parallel guide or guide fence
• Use the Guide Fence (6) assembled in conguration A or B
(Fig. VI), fastened to the Plunge Base (9) (see ‘Fitting & adjusting
the guide fence’), for edge-parallel cuts or batten-parallel cuts
(Figs XIX and XX)
• Ensure the depth of cut is set as required (see ‘Before Use’
sections pertaining to setting the depth of cut)
1. Adjust to required distance from the Guide Fence to the cutter
2. Power the Router (1) ON then guide the Router with a controlled
feed and lateral pressure along the workpiece’s edge
Routing with a batten guide
See Fig.XVIII
• A batten guide can be used when clamped on top of the
workpiece (see Fig. XXIV for distances to the edge of the bases
from the centre of the cutter as an approximate guide)
• The Guide Fence (6) in conguration B (Fig. VI) can be used with
the batten (Fig. XX)
• It is recommended that a test cut be performed on scrap
material prior to using the workpiece
Freehand routing
See Fig.XXI
• The Router (1) can be used for creative freehand or signwriting
work without the use of a guide
• Practise on scrap material before working on the workpiece
• Draw the design on the workpiece then router the design using
shallow passes
817698_OwnerManual.indd 19817698_OwnerManual.indd 19 11/11/2022 10:2511/11/2022 10:25

20
EN
Template & guide bush routing
See Fig.XXII and XXIII
• See ‘Fitting a guide bush for use with templates & jigs’
• Template patterns (Fig. XXII (a)) are used with a Guide Bush
(not supplied) (49) to allow the Router (1) to carve a pattern
in the workpiece (Fig. XXII (b)) and are used for consistent,
repeatable shapes
• When using a template and Guide Bush, the cut on the nal
workpiece will differ from the space in the template, and the
Offset (Fig. XXIII (c)) of the Guide Bush must be considered prior
to cutting
• To work out the Offset, use this formula: Offset = Guide Bush
outer diameter - Router Bit (48) diameter
• Template patterns and jigs can be made out of a variety of
materials such as hardboard, plywood, plastic or metal
Table-mounted operation
• Fitting and operating this router on a compatible router table
should be carried out in accordance with the instructions
supplied with the router table
• Ensure the Router (1) is tted to the Plunge Base (9) if using in a
compatible router table
• A Triton Table Height Winder engages with the Table Height
Micro Winder Connector (32) for quick and easy above-the-table
height adjustment when the router is table mounted, and there
is an access hole for the Height Winder
Accessories
• A full range of accessories, including router bits and guide
bushes, is available from your Triton stockist
• Spare parts can be obtained from toolsparesonline.com
Maintenance
WARNING: ALWAYS disconnect from the power supply before
carrying out any inspection, maintenance or cleaning.
General inspection
• Regularly check that all the xing screws are tight
• Prior to each use, inspect the supply cord of the tool for signs of
damage or wear. Repairs should be carried out by an authorised
Triton service centre.This advice also applies to extension cords
used with this tool
Cleaning
• Keep your tool clean at all times. Dirt and dust will cause
internal parts to wear quickly and shorten the tool’s service life
• Clean the body of the tool with a soft brush, or dry cloth. If
available, use clean, dry, compressed air to blow through the
ventilation holes
• Clean the tool casing with a soft, damp cloth using a mild
detergent. Do not use alcohol, petrol or strong cleaning agents
• Never use caustic agents to clean plastic parts
Lubrication
• All the bearings in this tool are lubricated with a sufcient
amount of high-grade lubricant for the life of the unit under
normal conditions.Therefore,no further lubrication is required
Brushes
• Over time the carbon brushes inside the motor may become
worn
• Excessively worn brushes may cause loss of power, intermittent
failure, or visible sparking
To replace the brushes (Fig. XXV):
1. Loosen the Brush Access Covers (12) with a at tip screwdriver
2. Use the screwdriver to retrieve the brushes
3. Replace both brushes by aligning the rectangular shape of the
brush with the slot then inserting
4. Replace the Brush Access Covers and tighten with a at tip
screwdriver
Note: There may be some sparking after installing new brushes
until the brushes have been bedded.This should happen normally
with short bursts of regular use.
Contact
For technical or repair service advice,please contact the helpline on
([phone]
Web: tritontools.com/en-GB/Support
UK Address:
Toolstream Ltd.
Boundary Way
Lufton Trading Estate
Yeovil, Somerset
BA22 8HZ, United Kingdom
EU Address:
Toolstream B.V.
De Keten
00004
5651 GJ
Eindhoven, Netherlands
Storage
• Store this tool in the supplied case,in a secure, dry location out
of the reach of children
Disposal
Always adhere to national regulations when disposing of power
tools that are no longer functional and are not viable for repair.
• Do not dispose of power tools, or other waste electrical and
electronic equipment (WEEE) with household waste
• Contact your local waste disposal authority for information on
the correct way to dispose of power tools
817698_OwnerManual.indd 20817698_OwnerManual.indd 20 11/11/2022 10:2511/11/2022 10:25
