S1 Steel Wheelchair
(CS1142SPMAG, CS1142T)
Instructions for use

Page 2 of 12S1 Steel Wheelchair (Issued 2021-08 rev1)
introduction
The S1 steel wheelchairs are intended to assist the transport of users
with mobility diculties. These wheelchairs are designed for occasional
or frequent use, and can be used indoors and outdoors, but should not
be used on rough terrain. Over-loading the wheelchairs is the only
known contraindication, although others may be specific to an individual
or care environment.
The wheelchair can be manually moved forward and in reverse. The
wheelchair is available as either a transit model, or a mag wheel self
propel model to be operated by the wheelchair user. The wheelchair
has a steel frame which can support users of up to 115 kg (18 stone).
parts description
SIDE
PANEL
FOOT
REST
FRONT
CASTOR
HEEL
STRAP
CALF
STRAP
REAR
TRANSIT
WHEEL
PUSH
HANDLE
BACKREST ARM REST
SELF PROPEL
MAG WHEEL
PARKING
BRAKE
STEPPER
TUBE
Self Propel model
18” (CS1142SPMAG)
Transit model
18” (CS1142T)

S1 Steel Wheelchair (Issued 2021-08 rev1) Page 3 of 12
symbolspreparing for use
These instructions should be read carefully before using the wheelchair.
This product does not have a service manual. The only parts for user
assembly are the footrests.
A risk assessment must also be performed to assess suitability of the device
for the user. This assessment should include, but not be limited to:
• Small adults (and children)
• Users (and attendants) who lack capacity
• Very active occupants
• Unauthorised access to the wheelchair
Independent users and attendants are responsible for determining that they
are both mentally and physically capable of using the wheelchair with
minimal risk of harm.
Maximum occupant mass
Exceeding the maximum occupant mass marked on your device can damage
the product and put users at risk of harm.
Remove all packaging and stand the wheelchair on the ground. Separate the
arm rests to open the wheelchair, then push down firmly. Once the seat is
secure, the backrest is upright and the footrests are attached (see overleaf),
the wheelchair is ready for use.
!
Warning
This wheelchair must not be used as a seat in a motor vehicle.
Users should always transfer to the vehicle's seat and the
wheelchair should be safely stowed away.

S1 Steel Wheelchair (Issued 2021-08 rev1) Page 4 of 12
footrest adjustment
To fit the footrests, place each
footrest on the two receiver
posts on the frame. Then swing
the footrest inwards until it locks
in position.
To remove, press the chrome
lever whilst swinging the
footrest out (as shown right).
For optimum comfort it is
important to attain the correct
leg position.
To adjust the height of the
footrests, press the brass
push buttons (right) and adjust
the footplates to the desired height. Release
the buttons and keep adjusting the footplate
until it locks in position with an audible click.
Adjusting
the footrest
!
Common misuse
Do not stand on the footrests. Overloading can damage the
product and cause harm to the occupant.

S1 Steel Wheelchair (Issued 2021-08 rev1) Page 5 of 12
brake operation
Parking Brakes
To apply the parking brakes, push the handle
on the brake unit until locked in place. To
release the brake, push the handle in the
opposite direction. The brakes should always
be applied when the wheelchair is stationary.
Note: The brake on your wheelchair model
may be visually dierent from that shown.
Operating
parking
brakes

Page 6 of 12S1 Steel Wheelchair (Issued 2021-08 rev1)
transfer and use
!
Before using the wheelchair, read the safety notices below;
• Do not exceed the 10º maximum gradient. Use slow speeds
and do not reverse down a gradient.
• Do not use on escalators.
• The wheelchair is only suitable for single occupancy.
• Keep your feet on the footrests when moving. Do not stand on
the footrests.
• Ensure that fingers and objects do not get caught in the wheel
spokes or any other moving parts during use and assembly.
• Maintain proper balance at all times. Users should not move
their centre of gravity out of the seating area.
• Do not reach for items further than your arm’s length.
• Parking brakes should always be applied when transferring.
• Be aware of hazards in your environment, such as narrow
doorways, steps, household appliances, children’s toys, etc.
• A risk assessment must be performed by a competent person
to ensure the wheelchair is suitable for the user. We
recommend you consult a healthcare professional before using
any assistive medical devices.
• Keep away from heating and ignition sources which may raise
surface temperatures or cause a fire.
Transfer: When transferring in and out of the seat, move the seats as
close as possible to each other. Parking brakes should always be engaged
during transfer and attendants should fold away footrests. If users need to be
lifted out of a seat, attendants are responsible for being suitably trained and
competent to lift occupants with minimal risk of harm. Good health and safety
practice must always be used.
Propelling: Attendants should push from behind using the handgrips, and
following the safety advice above. Wheelchairs with transit wheels can only be
propelled by attendants. Models with self propel wheels can also be propelled
by wheelchair users, pushing the handrims on the rear wheels. To slow down,
apply reverse pressure to the push handles or handrims.
When stationary, the brakes should always be applied.

Page 7 of 12S1 Steel Wheelchair (Issued 2021-08 rev1)
steep terrain, kerbs and steps
Steep terrain: These wheelchairs are not designed for use on gradients
beyond 10°. When on a slope, avoid swerving or sudden changes in movement.
Over kerbs: Attendants push down on the stepper tube with a foot to raise
the front castors (when mounting a kerb for example).
To mount, approach the kerb head-on. Then the attendant uses the stepper
tube to raise the front castors, and lowers the front castors on the raised kerb.
Finally the attendant should push the wheelchair forward, lifting it up slightly to
mount the kerb if required.
To go down, line up the front castors with the edge of the kerb. The attendant
uses the stepper tube to raise the front castors and tip the user slightly back.
Keeping the castors raised, slowly lower the wheelchair down the kerb.
using a wheelchair belt
Belts are often used to restrain wheelchair occupants during normal use.
However, belts are not necessary parts of this device. Any belts used should
be adjusted to suit each user. When fastened, they should be tight without
causing discomfort or undue pressure. Belts may not be suitable for all users.
Seek professional medical advice before using a wheelchair belt.
!
Common misuse
Do not lean or push down on the push handles, as this can
damage the wheelchair.
!
Warning
When going down a kerb, the front castors must be raised to
prevent the user from falling out. The above are only
recommendations and may not be suitable for all events.
Multiple steps: The wheelchair is not designed to mount staircases, so may
require carrying if no elevators or ramps are available. Attendants are
responsible for being suitably trained and competent to lift the wheelchair with
minimal risk of harm. Do not carry using the handles or any removable sections.

Page 8 of 12S1 Steel Wheelchair (Issued 2021-08 rev1)
folding and storage
This wheelchair is easily foldable to minimise storage space required. The
foot rests may be either be folded up and swung outwards, or removed by
following the steps in footrest adjustment.
Once the footrests have been moved, fold the wheelchair by grabbing the
centre of the front and rear edges of the seat sling. Pull upwards on the seat
canvas and the wheelchair should naturally fold.
Please note though that the wheelchair may be too heavy for some users to
lift. Also be sure to adopt the latest health and safety recommendations when
lifting the wheelchair.
Note: The wheelchair may be folded and stored in a motor vehicle.
The wheelchair should be stored in a dry environment, away from direct
sunlight. If wheels are attached, store with the parking brakes on.

S1 Steel Wheelchair (Issued 2021-08 rev1) Page 9 of 12
care and maintenance
Do not use a damaged or badly worn wheelchair. Users should routinely check for
any malfunctions or changes in performance. Contact Drive DeVilbiss Healthcare
Ltd or your provider to replace damaged or worn parts.
• Brakes and tyres should be checked before each use, and at least once a month.
Slightly loosen and tighten the lock nut on the axle to correct any side play.
• The wheelchair should be kept dust free and cleaned at least once a week.
Upholstery and tyres can be cleaned with a damp cloth and mild soap solution.
Avoid neat bleach or abrasive surface cleaners. Leave to fully dry before reuse.
Metal parts should also be polished once a month with an auto wax. Replace
worn or torn upholstery promptly, as it may not support your body weight.
• Drive DeVilbiss Healthcare Ltd recommend that an approved service engineer
maintains the wheelchair annually, and these items should be repaired,
replaced, adjusted and/or lubricated if required:
•When the product has reached the end of its useful life, follow local recycling
and disposal policies.
• Tyres and castors
• Wheel bearings
•
•
Brakes
•
Footrest locking mechanism
Seat upholstery
•
•
Back upholstery
•
Arm pads
•
Rear wheel quick release pin
•
Back posts
Wheelchair folding mechanism
powerpack installation
This wheelchair is suitable for some retrofit
powerpacks, which allow the device to be
controlled electronically. (See Powerpack
example image.)
Powerpacks are not required to use the
wheelchair. The mounting position will need
adapting to be suitable for both the user and the
powerpack used. Any installed powerpack must
be used in line with the manufacturer’s instructions
for use.
For more information about powerpacks, contact
Drive DeVilbiss Healthcare Ltd or your local dealer.
Powerpack
example

Page 10 of 12S1 Steel Wheelchair (Issued 2021-08 rev1)
specification
Model Self Propel
(CS1142SPMAG)
Transit
(CS1142T)
Maximum occupant mass 115 kg 115 kg
Overall length with footrest 106 cm 88 cm
Overall width 61 cm 60 cm
Folded width 26 cm 26 cm
Total mass 18 kg 15 kg
Static stability 10° 10°
40 cm 40 cm
45 cm 45 cm
Seat surface height at front edge 50 cm 50 cm
Overall height 90 cm 91 cm
Rear wheel diameter 24” 12½”

91 cm
S1 Steel Wheelchair (Issued 2021-08 rev1) Page 11 of 12
warranty
Your Drive branded product is warranted to be free of defects in materials
and workmanship for one year from date of purchase. This device was built to
exacting standards and carefully inspected prior to shipment. This warranty is
an expression of our confidence in the materials and workmanship of our
products and our assurance to the customer.
In the event of a defect covered by this warranty, we will at our option supply
parts or replace the device. This warranty does not cover device failure due
to owner misuse or negligence, or normal wear and tear. The warranty does
not extend to non-durable components, such as rubber accessories, castors
and grips, which are subject to normal wear and need periodic replacement.
The wheelchair frame has a 5-year warranty.
If you have any queries or require full warranty conditions, please contact
your provider.
accessories and spare parts
Drive DeVilbiss Healthcare Ltd provide a steel elevating footrest with some of
these models. Other accessories and spare parts are also compatible with
wheelchairs in this range.
To order these parts, contact your provider. Visit www.drivedevilbiss.co.uk to
find your local stockist. Spare part catalogues, compatibility charts and other
documentation can also be found on this website. Only use parts approved by
Drive DeVilbiss Healthcare Ltd.

S1 Steel Wheelchair (Issued 2021-08 rev1) Page 12 of 12
support
For more information, or assistance with use and maintenance, please
contact your provider. Users with visual, reading or cognitive disabilities
should seek advice from their provider or a professional care provider for an
appropriate format. For the latest version of this document, contact Drive
DeVilbiss Healthcare Ltd using the details below, or check our website.
Any serious incident that has occurred in relation to the device should be
reported to the manufacturer and the competent authority of your Member
State. Please quote the product serial code on all correspondence, which can
be found on the wheelchair frame under the seat.
Zhenjiang Assure Medical Equipment Co., Ltd
#297 Chuqiao Road, Zhenjiang City,
Jiangsu Province, 212009 CN
Lotus NL B.V.
Koningin Julianaplein 10, le Verd,
2595AA, The Hague, NL
GB
Drive DeVilbiss Healthcare Ltd
Sidhil Business Park, Holmfield, Halifax
West Yorkshire, HX2 9TN, GB
Drive DeVilbiss Healthcare Ltd provide these
instructions for use and product markings.
[email protected]
www.drivedevilbiss.co.uk
Service & Maintenance Spares Customer Service
Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
Approved service facility
