Drive DeVilbiss Healthcare Titan AXS User manual

Titan AXS Powerchair
Instructions for use

2
CONTENTS
1. INTRODUCTION 3
2. CONTACT INFORMATION 3
3. PRODUCT DESCRIPTION 4
3.1 Environment 4
3.2 Intended User Group 4
3.3 Intended Use 4
3.4 Indications 4
3.5 Product Overview 4
4. SAFETY 5
4.1 Warnings & Cautions 5
4.2 Risk Assessment 5
4.3 Contraindications 5
4.4 Powerchair Loading 6
4.5 Training 6
4.6 General Warnings 7
5. SYMBOL DEFINITION 9
6. PARTS IDENTIFICATION 11
7. TRANSPORT & STORAGE INCLUDING ASSEMBLY 12
7.1 Assembling the Powerchair 13
8. ADJUSTMENTS FOR COMFORT 15
9. CHARGING & PREPARING FOR USE 18
9.1 Installation 18
9.2 Battery Charging 18
9.3 Checking Before Use 19
10. OPERATION OF THE TITAN AXS POWERCHAIR 20
10.1 Operational Limits 20
10.2 Control Features 20
10.3 Driving the Powerchair 23
10.4 Steps, Kerbs & Fixed Obstacles 24
10.5 Inclines 25
10.6 Outdoor Operation & Inclement Weather Precautions 26
10.7 Aer Use Instructions 26
11. CLEANING 27
12. MAINTENANCE & SERVICING 28
12.1 General Guidelines 28
12.2 Fault Detection 30
12.3 Repair 30
13. DISPOSAL OF PARTS 31
14. ELECTROMAGNETIC COMPATIBILITY EMC 32
15. SPECIFICATION 33
16. WARRANTY 34
17. MAINTENANCE SCHEDULE 35

3
1. INTRODUCTION
ank you for purchasing this product. ese instructions for use should be
read carefully and understood before operating the powerchair. Improper use or
unfamiliarity with the powerchair may result in harm, injury or trac accidents.
A maintenance schedule has also included at the back. Keep this manual with the
powerchair, or in a safe place.
Contact Drive DeVilbiss Healthcare Ltd. or check our website for the latest version of
this document. Users with visual, reading or cognitive disabilities should seek advice
from a professional care provider for an appropriate format. If this is not viable, users
should contact Drive DeVilbiss Healthcare Ltd. If you have any questions concerning
the operation or maintenance of the powerchair, contact Drive DeVilbiss Healthcare
Ltd.
If the use of the powerchair results in a serious incident, reports should be forwarded
to the manufacturer and the MHRA or local competent authority of your Member
State. Please quote the product serial code on all correspondence, which can be found
at the bottom of the frame.
For Service & Support outside the United Kingdom, please contact the local
distribution company from where this equipment was purchased. Failure to do so
may result in the product warranty becoming void.
2. CONTACT INFORMATION
For assistance in setting up, using, maintaining your powerchair, to report unexpected
operation or for any service, warranty, sales or customer service information
regarding this product, please contact Drive DeVilbiss Healthcare Ltd.
Wu´s Tech (Vietnam) Co., Ltd.
No. 31, VSIP II, Road 6, Thu Dau Mot City,
Binh Duong Province, Vietnam
Drive DeVilbiss Healthcare Ltd.
Sidhil Business Park, Holmfield, Halifax, West Yorkshire,
HX2 9TN, Great Britain
Y. Sung Handelsvertretung
Toulouser Allee 9, 40211 Duesseldorf, Germany
Drive DeVilbiss Sidhil Ltd.
4 Trench Road, Mallusk, Newtownabbey
BT36 4TY, Northern Ireland
UK Aplan Corporation Ltd.
47 Wandle Road, Croydon, Surrey, CR0 1DF, England, Great Britain

4
3. PRODUCT DESCRIPTION
3.1 Environment
e Titan Powerchair can be used in both indoor and outdoor environments where
appropriate. e Titan Powerchair can be used on at, even path surfaces, however
the user should avoid grass, gravel, gradients greater than 6° and motorised roads.
Additional care should be taken to avoid inclement weather and wet surfaces.
3.2 Intended User Group
e Titan Powerchair is intended for a single user of weight up to 136kg (21.4st). e
intended user group for this device is any mobility restricted individual that requires
assistance with transport. e patient / occupant is the only intended operator. Users
must be both mentally and physically capable of operating the device with minimal
risk of injury to themselves and others.
3.3 Intended Use
e intended use of the powerchair is to transport an end user with restricted
mobility, as dened in section 3.2.
e powerchair is intended to support a single occupant. A risk assessment must
always be performed on the suitability of the user to the powerchair.
3.4 Indications
To provide transport mobility to an end user with restricted mobility.
3.5 Product Overview
e Titan Powerchair has been designed to provide a comfortable and secure solution
for users who have mobility restrictions. e product is a class A powerchair (under
EN 12184:2014), class I medical device and class 2 invalid carriage (under e Use of
Invalid Carriages on Highways Regulations 1988).
e Titan Powerchair is designed to be suitable for extended indoor use, but with
outdoor use capabilities. For specic guidance with outdoor use, see section 10.6.
is manual is composed from the product design and specications at the time of
publication. As designs change, some illustrations and pictures in the manual may
not correspond to the powerchair that you purchased. We reserve the right to make
design modications.

5
4. SAFETY
4.1 Warnings & Cautions
Warnings in this user manual highlight potential hazards that if
disregarded could lead to injury or death.
Cautions in this user manual highlight potential hazards that if
disregarded could lead to equipment damage or failure.
4.2 Risk Assessment
Before using the powerchair, a risk assessment must be performed by a competent
individual to ensure the safe use of the powerchair on a user-by-user basis. It is
the responsibility of users and carers to determine that they are both mentally
and physically capable of operating the powerchair with minimal risk of injury to
themselves or others.
e risk assessment should include, but not be limited to:
• Entrapment
• Falling out of the powerchair
• Small adults (and children)
• Individuals who lack capacity
• Users with visual, reading or cognitive disabilities
• Very active occupants
• Unauthorised people with access to the powerchair
Caution
Warning
4.3 Contraindications
• e end user exceeds maximum weight capacity indicated in section 4.4,
• e end user has postural support needs that are not addressed by the Titan
Powerchair,
• Inability to safely operate a power mobility device.
Other contraindications may be relevant which are specic to an individual and / or
care environment.

6
4.4 Powerchair Loading
e maximum occupant mass of the Titan Powerchair is: 136kg (21.4st)
Exceeding the maximum weight capacity will void your warranty. Drive DeVilbiss
Healthcare Ltd. will not be held responsible for injury and / or damages resulting
from failure to observe weight capacities.
• e maximum load is for the powerchair to be occupied by one
person only. Additional weight could damage components or
destabilise the powerchair, potentially causing injury.
• e powerchair may only be used to transport one person at
a time. It should not be used for climbing. e backrest is not
designed to support an entire person's body weight, and the
armrests are not designed to support other individuals sitting /
leaning — risk of collapse, entrapment.
• e powerchair is not a toy. Children should not be allowed to
play near or operate the powerchair, as they are at risk of harm.
• If any ancillary attachments or accessories are being transported
in addition to the occupant the rated load of the Titan powerchair
is not to be exceeded.
Warning
4.5 Training
All individuals operating the Titan Powerchair are to be suitably familiar with the
functionality and limitations prior to use. It is the responsibility of the user to ensure they
are suitably trained to use the powerchair and any associated parts safely and correctly.
Every eort should be made to resolve deciencies and should include consideration of
retraining, falls prevention and equipment alterations and modications.
If these instructions for use are not deemed sucient and the need for training
is required, please contact Drive DeVilbiss Healthcare Ltd. (see section 2) who can
discuss training options with you.

7
• Do not use a damaged or badly worn powerchair — risk of harm.
• Check the functionality of the powerchair before every use.
Ensure the joystick and control system is responsive and free from
unintended movement. Check the current fastest speed setting is
appropriate. (It is recommended to use a slower speed setting at
the beginning of every use, gradually increasing the speed setting
as appropriate.) Ensure your lap belt is secured before operating
the powerchair.
• Do not use the powerchair in rain or snow conditions — risk of
electric shock.
• Improper storage of your powerchair may result in permanent
damage to the frame and / or electronics.
• Do not drive on grass, motorised roads or in muddy or icy
conditions.
• Reduced speed and care should be taken when navigating
obstacles.
• Do not attempt to navigate on slopes greater than 6°.
• If unintended movement of the powerchair occurs, release the
joystick to automatically stop the powerchair. If this fails, cut o
power to the powerchair.
• Under no circumstances should the powerchair be used as a seat
in a motor vehicle
• e powerchair is designed for occupants who weigh less
than 136kg; overloading may put the user at risk of falling or
entrapment.
• Do not touch any exposed contacts or connectors while using the
product or while in contact with other individuals.
• Misused electrical equipment can be hazardous.
• Do not operate the powerchair while under the inuence of
alcohol or when excessively tired.
• Do not operate the powerchair at night near roads or in situations
without a clear line of sight.
• Only approved parts, specied for the Titan Powerchair, should
be used. Accessories that have not been approved or designed
for use with the powerchair are not to be used — a hazard could
be introduced due to product combination incompatibility. If in
doubt, contact your local distributor.
4.6 General Warnings
Warning

8
• Modication of the Titan Powerchair, its parts or features is not
allowed without the permission of Drive DeVilbiss Healthcare
Ltd. — a hazard could be introduced.
• e powerchair is electrically operated, so should not be used
in the presence of ammable gases, sources of heat or naked
ames — risk of explosion / re. Damaged or worn upholstery
may reduce its resistance to ignition and should be replaced
immediately.
• Individuals unable to drive the powerchair without assistance
or supervision must not use the powerchair without such
supervision. Unsupervised use of the powerchair must be avoided
if there is any doubt about the ability of an individual to operate
it safely.
• Do not step on the footrest while loading or unloading from the
powerchair. Risk of instability.
• Do not hang items from any part of the powerchair. Risk of
instability.
• If children, adults with learning diculties or pets pose a
potential risk of tampering with the powerchair, its suitability
for use is to be considered during the initial user / product risk
assessment.
• Do not use or leave the Titan Powerchair unattended while in
manual mode. Always seek assistance if manual mode is used. Do
not use the powerchair in manual mode when on any slope.
Warning

9
Medical Device
Maximum user mass
Do not create a stack of more than two boxes.
MD
5. SYMBOL DEFINITION
Symbol Description
Refer to instructions for use - Recommended
Failure to read the instructions for use could introduce a hazard
Refer to instructions for use - Mandatory
Failure to read the instructions for use could introduce a hazard
Warning
Beware of potential hazard
Caution
Beware of potential product damage
e following symbols are found on the Titan Powerchair:
!
2
Fragile, handle with care
Use no hooks
No heavy load

10
Beware of trapping points
This way up
W.E.E.E Label - Found on individual parts of electrical system
(Waste Electrical and Electronic Equipment) Refer to section 13
Manufacturer
Importer
Date of manufacture
Serial number
Symbol Description
REF
Product code
Importer code
Quantity
Authorised EU Representative
#
Keep away from rain
QTY
UK Responsible person
This device must not be used as a seat in a motor vehicle.

11
6. PARTS IDENTIFICATION
Backrest
Joystick
Drive
Wheel
Front
Castor
Footrest
Seat
Armrest
Control unit
Charging
Point
Lapbelt
Headrest
Freewheel
Levers
Adjustment
Bolts
Seat Swivel &
Release Lever
Rear
Castor

12
7. TRANSPORT & STORAGE
Environmental conditions for transport and storage:
Ambient temperature: 0°C to +50°C
Humidity: <80% RH
Follow these conditions when transporting or storing the powerchair:
• Store the powerchair on a at, level oor.
• Always fully charge, then remove the battery prior to long-term storage.
• e powerchair should be stored in clean and dry conditions. Cover to protect
from uid ingress, dirt, dust etc.
• Powerchairs should not be stored on their side, on their backs, or stacked.
• When transporting powerchairs by vehicle, they should be securely stowed in
the back of a van, truck, or boot of a car. Adjustable parts should be removed or
properly secured during transport.
• Keep the instructions for use with the powerchair or in a safe place.
Note: is vehicle is suitable for land and air transport, but contact your carrier in
advance to determine their specic requirements. e battery pack may require special
packaging and storage provisions in line with IATA or UN guidelines. To remove the
batteries, disconnect and li up the battery pack.
If your powerchair is stored for a prolonged period, at spots may develop in the wheels,
causing an uneven sensation when driving. is should work itself out over time. Drive
DeVilbiss Healthcare Ltd. suggests placing a sturdy platform under the frame to li the
wheels o the ground and take weight o the wheels during storage. If you notice at
spots aer continued use, replace the powerchair wheels immediately.
• Always li your powerchair by the frame. Do not attempt to li
by any removable parts (e.g. seat or armrests).
• Infrequently charged batteries, or batteries stored without a full
charge are susceptible to permanent damage, causing unreliable
performance from your powerchair.
• Avoid placing the powerchair in direct sunlight — this could
damage the electrical system and / or cause label fading.
• Clean the powerchair in line with section 11 prior to storage.
Caution
• Do not sit in the powerchair while in a moving vehicle.
Warning

13
7.1 ASSEMBLING THE POWERCHAIR
1. Loosen and remove the two knobs on the
shroud. Li up the shroud to remove.
2. Connect the battery pack. Ret the
shroud and tighten the two knobs to
secure.
4.Insert the arms in to the seat.
5. Set the arms to the required width then
secure by turning the armrest knobs clockwise.
3. Insert the seat in to the seat post.
Li up the swivel lever and rotate the
seat until it locks in position.
INITIAL ASSEMBLY (this is also applicable aer disassembly for transport)
Pictures for illustration purposes only
6. Ax the headrest to the top of the seat by
inserting the headrest posts into the holes in
the top of the seat.

14
7. Insert the controller’s square
mount into the housing under the
armrest. Tighten the star knob on
the underside of the controller arm
mount to hold it in place at the
desired extension.
8. Plug the cable from the joystick
remote in to the port at the centre of
the powerchair base.
Fully charge the powerchair
by inserting the round charger
connector into the battery charging
terminal on the front of the
controller, and then insert the
3-pronged plug into a standard
electrical outlet.
NOTE: e Titan AXS powerchair comes with interchangeable shrouds,
allowing you to customize your powerchair to your liking. All models come
with the red shrouds installed, and a spare set of blue shrouds included in
the box. e shrouds can be interchanged by hand, or using a small pry
tool. Be sure not to scratch the painted shrouds while using the pry tool.

15
8. ADJUSTMENTS FOR COMFORT
Seat Swivel
e seat can be swivelled le or right
to make getting on or o the seat more
convenient.
Li up on the handle on the le side of the
seat and then rotate the seat. Release the
handle and carry on rotating the seat until
it locks in position.
Joystick Position
e position of the controller can be
adjusted by loosening the bolt on the
underside of the controller arm and
sliding the arm forward or backward to
the desired position. Once the desired
position is reached, retighten the bolt to
secure the joystick in position.
Seat Height Adjustment
Remove the nut and bolt holding the seat
post in place with the tool kit included
with your powerchair. Adjust the seat post
to the desired height, and reinstall the nut
and bolt removed. Be sure the nut and bolt
are tightened securely to reduce vibrations,
and improve stability.

16
Armrest Height
e armrest height can be adjusted by
loosening the star knob on the top side of
the armrest, and sliding the armrests up
or down to the desired height.
Armrest Width
e width of armrests can be
adjusted by loosening the bolts on
the underside of the seat and sliding
the armrests inward or outward to
the desired width.
Once the desired position is reached,
retighten the bolt to secure the
armrest in position.
Armpad Angle
Adjust the angle of the arm pad be altering
the position of the screw and nut with a
spanner (as shown in the photograph).
To raise the angle, rst turn the screw
anticlockwise then turn the nut clockwise.
To lower the angle, rst turn the nut
anticlockwise and then turn the screw
clockwise.

17
Footplate Height
Remove the two sets of fasteners
attaching the footplate as shown in the
photograph.
Reposition the footplate to the required
height, then reattach the fasteners to
secure.
Footplate Height
Remove the two sets of fasteners
attaching the footplate as shown in the
photograph.
Reposition the footplate to the required
height, then reattach the fasteners to
secure.
Footplate Angle
e footplate angle can be adjusted
by liing up on the footplate, and
tightening or loosening the bolt under
the footplate. Tightening will lower the
angle, and loosening will raise the angle
of the footplate.
Seat Recline
e recline angle of the seat can be
adjusted by pulling up on the lever on
the side of the seat.

18
9. CHARGING & PREPARING FOR USE
9.1 Installation
• Before preparing the powerchair, ensure these instructions have
been read and fully understood.
• Prepare the powerchair in a dry, indoor environment. Risk of
electric shock if prepared in a damp area.
• Only competent persons are to prepare the powerchair for use. If
in doubt, contact Drive DeVilbiss Healthcare Ltd.
• Ensure a risk assessment in line with local health and safety
policy is undertaken to ensure that sta are not put at risk when
performing assembly activities.
Warning
9.2 Battery Charging
• Do not open the battery.
• Do not connect an extension cord to the battery charger.
• Keep metal objects away from the battery terminals; electric
shock may occur.
• Ensure the charging cable is not under excessive tension to avoid
cable damage — damaged cables can create an electrocution / re
risk.
• Ensure the battery is not exposed to direct sunlight or a
secondary heat source — direct heating of the battery via an
external source could pose a re risk or cause an explosion.
• Do not drive the powerchair while the charging cable is attached
or connected.
Warning
• Only charge the Titan Powerchair with the approved charger.
Never charge the powerchair using a dierent charger.
• Charge fully before each use.
• Use of the socket to supply power to other electrical equipment
may damage the powerchair's control system and EMC
performance.
Caution

19
e Titan Powerchair's batteries should be fully charged (approximately 8-10 hours)
before its initial use.
Battery chargers, specic to our product, are designed to not overcharge the batteries.
You may leave your power mobility product plugged into the charger for longer than
8 – 10 hours without causing damage to the batteries.
To Charge:
1. Only use the charger to recharge lead-acid batteries.
2. Keep the AC power switched o until the battery and charger have been connected.
3. Insert the end connector of the charger in to the socket on the front of the joystick.
4. Switch the AC power on. e LED will turn red to show that it is charging the
batteries.
5. When the LED turns from Red to Green this indicates that the batteries are
charged.
Note: the LED will also illuminate Green if the batteries are not connected. In the
event of the LED not turning red on start up check the connection.
If you use your powerchair on a daily basis, charge the batteries as soon as you are
nished with the day’s activities, and leave it on the charge until you are ready to use
the following day. Aer charging, unplug and remove the charger from the mains
socket and powerchair.
If there is a longer period of no use, it is recommended to charge the battery every
two months. is may help preserve / extend the life of the battery.
9.3 Checking Before Use
It is important to check the functionality of the powerchair before the initial use to
ensure its safe operation.
• Make sure that the motor levers are in engaged in drive mode by pushing down
on the levers. (Parallel to the wheels)
• Switch on powerchair and wait 5 seconds for the joystick to initialise.
• Gently press the joystick in any direction then check the battery indicator and
status light are illuminated on the joystick controller.
• Gently rotate the joystick in all directions and ensure that all the wheels rotate
freely.
• Release the joystick aer moving in any direction. e joystick should
immediately return to the middle position.

20
10. OPERATION OF THE TITAN AXS POWERCHAIR
10.1 Operational Limits
Ambient temperature: 0°C to +50°C
Operating humidity: 30% to 85% RH
10.2 Control Features
Control Panel
Please refer to the diagram below to identify your Titan Powerchair control panel
and its functions. Familiarise yourself with the terminology to better understand
references throughout these instructions.
Make sure the powerchair functions work correctly before operating,
using the checklist in section 9.3 for guidance.
Caution
On/O Switch & Status Indicator
Press the power button to switch the powerchair on. If the system is functioning
correctly, then the power button will light up green and the battery gauge will display
the power remaining in the battery. If the system detects a fault when powering up,
then the power button will indicate the fault with a series of red ashes and prevent the
system from driving. e battery gauge will ash continuously.
Press the power button again to switch the powerchair o.
Joystick
Horn
Button
Speed
Dial
Power
Button
& Status
Indicator
Battery
Indicator
