Drive Nebulizers 18080P Manual

Power Neb Ultra
Compresor Nebulizador
Modelo 18080, 18080P, 18081, 18082
Caution– Federal (U.S.A.) law
restricts this device to sale by, or
on the order of a physician.
Made in China. Latex Free.
Power Neb Ultra
Compressor Nebulizer
Model 18080, 18080P, 18081, 18082
Instruction
Guide

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
2
table of contents
TABLE OF CONTENTS
Important Safeguards...........................................................4
IEC Symbols........................................................................4
Important Safeguards..........................................................4
Introduction...........................................................................6
Statement Of Intended Use.................................................6
What Are Compressor Nebulizer Systems Used For?.........6
How Does A Compressor Nebulizer Work?.........................6
How Do I Take A Treatment?...............................................7
Product Identification and
Available Accessories...........................................................8
Operation...............................................................................9
How To Operate Your Compressor......................................9
Cleaning & Maintenance....................................................11
Nebulizer Cleaning.............................................................11
Compressor Cleaning........................................................12
Filter Change.....................................................................12
Maintenance......................................................................12
Specifications......................................................................13
Limited Warranty.................................................................15

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
4
important safeguards
Class II
Equipment
Alternating
Current
Type BF
Applied Part
Important Safeguards
When using electrical products, especially when children are present, basic safety precau-
tions should always be followed. Read all instructions before using. Important information is
highlighted by these terms:
DANGER Urgent safety information for hazards that will cause serious injury or death.
WARNING Important safety information for hazards that might cause serious injury.
CAUTION Information for preventing damage to the product.
NOTE Information to which you should pay special attention.
Read All Instructions Before Using
To reduce the risk of electrocution:
1. Always unplug this product immediately after using.
2. Do not use while bathing.
3. Do not place or store product where it can fall or be pulled into a tub or sink.
4. Do not place in or drop into water or other liquid.
5. Do not reach for a product that has fallen into water. Unplug immediately.
WARNING: If any of the motor housing parts should become detached or broken ex-
posing the motor or any other electrical component operation should
be discontinued immediately to avoid personal injury or further product
damage.
To reduce the risk of burns, electrocution, fire or injury
to persons:
1. The product should never be left unattended when plugged in.
2. Close supervision is necessary when this product is used by, on, or near children
or disabled individuals
3. Use this product only for its intended use as described in this guide. Do not use
attachments not recommended by the manufacturer.
4. Never operate this product if:
a. It has a damaged power cord or plug. c. It has been dropped or damaged.
b. It is not working properly. d. It has been dropped into water.
5. Keep the power cord away from heated surfaces.
6. Never allow the power cord to be pulled, jerked, strained, twisted or severely bent
especially at the plug connections. Damage will occur at the high ex point of entry
to the device, causing it to rupture and short.
7. Never block the air openings of the product or place it on a soft surface, such as bed
DANGER!
WARNING!
1
Follow Operating
Instruction
ON OFF This dispostivo contains
electrical equipment and
/ or mail to be recycled
according to EC 2002/96
/ EC directive - Waste
Electrical and Electronic
Equipment (WEEE)

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
5
important safeguards
or couch, where the air openings may be blocked. Keep the air openings free of
lint, hair, and the like.
8. Never use while drowsy or asleep.
9. Never drop or insert any object into any opening or hose.
10. Do not use outdoors. This product is for household use only.
11. DO NOT use this product in or near explosive environments, or where aerosol
(spray) products are being used.
12. DO NOT pump combustible liquids or vapors with the product or use in or near an
area where ammable or explosive liquids or vapors may exist.
13. DO NOT operate this product in an oxygen enriched environment, i.e. oxygen tent
or oxygen hood.
14. Use only in well ventilated areas.
15. Do not use this product with a DC to AC converter, or with any AC voltage and/or
frequency other than specied.
16. Do not operate unit in a backpack or carrying bag.
17. Care should be taken when this product is used in the vicinity of other electronic
equipment concerning the possible interference between them. They may need to
be moved apart.
18. Use caution when plugging in and unplugging device. Do not allow jewelry or
other metal items to contact plug.
19. Warning: This product contains small parts that may represent a choking hazard.
20. The device does not need to be calibrated.
21. Do not position the equipment so that it is dicult to operate.
22. To avoid strangulation and entanglement, keep power cord and air tubes out of
reach of young children.
23. The air lter shall not be serviced or maintained while the compressor is in use.
24. Warning: No modication of this equipment is allowed.
NOTE This unit employs a temperature and/or current limiting device that will shut o
the entire product should a malfunction occur or in the event of product misuse, abuse, or
abnormal operation.
NOTE This is based on the thermal interrupt safety device that is integrated into the mo-
tor. As the unit runs it generates heat and gets warm. If the unit is run for over 30 minutes
continuously the thermal interrupt may trip which would stop the user’s treatment. Some
models of this appliance have a polarized plug (one blade is wider than the other). As a
safety feature, this plug will t in a polarized outlet only one way. If the plug does not t fully
in the outlet, reverse the plug. If it still does not t, contact a qualied electrician. Do not at-
tempt to defeat this safety feature. If repair or replacement of the cord or plug is necessary,
contact your qualied Drive provider.
NOTE The exterior surfaces of the unit and the air outlet connector may become slightly
warm to the touch during use. Warm air can also be felt exiting the vents on the sides of the
case of the unit. This is normal.Your doctor has prescribed a liquid medication to treat your

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
6
introduction
respiratory condition. To best utilize this liquid medication, he has prescribed a Drive brand
compressor nebulizer. Your Drive compressor nebulizer works to convert the medication to
a high-quality mist of ne particles that penetrates deep into the lungs.
Be sure that you read and understand the information in this instruction guide. By following
these simple instructions and the advice of your physician, your compressor will become
an eective addition to your therapeutic routine.
Statement of Intended Use
The Drive compressor nebulizer includes an AC powered air compressor that provides a
source of compressed air for home health care use. The compressor is used in conjunction
with a jet (pneumatic) nebulizer to convert certain inhalable drugs into an aerosol form for
inhalation by a patient. The device can be used with adult or pediatric patients.
What are Compressor Nebulizer Systems Used For?
People with breathing problems, such as Asthma, Chronic Obstructive Pulmonary Disease
(COPD) or Cystic Fibrosis are often prescribed medicines that minimize or control symp-
toms of their disease. Compressor Nebulizer Systems are a means of delivering these
prescribed medications to the lungs. These medications and the compressor nebulizer
systems should be used as directed by a physician to maximize benets. Compressor
Nebulizer systems can be prescribed for use everyday or periodically as symptoms present
themselves, such as the springtime when Hay Fever or Allergies are normally present.
How Does a Compressor Nebulizer Work?
Most medicines for use with a compressor nebulizer system are created in a liquid form.
This liquid medication is placed in the “cup” of the nebulizer (please refer to this Instruc-
tion Guide for more information on the proper use of a nebulizer). The compressor, which
is connected to the nebulizer by exible tubing, generates a specic pressure and ow of
air that essentially “drives” the nebulizer. The pressurized air produced by the compressor
initiates the nebulizer’s ability to break down the liquid medication into a very ne mist. This
mist, often referred to as an aerosol cloud, is then propelled out the nebulizer and inhaled
into the lungs where the medicine is readily absorbed. Please consult your prescription for
details on the amount of liquid medication that should be placed in the nebulizer. If you
should have any questions about your medication or its use, please contact your physician
or pharmacist.
2

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
7
introduction
How Do I Take a Treatment?
A nebulizer is the optimal delivery method of medication to the lungs. However, some users
may nd it dicult to use, especially very young children. In this case, an aerosol mask
may be used. To ensure that the proper mask is utilized, please consult your home health
provider or physician.
The most important aspect of taking a treatment is the patient’s breathing pattern while
inhaling the medication mist.
It should be slow and deep, all attempts should be made to sit up straight and breathe in
deep.
A general rule of thumb is to attempt to breathe in so deeply that it feels as though the
lungs are completely full of air and inhaling any additional air is impossible.
If possible, hold your breath for 1-2 seconds unless directed otherwise by your physician
and then slowly exhale through the nebulizer mouthpiece or mask. Holding your breath for
1-2 seconds after inhaling the medication allows for optimal absorption of medication in the
lungs.
Repeat this breathing pattern for the entire treatment.
The length of a treatment can last anywhere from 5 to 20 minutes, depending on the
amount of medication and the performance of your compressor and nebulizer system.
When you cannot see any medication in the nebulizer cup and the nebulizer has stopped
producing a mist, the treatment has been completed. Turn o your compressor and follow
the cleaning instructions found in this instruction guide.
If you have any additional questions regarding your equipment, medication, or treatment,
please consult your physician.

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
8
available accessories
Product Identification
MODELS DESCRIPTIONS
18080 Power Neb Ultra Compressor Nebulizer with Disposable Nebulizer
18080P Power Neb Ultra Compressor Nebulizer with Disposable Nebulizer and
Pediatric Aerosol Mask
18081 Power Neb Ultra Compressor Nebulizer with Disposable and Reusable
Nebulizer
18082 Power Neb Ultra Compressor Nebulizer with Two Reusable Nebulizers
Available Accessories
18254 Reusable Nebulizer (10/cs)
18260 JetNeb Reusable Nebulizer (12/cs)
NEB KIT 500 Disposable Nebulizer Kit with
mouthpiece, 7’ tubing (50/cs)
NEB KIT 600 Disposable Nebulizer Kit with
Adult Aerosol Mask (50/cs)
NEB KIT 700 Disposable Nebulizer Kit with
Pediatric Aerosol Mask, 7’ Tubing (50/cs)
MASK 001A Adult Aerosol Mask (50/cs)
MASK 001P Pediatric Aerosol Mask (50/cs)
18090F Replacement Filter 10/bag
3

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
9
available accessories
How to Operate Your Compressor
NOTE Before initial operation, the nebulizer cup assembly should be
cleaned following instructions described in the “Cleaning” section.
WARNING Before connecting the power cord, make sure the I/O (ON/OFF)
switch is in the O (OFF) position.
The plug is also served to disconnect the device.
Daily Use Operation
CAUTION The Compressor is designed for intermittent use only. Do not
operate it continuously for more than 30 minutes for a single use
without turning it o and following a cooling period for least 30
minutes.
1. Before each use inspect the Compressor and nebulizer cup assembly
for damage or wear, replace as needed.
2. Place the Compressor on a table or other at stable surface. Be sure
you can easily reach the controls when seated. Do not use this device on
the oor.
3. With the power switch in the O (OFF) position, plug the power cord into an
appropriate electrical wall outlet.
4. Connect one end of the tubing to the compressor air-outlet connector.
5. Assemble the nebulizer cup and add indicated medication to the nebulizer’s
cup before use.
6. Attach the other end of the tubing into the air-inlet connector found at the
bottom of the nebulizer cup.
7. Turn on the Compressor by pressing the power switch to the I (ON)
position and begin treatment.
8. If treatment needs to be interrupted, simply press power switch to
O (OFF) position.
9. When the treatment is complete, turn o the compressor by pressing the
power switch to O (OFF) position and unplug the unit from the electrical
outlet.
10. Always unplug this device immediately after use.
Equipment not suitable for use in the presence of a ammable anesthetic
mixture with air or with oxygen or nitrous oxide. This device has no AP or
APG protection not intended for use with oxygen or oxygen enriched
atmospheres.
operation
4

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
10
11. DO NOT use this product in or near explosive atmospheres, or where aerosol
(spray) products are being used.
12. DO NOT pump combustible liquids or vapors with the product or use in or near an
area where ammable or explosive liquids of vapors may exist.
13. DO NOT operate this product in an oxygen enriched environment, i.e. oxygen tent
or oxygen hood.
14. Use only in well ventilated areas.
Safety Overload
NOTE Do not exceed 30 minutes of continuous operation.
NOTE This is based on the thermal interrupt safety device that is integrated into the mo-
tor. As the unit runs it generates heat and gets warm. The thermal interrupt will cut
power to the unit if the temperature inside gets to an unsafe level. Once the unit
cools o it will work normally. If the unit is run for over 30 minutes continuously the
thermal interrupt may trip which would stop the user’s treatment
1. The motor of this device has a built-in thermal overload protector. Should the mo-
tor overheat, the protector will automatically shut o the motor. Should this occur,
turn the I/O (ON/OFF) switch to the O (OFF) position and allow the motor to cool
down for approximately 30 minutes before turn it on again.
2. If the overload protector shuts o the motor frequently, you may have an unstable
voltage situation.

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
11
Nebulizer Cleaning
All parts of the nebulizer, except tubing, should be cleaned according to the following
instructions. Your physician and/or Drive provider may specify a certain cleaning procedure.
If so, follow their recommendations.
To prevent possible risk of infection from contaminated
medication, cleaning of the nebulizer is recommended after
each aerosol treatment. Disinfecting is recommended once a day.
In order to decrease the risk of contamination, nebulizer cups are for single patient use only.
Clean After Every Use:
1. With power switch in the “ O” position, unplug power cord from wall outlet.
2. Disconnect tubing from the air-inlet connector and set aside.
3. Disassemble mouthpiece or mask from cap. Open nebulizer by turning cap
counterclockwise and remove bae.
4. Wash all items, except tubing, in a hot water/dishwashing detergent solution.
Rinse under hot tap water for 30 seconds to remove detergent residue. Allow to
air dry.
5. For reusable nebulizer only, it can be cleaned daily in dishwasher using top shelf
or by following the above cleaning procedure.
The Drive Reusable Nebulizer is dishwasher safe, but do not place
any Drive Disposable Nebulizer parts in an automatic dishwasher;
doing so could cause damage.
Disinfect Daily
1. Using a clean container or bowl, soak items in three parts hot water to one part
white vinegar for 30 minutes OR use a medical bacterial-germicidal disinfectant
available through your provider. Be sure to follow manufacturer’s instructions care-
fully.
2. With clean hands, remove items from disinfectant solution, rinse under hot tap
water, and air dry on a clean paper towel. Store in a zip-lock bag.
NOTE Do not towel dry nebulizer parts; this could cause contamination.
To prevent possible risk of infection from contaminated cleaning
solutions, always prepare fresh solution for each cleaning cycle
and discard solution after each use.
WARNING!
CAUTION!
cleaning and maintenance
5
WARNING!

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
12
3. Keep the outer surface of the tubing dust-free by wiping regularly. Nebulizer tubing does
not have to be washed because only ltered air passes through it.
NOTE The Drive Disposable Nebulizer will last at least 15 days and possibly
longer, depending on usage. Proper cleaning will also help extend the life
of the nebulizer. Because it is disposable, we recommend that an extra
nebulizer be kept on hand at all times. The Drive Reusable Nebulizer is
dishwasher safe and may be cleaned and reused for up to one year.
Compressor Cleaning
1. With power switch in the “O ” position, unplug power cord from wall outlet.
2. Wipe outside of the compressor cabinet with a clean damp cloth every few
days to keep dust-free.
Do not submerge in water; doing so will result in compressor
damage.
Filter Change
1. Filter should be changed every 6 months
or sooner if lter discolors.
2. Remove lter by grasping it rmly and pulling
out of the unit. Discard old lter.
3. Replace with a new Drive lter. Additional
lters should be purchased from your
Drive provider.
4. Push new lter into position.
Do not reuse or wash lter or substitute any other material
such as cotton for a Drive air-inlet lter. It will result in
compressor damage.
Maintenance
All maintenance must be performed by a qualied Drive provider or authorized service
center.
Electric shock hazard. Do not remove compressor cabinet.
All disassembly and maintenance must be done by a qualied
Drive provider.
WARNING!
DANGER!
Filter
cover
WARNING!

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
13
Size 16 cm x 9 cm x 13.7 cm
Weight 3.0 lbs
Operating Voltage 120 Vac, 60Hz
Power Consumption 110 VA
Storage/Transport Temperature Range -25 to 70°C (-13 to 158°F),
Storage/Transport Humidity 10 – 95%
Storage/Atmospheric Pressure 750-1060 hPa
Operating Humidity 15 – 95% non-condensing
Operating Temperature Range 10 to 40°C (50 to 104°F)
Operating/Atmospheric Pressure 750-1060 hPa
Compressor Free Air Flow 8 LPM.
Max Pressure 30 psig or greater / 206 KPa
Operating Pressure Range 30 psig or greater
Operating Noise Level < 63 dBA
Equipment Classifications:
Protection against electric shock: Class II
Degree of protection against electric shock: Type BF
Equipment not suitable for use in the presence of ammable anaesthetic mixture with air.
Not intended for use with oxygen enriched atmospheres such as oxygen hoods or tents.
*Conditions may vary based on altitude above sea level,barometric pressure, and temperature.
**Value determined with minimum ow rate through the nebulizer (20°C, sea level).
There are no hazardous materials used in the construction of this unit, therefore, there are no
known risks associated with disposal of the equipment. This product complies with the following
electromagnetic compatibility standard:
IEC 60601-1-2
specications
6

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
14
Save These Instructions
Recommended separation distances between portable and mobile RF communi-
cations equipment and the Power Neb Ultra Compressor Nebulizer 18080, 18080P,
18081, 18082.
The Power Neb Ultra Compressor Nebulizer is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled. The customer or the user
of the Power Neb Ultra Compressor Nebulizer can help prevent electromagnetic interfer-
ence by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the Power Neb Ultra Compressor Nebulizer as recommended
below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz
d= 1.2 √Pd= 1.2 √P d = 2.3 √P
0,01 0.12 0.12 0.23
0,1 0.38 0.38 0.73
1 1.20 1.20 2.30
10 3.79 3.79 7.27
100 12.00 12.00 23.00
For transmitters rated at a maximum output power not listed above, the recommended
separation distance din metres (m) can be estimated using the equation applicable to the
frequency of the transmitter, where Pis the maximum output power rating of the transmit-
ter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic propa-
gation is aected by absorption and reection from structures, objects and people.
Please dispose of this nebulizer in accordance with local, municipal,
state and federal law for electronic devices

..............................................................................................................................................
DRIVE COMPRESSOR/NEBULIZER MODEL 18080, 18080P, 18081, 18082
...............................................................................................................................................
15
Five-Year Limited Warranty on Compressor Parts
Your Drive brand product is warranted to be free of defects in materials and workmanship
for ve years of the original consumer purchaser.
This device was built to exacting standards and carefully inspected prior to shipment. This
5 year Limited Warranty is an expression of our condence in the materials and
workmanship of our products and our assurance to the consumer of years of dependable
service.
This warranty does not cover device failure due to owner misuse or negligence, or normal
wear and tear. The warranty does not extend to non-durable components which are
subject to normal wear and need periodic replacement.
If you have a question about your Drive device or this warranty, please contact an
authorized Drive dealer.
limited warranty
7
Save These Instructions
