DT Research DT509 Assembly instructions

DT509
ENGLISH
Integrated LCD System
BASIC OPERATION GUIDE
DT509
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2012, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
INTRODUCTION
Thank you for acquiring DT Research’s
DT509 Integrated Signage/ Kiosk Terminal. With an 8.9-inch TFT
display and powered by the Intel®Atom™ processor, the DT509
offers opmal combinaons of performance and power savings.
With fully-integrated point-of-service modules within an elegant,
space-saving design, the DT509 is the opmum soluon to enhance customer service.
Please take a few moments to review the contents of this document to ensure that the setup and
startup proceed smoothly. The DT509 Integrated Signage/ Kiosk Terminal is ready for use, out of
the box, in its default configuraon when powered by the power source provided. The following
discussion offers guidance on the hardware elements and features of the
DT509. Please refer to your device provider for informaon pertaining to the soware operang
system or soware applicaons.
Package Contents
One DT509•
AC-DC power adapter with power cord•
B•asic operaon guide
BOG030612DT509ENG
SPECIFICATIONS
System
Processor Intel® Atom™ Z530, 1.6GHz
Memory (RAM) 1GB to 2GB
Storage 2GB to 16GB Flash
Operang Systems Microso® Windows® XP Embedded
Display 8.9”TFT-LCD
Display Resoluon 1024 x 600
Touch Screen Resisve touch
Network Interface Ethernet 10/ 100 MB Base-T LAN; 802.11a/b/g WLAN (oponal)
Stereo Speaker Built-in speaker
Input/Output Ports 2 USB 2.0 ports; 1 Audio-out jack; 1 Microphone-in jack; 1 RJ45
connector for Ethernet; 1 Phoenix connector
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 12V DC, 3.5A
Mechanical
Enclosure ABS + PC plascs
Dimensions (H x W x D) 9.69 x 6.93 x 1.61 in/ 246 x 176 x 41 mm
Weight 2.9 lbs/ 1.3 kg
Environmental
Regulatory FCC Class B, CE, C-Tick, RoHS compliant
Temperature Operaon: 5°C - 35°C; Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing
Data Capture Options
MSR Yes; triple track readers (ISO TK1, 2 & 3), bidireconal
Presence Sensor and
Scanner Auto Detecon
Yes; reads both 1D and 2D barcodes, integrated for hassle-free
operaon
RFID Reader Yes, HF 13.56MHz, ISO standard 15693, 14443A(B), 18092
compliant
* Specificaons subject to change without noce.

DT509
ENGLISH 23ENGLISH
Precauons
Always exercise care when operang and handling the DT509.•
Never disassemble any poron of the enclosure, as this will void any product warranty on the•
DT509.
Do not use any AC/DC adapter other than the one provided with the device or a replacement•
acquired from the manufacturer.
In the unlikely event that smoke, abnormal noise or strange odor is present, immediately power•
down the DT509 and disconnect all power sources. Please report the problem to your device
provider immediately.
Basic Features
The DT509 integrates a bright and responsive touch display, two USB ports, and is complemented
by a suite of opons including a magnec stripe reader (MSR), 2D barcode scanner, RFID reader,
presence sensor and scanner auto-detecon for comprehensive point-of-service applicaons.
Powering ON and OFF
The DT509 is programmed to Power On automacally when power is first applied or re-established.
To turn offthe device, use the soware shutdown interface provided, or unplug the device.
In the event of system lockup, unplug and then re-plug the power cable.
Calibraon
The touch display for the DT509 is calibrated before shipping. In the event that the calibraon has
been modified or is unsasfactory, the respecve calibraon rounes (e.g., PenMount (PM) for
Windows XP) to calibrate the touch interface may be used. Such applicaons are typically executed
through touch input via Stylus or through mouse click via a USB mouse.
I/O Panels
The DT509 has a comprehensive set of I/O ports. The following ports are located along the lower
rear edge of the display unit.
Opons
The DT509 has a number of oponal modules. These include:
Magnec stripe reader (MSR)•
Presence sensor and scanner auto detecon•
2D barcode scanner•
RFID reader•
Wi-Fi networking•
A
A
B
B
C
C
D
D
E
E
Mic and line-out jacks
USB ports x 2
Ethernet port
DC-in jack (AC/ DC)
Phoenix connecter (DC/ DC)
