Dtronic DT3108 User manual

User Manual
DT3108
Barcodescanner –DT3108
:0645733500
: [email protected]
:https://www.dtronic.nl/
Datum :27-1-2024
Versie :1.0

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 2 van 47
Introduction
Thank you for trusting a product from DTRONIC. Please read the contents of the user manual
carefully in order to use the products safely and effectively.
You are advised to keep this manual correctly for your installation and as a reference. Please do not
disassemble the product or tear off the seal, otherwise we will not provide warranty or
replacement service.
The illustrations in this user manual are for reference only. If there are images that do not match
the actual product, please take the actual product as standard.
Updated information is subject to change without notice. All information in this manual is
copyrighted and our company reserves all rights. It is prohibited to distribute, copy, compile or sell
all or part of this manual without our written permission.
DTRONIC is a BOIP registered trademark and legally protected in cooperation with GS1. Diwolar is
the only company with the rights to market this trademark. If you have purchased a product that
was not purchased through Diwolar, the warranty is void. When contacting customer service
always ask for the order number. This user manual applies to DTRONIC barcode scanners that
identify barcodes using a laser scan pattern.
DTRONIC is not liable for damages and defects suffered when the barcode scanner fails, does not
work properly or is misused.
Do you have any questions about your product? We will be happy to assist you.
Mail: [email protected] Bereikbaar van 09:00-17:00u
WhatsApp: [phone] Bereikbaar van 09:00-17:00u
Website: www.dtronic.nl Webshop 24/7 geopend
Kind regards, team Dtronic
-Diederik Director
-Arjan Operations manager
-Marjolein Financial employee
-Jaxx Administrative employee
-Tim Customer service
-Hessel Customer service
- Roger Test center
- Kees-Jan Logistics

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 3 van 47
Inhoud
INTRODUCTION..........................................................................................................................2
1. PRODUCT.............................................................................................................................6
1.1 Function............................................................................................................................ 6
1.2 Unbox................................................................................................................................ 6
1.3 Start .................................................................................................................................. 6
1.4 Window............................................................................................................................. 6
1.5 Reading ............................................................................................................................. 7
1.6 Picture............................................................................................................................... 7
1.7 Led indicator..................................................................................................................... 7
2. SYSTEM SETUP .....................................................................................................................8
2.1 System Setup .................................................................................................................... 8
2.1.1 Setup code.............................................................................................................. 8
2.1.2 Restore factory default settings............................................................................. 8
2.1.3 Read version number ......................................Fout! Bladwijzer niet gedefinieerd.
2.1.4 Product User Settings............................................................................................. 8
2.1.5 Led .......................................................................................................................... 9
2.1.6 Level lighting....................................................Fout! Bladwijzer niet gedefinieerd.
2.1.7 Beeper Duration..................................................................................................... 9
2.1.8 Beeper settings....................................................................................................... 9
2.1.9 Set the beep switch.............................................................................................. 10
2.1.10Power on beep switch.......................................................................................... 10
2.1.11Read success beep switch .................................................................................... 10
2.2 Reading mode settings ................................................................................................... 10
2.2.1 Level trigger mode...........................................Fout! Bladwijzer niet gedefinieerd.
2.2.2 Continuous mode (default) .................................................................................. 10
2.2.3 Pulse trigger mode ..........................................Fout! Bladwijzer niet gedefinieerd.
2.2.4 Auto Scan mode ................................................................................................... 11
2.2.5 Repeat read switch..........................................Fout! Bladwijzer niet gedefinieerd.
2.2.6 Code reading timeout......................................Fout! Bladwijzer niet gedefinieerd.
2.2.7 One read timeout............................................Fout! Bladwijzer niet gedefinieerd.
2.3 Communication settings.................................................................................................12
2.3.1 Communication settings.......................................................................................12
2.3.2 USB keyboard .......................................................................................................12
2.3.3 USB keyboard sending speed...............................................................................13
2.3.4 Set USB keyboard sending speed.........................................................................14
2.3.5 Control Characters...........................................Fout! Bladwijzer niet gedefinieerd.
2.3.6 Serial communication settings .............................................................................14
2.3.7 Serial port baud rate setting.................................................................................15
2.3.8 Serial port output ............................................Fout! Bladwijzer niet gedefinieerd.
2.3.9 Serial port parity bit setting..................................................................................15
2.4 Data format setting....................................................Fout! Bladwijzer niet gedefinieerd.
2.4.1 Hide 1 character ..............................................Fout! Bladwijzer niet gedefinieerd.
2.4.2 Custom prefix on/off settings............................................................................... 16
2.4.3 Customized prefixes............................................................................................. 16
2.4.4 Custom suffix on/off settings ...............................................................................17
2.4.5 Custom suffixes ....................................................................................................17
2.4.6 Custom ID output method ................................................................................... 17
2.4.7 Customize Code ID ............................................................................................... 18

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 4 van 47
2.4.8 Terminator settings..............................................................................................19
2.4.9 CTRL + X................................................................................................................20
2.4.10Case output settings............................................................................................. 21
2.4.11Data output settings........................................Fout! Bladwijzer niet gedefinieerd.
2.4.12Pre/Post data length setting............................Fout! Bladwijzer niet gedefinieerd.
2.5 Symbologies.................................................................................................................... 22
2.5.1 1D all symbologies................................................................................................ 22
2.5.2 2D all symbologies................................................................................................ 22
2.5.3 QR mirror code.....................................................................................................22
2.5.4 Inverse barcode...............................................Fout! Bladwijzer niet gedefinieerd.
2.5.5 Data matrix mirror code....................................................................................... 22
2.5.6 Mirror Code for all symbologies...........................................................................23
2.5.7 All barcodes.......................................................................................................... 23
2.5.8 EAN8 Settings .......................................................................................................23
2.5.9 Code 11 Settings................................................................................................... 23
2.5.10Add-on code setting .............................................................................................24
2.5.11EAN 13 settings.....................................................................................................24
2.5.12ISSN Settings......................................................................................................... 25
2.5.13HANXIN............................................................Fout! Bladwijzer niet gedefinieerd.
2.5.14ISBN setting ..........................................................................................................25
2.5.15UPC-A settings...................................................................................................... 25
2.5.16UPC-E settings ......................................................................................................26
2.5.17UPCE ..................................................................................................................... 26
2.5.18EAN/UPC...............................................................................................................27
2.5.19Code 39 Settings................................................................................................... 27
2.5.20Code 39 Length Setting ........................................................................................28
2.5.21Code 32 settings................................................................................................... 28
2.5.22Code 128 settings.................................................................................................28
2.5.23Code 128 length setting ....................................................................................... 29
2.5.24Code 93 settings................................................................................................... 29
2.5.25Code 93 Length Setting ........................................................................................29
2.5.26Codabar Settings ..................................................................................................30
2.5.27Codabar Length Setting........................................................................................ 31
2.5.28Codablock A.....................................................Fout! Bladwijzer niet gedefinieerd.
2.5.29Codablock F .....................................................Fout! Bladwijzer niet gedefinieerd.
2.5.30GS1 Databar Limited............................................................................................. 31
2.5.31GS1 Databar omnidirectional...............................................................................31
2.5.32GS1 Databar Expanded......................................................................................... 32
2.5.33DOT_CODE.......................................................Fout! Bladwijzer niet gedefinieerd.
2.5.34Composite .......................................................Fout! Bladwijzer niet gedefinieerd.
2.5.35Data matrix Code.................................................................................................. 32
2.5.36MSI........................................................................................................................32
2.5.37QR......................................................................................................................... 33
2.5.38Micro QR code...................................................................................................... 33
2.5.39PDF417 .................................................................................................................33
2.5.40Micro PDF417....................................................................................................... 33
2.5.41Pharmacode ....................................................Fout! Bladwijzer niet gedefinieerd.
2.5.42RSS-Expanded.......................................................................................................34
2.5.43RSS-Limited........................................................................................................... 34
2.5.44RSS-14...................................................................................................................34
2.5.45Trioptic Code ...................................................Fout! Bladwijzer niet gedefinieerd.

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 5 van 47
2.5.46Telepen............................................................Fout! Bladwijzer niet gedefinieerd.
2.5.47Straight 2 of 5 Industrial....................................................................................... 34
2.5.48Maxicode.........................................................Fout! Bladwijzer niet gedefinieerd.
2.5.49Interleave 2 of 5 (ITF5) setting ............................................................................. 35
2.5.50Extra code setting............................................Fout! Bladwijzer niet gedefinieerd.
2.5.51Airline 2 of 5 ....................................................Fout! Bladwijzer niet gedefinieerd.
2.5.52Aztec code ............................................................................................................35
2.5.53ITF25 length setting..............................................................................................35
3. APPENDIX ..........................................................................................................................37
3.1.1 Appendix 4 ASCII Code table ...........................Fout! Bladwijzer niet gedefinieerd.

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 6 van 47
1. Product
1.1 Function
- Works with Plug&Play and without installation software.
- Works with most WMS systems.
- Some WMS or POS systems must be set up to use a scanner.
- Device the scanner is connected to will see it as keyboard.
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this
manual.
- There are patented parts in the scanner, DTRONIC has the rights to sell these items on the
Dutch, Belgian and German market
1.2 Unbox
After opening the box containing the product, perform the following steps:
- Remove the scanner accessories from the packaging.
- Remove the scanner from the packaging.
- At the packing list, check that everything is complete and in good condition. If there are
damaged or missing parts, save the original packaging and contact DTRONIC for customer
service.
Packing list:
1. Handheld scanner
2. USB Connection Cable (for wireless scanners, this is the charging cable).
3. Paperclip
4. Abridged user manual
1.3 Start
Startup: connect the computer to the scanner. The computer will recognize it as a keyboard and the
scanner can be used.
Power off: remove the cable connected to the scanner; remove the USB connected to the
computer.
Restart: if the scanner crashes or is unresponsive, turn it off and restart it. Optionally, use the
factory setting from this manual
1.4 Window
The scanning window must be kept clean, the supplier does not bear the warranty responsibility
due to improper maintenance. Prevent the window from wearing out or being scratched by a hard
object. Use a soft cloth to remove stain on the scanning window. Clean the scan window with a soft
cloth, such as a lens cleaning cloth
Spraying liquid on the scan window is prohibited. Prohibit all cleaning solvents except cleaning
water.

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 7 van 47
1.5 Reading
If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be
further away from the scan window for easier reading.
If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar
code at an angle to scan the bar code. The best distance to read a bar code is 10-15 cm
1.6 Picture
1.7 Led indicator
INDICATOR STATUS
EXPLAIN
Red light on
Charging
Red light off
No charging
Green light on
No decoding
Green light off
Decode succesfully
One blue light on
Pairing successful or connect to
USB

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 8 van 47
2. System Setup
2.1 System Setup
Option and function setting mainly by reading a series of special bar codes. In this chapter, we give
you a detailed introduction to the options and functions available for user setup and the
corresponding setup code.
This method of setting up the scan is direct, easy to understand and user-friendly.
2.1.1 Setup code
Startup settings (default)
Exit Settings
2.1.2 Restore factory default settings
Restore factory settings
2.1.3 Product User Settings
Save user default settings
Restore user default settings

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 9 van 47
2.1.4 Led
Always off
Always on
Blink test mode
Disable blink test mode
2.1.5 Beeper Duration
Short
Normal
2.7Khz
Mute
2.1.6 Beeper settings
Volume set to High (50%) (default)
Volume set to midrange (25%)
Volume set to bass (12.5%)

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 10 van 47
2.1.7 Set the beep switch
Open (default)
Close
2.1.8 Power on beep switch
Open (default)
Close
2.1.9 Read success beep switch
Open (default)
Close
2.2 Reading mode settings
2.2.1 Continuous mode (default)
When the reading setting code is switched to this mode, it enters the continuous reading state. In
this mode, the "repeat read switch" can be used to prevent the same barcode from being read
more than once.
Continuous mode (default)

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 11 van 47
2.2.2 Auto Scan mode
Auto scan
Delay 50ms
Delay 100ms
Delay 300ms

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 12 van 47
2.3 Communication settings
2.3.1 Communication settings
USB HID (default)
USB serial port
RS-232 serial port
Mac
USB CDC
Enable virtual keyboard
Disable virtual keyboard
2.3.2 USB keyboard
Portuguese (Brazil) cannot output "?" and "/" .
Nederlands
Italian
Spanish (Brazil)
Portuguese

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 13 van 47
Portuguese (Brazil)
French
German (Austria)
Turkish Q
Turkish F
English (UK)
Japanese
German (Switzerland)
French (Belgium)
America
2.3.3 USB keyboard sending speed
If there is missed data at the receiver side, the occurrence speed should be turned down, which is
easy to occur at the receiver side with poor performance.
5 ms (default)
10 ms

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 14 van 47
20 ms
2.3.4 Set USB keyboard sending speed
USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time
range: 0ms~200ms.
Set USB keyboard sending speed
Setting the USB keyboard to send speed of 50ms can be set by reading the following barcodes in
order.
1. Read "Startup Settings"
2. Read the "Set USB keyboard send speed" setting code
3. Read data code: "5" "0" (see data code table)
4. Read "Save" (see data code table)
5. Read "Exit Settings"
2.3.5 Serial communication settings
Data bit 7
Data bit 8
Stop bit 1
Stop bit 2

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 15 van 47
2.3.6 Serial port baud rate setting
Baud rate 4800
Baud rate 9600 (default)
Baud rate 19200
Baud rate 38400
Baud rate 57600
Baud rate 115200
2.3.7 Serial port parity bit setting
No checksum (default)
Odd calibration
Even Check

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 16 van 47
2.3.8 Custom prefix on/off settings
Custom prefixes add a user-defined string before the decoded information. For example, if you
allow to add a custom prefix and set the prefix to the string "AB", after reading the barcode with
the data "123", the scanner adds the string "AB" before the string "123", and the host side receives
"AB123". After the barcode reading data is "123", the scanner will add the string "AB" before the
string "123", and the host side will receive "AB123".
If set to "Off", the decoded information will only have the barcode data information, no prefix, and
the default value is to turn off the custom prefix output.
Enable
Disable (default)
Clear all custom prefixes
2.3.9 Customized prefixes
The custom prefix adds a user-defined string before the decoded information, and the output
format after customization is "Custom Content + Barcode Content".
Set the custom prefix to 'a' (the hex value of a is 0x61)
1. Read "Startup Settings"
2. Read the "Custom Prefix" setting code
3. Check the ASCII code of the character "a": the ASCII code of "a" is "0x61" (see ASCII code table)
4. Read data code: "6" "1" (see data code table)
5. Read "Save" (see data code table)
6. Read "Exit Settings"
Customized prefixes

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 17 van 47
2.3.10 Custom suffix on/off settings
The custom suffix adds a user-defined string after the decoded information. For example, it is
allowed to add a custom suffix and set the suffix to the string "AB", after reading the barcode with
the data of "123", the scanner adds the string "AB" after the string "123", and the host side receives
"123AB". After the barcode reading data is "123", the scanner will add the string "AB" after the
string "123", and the host side will receive "123AB".
If set to "Off", only the barcode data information will be in the decoded information, no suffix, and
the default value is to turn off the custom suffix output.
Enable
Disable (default)
Clear all custom suffixes
Output all
2.3.11 Custom suffixes
Custom suffix adds a user-defined string after the decoded information, and the output format
after customization is "barcode content + custom content".
Set the custom suffix to 'a' (the hex value of a is 0x61)
1. Read "Startup Settings"
2. Read the "Custom Suffix" setting code
3. Check the ASCII code of the character "a": the ASCII code of "a" is "0x61" (see ASCII code table)
4. Read data code: "6" "1" (see data code table)
5. Read "Save" (see data code table)
6. Read "Exit Settings"
Custom suffixes
2.3.12 Custom ID output method
The user can use Code ID to identify the barcode type and the Code ID corresponding to each
barcode type is customizable. The Code ID for all barcodes is 1 character.

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 18 van 47
Close Code ID (default): Code ID is not spliced to the read string.
Code ID prefix: The Code ID is spliced before the recognition string.
Code ID suffix: The Code ID is spliced after the recognition string.
Restore the Code ID of all barcodes, including Codabar, to the default value of.
1. Read "Startup Settings"
2. Read "Clear all custom Code IDs".
3. Read "Exit Settings"
Disable CODE ID (default)
Code ID prefix
Code ID suffix
Clear all custom Code IDs
2.3.13 Customize Code ID
Please refer to the following example for how to modify the Code ID.
Modify the Code ID of Codabar (Code ID:0x61) to "Y" (hexadecimal value 0x59).
1. Read "Startup Settings"
2. Read "Custom Code ID"
3. Check the Code ID of the barcode: the Code ID of "Codabar" is "0x61" (see the list of code system
support)
4. Check the ASCII code of the character "Y": the ASCII code of "Y" is "0x59" (see ASCII code table)
5. Read data code: "6" "1" "5" "9" (see data table)
6. Read "Save" (see data code table)
7. Read "Exit Settings"
Custom Code ID

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 19 van 47
2.3.14 Terminator settings
The terminator suffix is used to mark the end of a complete piece of data information. The
terminator suffix stands alone and does not participate in any other form of data formatting. The
terminator suffix must be the last piece of data sent, and no additional data will be added
thereafter.
The ending character can be set to carriage return, line feed, carriage return line feed, tab or ETX,
and the default ending character is set to carriage return.
No terminator
Enter (default)
Line Feed (Down)
Carriage return + Line feed (Enter+Down)
Tab
ETX

User manual ‘DT3108’
Datum : feb-2024
Versie : 1.0
pagina 20 van 47
2.3.15 CTRL + X
Non- printable
ASCII control characters
Keyboard Control + ASCII ( CTRL+ X) Mode
Control + X Mode Off
Windows Mode Control + X
Mode On
DEC
HEX
Char
CTRL + X
CTRL + X
function
0
00
NUL
CTRL+ @
1
01
SOH
NP Enter
CTRL+ A
Select all
2
02
STX
Caps Lock
CTRL+ B
Bold
3
03
ETX
ALT Make
CTRL+ C
Copy
4
04
EOT
ALT Break
CTRL+ D
Bookmark
5
05
ENQ
CTRL Make
CTRL+ E
Center
6
06
ACK
CTRL Break
CTRL+ F
Find
7
07
BEL
Enter / Ret
CTRL+ G
8
08
BS
CTRL+ H
History
9
09
HT
Tab
CTRL+ I
Italic
10
0A
LF
CTRL+ J
Justify
11
0B
VT
Tab
CTRL+ K
hyperlink
12
0C
FF
Delete
CTRL+ L
list, left align
13
0D
CR
Enter / Ret
CTRL+ M
14
0E
SO
Insert
CTRL+ N
New
15
0F
SI
ESC
CTRL+ O
Open
16
10
DLE
F11
CTRL+ P
Print
17
11
DC1
Home
CTRL+ Q
Quit
18
12
DC2
PrtScn
CTRL+ R
19
13
DC3
Backspace
CTRL+ S
Save
