DUO-FAST DF150S-TC User manual

1
Part # 503400
IMPORTANT!
DO NOT DESTROY
It is the customer’s responsibility to have all
operators and service personnel read and
understand this manual.
OPERATING MANUAL AND
SCHEMATIC
503410-3
07/10
PRINTED IN U.S.A.
© 2010, Illinois Tool Works, Inc.
MODEL DF150S-TC
TICO NAILER

2
INTRODUCTION
TOOL AND FASTENER SPECIFICATIONS ................................................................. 3
SAFETY INSTRUCTIONS ............................................................................................. 4
TOOL INSTALLATION AND OPERATION ................................................................ 5-6
AIR SYSTEMS ............................................................................................................. 7-8
FEATURES AND BENEFITS .......................................................................................... 9
EXPLODED VIEW AND SPARE PARTS LIST ....................................................... 10-11
MAINTENANCE ....................................................................................................... 12-13
TROUBLESHOOTING .................................................................................................. 14
WARRANTY .................................................................................................................. 15
ACCESSORIES ........................................................................................................... 16
The DUO-FAST® DF150S-TC Tico Nailer is a quality-built tool designed for use in
residential framing applications. This tool will deliver efficient, dependable performance
when used according to the manufacturer’s guidelines. Please study this manual,
including the safety instructions, to fully understand the operation of this tool.

3
TOOL SPECIFICATIONS
MODEL NO. DF150S-TC (Part# 503400)
HEIGHT
11.7”
WIDTH
LENGTH 13"
WEIGHT 6 lbs. 4 oz.
OPERATING PRESSURE 90 to 120 psi (6.2 to 8.3 bar)
FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
This tool uses a 1/4” N.P.T. male plug. The fitting must be capable of discharging
tool air pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
90 to120 psi (6.2 to 8.3 bar). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
NAIL LENGTH 1-1/2”
SHANK DIAMETER .131-.148
TOOL AND FASTENER SPECIFICATIONS
NAIL COATINGS Heat Treated,
Galvanized Heat Treated
MAGAZINE TYPE 30 Degree, 1 Strip
3.7”

4
WARNING
Failure to follow any of the above instructions could result in severe personal
injury to tool user and bystanders or cause damage to tool and property.
SAFETY INSTRUCTIONS
SAFETY FIRST
WEAR EYE AND HEARING PROTECTION
Always wear hearing and eye protection devices, that
conform to ANSI Z87.1 requirements, when operating
or working in the vicinity of a tool. As an employer you
are responsible for enforcing the use of eye protection.
Wear hard hats in environments that require their use.
THE TOOL MUST BE USED ONLY FOR THE PUR-
POSE FOR WHICH IT WAS DESIGNED
Do not throw the tool on the floor, strike the housing in
any way or use the tool as a hammer to knock
material into place.
NEVER ENGAGE IN HORSEPLAY WITH THE TOOL
The tool is not a toy so do not use it like one. Never
engage in horseplay with the tool or point it at yourself
or any other person, even if you think it is not loaded.
NEVER ASSUME THE TOOL IS EMPTY
Check the magazine for fasteners that may be left in the
tool. Even if you think the tool is empty or disconnected,
never point it at anyone or yourself. Unseen fasteners
could fire from the tool.
NEVER CLAMP THE TRIGGER IN A LOCKED OR
OPERATING POSITION
The trigger of the tool must never be tampered with,
disabled or clamped in a locked or operating position
since this will cause the tool to drive a fastener any
time the work contacting element depressed.
DO NOT LOAD FASTENERS WITH THE AIR LINE
CONNECTED, OR WITH THE TOOL TRIGGER OR
WORK CONTACTING ELEMENT DEPRESSED
When loading fasteners into the tool be sure you
disconnect the air line and that you do not depress
the trigger or work contacting element.
OPERATE THE TOOL ONLY ON A WORKPIECE
The tool should be operated only when it is in contact
with the workpiece. Even then you should be careful
when fastening thin material or working near the edges
and corners of the workpiece since the fasteners may
drive through or away from the workpiece.
DO NOT DISABLE OR REMOVE THE WORK
CONTACTING ELEMENT
This tool is equipped with a safety mechanism, called
a work contacting element, to help prevent accidental
firing. Never tamper with, disable or remove the work
contacting element. Do not use the tool unless the
work contacting element is working properly. The
tool could fire unexpectedly.
DISCONNECT THE TOOL WHEN NOT IN USE
Always disconnect the tool from the air line when it
is not in use, when you leave the work area or when
moving the tool to a new location. The tool must
never be left unattended because people who are
not familiar with the tool might handle it and injure
themselves or others.
CARRY THE TOOL ONLY BY THE HANDLE
Always carry the tool by the handle only. Never carry
the tool by the air hose or with the trigger depressed
since you could drive a fastener unintentionally and
injure yourself or someone else.
DO NOT WEAKEN THE TOOL HOUSING
The tool housing is a pressure vessel and should never
be weakened by having your company’s name, area of
work or anything else stamped or engraved into its
surface.
DISCONNECT THE TOOL WHEN PERFORMING
REPAIRS AND CLEARING JAMS
Never attempt to clear a jam or repair a tool unless you
have disconnected the tool from the air line and
removed all remaining fasteners from the tool.
ALWAYS USE THE PROPER FITTING FOR THE
TOOL
Only MALE pneumatic type air connectors should be
fitted to the tool, so that high pressure air in the tool is
vented to atmosphere as soon as the air line is
disconnected.
NEVER install FEMALE quick disconnect couplings on
the tool. Female couplings will trap high pressure air in
the tool when the air line is disconnected, leaving the
tool charged and able to drive at least one fastener.
DO NOT EXCEEDTHE MAXIMUM RECOMMENDED
AIR PRESSURE
.erusserpriadednemmocerehttaylnolootehtetarepO
Do not exceed the maximum air pressure marked on
the tool. Be sure the air pressure gauge is operating
properly and check it at least twice a day.
Never use any bottled air or gases such as oxygen to
operate the tool since they could cause the tool to
explode.
INSPECT TOOL FOR PROPER OPERATION
.deriuqersaetacirbuldnayliadtsaeltalootehtnaelC
Never operate a dirty or malfunctioning tool.
USE ONLY PASLODE RECOMMENDED PARTS AND
FASTENERS
Use only parts and fasteners specifically designed and
recommended by Duo-Fast® for use in the tool and
for work to be done. Using unauthorized parts and
fasteners or modifying the tool in any way creates
dangerous situations. Replace all missing warning
labels---refer to tool schematic for correct placement
and part number.
These safety instructions provide information necessary
for safe operation of Duo-Fast® tools. DO NOT ATTEMPT
TO OPERATE THE TOOL UNTIL YOU READ AND
UNDERSTAND ALL SAFETY PRECAUTIONS AND
MANUAL INSTRUCTIONS.

5
TOOL INSTALLATION
Your Duo-Fast® tool comes ready for immediate use
and can be installed by following these steps:
1. SAFETY - All tool operators and their immediate
supervisors must become familiar with the operator
safety instructions before operating the tool. The
instructions are on page 4 of this manual.
2. Included with each tool is a copy of the operation
manual and schematic.
Keep this publication for
future reference. An ownership registration card is
also included. This card must be completed and
returned to Duo-Fast®immediately to register your
ownership.
3. The plastic cap in the air inlet of the tool must be
removed before the male fitting is installed. The fit-
ting must be a male pneumatic type that discharges
the air from the tool when the air line is discon-
nected.
4. Install a filter/regulator/lubricator unit, with a
gauge as close as practical to the tool, preferably
within ten feet. Refer to the Air Systems section of
this manual for air hose requirements and lengths.
In general, no other special installation is required.
5. If the operator is working at a bench or table,
it is usually best to run the air line underneath the
bench. A small tray under the benchtop can hold
the fastener supply and the tool when not in use.
6. If this tool does not work when it is first connect-
ed, do not try to make repairs. Call your Duo-Fast®
representative immediately.
TOOL OPERATION
■Depress the work contacting element and hold
it against the work surface before pulling the
trigger.
■After each fastener is driven, completely release
the trigger and lift the tool from the work surface.
Driving of Nails
The tool is equiped with a sequential (gray) trigger
to operate the tool.
Step No. 1- Grasp the nailer handle firmly.
Loading of Nails
Step No. 2-Insert one strip of fasteners into the
rear of the magazine with the point of the nails
facing the nose area.
Step No. 3-Pull the follower to the rear of the
magazine until it is engaged behind the nails.
The tool is now ready to use.
Use only fasteners that meet Duo-Fast® specifications.
Use of fasteners that do not meet Duo-Fast® specifica-
tions can result in damage to the tool or injury to the
operator or bystanders.
WARNING
Note:
Follow the metal connector manufacturer’s
instructions when installing the nails. Always
use the nail size specified by the metal
connector manufacturer and/or the local
building codes.

6
TOOL OPERATION -
continued
Nose Probe
The nose probe’s unique design allows you to locate the hole on the metal connector.
Place the nose probe into the hole of the metal connector. Hold the tool perpendicular to the
metal connector.
Depress the work contacting element and hold it against the work surface then pull the trigger.
Note:
The probe is a wear item and should be replaced when it can no longer locate the hole in the
metal hardware.

7
AIR SYSTEMS
For air-powered tools to work their best, the air
supply system must be properly installed and
maintained regularly. A drawing in this section
shows a properly installed air supply system.
Handy checklists for installing and maintaining
air supply systems follow.
Indoor Air System Installation
-Be certain that:
•All pipes supplying air have a large enough
inside diameter to ensure adequate air supply.
•The main supply pipe slopes down, away from
the compressor (1/16 inch per foot).
•Air storage is provided along lengthy air lines.
•Pipe line branch outlets are at the top of the
main pipe line.
• Cutoff valves are provided at each branch pipe
line throughout the system.
•Water legs extend from the bottom of each branch
line.
•A refrigerant-type dryer is installed on the system.
•Air hoses are kept as short as practical.
•A regular maintenance program is followed.
Outdoor Air System Installation
-Be certain that:
•A moisture trap and a filter/regulator/lubricator are
installed at the compressor.
•Air hoses and fittings are large enough so that air
flow is not restricted. Minimum hose size is 3/8
inch ID with 1/2 inch ID hose used for any
application over 25 feet.
•Air hoses are not longer than 150 feet.
•The air system is lubricated regularly.
•A regular maintenance program is followed.
Filter/Regulator/Lubricator Units
Filter/regulator/lubricator units that can supply
enough air and protection for Duo-Fast®tools
must meet the following specifications:
•Minimum 3/8 inch NPT port size .
•50 micron or fine filters.
•Regulated pressure from zero to 120 psi.
•Lubricators designed for low or changing
airflow.

8
AIR SYSTEMS - Continued
Calculating Compressor Size
Use the air consumption chart in the Tool
Schematic for each tool when calculating the
operating requirements for the tools.
tools are designed to operate efficiently
between 80 and 120 psi and should never be
operated at pressure greater than 120 psi.
The air consumption chart will help you find the
correct compressor size for your application
that will quickly replenish tool air pressure.
To use the chart you will need to know how
many tools will be used and approximately
how many fasteners will be driven each minute
by each tool onthe line. Using the equation:
Number of tools X average fasteners/minute/
tool X 1.2 (safety factor) X air consumption
(scfm) @ pressure* (psi) = scfm required.
We can use the following example:
10 tools X 30 fasteners/minute/tool X 1.2 X
0.051scfm* (@100psi) = 18.36 scfm.
*This number is found in the Air Consumption
Chart
In this example, using the air consumption
chart we find that a compressor providing at
least 19 scfm of air is required. Because in
compressors approximately 1 hp is required to
produce 4 scfm, a compressor of at least 5 hp
is required.
Calculated Required Piping
For example, given a 20 hp electric compressor
supplying approximately 80 cfm of air at 120 psi
and a main supply pipe length of 350 feet, we see
by the table the minimum main pipe inside diam-
eter required for this application is 1-1/4 inch.
Pneumatic System Maintenance
- Be certain that:
•Pneumatic fittings are tight and do not leak.
and ensure that automatic draining systems are
operating correctly.
• Air lines are cleared to prevent freezing,
especially in winter.
• Lubricator operation is checked regularly and
ensure it has an adequate supply of lubricant.
(Part No. 403720)
• Only regulated air is being used and that each
regulator is operating properly.
Duo-Fast®

9
DF150S-TC FEATURES AND BENEFITS
Tool-less Adjustable
Exhaust Cap
Deflects air away
from user.
Bypass Follower
Quickly load nails in
place.
Rear Load Compact Magazine
Fits better in tight spaces.
Nose Probe
Comfort Grip
Ergonomic design provides
greater comfort.
Locates hole and
guides nail as it is
driven.
Compact Design
Left/Right Rafter Hook
Accommodates left-or right-
handed operators.
Nail Guide
Helps guide fasteners
into magazine for quick
loading.
Sequential Trigger
Lock-Out
Eliminates blank firing.
Promotes driver blade
durability.
End Cap
Inline Magazine
Narrow design for balance,
maneuverability, and unobstructed
operation.
For added nail control.
Able to get into tight
areas.

10
PARTS LEGEND DF150S-TC 503400
▲
1 503402 1 Main Valve Nut
2 502304 1 Air De ector
3 502343 1 Wave Washer
4 502339 4 S.H.C.S. #10-24 x 7/8”
5 408302 7 Flat Washer
6 503401 1 Cap
7 502313 1 Gasket, Cap
8 360594 1 Spring,
* 9 202382 1 O-Ring
*10 201806 1 O-Ring
*11 539676 1 O-Ring
*12
13
502056 1 Exhaust Seal Assembly
14
1011802 1 Washer
15
502327 1 B.H.C.S. 1/4-20 x 1-1/2”
16
502311 1 Piston Seal
17
502309 1 Sleeve,Cylinder
*18
502104 1 O-Ring, Flange
*20
192799 1 O-Ring, Flange
*21
502310 1 Check Band
22
502317 1 Bumper
24
502302 1 Housing W/Overmolded grip
*26
502345 1 S.H.C.S. 5/16-18 x 5/8”
27
502034 1 Label, Housing RIGHT
30
502305 1 End Plug, Housing
*28
502035 1 Label, Housing-Left
402963 1
29
32
502336 2 S.H.C.S. #10-24 x 1”
33
502306 1
34
380931 1 Roll Pin 3/16 x 1-1/2”
*35
502333 1 Roll Pin, Trigger 1/8 x 1-1/2”
*37
197913 1 O-Ring
502044 1
*38
502059 1 Spring, Valve Pin
39
1015358
1 O-Ring
*40
502045 1 Valve Pin
41
196345 1 O-Ring
*42
502043 1 Lower Valve Spool
43
092747 1 O-Ring
44
403796 1 Roll Pin 1/8”x 1-1/4”
45
502060 1 Spring, Trigger
▲
46
502225 1
S.H.C.S. 1/4-28 x 1/2”
*47
502224 1 Trigger, Sequential
48
502042 1 O-Ring
49
091866 2 Roll Pin 1/8” x 3/4”
50
002187 5 Lock Washer
*51
091545 4 S.H.C.S. 1/4-20 x 7/8”
52
502328 1
53
502321 1 W.C.E. Upper
54
502337 1 S.H.C.S. 1/4-20 x 3/8”
55
404800 1 Flat Washer
*56
502325 1
57
511059 1
58
502320 1
Drum Pin Assembly
59
502338 2
Negator Spring
▲
61
503409 1 Label
62
442681 1 Lock Nut
63
503404 1 Magazine Assembly
64
092037 1 Lock Nut
65
503407 1 End Cap, Magazine
66
502319 1 Follower Claw
67
68
502025 1
69
502017 1 B.H.C.S 1/4-20 x 3/4”
70
*19
502307 1 Flange
72
502335 1
B.H.C.S. 8-32 x 1/2”
73
502347 1 S.H.C.S. 10-32 x 5/8”
74 402734 1 Spring, Follower Body
1 Follower Body
60
502323 1
Magazine Washer
23
500729 1 Blade Seal
502332 1 Rafter Hook
*Denotes Normal Wear Items
**
Make sure Warning Label (Part No.502917)
is properly af xed. Replace if necessary.
Label available at no charge through the
Service Department.
▲ Apply Loctite 242 (Blue) Part No. 093500
■
Apply Loctite 620 (Green) Part
No. 401491
Denotes New Change
WARNING
All parts must be periodically inspected and replaced if
worn or broken. Failure to do this can affect the tool’s
operation and present a safety hazard.
AIR CONSUMPTION CHART
RENETSAFMFCS-NOITPMUSNOCRIA
AIR PRESSURE-PSIG
503406
25
31
36
502324 1 Pin, Trigger
71
500627 1
.120
.110
.080
.090
.100
120
.060
.070
11010090807060
➔
**
.086
503408 1
O-Ring, Housing End Plug
W.C.E. Guide Block
Nose
Upper Valve Spool
Trip Lever
Spring, W.C.E.
Probe Pin
Probe
W.C.E., Lower
Lockout Bar
502226 1
502340 1 Spiral Pin
▲
▲
▲
▲
▲
▲
*
®
®
Tico Nailer
➔

DF150S-TC
503400
503400
47
46
45
44
48
Trigge r
Assembly
#502253
Seal must be installed
in this position.
*
42
33
40
39
37
36
35
41
38
Trigge r
Valve
Assembly
#502908
43
Piston
Assembly
#502308
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 26
24
23
22
21
20
19
18
17
25
27
28 29 5
30
31
52
51
48
55
54
49
53
50
49
34
32
65
70
5
69
64
63
62
57
56
61
59
58
67
72
66
71
68
74
73
60
Torque Values
IN/LBS
15
20
160
180
80
140
140
80
120
140
70
Poppet
Assembly
#502920
*
Tico Nailer
11

12
MAINTENANCE
Duo-Fast®tools are built for ease of maintenance. A few
simple details will assure trouble-free operation and long
tool life. Anyone who uses or maintains the tool must read
the safety and maintenance instructions. Study the sche-
matic drawing before starting any repairs on the tool.
Air-operated tools must be inspected periodically, and worn
or broken parts must be replaced to keep the tool operating
safely and efficiently. Also the items on the maintenance
chart must be checked often.
Cold Weather Care
When temperatures are below freezing, tools should be
kept warm by any convenient, safe method. If this is not
possible, the following procedure should be used to warm
up the tools.
❑Reduce the regulated air pressure to 30 psi.
❑Remove all fasteners from the tool.
❑Connect an air line and blank fire the tool. The reduced
air pressure will be enough to free-fire the tool. Slow speed
operation tends to warm up the moving parts. Slowing up
the piston helps the bumper and the O-rings to become
springy.
❑Once the tool is warmed up, readjust the regulator to the
proper working pressure and reload the tool.
❑Tool operators working outdoors or in unheated areas in
extremely cold temperatures should also:
Use pneumatic oil with antifreeze in the lubricator,
Part No. 219090 (8oz.)
Cleaning the air-operated tools with solvents removes the
thin coating of grease applied to the cylinder wall and
O-rings at the factory. To replace this coating of grease,
use Chemplex grease (Part No. 403734).
❑Open the drain on the air compressor tank to drain any
moisture at least daily in extremely cold or humid weather.
A few ounces of antifreeze in the tank will keep the air
free of frost.
Testing the Tool After Servicing
After replacing any part or parts, it is important to check
the tool for proper operation. This ensures that the tool
was put together correctly, is safe to use, and will perform
the job properly.
❑Ensure that all hardware is tight.
❑Ensure that the work contacting element is installed
correctly in relation to the trigger, and that both parts move
freely.
❑Ensure that the magazine is properly attached.
❑Ensure that the required safety information on the tool
is legible.
❑Use only Duo-Fast®approved fasteners in the tool, and
ensure that they are correct for the application.
❑Ensure that a male air fitting is securely connected to
the tool.
❑Test the tool by driving fasteners into a workpiece iden-
tical to the tool's application.
❑Check the tool for air leaks during testing and for the
proper sequence of operation.
❑Ensure that all fasteners are driven to the same depth
and that the crown of the fastener is flush with the work-
piece.
Tool Lubrication
It is most important that the tool be properly lubricated by
keeping the air line lubricator filled and correctly adjusted.
Without proper lubrication the tool will not work properly
and parts will wear prematurely.
Use the proper lubricant in the air line lubricator. The
lubricator should be of low air flow or changing air flow
type, and should be kept filled to the correct level. Use
only Duo-Fast®recommended lubricants. Substitutes may
harm the rubber compounds in the tools O-rings and other
rubber parts. Part No. 403720 is a pneumatic lubricating
oil specially made for pneumatic applications.
If a filter/regulator/lubricator is not installed on the air sys-
tem, air operated tools should be lubricated at least once
a day with 6 to 20 drops of oil, depending on the work
environment, directly through the male fitting in the tool
housing.
Most minor problems can be resolved quickly and eas-
ily using the maintenance table that follows. If problems
persist, contact your Duo-Fast®dealer for assistance.
®

13
MAINTENANCE - Continued
Drain air line filter(daily).
Keep lubricator filled.
Clean filter element-then blow
air through filter in direction
opposite to normal flow.
Check that all screws on tool
are tight.
Keep work contacting element
working properly.
Keep magazine and feeder
mechanism clean.
Lubricate "O" rings that are
replaced.
Use only Duo-Fast®replacement
parts.
ACTION WHY
HOW
MAINTENANCE TABLE
Prevent accumulation of
moisture and dirt.
Keep tool lubricated.
Prevent clogging of filter with
dirt.
Prevent air leakage and pro-
mote efficient operation.
Promote operator safety and
efficient tool operation.
Prevent jamming of fasteners.
Assure long life and proper
operation of tool.
Keep tool operating efficiently
and maintain Paslode tool
warranty.
Open manual petcock (most
air supply systems have such
a valve).
Fill with pneumatic tool
lubricant. Part No. 403720.
Wash with soap and water or
follow manufacturers instruc-
tions.
Check screws daily.
Blow clean daily.
Blow clean daily.
Use Chemplex grease, Part
No. 403734.
Order any repacement parts
needed from Duo-Fast®Dealer.
Check the driver blade regularly
and replace when worn.
Ensure proper operation of the
tool. Remove piston and driver
assembly from tool and com-
pare with new driver blade.
Replace when worn.
®

14
OPERATOR TROUBLESHOOTING
PROBLEM CORRECTIVE ACTION
Fasteners will not drive completely into wood.
Fasteners penetrate properly during normal
operation, but won't drive fully at faster speeds.
Fasteners drive too deeply into wood.
Tools skips during operation - no fasteners are
driven from time to time.
Tool operates, but no fasteners are driven.
Air leaks at cap when tool is connected to air.
Increase air pressure (do not exceed 120 psi).
Increase air flow to tool -- use larger air lines
(3/8 inch ID minimum).
Reduce air pressure.
Check magazine for proper fasteners. Magazine fol-
lower should slide freely. Clean as needed to remove
debris.
Make sure correct fasteners are being used.
only.
Use fasteners that meet Duo-Fast®
specifications
Increase air flow to tool -- use larger air lines
(3/8 ID minimum).
Check magazine for proper fasteners. Fasteners
should slide freely with no follower pressure.
Increase air pressure (do not exceed 120psi).
Tighten capscrews.

15
An Illinois Tool Works Company
955 National Parkway
Schaumburg, Illinois 60173-5172
TOOL WARRANTY AND LIMITATIONS
TOOL WARRANTY
Duo-Fast®warrants that newly purchased power
fastening tools, parts and accessories will be free
from defects in material and workmanship for the
period shown below, after the date of delivery to the
original user.
90-DAY LIMITED WARRANTY
A 90-day warranty will apply to all parts, except
those which are specifically covered by an extended
warranty.
EXTENDED LIMITED WARRANTY FOR ON SITE
CONSTRUCTION APPLICATIONS
assembly castings. A six month warranty will apply
to all magazine parts.
NORMAL WEARING PARTS
The following parts are considered normal wearing
parts and are not under warranty.
• Bumper
• Driver Blades
• ”O” Rings
• Piston Rings
• Probe
WARRANTY STATEMENT
Thiswarrantyis limitedtotools soldandservicerequested
in the United States. To obtain information on warranty
service in the United States, refer to the Service Center
listing that was provided with your tool.
Duo-Fast's sole liability hereunder will be to replace any part
or accessory which proves to be defective within the specific
time period. Any replacement part or accessory provided in
accordance with this warranty will carry a warranty for the
balance of the period of warranty applicable to the part it
replaces. This warranty does not apply to part replacement
required due to normal wear.
This warranty is void as to any tool which has been subjected
to misuse, abuse, accidental or intentional damage, use with
fasteners,fuel,batteries,orbattery chargers not meeting Duo-
Fast specification, size, or quality, improperly maintained,
repaired with other than genuine Duo-Fast®replacementparts,
damagedintransitor handling,orwhich,in Duo-Fast's opinion,
has been altered or repaired in a way that affects or detracts
from the performance of the tool.
DUO-FAST®MAKES NO WARRANTY, EXPRESSED OR
IMPLIED, RELATING TO MERCHANTABILITY, FITNESS,
OR OTHERWISE, EXCEPT AS STATED ABOVE, and DUO-
FAST's liability AS STATED ABOVE AND AS ASSUMED
ABOVE is in lieu of all other warranties arising out of, or
in connection with, the use and performance of the tool,
except to the extent other wise provided by applicable law.
DUO-FAST®SHALL IN NO EVENT BE LIABLE FOR ANY
DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES,
INCLUDING, BUT NOT LIMITED TO, DAMAGES WHICH
MAY ARISE FROM LOSS OF ANTICIPATED PROFITS OR
PRODUCTION, SPOILAGE OF MATERIALS, INCREASED
COST OF OPERATION, OR OTHERWISE.
A one year warranty will apply to all housing and cap
Duo-Fast®reserves the right to change specifications, equipment, or
designs at any time without notice and without incurring obligation.

Lubricants and Loctite
Loctite 242 (Blue) Part No. 093500
Lubricating Oil 16 oz. Part No. 403720
Lubricaing Oil with Antifreeze 8 oz. Part No. 219090
Chemplex 710 Lubricant 1lb.
Part No. 403734
Tool Cleaner
Ideal cleaner for all Duo-Fast®tools. Part No. 219348
Safety Glasses
283104.oNtraPraelC
ACCESSORIES
®
®
Lubricant 5 gram tube
Part No. 219188
Duo-Fast® is a registered trademark of ITW.
All other trademarks are property of their respective owners.
®
An Illinois Tool Works Company
955 National Parkway
Suite 95500
Schaumburg, Il 60173
www.duo-fastconstruction

Lubricantes Y Loctite
Loctite 242 (Azul) Pieza No. 093500
Aceite Lubricante 16 oz. Pieza No. 403720
Aceite Lubricante con Anticongelante 8 oz. Pieza No. 219090
Lubricante Chemplex®710 1lb. Pieza No. 403734
Limpiador
Pieza No. 219348
Lentes de Seguridad
Claros Pieza No. 401382
ACCESORIOS
PUBLICADO EN EE.UU.
© 2010, Illinois Tool Works, Inc.
®
Una Compañia de Illinois Tool Works
El limpiador ideal para todas las herramientas.
Lubricante en Tubo de 5 gramos
Pieza No. 219188
Duo-Fast®es una marca registrada de ITW.
Las marcas registradas son propiedad de
sus empresas individuales.
®
955 National Parkway
Suite 95500
Schaumburg, Il 60173
www.duo-fastconstruction

15
GARANTÍA
TERMINOS DE LA GARANTÍA
Duo-Fast®garantiza que sus herramientas mecánicas,
sus piezas y accesorios, que hayan sido comprados
nuevos, están libres de defectos de material y
fabricación por el período indicado más abajo, a partir
de la fecha de compra del comprador original.
DECLARACIÓN DE LA GARANTÍA
Esta garantía esta limitada a las herramientas vendi-
das y revisadas en los Estados Unidos. Para obtener
más información sobre el servicio de garantía en los
Estados Unidos, véa la lista de Centros de Servicio
que fue proporcionada con su herramienta.
Duo-Fast asume únicamente la responsabilidad de reponer
cualquier pieza o accesorio que se compruebe como defec-
tuoso dentro del período especificado. Cualquier pieza o
accesorio de repuesto, entregado de conformidad con esta
garantía, gozará de la garantía por el período restante de la
garantía que cubría a la pieza o al accesorio original. Esta
garantía no cubre las piezas que necesitan ser repuestas
como consecuencia de su desgaste normal.
Se cancelará esta garantía a cualquier herramienta que haya
sido usada incorrectamente, dañada accidental o intencio-
nalmente, usada con sujetadores, combustible, baterías o
cargadores de batería que no reúnan las especificaciones,
el tamaño o la calidad de Duo-Fast, o a la que no se le haya
dado el mantenimiento o el uso adecuado, o que haya sido
reparada con piezas que no sean marca Duo-Fast, o que
en opinión de Duo-Fast hayan sido modificadas o reparadas
de manera que afecte o sea contraria al funcionamiento de
la herramienta.
DUO-FAST®NO OTORGA NINGUNA GARANTÍA EX-
PLÍCITA O IMPLÍCITA CON RESPECTO A LA COMER-
CIALIZACIÓN O ADAPTACIÓN AL USO PREVISTO, O DE
CUALQUIER OTRA NATURALEZA, CON EXCEPCIÓN DE
LO DECLARADO ANTERIORMENTE, y la responsabilidad
de Duo-Fast®TAL COMO SE INDICA Y SE ASUME MÁS
ARRIBA reemplaza a todas las otras garantías que resulten
o estén relacionadas con el uso y funcionamiento de la
herramienta, excepto según lo estipulen las leyes pertinen-
tes. DUO-FAST®NO SERÁ RESPONSABLE EN NINGÚN
CASO POR NINGÚN DAÑO DIRECTO, INDIRECTO O
CONSECUENTE INCLUYENDO, PERO SIN LIMITARSE,
CUALQUIER DAÑO RESULTADO DE LA PÉRDIDA DE
PRODUCCIÓN O GANANCIAS ANTICIPADAS, EL DETE-
RIORO DE MATERIALES, AUMENTOS EN EL COSTO DE
OPERACIÓN O CUALQUIER OTRO.
Una Compañia de Illinois Tool Works
955 National Parkway
Schaumburg, Illinois 60173-5172
Duo-Fast®se reserva el derecho de cambiar las especificacionnes, el equipo o los
diseños en cualaquier momento, sin aviso previo y sin incurrir en obligación alguna.
GARANTIA LIMITADA DE 90 DÍAS
La garantia limitada de 90 días cubre todas las
piezas, con excepción de las que estén especifica-
mente cubiertas por una garantía extendida.
GARANTIA LIMITADA ADICIONAL PARA APLICA-
CIONES EN EL LUGAR DE CONSTRUCCION.
Todas las piezas fundididas del armazón y de la tapa
están cubiertas por una garantía de un año.
Todas las piezas del cargador están cubiertas por
una garantía de seis meses.
PIEZAS DE DESGASTE NORMAL
Las siguientes piezas se consideran como piezas
que sufren desgaste normal y no están cubiertas por
ninguna garantía.
• Amortiguador
• Hojas del impulsor
• “O rings”
• Anillos del pistón
• Sonda

30
DETECCION Y CORRECCION DE FALLAS
14
PROBLEMA SOLUCIÓN
Los sujetadores no penetran completamente en la
madera.
Los sujetadores penetran bien durante las operaciones
normales, pero fallan a velocidades más altas.
Los sujetadores penetran demasiado en la madera.
Los sujetadores se acumulan en la punta de la her-
ramienta.
La herramienta “salta” mientras está funcionando; de
vez en cuando no impulsa sujetadores.
La herramienta funciona, pero no dispara sujetadores.
Hay pérdidas de aire en la cubierta cuando la herra-
mienta está conectada a la línea de aire.
Aumente la presión de aire (no debe exceder 120 psi).
Aumente el flujo de aire a la herramienta; use líneas
de aire más grandes (3/8” de diámetro como mínimo).
Reduzca la presión de aire.
Abra el seguro delantero, quite el sujetador obstruido y
cierre bien el segurro.
Compruebe si el cargador tiene los sujetadores apro-
piados. El transportador debe deslizarse sin dificultad.
Límpielo para quitar cualquier suciedad.
Verifique que se usen los sujetadores apropiados.
Use solamente sujetadores que reúnan las especifica-
ciones de Duo-Fast®.
Aumente el flujo de aire a la herramienta; use líneas
de aire más grandes (3/8” de diámetro como mínimo).
Compruebe si el cargador tiene los sujetadores apro-
piados. Los sujetadores deben deslizarse libremente
sin presión del transportador.
Abra el seguro delantero o afloje el botón del cargador
y revise si hay suciedad o alguna obstrucción en el
área de la punta. Límpiela si es necesario.
Aumente la presión de aire (no debe exceder 120 psi).
Apriete los tornillos.
PRECAUCIÓN
Desconecte la herramienta al hacer cualquier
reparación o eliminar cualquier obstrucción.

29
13
MANTENIMIENTO (continuación)
ACTIVIDAD POR QUE COMO
Purgar el filtro de la línea de aire a
diario.
Mantenga lleno el lubricador.
Limpie el elemento del filtro;
luego, sople aire a través del filtro
en la dirección opuesta a la
corriente normal.
Verifique que todos los tornillos de
la herramienta estén apretados.
Revise si el elemento de contacto
funciona correctamente.
Mantenga limpios los mecanismos
del cargador y del alimentador.
Lubrique los anillos-o que se
hayan reemplazado.
Use solamente piezas de repuesto
Duo-Fast®.
Para evitar que se acumulen la
humedad y la suciedad.
Para mantener lubricada la
herramienta.
Para evitar que la suciedad ob-
struya el filtro.
Para evitar pérdidas de aire y
asegurar el buen funcionamiento
de la herramienta.
Para promover la seguridad del
operador y el buen funcionamiento
de la herramienta.
Par prevenir que se obstruyan los
sujetadores.
Para prolongar la vida de la
herramienta y su funcionamiento
adecuado.
Para que la herramienta continúe
funcionando eficientemente y
mantener vigente la garantía de
Duo-Fast®.
Abra la llave de escape.
(La mayoría de los sistemas
neumáticos la tienen.)
Llene con lubricante neumático
N° 403720 (474 ml).
Lave con agua y jabón, o siga las
instrucciones del fabricante.
Revise los tornillos a diario.
Límpielo con aire a diario.
Límpielos con aire a diario.
Use grasa lubricante Chemplex
N° 403734.
Solicite al representante de
Duo-Fast®cualquier pieza de
repuesto que necesite.
PRECAUCIÓN
Desconecte la herramienta al hacer cualquier
reparación o eliminar cualquier obstrucción.
TABLA DE MANTENIMIENTO
Revise la hoja de impulso
periódicamente y reemplaze si
esta desgastada.
Asegure el funcionamiento apropiado
de la herramienta.
La punta de la hoja de impulso se
debe inspeccionar periódicamente
por desgastes.
Reemplaze cuando este
desgastada.
®
