DVB STJL-04 User manual

6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
PRODUCT
INSTALLATION MANUAL
HINGE STEPS (PAIR)
07+/20+ JEEP JK/JL/JT WRANGLER/ GLADIATOR
STJL-04
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
- T45 Torx Bit (T40 for JK)
- 5mm Allen Bit
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself however,
additional help will be useful
- 1 Hour
Time to install this should only
take about an hour
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 1 | Prior to removal of any
hardware, it is necessary to close the door
tightly and folded cardboard/paper in the
bottom door seem.
This will prevent the door from moving
or shifting while the hinge hardware is
removed.
DO NOT OPEN THE DOOR WHILE THE
HARDWARE IS REMOVED.
STEP 2 | Use a T45 (T40 for JK) bit to
remove the bolts securing the hinges to
the doors.
It is recommended to break the hardware
loose with a breaker bar rst. Be careful,
this hardware can strip easily.
Begin by unpacking all items and inspecting
for missing pieces or damage. If you have any
concerns, please contact the company the
product was purchased from. Extra hardware
may be included with the product.
(8) M8x35 Allen
(8) Aluminum Spacers
HARDWARE INCLUDED

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 3 | Use the supplied M8
hardware and spacers to secure the steps
loosely to both hinges.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 4 | With the step loosely secure,
adjust the step so it is centered on the
hinges and covering the mounting holes,
then secure using a 5mm allen bit.
STEP 5 | Remove cardboard/paper
from the seem under the door.
Double check tment and hardware is
secure.
STEP 6 | Congrats! You are nished
with the install of the 18+/20+ JL/JT
Wrangler/Gladiator Hinge Steps!
