DW DWC-B1362TIR650 User manual

ABOUT MANUAL
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
High Resolution Bullet Camera
DWC-B1362TIR650
08092012

22
PRECAUTIONS
FCC COMPLIANCE
WARNING : Changes or modifications are not expressly approved by the manufacturer.
Do not open or modify.
Do not open the case except during maintenence and installation,
for it may be dangerous and can cause damages.
Do not put objects into the unit.
Keep metal objects and flammable substances from entering the camera.
It can cause fire, short-circuits, or other damages.
Be careful when handling the unit.
To prevent damages, do not drop the camera or subject it to shock or vibration.
Do not install near electric or magnetic fields.
Protect from humidity and dust.
Protect from high temperature.
Be careful when installing near the ceiling of kitchen or a boiler room,
as the temperature may rise to high levels.
Cleaning
To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.
Mounting Surface.
The material of the mounting surface must be strong enough to support the camera.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to Provide reasonable protection against harmful
interference. when the equipment is operated in a residential environment. This equipment generates, uses,
and radiates radio frequency energy; and if it is not installed and used in accordance with the instruction
manual, it may cause harmful interference to radio communications.

3
Table of Contents
Introduction
Installation
Troubleshooting
Warranty Information
Memo 18-19
Specifications
Features
Parts and Descriptions
Dimensions
Included Accessories
Surface Mount Installation
Connecting to Monitors
4
5
6
7
8
9
10
13
14-15
16-17
Camera’s Control Board
Adjusting the Camera’s Angle
Adjusting the Camera’s Lens 11
12

4
FEATURES*
1/3” Sony Super HAD Ⅱ CCD
570TV Lines (B/W), 540TV Lines (Color)
6 ~ 50mm Varifocal Auto Iris Lens
250ft Range IR with Intelligent Camera Sync
True Day & Night / TDN5 (Electro Magnetic Mechanism)
DRC (Dynamic Range Compressor)
HME (Highlight Masking Exposure)
SLC (Side Light Compensation)
AGC / BLC / AWB
Negative Imaging
Mirror Image Control
RS485 Built-In
Programmable Privacy Zone (4) & Motion Detection
Easy Icon Driven OSD Menu with Built-In Joystick
Auto Sensing 12VDC or 24VAC with Line Lock
Secondary Video-BNC Output

5
5
PART & DESCRIPTIONS*
1
11
3
910
12
13
2
4
56
7
8
1Front Case
2Zoom, Focus Housing
3Sunshield
4Lens
5Rear Case
6Control Board
7Con Cap
8Double Arm Bracket
9BNC Jack
Assembly Screw
Fixing Screw
Set Screw
10 Power Input Connector
DC 12V / AC24V Voltage
11
12
13
RS 485
OPTION

6
DIMENSIONS IN MILLIMETERS*
230.0
(9.05”)
86.5
(3.4”)
122
(4.8”)
96.5
(3.8”)
68
(2.67”)
68
(2.67”)
96
(3.77”)
5
(0.2”)
78
(3.07”)

INSIDE THE BOX*
Included with B2 Bullet Camera
1
2
3
4
5
6
User Manual
Mounting Template
4 Machine Screws and 4 Dry Wall Anchors
Secondary Video-BNC Cable
L-Key
Double-Sided TORX-T20 Hex Key
ABOUT MANUAL
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Bullet Camera
7

8
SURFACE MOUNT INSTALLATION INSTRUCTIONS*
Use the 4 mounting screws to install the camera on the
wall or ceiling.
Then, follow the next step on the pages 9-12.
NPT 3/4” Pipe

*Installation Using a Junction Box
*Note: Electrical junction box and required screws sold separately.

Use the diagram below to connect to a Monitor or CRT Monitor properly.
12VDC/24VAC
Monitor
CCTV Monitor
Second Video Output
Right
Left
Up
Down
Power connection - 12VDC/24VAC Dual Voltage (Auto Polarity Detection and Protection)
All camera are equipped with a second video output for on-site configuration.
9
CONNECTING TO MONITORS*

10
Joystick: Controls the OSD menu.
Secondary Connector:
Video Output Connector for
On-Site Configuration
CONTROL BOARD*
Remove clear plastic ring from the control cap.
Turn control cap counter-clockwise until cap separates completely from the camera body.
1
2
