DW DWC-V7253WTIR User manual

Quick Start Guide Quick Start Guide
1. The mounting surface must withstand five times the weight of your
camera.
2. Pay attention to the cables. The can easily become caught and
damaged. Any damage may cause a short or fire.
3. Detach the camera’s dome cover by loosening the 2 screws on the
dome using the included torque wrench.
4. Use the mounting template to mark and drill the necessary holes in
the mounting surface.
STEP 1 – PREPARING TO MOUNT THE CAMERA
Pass the wires through the mount bracket and make all necessary
connections. Connect the BNC cable and power cables to the
camera.
STEP 2 – CABLING THE CAMERA TO
EXTERNAL DEVICES
Power requirements Power consumption
12VDC ON LY !
CAUTION! The camera supports
DC power supply only
DC12V(LED o): 1.7W
DC12V(LED on): 2.9W
Tel: [phone]
Technical Support Hours:
9:00AM – 8:00PM EST, Monday thru Friday
digital-watchdog.com
WHAT’S IN THE BOX
Mounting
bolt and nuts 1 set Mounting templates 1
Hex Allen
wrench 1Quick set up guide 1
Screws
and plastic
anchor-2pcs
1 set Test video
cable 1
Protective sheet
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Manual
Template Sheet
for installing by Bolt & Nut
Mount Bolt & Nut
Screw &
Plasc Anchor-2pcs
Torx Wrench
Test Video Cable
Attention: This document is intended to serve as a quick reference for initial
set up. It is recommended that the user read the entire instruction manual for
complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in
the ‘Search by Product’ search bar. Results for
applicable part numbers will populate automatically
based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
DW® Universal HD over Coax®
ultra low-profile vandal dome cameras
DWC-V7253WTIR
Mounting template
Protective sheet

Quick Start Guide
1. The camera supports HD-Analog, HD-CVI and HD-TVI signals. To
switch between the signals:
a. Remove the camera’s dome to access the joystick and OSD
control on the base of the camera.
b. Use the OSD Switch to switch the camera’s signal.
1. Once all cables have been connected, use the screws included with
the camera to properly mount and secure the camera to the mounting
surface.
2. Adjust the camera’s pan, tilt and position to achieve the desired view.
The cameras’ max angles are:
Pan: 0° ~ 360°
Tilt: 0° ~ 70°
Rotation: 0° ~ 360°
3. Once the installation is complete, remove the protective film from the
camera’s dome cover.
4. The camera has a manual IR switch, located under the camera’s lens.
You can use this switch to manually turn the IR LED board on or o
according to the installation needs.
STEP 4 – INSTALLING THE CAMERASTEP 3 – CHANGING THE SIGNAL IN
THE CAMERA
Rev Date: 09/19
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
Mounting template
1. Using the bolt and nut mounting template, mark and drill the
necessary holes in the mounting surface.
2. Pass wires through and make all connections (see STEP 2 for more
information).
3. Secure the two long mounting screws to the camera’s base.
4. Mount the camera to the mounting surface by using the 2 mounting
nuts.
5. Rotate the locking discs over the screws until the camera is held
tightly from the mounting surface.
For a bolt and nut installation:
Rotation 360°
Titling 70°
Panning 360°
On/o
- To switch the camera to
HD-TVI mode, press OSD
joystick to the left
for 5 seconds.
- To switch the camera to
HD-Analog mode, press OSD
joystick to the right
for 5 seconds.
- To switch the camera to CVBS
mode, press OSD joystick up
for 5 seconds.
- To switch the camera to
HD- CVI mode, press OSD
joystick down for 5 seconds.
DOWN
UP
