DXV Modulus D19025036 Series User manual

- 1 -
INSTALLATION INSTRUCTIONS
SAVE FOR FUTURE USE
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2015 7302268-100 Rev. A (8/17)
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work has begun.
ROUGHING-IN DIMENSIONS:
• For reference
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid extreme
changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units. Avoid placing
furniture directly under windows.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
Model D19025036 Series
DXV Modulus™
Wall-Hung Drawer Unit
10'
Electric
Drill Tape Measure
#10 x 2" Flat
Phillips Screws
¼" x 1 ½"
Lag Screw
Level
Square
36"
(914 mm)
21"
(533 mm)
8-9/16"
(218 mm)
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx

- 2 - 7302268-100 Rev. A (8/17)
DRAWER INSTALLATION
• Studded walls must be exposed for installation of brackets.
• Provide suitable 2x8 horizontal brace at least 36" long, notched and
ush to exposed studs where the drawer will be mounted. Figure 1.
NOTE: Remove bracket mounting screws to remove brackets from drawer.
• Brackets must be spaced at 34-1/2" apart on the 2x8 horizontal brace
and level. Mark these hole locations on the 2x8. Figure 2.
• Drill 3-32" pilot holes for each of the holes where the 1/4 x 1-1/2"
Lag Screws will go.
• Install each bracket using the 1/4 x 1-1/2" Lag Screws ensuring the
brackets are level and at the required 34-1/2" distance from each other.
• Finish covering the wall with waterproof drywall.
Do not cover the brackets mounting base area.
• Unpack unit carefully, taking care not to damage the corners, unit is heavy.
• Remove the drawer from the cabinet by rotating the plastic clips underneath
the drawer rails, then pull drawer off the rails.
• Place the cabinet section of the drawer into the mounting brackets and
ensure the cabinet sits ush against the surface of the wall.
• Drill a 1/8" pilot hole through each of the brackets holes into
the wooden cabinet.
CAUTION: DO NOT DRILL THROUGH THE SIDE OF THE CABINET!
• Use a #10 x 1-3/4" wood (preferably MDF) screws to attach the cabinet
to the bracket.
• Place the drawer back onto the cabinet rails and latch the plastic clips back
into place to secure the drawer to the cabinet rails.
Figure 1.
Figure 2.
2x8 BRACE
34-1/2" D.
BRACKETS
34-1/2"
(876 mm)
