DXV Modulus D19075036LH Series User manual

- 1 -
INSTALLATION INSTRUCTIONS
SAVE FOR FUTURE USE
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017 7302327-100 (4/17)
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work has begun.
ROUGHING-IN DIMENSIONS:
• For Reference
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid extreme
changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units. Avoid placing
furniture directly under windows.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
Model D19075036LH Series
DXV Modulus™
Wall-Hung Vanity - Left Hand
10'
Electric
Drill Tape Measure
#10 x 2” Flat
Phillips Screws
Level
Square
36"
(914 mm)
21"
(533 mm)
25-15/16"
(658 mm)
XX"
(XX mm)
11-3/4"
(298 mm)
11-3/4"
(298 mm)
34-5/8"
(880 mm)

- 2 -
7302327-100 (4/17)
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
VANITY INSTALLATION
• Unpack unit carefully, taking care not to damage corners, unit is heavy.
• Provide suitable 2x6 reinforcement required for anchoring the vanity to
the wall using the vanities stringer.
• Roughing-in supply lines and waste per roughing-in dimensions. Figure 1.
NOTE: Vanity is designed for a lavatory/sink with a drain that is
offset to the left and not center of the vanity.
• Remove both vanity drawers to aid moving and handling of vanity
and to provide room to connect water supplies and drain. To do so,
move white tab all the way under drawer rail to one side, then pull
the orange tab towards the inside which will release drawer
from slide rail.
• Mark wall using the provided wooden stringer where the vanity will be hung.
NOTE: Water supply and drain need to be offset to the left of vanity to clear
opening in the top drawer when installed. Figure 2.
• Screw the stringer into place using 4, #10 x 2” screws.
Carefully lift vanity onto stringer and ensure vanity sits at
and square to surface of wall with no gaps between vanity
and wall. Ensure vanity is level.
WATER/DRAIN CENTER LINE (OFFSET TO LEFT OF VANITY)
Figure 1.
Figure 2.
• Carefully place vanity on its back side to expose the underside/bottom
of the vanity.
• Threaded mounting holes for supplied screws are installed on both
sides of the vanity.
• Vanity legs are screwed in place with the supplied screws on each side.
NOTE: Ensure that the outer edges of each leg do not protrude beyond the
sides of the vanity once installed.
• Continue to mount vanity as per steps for “Vanity Installation”.
Vanity Legs
Model D19076000 Series
LEG INSTALLATION
NOTE: Vanity legs are optional and need
to be purchased and considered before
the actual installation of the vanity to
ensure height dimensions are correct
for water supply lines and waste drain.
