AT200® LS SPALET®
Questions and Answers
Warranty What is the warranty?
There is a three year warranty on all parts of the SpaLet for residential applications and a two year warranty
on parts for commercial applications.
Installation Is a professional plumber required for installation?
The SpaLet toilet can be installed but professional installation is recommended especially if this is your first
toilet install. The installation is similar to a regular toilet but uses a drain socket and a gasket dierent from
a traditional wax ring. We have designed this for an easier installation but it depends on your technical
expertise and comfort level.
What type of power is needed?
AC120V GFCI outlet. The seat consumes 1300W +/- 10%
What type of water pressure is needed?
Minimum water pressure: 0.1 MPa (1.0 bar): 14.5 psi Flow pressure
Maximum water pressure: 0.75 MPa (7.5 bar): 109 psi Hydrostatic pressure
What is the heater capacity?
48W
What is the warm air heater capacity?
500W
What is the air volume?
0.3 m3 /min
How much electricity does this SpaLet toilet consume?
The AT200 LS has a rated power consumption of 850 W (environment 20°C/68°F, water 15°C/59°F)
Do you need to buy anything else for installation?
Items needed for installation include standard household tools, drill and bits, caulking and tape
Components What comes with the product?
The following parts are included in the product:
SpaLet Toilet:
 •Bidetseatandwatersupplyhose
 •Watershutovalveandclip
 •Remotecontrol
 •Screws,anchors,andAAbatteries(forremotecontrol)
 •Anti-theftnut,screw,andwasher(forremotecontrol)
 •Waterdrainsocket
 •Securingmember
 •Screw,washer,anchor,screwwithcap
 •Papertemplate
 •Installationsupportbase
 •Frontsecuringmember/adhesivematerial
 •Manualset
 •Wallprotectioncover
Is the remote included in the product?
The remote and batteries are included with the purchase of the AT200 LS SpaLet.
(Continued on next page)

©2018 AS Americas, Inc. 2
Dimensions What is the size of the seat opening?
The inner diameter of the seat is 7-7/8" (200 mm) wide and 11-53/64" (306 mm) long.
How long is the power cord?
Eective length 39" or 1.0m.
What are the dimensions for the toilet? Can I replace a standard toilet?
The dimension of the toilet is 14-3/4" x 15-3/4" x 25-13/16" (375 x 400 x 655 mm) and it can replace
a standard toilet.
Is this SpaLet® toilet ADA compliant?
Yes, it is an ADA compliant product.
Function and Features
How does the self-cleaning nozzle work?
Once the user presses the spray function, the automatic self-cleaning nozzle function rinses the nozzles
prior to opening the nozzle shutter door and extending the nozzles. This function cleans the nozzle and
surrounding area before and after use of the posterior washing, posterior washing – mild and feminine
washing features.
What is a nozzle shutter?
The nozzle shutter is the door that covers the nozzles. This provides an additional level of hygiene by
preventing waste or debris from contacting the nozzle tips.
What are the main features?
 •WaterSensedualush(1.32-0.92gpf/4.9-3.4Lpf)
 •Automaticopen/slow-closelid&seat
 •Adjustable,automaticushsetting
 •Heatedseat(6oflevels)
 •Warmairdryer(4temperaturelevels)
 •Dual,adjustable,self-cleaningwaterspraysforindependentfrontandbackcleansing
 •Adjustablewatercontrolsettings:Pressure(6levels),temperature(6levels),massageandoscillation
 •AirShielddeodorizerwithreplaceablecharcoallter
 •AirSterilization(Plasmacluster)withbluelight
 •RoomRefreshDeodorizer
 •HyperCleanSurfacetopreventscratchesandpreservecleanlinessofthebowl
 •Prewashtohelppreventbuildup(on/ooption)
 •PowerStreamFlush:doublevortexushwithsiphonjet
 •SoftnightlightBowl+Seat(on/o–onallthetimeoption)
Does this toilet have PreMist?
Yes, This toilet has Prewash function to help prevent buildup.
How long is the spray cycle?
 Boththerearandfrontcleansingautomaticallystopsafter2minutesbutcanmanuallybestoppedby
pressing the Stop button at any time and can be extended buy pressing the cleansing button again or
adding oscillation/massage.
How much water is used during the spray cycle?
The spray volume used is as follows:
 •Posteriorwashing:0.43L/min,0.11gpm(6-leveladjustable),
 •Posteriorwashing-gentle:0.45L/min,0.11gpm(6-leveladjustable)
 •Femininewashing:0.45L/min,0.11gpm(6-leveladjustable)
(Continued on next page)

©2018 AS Americas, Inc. 3
Functions and Features (continued)
How long is the drying cycle?
The drying cycle is approximately 4 minutes but it can be stopped at any time by pressing the stop button.
How many dierent water temperature settings are available?
There are 6 dierent levels of water temperature settings on the AT200® LS.
How many heated seat temperature settings are available?
There are 6 dierent levels of heated seat settings on the AT200 LS.
How many water pressure settings are available?
There are 6 dierent levels of water pressure settings are available on the AT200 LS.
What are the dierent spray patterns?
 Thereare5dierentspraypatterns:Posterior,Posterioroscillation,Posteriormassage,Bidet(Feminine),
Bidet(Feminine)Oscillation.
What is Oscillation?
 Oscillationspraymovesthenozzlesforwards&backwardscontinuouslyallowingforawiderareatobe
cleansed.
What is the temperature of the heated seat?
Depending on the use of the ECO mode, the temperature of the seat can vary. If the Eco Mode Power
Savings is being used the seat will be at room temperature and begin to heat up only after the user initiates
using the bidet seat. If Eco mode is not being used the temperature ranges from approx. 82.5°F–97°F
(approx. 28°C–36°C).
What is the temperature of the water?
 Thereare6levelsofadjustmentrangingfrom89.5°F–104°F(32°C–40°C):iftheheatingfunctionissetto
OFF the water will be at an ambient temperature.
What is the temperature of the heated air?
 ThetemperatureoftheheatedaircouldbeadjustedonLow(Roomtemp.),Medium(Approx.40°C,104°F)
and High (Approx. 55°C, 131°F).
Does this have an automatic seat? Slow close seat?
Yes, this SpaLet toilet is equipped with an automatic open/slow-close lid and seat for users convenience.
How long does the heated seat stay warm?
You can set the seat to be warm all the time if you do not use the ECO function. If you use the eco power
saving mode it shuts the water and seat heater o for 8 hours then restores the power. If High Eciency
Power savings is used it turns the water and seat heater o until the product is back in use.
Explain the power save function, how does it work?
It reduces power consumption by turning o the water and seat heater for 8 hours. The power settings are
automatically restored after 8 hours. To use this feature press the set/next button repeatedly until the setting
3 screen appears then press the button below power save repeatedly to select the setting.
How does the heated water supply work, where do I get the warm water from?
The incoming water is transferred through an instant water heating element that keeps the water warm on a
continuous basis during use.
How long does the heated water last for?
The AT200 LS SpaLet® toilet has instant heat so the warm water does not run out.
Where does the water come from that the bidet function uses?
The clean water comes from the incoming water supply line. Tank water is NOT used for the bidet function.
Does this toilet have a nightlight?
Yes it has a nightlight. When the sensor detects a user, a soft light illuminates the inside of the bowl and
user’s foot area. When the user leaves the SpaLet, the light goes out automatically after about 1 minute.
(Continued on next page)

©2018 AS Americas, Inc. 4
Functions and Features (continued)
Is there a child lock out feature?
There is no specific child lock out feature but we do have a seat sensor that must be covered to operate the
bidet function. The bidet will not operate unless both the sensor is covered and a user initiates a cleansing
cycle simultaneously.
What is Plasmacluster?
PlasmaCluster is an air disinfecting technology which eectively removes bacteria from the environment.
PlasmaClustertechnologyworksjustlikeyourroomair-purier.Itgeneratespositive(+)&negative(-)ions,
and releases them into the air. When ions come into contact with mold, bacteria or virus, they transform into
OH radicals, instantly drawing hydrogen (H) from the proteins on the bacteria surface and breaking down the
proteins. OH then combines with Hydrogen to form water (H2O) ions and this returns to the air.
What is Room Refresh?
 RoomrefreshdeodorizerusesPlasmaclustertechnologytocleantheairaroundthetoilet.Thisfeaturecan
be set to run once a day at your choice of time.
What is Air Sterilization?
Air sterilization with blue light uses Plasmacluster technology to constantly clean the air in the bowl when
the lid is closed.
What is Air Shield Deodorizer?
Air shield deodorizer uses air currents and active carbon to shield and neutralize the odor in the bowl
producing fresh air.
What is HyperClean?
Exceptionally smooth and hard surface of the bowl. This prevents scratches and maintains bowl cleanliness.
Explain Triple Vortex Flush
 Triplevortexushusestwojetstreamsfromtherimtocleantheentirebowlandapowerfulsiphonjetto
remove the waste.
How much water does the toilet consume?
 Itashesindualushconsuming5.0L,1.32gpf(Fullush),3.5L,.9gpf(Lightush).
How to Use How do you adjust the nozzles for a better aim?
 OurSpalettoilethas5levelsofnozzlepositionadjustment.Theseareeasilychangedbypressingthenozzle
position arrows (left of the LED screen) on the user-friendly remote.
How does the bidet work?
The user must sit on the seat to cover the seat sensor to allow the bidet functions to work. Then with the
touch of a button, the self-cleaning nozzles extend from behind the nozzle shutter, under the seat to deliver
soothing warm water for cleansing.
What type of maintenance is required/recommended?
 •Cleaningoftheseatcanbeachievedbuyusingaclothandanonchlorinatedcleaner
 •Changingorcleaningthenozzletips
 •Changingorcleaningthenozzleshutter
 •Cleaningthedeodorizerscreen
 •Cleaningthestrainer
 •Winterizingtheseatwhenleftinvacationorunoccupiedhomes
 •Changingthebatteriesintheremote
Is this product suitable for children?
When small children are using this product, ensure that the proper operating procedures are followed at all
times to ensure the user’s safety.
(Continued on next page)

©2018 AS Americas, Inc. 5
How to Use (continued)
Can you customize the settings?
 Yes,youcancustomizeyourcleaningexperiencebyadjustingthewatercontrolsettings,waterpressure
settings (6 levels), water temperature settings (6 levels) plus the massage and oscillation features to
maximize your cleansing experience.
Can you save the customized settings?
No, You cannot save customized user settings as in user 1, user 2 but the settings will stay the same until
they are manually changed.
How do I clean this product?
You can clean the seat by using soft cloth and non-chlorinated cleaner.
Do I have to mount the remote?
No, You do not have to mount the remote if you do not have an accessible wall to mount this on but it is
recommended to do so for ease of use if a wall is located within arms reach of the toilet.
Can you turn o the deodorizer?
Yes, you can turn the deodorizer o by pressing the set/next (gear) button repeatedly until the setting
3 screen appears then press the button below odor absorption repeatedly to select the setting.
Can you flush the SpaLet toilet without the remote?
 Youcanushwithouttheremotebyusingtheexternalmanualushbuttononthesideoftheseatunit.
It is placed on the right side when facing the product.
How long should I use a bidet?
How long an individual may use the bidet function will vary depending on personal cleansing needs.
Duration of the spraying function can last up to 2 minutes and the user can strop the spray cycle at any time
by pushing stop. The cycle will automatically stop at 2 minutes but can be extended up to 6 minutes using
the massage function or pressing the spray cycle again.
Can you flush the SpaLet toilet when you have a power failure?
 Yes.Ifapoweroutagehasoccurred,theSpaLettoiletcannotbeushedbytheremotecontrol.
Flush the SpaLet toilet by following procedures below.
1. Detach the top cover.
2. Press the trip lever (red) for about 5 seconds. Water will run from the rim to the bowl,
washing waste to the bottom of the bowl.
 3.Pullthetriplever(red)forabout5seconds.Waterwillrunfromthejetholeatthebottomof
the bowl to dispose the waste.
4. Press the trip lever (red) for about 5 seconds again. Water will runs from the rim to the bowl
to store water in the bowl.
 5.Releaseyourhandfromthetripleverafterstoringwaterinthebowl.Thetripleverreturns
to the original position, and the water will stop running.
Other Where is it manufactured?
The AT200® LS SpaLet toilet is manufactured in Japan.
What is the weight limit for this toilet?
 TheseseatsaredesignedtopasstheindustrystandardANSIZ124PlasticToiletSeatTestRequirementsfor
residential toilet seats. This specification calls out static load tests of 300 lbs. and several dynamic tests that
involve side load rocking and drop testing, which these seats have passed.
Could you use it outside North America?
This product is designed for use in the USA and Canada. Please refer to the product specifications chart in
the installation manual for electrical and water requirements.
