Dyna-Glo GRAB 'N GO HA10BK Manual

1
USER'S MANUAL AND OPERATING INSTRUCTIONS
READ INSTRUCTIONS CAREFULLY:
Read and follow all instructions. Place
instructions in a safe place for future ref-
erence. Do not allow anyone who has
not read these instructions to assemble,
light, adjust or operate the heater.
This heater is equipped with a SAFETY SYSTEM designed to
turn off the heater if not enough fresh air is available.
If the heater shuts off, do not relight until you provide fresh air.
If heater keeps shutting off, have the heater serviced. Keep
burner and control compartment clean.
PORTABLE PROPANE HEATER FOR
OUTDOOR,
EMERGENCY INDOOR, AND
RECREATIONAL ENCLOSURES
FOR US SALE EXCEPT
MASSACHUSETTS
FIRE OR EXPLOSION HAZARD
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect fuel supply.
4. Leave the area immediately.
5. Allow gas to dissipate 5 minutes before
relighting the appliance.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Failure to follow these instructions could result
in fire or explosion, which could cause property
damage, personal injury, or death.
CARBON MONOXIDE POISONING
MAY CAUSE DEATH OR INJURY
When used without adequate combustion and
ventilation air, heater may give off excessive CARBON
MONOXIDE, an odorless, poisonous gas.
This is an unvented gas-fired heater. The heater uses
air (oxygen) from the area in which the heater is used.
Adequate combustion and ventilation air must be
provided. (Refer to page 4)
DO NOT TAMPER WITH THE SAFETY SYSTEM!
Model #
GRAB 'N GO
RADIANT HEATER
1IMHA10HA18-NFR
HA10BK
HA10G
HA10O
HA10R
Grab 'N Go 10K
Portable Heater
Grab 'N Go 18K
Portable Heater
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
or email us at [email protected]
www.ghpgroupinc.com
CONSUMER: Retain this manual for future reference.
US
ANSI Z21.103-2017 Unvented portable type
gas camp heaters for indoor and outdoor use
WARNING WARNING
CONTROL
KNOB
OFF
POSITION
LOW
POSITION
HIGH
POSITION
KNOB
INDICATOR
MARK
PILOT
POSITION
MEDIUM
POSITION
PIKOT FLAME
PILOT AIR
HOLE
VALVE
REGULATOR
REGULATOR
ORIFICE
ODS PILOT
ASSY
PILOT
POSITION
WIND
DIRECTION
334
WIND
DIRECTION PILOT
POSITION
OFF
POSITION
KNOB
INDICATOR
MARK
PILOT
POSITION
HIGH
POSITION LOW
POSITION
CONTROL
KNOB
PIKOT FLAME
PILOT AIR HOLE
Regulator
1 lb. DOT Approved Cylinder
Tank
Regulator
Fuel Filter &
Hose Kit #
HAKITDG
VALVE
ODS PILOT
ASSY
ORIFICE
REGULATOR
HA18BK
HA18G
HA18O
HA18R

NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
2
Service / Parts Ordering Information ....................................................................................1
General Information .............................................................................................................3
General Safety Instructions ..................................................................................................4
Tank Installation Instructions ................................................................................................5
Operating with Disposable Propane Cylinders ......................................................................6
Operating With Hose Connected to Remote Cylinder. ...........................................................6
Lighting Operation Instructions..............................................................................................7
Maintenance ........................................................................................................................9
Troubleshooting .................................................................................................................10
Parts List .......................................................................................................................... 12
Warranty.............................................................................................................................14
TABLE OF CONTENTS
WARNING:
Every time hose or tank is connected to unit, connection
must be checked for leaks in one or more ways: Apply
soapy water to connection, look for bubbles, listen for
hiss of escaping gas, feel for extreme cold, smell for
rotten egg odor. Do not use if leaking!
Any changes to this heater or its controls can be
dangerous.
Some people-pregnant women, persons with heart
or lung disease, anemia, those under the inuence of
alcohol, those at high altitudes - are more affected by
carbon monoxide than others.
If the recreational or commercial enclosure does not
have a window or roof vent that is open, DO NOT USE
THIS HEATER inside.
WARNING:
WARNING: WARNING:
Early signs of carbon monoxide poisoning resemble the
u, with headache, dizziness and/or nausea. If you have
these signs, heater may not be working properly.
Get fresh air at once! Have heater serviced.
WARNING:
This product and the fuels used to operate this product (liquid propane), and the products of combustion of such fuels, can
expose you to chemicals including benzene, which is known to the State of California to cause cancer and reproductive harm.
For more information go to www.p65Warnings.ca.gov
WARNING:
NOTICE: Not for use in a "dwelling home" in California. Never use these heaters in a bedroom or bathroom.
EMERGENCY INDOOR USE IS DEFINED AS
1. The permanent heating system is temporarily out of service.
2. Heat is necessary to prevent damage to the property or contents.
3. The temporary heating equipment is not left unattended.
4. The minimum opening area for ventilation of fresh supply air must be 18
square inches (An opening of 4 1/4 inches x 4 1/4 inches)
5. The portable heater used shall be discontinued and removed from the
building at the time the permanently installed appliances are placed
back in operation.

NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
3
GENERAL INFORMATION:
• This heater is safe for indoor use in small recreational enclosures, having means for providing combustion air and ventilation, such
as enclosed porches, cabins, shing huts, trailers, tent trailers, tents, truck caps and vans. It may be used for emergency indoor
heating when connected to a disposable 1 lb. propane cylinder and for indoor use in commercial enclosures, having means
for providing combustion air and ventilation, such as construction trailers or temporary work enclosures.
• When the heater is cold or at room temperature, it will take a few minutes for the burner to turn bright orange. This is normal
and the heater is working properly. Also, during the initial lighting, the oil used during manufacturing process needs to burn off. This can
take up to 60 minutes of continuous burning. Some odor and yellow ames may occur during this time but will diminish after the burn-in
period.
• It is recommended not to use the heater in windy conditions. The heater may utter reducing the effectiveness of the
appliance and could have excessive pilot outages.
• When moving heater when lit or bumping heater setting it down, tip over switch may shut off heater. If this happens,
re-light.
• Operating time will vary depending on the heater setting and the supply cylinder size. See chart and "Cold Weather
Operations" section.
• NOTE: THIS HEATER MAY BE OPERATED WITH DISPOSABLE 1LB. PROPANE CYLINDERS OR WITH (1) REMOTE
REFILLABLE PROPANE CYLINDER MAX. 20 LBS USING DYNA-GLO KIT # HAKITDG WHICH INCLUDES A 12’ PROPANE
HOSE AND FUEL FILTER (SOLD SEPARATELY)
COLD WEATHER OPERATION:
• Cold weather is generally dened as ambient temperatures below 32 degrees F.
• 1 lb. propane cylinders have difculty producing sufcient gas at lower temperatures and can “freeze-up”, reducing the time of
operation by as much as 50-70%. For this reason, it is recommended to use only 20 lb. propane tanks under these conditions.
• If a 1 lb. tank is used in cold weather, such as in an ice shing hut, following are some operating suggestions;
1. Expect operating times to be signicantly reduced.
2. Never use only a single 1lb. tank on the Grab N Go 18K models.
3. Never set the heater directly on the ice. Set the heater on a rigid piece of ame retardant insulation and make sure the
ventilation slots on the bottom of the heater are not obstructed.
4. Elevate the heater slightly above the ground level. Insure the unit is level and secure and cannot be knocked over.
5. Adequate ventilation and combustion air must be provided.
6. Maintain all clearances as specied on Page 4.
Carefully watch the Heater for signs of the 1 lb. cylinder "freezing-up". If the lower portion of the burner starts to turn from
orange to blue and begins sputtering immediately shut off the heater and remove it from any enclosure.
WARNING:

NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
4
GENERAL SAFETY INSTRUCTIONS
• Do not use non-approved attachments on this heater.
• Due to high temperatures, the appliance should be located out of trafc and away from combustible materials.
• Children and adults should be alerted to the hazard of high surface temperatures and should stay away to avoid burns
or clothing ignition.
•Young children should be carefully supervised when they are near the appliance.
• Do not place clothing or other ammable material on or near the appliance.
• Do not operate heater in any moving vehicle.
• This heater can be used in a recreational or commercial enclosure with a window or roof vent. It may also be used outdoors.
• This heater requires a vent area of 18 square inches (example 4 1/4" x 4 1/4" opening) minimum for adequate ventilation during
operation. Do not use other fuel burning appliances inside.
• Gas pressure at heater is regulated and xed at 11" w.C. When using a remote hose connection to heater regulator(s), do not regulate or
reduce propane tank supply pressure to heater.
• Regulator(s) in heater must always be in place during operation.
•Any guard removed for servicing the appliance must be replaced prior to operating the heater.
• The appliance should be inspected before each use. Frequent cleaning may be required. The control compartments,
burner(s) and circulating air passageways of the appliance must be kept clean, see MAINTENANCE.
• DO NOT use this heater if any part has been under water. Immediately call a qualied service technician to inspect
the heater and to replace any part of the control system and any gas control which has been under water.
• When used without adequate combustion and ventilation air, this heater may give off excessive CARBON MONOXIDE,
an odorless, poisonous gas.
• Some people - pregnant women, persons with heart or lung disease, anemia, those under the inuence of alcohol, those at
high altitudes - are more affected by carbon monoxide than others.
• Cylinders must be disconnected when the heater is not in use.
• When heater is placed on the ground, make sure the ground is level and keep any objects at least 15"' from the edge
of the heater. This heater is equipped with a tip over switch that will shut the heater off if the heater tips over. However, do not leave
heater unattended or where children may cause the heater to tip over. Never operate the heater while sleeping!
• Keep remote 20 lb. rellable cylinders at least 6 ft. away from heater at all times.
• Do not leave this appliance unattended while it is in operation. Keep children and pets away from the appliance at all times.
• This heater can be used in a recreational enclosure only if the enclosure has a window
or roof vent.
GENERAL SAFETY INSTRUCTIONS
THIS IS A HEATING APPLIANCE. DO NOT OPERATE THIS APPLIANCE WITHOUT THE WIRE GUARD INSTALLED. DO NOT
ATTEMPT TO WARM OR COOK FOOD ON THIS HEATER.
MODEL NO.. HA10BK / HA10G / HA10O / HA10R / HA18BK / HA18G / HA18O / HA18R
GAS TYPE .................................................................................................PROPANE
INPUT BTU/HR. ............................................................. HA10 Series - 5,500 - 10,000
.......................................................................... HA18 Series - 5,500 - 10,000 - 18,000
MAX. SUPPLY PRESSURE......................................................BOTTLE PRESSURE
CLEARANCE TO COMBUSTIBLES
TOP ............................................................................................... 30 inches (762 mm)
FRONT .......................................................................................... 24 inches (310 mm)
SIDES ............................................................................................. 6 inches (153 mm)
REAR .................................................................................................. 0 inches (0 mm)
SPECIFICATIONS CAUTION:
• Some linoleum surfaces may discolor if heater
is placed directly on these oor coverings.
Cylinder Size Operating Time
Grab 'N Go (10K) Grab 'N Go XL (18K)
One 1 lb. cylinder 2.2 hrs (high) - 4.2 hrs (low) NOT RECOMMENDED
Two 1 lb. cylinders N/A 2.4 hrs (high) - 4.5 hrs (medium) - 9.2 hrs (low)
One 20 lb. cylinder 45 hrs (high) - 79 hrs (low) 25 hrs (high) - 45 hrs (medium) - 79 hrs (low)

5
TANK INSTALLATION INSTRUCTIONS
Tank Installation for DOT Certied 1 lb. Propane Cylinder(s) (Fig. 1)
• Open easy access tank compartment door(s). (On 18K Model Only)
• Locate regulator and swivel it upward by hand to provide better access for cylinder
• Attach cylinder(s) to swivel mount by gently turning clockwise until it is hand tight. Do not overtighten. Do not use tools to tighten.
• Check for gas leaks by using a 50% soap-water solution at the joint of the regulator and cylinder.
HANDLE POSITIONING FOR NORMAL OPERATION
The heater ships with the handle in a compact position that must be raised for normal operation (Fig. 1a)
• Grab handle and pull directly upward until the handle snaps into position.
• Do not lower the handle to the previous location. The “UP” position is the normal operating orientation.
Handle raised to
operating position
Handle in "shipped"
position
Fig. 1a - Handle Position
