Dyson Purifier Humidify+Cool User manual

User manual
Getting started
Assembling your machine
Connecting to the Dyson Link app
Filling the water tank
Power and continuous monitoring
Information menu
Auto purify mode
Auto humidify mode
Oscillation
SV12 JN.00000 PN.000000-00-00
00.00.00 VERSION NO.01
Airflow speed and direction
Sleep timer
Night mode
Deep cleaning your machine
Changing your HEPA+Carbon filter
Looking after your machine
Alerts
Dyson purifier humidify plus cool

Getting started
Deep clean cycle button
Stand-by button
Amplifier loop
Outer cover
release buttons
Outer cover
Water tank
release buttons
Stand-by
Auto purify mode
Airflow speed
Oscillation
Sleep timer
Information menu
Auto humidify mode
Humidity control
Airflow direction
Night mode
The layout of the remote control with the standby button on the top left, the Auto purify mode button below, then the
Airflow speed toggle up and down button. Below that is the Oscillation button and finally at the bottom is the Sleep timer
button. On the top right-hand side is the Information menu button, then going downwards, the Auto humidify mode
button, humidity control toggle button, Airflow direction and then Night mode button at the bottom.
Image of the machine with the location
of parts labelled.
The large oval loop making
up the top of the machine.
Two push down buttons
located either side of the
main body of the machine.
The mesh cover on the
bottom of the machine is
intwo parts, front and back.
The buttons to remove the
water tank are located on
both sides, just above the
bottom of the machine.
The top, of the two buttons
located on the main body of
the machine just below the
loop amplifier, is the Deep
clean cycle button.
Below the Deep clean
cycle button is the
standby button.

Assembling your machine
Use both hands to lift your machine out of the box, by its base.
Do not lift out by the loop amplifier.
Assemble your machine with the filters that are supplied.
Your machine comes with a HEPA+Carbon filter. If you
purchased the Dyson Purifier Humidify+Cool Formaldehyde™
your machine also comes with a permanent catalytic filter.
Push the HEPA+Carbon filter into the outer cover and position
on the base. Push firmly until both outer covers click into place.
SCONON-SCOSCONON-SCO
Scaled 81% for QSG to maintain minimum line weight
Original scale
clik
clik
clik
clik
clik
clik
MAX
clik
clik
clik
clik
clik
clik
MAX
Place the remote control on top of the machine with the buttons
facing down.
Plug in and switch on.
The purifying humidifying fan with the filter covers open showing a HEPA plus
carbon filter located in the filter covers and a catalytic filter. Arrows demonstrate
that the catalytic filter is fitted directly to the base of the machine and the filter
covers will need to be assembled onto the base of the machine.

Connecting to the Dyson Link app
Take full control with the Dyson Link app and access step-by-step set up and
support, control how and when your Dyson purifying fan operates, monitor
air quality with visual updates and automatically keep up to date with the
latest software updates.
Download the Dyson Link app from the App Store or Google Play.
Opentheapp and follow the on-screen instructions to create a new account.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.
App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
GooglePlayandthe Google Play logo are trademarks of Google Inc.

Filling the water tank
Before you remove the water tank, make sure humidification modes are
turned off and the water tank is empty.
Keep the cap dry
Keep the cap on the water tank dry when you run a Deep clean cycle or fill
the tank. It contains power connections and should not be washed. If wet,
wipe thoroughly with a dry cloth. Make sure the cap and connections are
completely dry before refitting.
Remove the tank
Push down the Water tank release buttons on the sides of your machine.
Slide the water tank out of your machine.
Carry the water tank by its handle to the tap, and unclip the cap.
Fill the tank
MAX level
Fill the water tank to the Max level with cold tap water.
Replace the tank
Replace the cap and secure the cap clips in place.
Make sure the cap is completely dry. If wet, wipe thoroughly with a dry cloth.
Slide the water tank back into your machine until it clicks securely in place.
The water tank cap has two lips either side that
can be pulled upwards to release the cap.

Power and continuous monitoring
Stand-by on/off
Press the Standby on/off button on your Dyson purifier humidifier fan or remote
control to stop your machine. It will continue to monitor the air quality.
Continuous monitoring
Continuous monitoring is turned off by default. Once turned on, it will always
be active until you turn it off again.
With continuous monitoring turned on, your Dyson purifier humidifier fan will
gather air quality, temperature and humidity information, which is displayed
on the LCD screen and in the Dyson Link app.
Continuous monitoring on/off
Press and hold the Auto mode button on the remote control for 5 seconds to
turn it on. The LCD screen will indicate when continuous monitoring is on or off.
Wi-Fi Connectivity
Wi-Fi is on by default. To turn the Wi-Fi on or off, press and hold the Stand-by
on/off button on your machine for 5 seconds.

Information menu
Press this button to scroll through the information being monitored by your
Dyson purifying humidifying fan.
Information about air quality, temperature, humidity. Filter and evaporator
levels are shown.
When a particular type of pollutant causes air quality to decrease,
aniconforthe pollutant will show on the LCD screen.
Indoor air quality - 12 seconds
Monitor the current air quality with a graph
showing the last 12 seconds of data.
Particulate matter (PM10)
Larger microscopic particles up to 10 microns
in size, suspended in the air we breathe. These
include dust, mold and pollen.
Nitrogen dioxide and other oxidizing gases
These potentially harmful gases are released
into the air by combustion, for example, the
burning gas when cooking and in vehicle
exhaust emissions.
Indoor humidity
The amount of water vapor in the air,
shown as a percentage.
Particulate matter (PM2.5)
Microscopic particles up to 2.5 microns in size,
suspended in the air we breathe. These include
smoke, bacteria and allergens.
Volatile organic compounds
VOCs are typically odors that may be potentially
harmful. These can be found in cleaning products,
paints and furnishings.
Indoor temperature
Monitor the ambient temperature to help maintain
a comfortable environment.
Indoor air quality - 24hrs
Monitor the current air quality with a graph
showing the last 24 hours of data.
Filters
The remaining filter life is shown on the
LCD screen and will indicate when your
filters need replacing.
Evaporator
The status will show how full the evaporator is
with mineral build-up and how soon a deep clean
cycle is required.
Wi-Fi
The current status of connection to
the Wi-Fi network.
The remote control with
the information button
on the top right.

Auto purify mode
Set your Dyson purifying humidifying fan to Auto purify mode and the on-
board sensors will intelligently adjust the settings of your machine according
to the air quality.
Air quality: your machine will pause when the target air quality has been
reached, switching on again when the air quality levels drop.
Airflow speed: the airflow speed will increase until the target air quality and
temperature have been reached.
Night mode: your machine will only run with airflow speeds from 1 to 4.
Auto humidify mode
Set your Dyson purifying humidifying fan to Auto humidify mode and the on-
board sensors will intelligently adjust the settings of the machine according to
the temperature and humidity of your room.
Room humidity: your machine will pause when the target room humidity has
been reached, switching on again when the room humidity levels drop.
Airflow speed: the airflow speed will increase until the target humidity level
has been reached.
To turn off Auto humidify mode or to change the humidity levels manually,
press the Humidity control button.
Oscillation
Press the Oscillation button and select the angle of oscillation to
0°,45°,90°or Breeze mode.
Pause the oscillation at any point by pressing the Oscillation button.
Press the Oscillation button again to resume.
To reset the Oscillation direction to the center, press and hold the
Oscillationbutton for two seconds.
The remote control with
the Auto purify button
on the left hand side,
below the Standby
button.
The remote control
with the Auto humidify
button on the right
hand side, below the
Information button.
The remote control with
the oscillation button
on the left above the
sleep timer.

Airflow speed and direction
Press the Airflow speed button to increase and decrease the airflow speed.
Press the Airflow direction button to change the direction of airflow from front to back.
Change the airflow direction for your personal comfort.
Select the Airflow direction to Fan mode for airflow from the front for
purifyingandcooling.
Set the Airflow direction to Backwards airflow mode, for airflow from the
bock for purifyingwithoutcool air.
Your machine will continue to purify and humidify (if selected) in both
FanandBackwards airflow mode.
Use your Dyson Link app to personalize your settings for Airflow speed and direction.
Sleep timer
Your Dyson purifying humidifying fan will turn off automatically after the
selected amount of time.
To set the time: press the button to scroll through the time options. Once
activated, press the Sleep timer button once to see the time selected.
To cancel the Sleep timer: press the Sleep timer button to scroll through all
the options and select the cancel option.
Night mode
In Night mode, your Dyson purifying humidifying fan will continue to monitor
and respond to changes in air quality and temperature, but only using its
quietest settings - and with its LCD screen dimmed.
If Auto purify mode or Auto humidify mode hove been set, Night mode will
reduce the airflow speed to a range from 1 to 4.
Personalize your Night mode settings in the Dyson Link app.
The remote control with
the Night mode button
on the right at the
bottom.
The remote control with
the sleep timer button
on the bottom left.
The remote control
with the Airflow speed
toggle button on the
left hand side, below
the Auto purify button.
The Airflow direction
button is on the right
above the Night mode
button.

Deep cleaning your machine
To always get the best performance from your Dyson purifying humidifying fan,
it is important to carry out regular deep cleaning to remove any mineral build-up.
Before and after long periods where humidification is not used, we recommend
you run an additional Deep clean cycle.
In hard water areas you may need to run the Deep clean cycle more frequently.
We recommend you use filtered water to always get the best performance from
your machine.
Your machine will alert you when it needs you to carry out a Deep clean cycle.
If you are connected to the Dyson Link app, you will receive a notification
message.
If you are not using the Dyson Link app, the LCD screen on your machine will
alert you and the Deep clean cycle button will light up.
To cancel the Deep clean cycle at any point, press and hold the Deep clean cycle
button for five seconds.
Keep the cap dry
Keep the cap on the water tank dry when you run a Deep clean cycle or fill
the tank. It contains power connections and should not be washed. If wet,
wipe thoroughly with a dry cloth. Make sure the cap and connections are
completely dry before refitting.
Step 1
Remove the water tank
Press the Deep clean cycle button on the front of your machine and your
instructions will be shown on the LCD screen.
Push down on the Outer cover release buttons to remove the outer covers.
The inner door will spring open. Put the Outer covers to one side as you carry
out the Deep clean cycle.
Push down the Water tank release buttons on the sides of your machine.
Slide the water tank out of your machine and unclip the cap.
Step 2
Remove the evaporator
Remove the evaporator from your machine, place it in the water tank and
refit the cap.
The Deep clean cycle button
can be located above the
Standby button.

Step 3
Make a descaling solution
MAX level
Carry the water tank by its handle to the tap.
Remove the cap and evaporator. Fill the water tank halfway to the Max level
with cold tap water.
Measure out 150g of citric acid and place it in the water tank.
Agitate gently until all the citric acid has dissolved.
Place the evaporator in the water tank. Fill the water
tank to the Max level with cold tap water.
Step 4
Replace the cap
Replace the cap and secure the cap clips in place.
Wipe off any excess water to avoid drips.
Make sure the cap is completely dry. If wet, wipe thoroughly with a dry cloth.
Step 5
Replace the tank
Slide the water tank back into your machine until it clicks securely in place.
When prompted by the LCD screen, press the Deep clean cycle button.
The Deep clean cycle will start and the LCD screen will show
a countdowntimer.
Step 6
Remove the water tank
When the LCD screen shows the Deep clean cycle is complete, push down
the water tank release buttons on the sides of your machine.
Slide the water tank out of your machine. Carry the water tank by its handle
to the tap.

Step 7
Rinse
Unclip the cap, take the evaporator out of the water tank and rinse under
a cold tap.
Wipe away any excess water to avoid drips and place the evaporator to
one side.
Rinse the water tank under a cold tap. Wipe the inside of the tank to
remove any excess solution and any debris.
Step 8
Refill
MAX
level
Refill the water tank to the Max level and wipe off any excess water and
replace the cap, making sure that the cap clips are secured.
Step 9
Reassemble
Push the evaporator back into your machine, making sure that it is securely
in position.
Close the inner door and replace the outer covers.
Make sure the cap is completely dry. If wet, wipe thoroughly with a dry cloth.
Slide the water tank back into your machine and make sure it is securely
inplace.
The evaporator is inserted
behind the door that springs
open when pressed, inside
your machine.

Changing your HEPA+Carbon filter
x2
x2
x2
x2
clik
clik
x2
x2
x2
x2
clik
clik
SCONON-SCOSCONON-SCO
Scaled 81% for QSG to maintain minimum line weight
Original scale
clik
clik
clik
clik
clik
clik
MAX
clik
clik
clik
clik
clik
clik
MAX
Supplied with a HEPA+Carbon filter.
To change your HEPA+Carbon filter, push down on the buttons either side
of your machine to release the outer cover. Push down on the tabs to remove
the filter.
Push the replacement filter into the outer cover and make sure the tabs click
into place.
Put the outer covers into position on your machine and push firmly until they
both click securely into position.
Plug in and switch your machine, and reset your filter life.
Resetting your filter life
5, 4, 3, 2, 1...
It’s important to reset your filter life after you have replaced your filter.
Press and hold the Night mode button on the remote control.
The LCD screen on your machine will count down from five, ending with
default screen.
The filter life has been reset and your machine is ready to use.
The purifying humidifying fan with the filter covers open
showing a HEPA plus carbon filter located in the filter covers
and a catalytic filter. Arrows demonstrate that the catalytic filter
is fitted directly to the base of the machine and the filter covers
will need to be assembled onto the base of the machine.

Looking after your machine
To always get the best performance from your Dyson purifying fan,
it’s important to regularly clean it and check for blockages.
Cleaning your machine
If your machine is dusty, wipe with a damp lint-free cloth.
Look for blockages in the air inlet holes on the filter and the small
aperture inside the loop amplifier.
Use a soft brush to remove dust and debris.
Don’t use detergents or polishes to clean your machine.
Alerts
Continuous alert icon
Switch off and unplug your machine.
Leave for 10 seconds and then plug your machine back in and switch it on.
If the alert icon continues to show on the LCD screen, contact Dyson.
Temporary alert icon
If the alert appears on the LCD screen and then disappears,
continue to use your machine.
If any other alert icons show on the LCD screen,
contactDysonforfurther advice.
