Dyson Ball DC25 User manual

After registering for your 2 year guarantee, your
Dyson vacuum cleaner will be covered for parts and
labour for 2 years from the date of purchase, subject
to the terms of the guarantee. If you have any queries
about your Dyson vacuum cleaner, call the Dyson
Customer Care Helpline with your serial number
and details of where/when you bought the vacuum
cleaner. Your serial number can be found on the
rating plate which is behind the clear binTM.
Register for your
2 year guarantee
www.dyson.com.au
www.dyson.co.nz
AU 1800 239 766
NZ 0800 397 667
SG 7000 453 7546
ID 021 707 39766
Complete and return the
registration form.
Note your serial number for future reference
See back page for full contact details This illustration is for example purposes only.

Do not pull on the cable. Do not store near
heat sources.
Do not use near
naked flame.
Do not run over
the cable.
Do not pick up water
or liquids.
Do not pick up
burning objects.
Do not use above you
on the stairs.
Do not put hands near
the brushbar when the
vacuum cleaner is in use.
GENERAL SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
When using an electrical vacuum cleaner, basic precautions should always be
followed, including the following:
This vacuum cleaner is for domestic use only. Do not use outdoors or on wet1.
surfaces.
Do not handle plug or vacuum cleaner with wet hands.2.
Do not allow to be used as a toy. Close attention is necessary when used by or3.
near children.
Do not use with damaged cable or plug. If the supply cable is damaged, it must4.
be replaced by Dyson’s authorized Service centres.
If the vacuum cleaner is not functioning properly, has been dropped, damaged,5.
left outdoors, or immersed in liquid, do not use, contact the Dyson Helpline.
Do not use the vacuum cleaner if any parts appear to be faulty, missing or6.
damaged.
Ensure all parts including the clear bin7. TM are securely attached before using or
carrying the vacuum cleaner.
This vacuum cleaner is not intended for use by persons (including children)8.
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the vacuum cleaner by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the vacuum cleaner.
Do not leave vacuum cleaner when plugged in. Unplug from outlet when not in9.
use, and before performing user maintenance, connecting or disconnecting the
hose or changing accessories.
Store the vacuum cleaner indoors. Put the vacuum cleaner away after use with the10.
cable stored safely, to prevent tripping hazards.
If the vacuum cleaner overheats it will cut-out. It must be switched off, unplugged11.
and allowed to cool down before attempting to check lters or for blockages.
Turn off all controls before unplugging.12.
Do not unplug by pulling on cable. To unplug, grasp the plug, not the cable.13.
Do not pull or carry by cable, use cable as a handle, close a door on cable, or14.
pull cable around sharp edges or corners. Do not run vacuum cleaner over cable.
Keep cord away from heated surfaces.
The use of an extension cable is not recommended.15.
Keep hair, loose clothing, ngers, and all parts of body away from openings and 16.
moving parts, such as the brushbar.
Do not put any object into openings. Do not use with any opening blocked.17.
Take extra care when vacuuming on stairs. Do not work with the vacuum cleaner18.
above you on the stairs.
Keep the vacuum cleaner on the oor. Do not put the vacuum cleaner on chairs, 19.
tables etc.
Do not shake the vacuum cleaner or press the cyclone release button while20.
carrying the vacuum cleaner, or it could fall and cause injury.
Do not use to pick up ammable or combustible liquids, such as petrol, or use in 21.
areas where they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes, matches,22.
or hot ashes.
Check to ensure your electricity supply matches that shown on the rating plate.23.
The vacuum cleaner must only be used as rated.
Use only as described in this manual. Use only Dyson recommended24.
attachments.
Do not use without clear bin25. TM and lters in place.
Do not lubricate any parts, or carry out any maintenance or repair work other26.
than that shown in this manual, or as advised by the Dyson Helpline.

1 2 3
clik
clik
2
3
clik
1
clik
ON
OFF
ON/OFF
12
Clear binTM emptying
Blockages
Using your Dyson vacuum cleaner

clik
clik
2
3
clik
1
clik
ON
OFF
ON/OFF
12
High-reach cleaning
Blockages Clearing obstructions
Carpets/hard oors

1
2
3
4
5
6
7
8
9
10
11 12
24
1
2
3
4
5
6
7
8
9
10
11 12
24
1
2
3
4
5
6
7
8
9
10
11 12
24
Filter
Filter
A
B
IMPORTANT! 3
months
WASH FILTERS

1
2
3
4
5
6
7
8
9
10
11 12
24
1
2
3
4
5
6
7
8
9
10
11 12
24
1
2
3
4
5
6
7
8
9
10
11 12
24
Filter
Filter
A
B
Wash lters with cold water at least every 3 months or as required.
Rinse and shake filter under tap.
Turn over and tap very firmly to
remove motor emissions.
Repeat until water runs clear.

ASSEMBLY
Lie the vacuum cleaner at and attach the vacuum cleaner head by sliding it on until it
clicks. Stand vacuum cleaner up straight, attach wand to hose and push into place until
it clicks. Push wand down into hose and attach tools to the side of the vacuum cleaner.
USING YOUR DYSON VACUUM CLEANER
Press foot pedal and recline handle to use. The stabiliser stand will automatically lift up.
To switch ‘ON’, depress power button in front of handle. After cleaning, push the
vacuum cleaner into an upright position and stabiliser wheels will automatically drop.
Use the carrying handle located above the clear bin™ to carry the vacuum cleaner.
CAUTION:
• When returning to the upright position, ensure that the stabiliser wheels are fully
engaged before releasing the vacuum cleaner.
• Do not press the cyclone release button while carrying the vacuum cleaner.
PLEASE NOTE:
Fine dust such as plaster or our should only be vacuumed in very small amounts. •
Consult your ooring manufacturer’s recommended instructions before vacuuming •
and caring for your ooring, rugs and carpets. Some carpets will fuzz if a rotating
brushbar is used when vacuuming. If this is the case, we recommend vacuuming in
hard oors mode and consulting with your ooring manufacturer. (Refer to carpets/
hard oors section.)
If used in a garage when car cleaning, care should be taken to wipe the soleplate•
and wheels with a dry cloth after vacuuming to clean off any sand, dirt, or pebbles
which could damage delicate oors.
CARPETS/HARD FLOORS
The brushbar will always default to ‘ON’ (spinning) each time you switch on the
vacuum cleaner and recline it for cleaning. The brushbar will automatically stop if it
becomes obstructed. If the brushbar stops during use, please refer to the ‘Clearing
brushbar obstructions’ section. To switch the brushbar ‘OFF’ (e.g. for hard oors),
recline the vacuum cleaner and turn it ‘ON’, then press the brushbar ‘ON/OFF’
button - the brushbar will stop spinning.
HIGH-REACH CLEANING
CAUTION:
• Powerful suction can cause the hose to ‘pull back’ - please take care.
• To avoid personal injury and to prevent the vacuum cleaner from falling when
cleaning stairs, do not work with the vacuum cleaner above you on the stairs.
• To release the wand, open the wand cap. Extend the red tube until the handle slides
off the vacuum cleaner. Tools can be attached to either the hose or wand. Ensure
wand cap is closed when wand is not in use.
CLEAR BINTM EMPTYING
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before emptying the clear bin™.
Empty as soon as the dirt reaches the level of the MAX mark – do not overll.
To remove the clear bin™ from the vacuum cleaner press the button at rear of
carrying handle. To release the dirt, press the red clear bin™ release button.
The British Allergy Foundation is a UK national charity with the aim of improving
awareness, prevention and treatment of allergies. The British Allergy Foundation
Seal of Approval is a UK registered trademark.
PLEASE NOTE:
Do not use the vacuum cleaner without the clear bin• TM in place.
CLEAR BINTM CLEANING
CAUTION:
• Do not immerse the whole cyclone in water or pour water into the cyclones.
• Ensure the clear binTM is completely dry before replacing.
PLEASE NOTE:
Do not use detergents, polishes or air fresheners to clean the clear bin™.•
Do not put the clear bin™ in a dishwasher.•
When vacuuming, certain carpets may generate small static charges in the clear•
bin™. These are entirely harmless and are not associated with the mains supply.
To minimize any effect from this, do not put your hand or insert any object into the
clear bin™ unless you have rst emptied it and rinsed it out with cold water.
wASHING YOUR FILTERS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before removing the lters.
• Ensure lters are completely dry before retting into the vacuum cleaner.
PLEASE NOTE:
This machine has two lters, located as shown. It is important to check your lters •
regularly and wash with cold water at least every 3 months or as required.
The lter in the ball should be rinsed and tapped out until the water runs clean, •
then tapped out again to ensure all excess water is removed. Please leave to dry
completely for 24 hours.
It is normal for the lter in the ball to turn grey in colour. The lters may require •
more frequent washing if vacuuming ne dust.
Do not use detergents to clean the lters.•
Do not put the lters in a dishwasher, washing machine, tumble dryer, oven, •
microwave or near an open ame.
BLOCkAGES
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before checking for blockages.
• Please ensure vacuum cleaner is upright before removing hose or airway
inspection parts.
• Beware of sharp objects when clearing blockages.
• Ret all parts of the vacuum cleaner securely before using.
PLEASE NOTE:
Clearing blockages is not covered by your vacuum cleaner’s 2 year guarantee.•
If any part of your vacuum cleaner becomes blocked, it may overheat and then
automatically shut off. Unplug the vacuum cleaner and leave to cool down.
Clear blockage before restarting.
CLEARING OBSTRUCTIONS
CAUTION:
Switch ‘OFF’ and unplug the vacuum cleaner before clearing brushbar obstructions.•
Failure to do so could result in personal injury.
If your brushbar is obstructed, it may shut off. If this happens you will need to•
remove brushbar as shown and clear any obstructing debris. Failure to do so could
result in personal injury.
CONFORMITY INFORMATION
A sample of this product has been tested and found to be in conformity with the
following European Directives: 2006/95/EC Low voltage Directive, 2004/108/EC
EMC Directive, 93/68/EEC CE Marking Directive.
PRODUCT INFORMATION
Net weight 7.5kg, 230-240V, 50Hz, maximum power 1200W.
Please note: Small details may vary from those shown.
This product is protected by the following intellectual property rights:
PATENT/PATENT APPLICATION NUMBERS:
JP 2004-537336; EP 1361812; AU 744408; EP 1119282; JP 2002-527132;
US 6,519,807; AU 744362; EP 1121043; JP 2002-527131; US 6,572,078;
GB 0326102.1; AU 2002-226556; EP 1370172; JP 2004-528876; US 6,991,666;
AU 2002-225207; EP 1361814; JP 2004-520137; US 7,018,439; AU 2001-240894;
EP 1268076; JP 2003-528704; US 6,835,222; AU 2002-225232; EP 1361815;
JP 3940082; US 6,974,488; AU 2003-283157; EP 1526796; JP 2006-503607;
US 2005-0235454; AU 2003-283159; EP 1526797; JP 2005-534442;
AU 2003-283161; EP 1526798; JP 2006-503608; AU 2004-294771; EP 1680232;
JP 2007-508934; US 2007-0079579; AU 2005-263889; EP 1768536.
Equivalent patents, registered designs and applications exist in other countries.

JN.21720 PN.14647-04-02 20.05.08 www.dyson.com
AU Dyson Customer Care
[email protected]
1800 239 766
Dyson Appliances (Aust) Pty Ltd., PO Box 2175, Taren Point,
Australia, NSW 2229
www.dyson.com.au
NZ Dyson Customer Care
[email protected]
0800 397 667
Avery Robinson Ltd., Unit F, 151D Marua Road,
Ellerslie, Auckland
www.dyson.co.nz
SG Dyson Service Centre
[email protected]
7000 453 7546
Service @ Home Pte. Ltd.,
2 Leng Kee Road, #04-09A Thye Hong Centre,
Singapore 159086
ID Indonesia Service Centre
021 707 39766
PT. Higienis Indonesia, Permata Plaza Top floor TF-04
J1. M. H. Thamrin Kav. 57, Jakarta 10350
Dyson Customer Care
If you have a question about your Dyson vacuum cleaner, call Dyson
Customer Care with your serial number and details of where and when
you bought the vacuum cleaner, or contact us via the Dyson website.
The serial number can be found on the main body of the vacuum
cleaner behind the clear binTM.
IMPORTANT!
WASH FILTERS
Wash lters with cold water at least every 3 months or as required.
3
months
