E Star MID7138G User manual

User Manual
7" Tablet Android 4.1
Model No: eSTAR MID7138G
www.estar.eu

Welcome
Thank you for purchasing this tablet.
It brings you much convenience for your business (supports Word, Excel,
send & receive e-mails...) and entertainment (supports 3D game, chatting,
movie playback, eBooks.....).
Running on Android 4.1 with a 1.2 GHz processor and highly responsive
capacitive touch screen, it brings you wonderful user experience.
Before beginning, please refer to this user manual carefully.
Important Notices
 The new battery will be in its best condition after 2-3 times full charge and
discharge.
 While using the earphone, if the volume is excessively high it may cause
hearing damage. So please adjust the volume of the player to a moderate
level and balance the time of using.
 Do not disconnect the tablet suddenly when formatting or uploading and
downloading, which can lead to program errors.
 Do not dismantle the tablet by yourself, and do not use alcohol, thinner or
benzene to clean its surface.
 Do not use the tablet while driving or walking.
 The tablet is not moisture and water resistant. Please do not use it in a
damp environment.
 Do not drop or hit it to hard surface, or the screen may get damaged.
 Do not upgrade the firmware by yourself. This would cause damage to
your tablet.
Important information
 Battery will operate properly and will be in the best condition after full
charge and discharge 2-3 times.
 Using headphones excessive sound can damage your hearing. Therefore,
please adjust the audio player accordingly and choose a proper use of time.
 While forming, or uploading or downloading documents or programs do
not disconnect the Tablet PC rapidly, that may lead to damage of the
programs.
 Do not disassemble Tablet PC yourself; do not use alcohol, thinner or
benzene for cleaning the Tablet PC surface.

 Do not use Tablet PC while driving or walking.
 Tablet PCs are not resistant to moisture and water.
 Do not drop the device or push the screen too hard, because it can be
damaged.
 Do not update firmware by yourself. It can damage your Tablet PC.
Safety features
In order to avoid damage to the device, yourself or others, before using
your device read all the information provided
Warning: beware to cause electric shock, fire and explosion.
Do not use damaged power wires or cables and loose power sockets.
Do not touch the power cable with wet hands and do not connect the
charger by holding cable.
Do not bend or damage to the power cord.
Do not use the device while charging and do not touch the device with
your wet hands.
Do not short circuit the charger.
Do not drop and break the charger or device.
Do not use battery chargers which where not approved by manufacturer.
Do not use the device during lightning storms.
It may cause decrease in performance of device and improve the risk of
electrical shock.
Use batteries and charges approved by eSTAR, and specially design for
your device. Usage of incompatible charger can lead to serious damage to
the device. Never burn the device. For device recycle follow local
regulations and requirements. Under no circumstances place the device on
heating devices, such as microwaves or stoves and heaters. Overheated
batteries can explode. Under no circumstances do not Do not squeeze or
puncture the device. Make sure that the device is not under external
pressure, as this may result in short-circuit inside the device or the device
may overheat.

This symbol on placed on the product or the user's guide
shows that shows your electrical or electronic equipment at the end of it's
life must be collected separately from other household waste. It is has a
separate collection and recycling system. Dear user - Protect yourself and
the surrounding environment, take the opportunity to contribute to nature
conservation for future generations
Inactive, unusable batteries and accumulators are on site accepted.
Bin unsuitable batteries and accumulators in a special container that is
labeled with battery and / or / accumulator / collection sign.
Do not dispose batteries and accumulators into the general municipal
waste stream.
You can get the information about collection and recycling on site, on
website of Ministry of Environment and other informational publications.
Device and it's chargers should be managed and utilized carefully
CE Marking on the product (or it's package) displays that
it is manufactured in Europe or other place in accordance
with the safety, helps and environmental requirements of
European Union.
RoHS marking ensures parts are made from recycled materials.

Safety requirements
Protect device and chargers from damage
• Make sure the device is protected from cold or heat.
• Extreme temperatures could deform your device and reduce the charge and the
life of device and the battery.
• Do not charge the device with the damaged charger, under no circumstances.
Warning: when using the device in restricted areas, observe all safety warnings
and instructions.
Always turn off your device where it's usage is forbidden
Follow all the rules limiting the use of mobile devices in certain locations.
Do not use your device neat other electronic appliances.
Most electronic devices use radio frequency signals. Your device can disturb
other electronic appliances.
Do not put your device near the heart pacemaker.
• If possible, try not to hold your device closer than 15 cm from heart
pacemaker; your device can disturb the pacemaker.
• If you need to use the device, keep at least 15 cm distances from heart
pacemaker.
• In order to reduce the likelihood of interference with heart pacemaker, hold
the device on the opposite side of the body than a stimulant.
Do not use your device in hospital or close to medical appliances, the radio
frequencies of which could be disturbed
In case you are used any medical device, contact it's manufacturer and make
sure that it will not be disturbed by radio frequencies of your Tabloid PC.
Turn of the device when near to potentially explosive places
• Always follow the instructions for the potentially instructions, markings and
signs.
• Do not use the device when pouring fuel (in gas station) or in places near fuels
or chemicals.
• In place where the device, part or accessories of it kept, do not keep
flammable liquids, gas or explosive materials.
Your main responsibility is to drive safely. Never use the device while driving,
if the law forbids that. For safety of your own and others always act wisely, and
remember these tips:
Keep the device safely
• Moisture and the liquids of all kinds can damage parts or electronic chains of
device.
• Do not turn on the device when it is wet. If the device is already turned on,
turn it off immediately and take out the battery (if the device cannot be turned

off or you cannot take out the battery - do nothing). Wipe the device a towel and
bring it to a service center.
• If the failure of device will be caused by the moisture, you will lose the
manufacturer's guarantee.
Do not use the device in dusty, dirty places
The trapped dust inside the device can interfere its functioning.
Do not place the product on a sloping surface
If the device will skim, it can be damaged.
Do not keep the device in cold or hot places. Use the device only in
temperatures of -20–45 °C
• The device left in closed vehicle may explode, because the temperature inside
can reach 80 ° C.
• Do not keep the device in direct sunlight for long time (for example on the
deck of the car).
• Keep the accumulator in temperatures of -20–45 °C.
Do not keep the device near magnetic fields
• Due to effect of magnetic fields the device might start to function improperly
or the battery can be discharged.
Cards with a magnetic stripe, including credit, phone, bank cards and electronic
vouchers, within the coverage of magnetic field can get damaged.
Do not keep the device near heaters or on then for example microwaves,
frying appliances or high pressure containers
• Battery leakage might appear.
• Your device might overheat and cause the fire.
Do not drop and hit your device.
• You can break the screen of device.
• The device or parts of it can be damaged or start to malfunction when bended
and deformed.
Protect your eyes from the adverse effects of light flashes
The room where you use your device lit be at least minimally, also do not hold
the screen very close to eyes.
• Watching movies or playing video games for a long time, due to exposure to
bright light, may be temporarily reduced your vision. If you feel unpleasant
symptoms, turn off the device immediately.

Act in a way to ensure the maximum life cycles battery and charger
Do not charge the battery for longer than a week since. Overcharging can
shorten its lifespan.
• Over time, unused batteries will discharge itself and it must be re-charged
before usage.
• Disconnect chargers from the mains, when not using it.
Use batteries, charges, accessories and additional parts only if they are
approved by manufacturer.
• Usage of non-original batteries and charges might lead to shortening the
lifespan of the device and malfunction.
• eSTAR cannot take responsibility for user's safety if they are using accessories
nor authorized by eSTAR.
Protect your hearing while using headphones
• Too loud sound can damage your hearing.
• Loud sound while driving can distract and cause an accident.
• Before connecting to the sound source always quiet down the sound and set
the parameter of minimal volume, necessary to listen to conversation or music.
• If you are in dry place, headphones can produce static electricity. Avoid using
headphones in dry places, or before connecting the headphones to the device,
touch them to
a piece of metal to cause static electricity discharge.
While walking or moving, take the safety measures
Always follow the environment to avoid injuries to yourself or others.
Do dissemble, modify or repair your device
You will lose manufacturer's warranty if you'll make any changes or
modifications.
In order to repair the device, bring it to eSTAR customer service center.
Do not paint or put stickers on the device
Paint or stickers can interfere with moving parts and handicap the performance
of your device.
Device cleaning instructions:
• Clean your device and charge with a towel or sponge.
• Do not use chemicals or disinfectants

Do not use the device, if the screen is broken or damaged
Broken glass can cause injuries to your face and arms. In order to repair the
device, bring it to eSTAR customer service center.
Use the device only for its intended purpose
When using the device in a public place try not to impede others
Device can be repaired only by qualified professional
Do let the unqualified specialists to repair the device, because they can damage
your device, you will also lose the manufacturer's warranty.
Be careful while dealing with memory cards
• Do not pull out the memory card at a time when the devise is downloading or
uploading information, it can lead to data loss and (or) damage the card or
device.
• Protect cards from shocks, static electricity, and electrical noise caused by
other devices.
Do not touch with your fingers or metal objects the gold-colored contacts or
clips of the memory card. If it is dirty, clean the card with a soft tissue.
Protect your personal and other important data
• Do not forget to back up your data, while using your device. eSTAR is not
responsible for data loss.
• If you decided to dispose your device, make the backup of all the date stored
in it. Then restore the factory setting, so the other parties will not be able to use
your data.
Do not share the materials which are protected by copyrights
Do not distribute the materials which you recorded, and which are protected by
copyrights without owner's permission, in doing so you may violate copyright
laws. The manufacturer is not responsible for any legal issue, determined by
the fact that the material in which copyright is protected was illegally used by
the consumer.

Key Functions
 7”, 1024*600 TN capacitive touch screen.
 Support WI-FI, 3G wireless Network
 Cortex A9 dual-core processor, running the highest frequency of 1.2 GHz;
 Adopt android 4.1 Jelly Bean system;
 Support auto rotation the screen horizontally or vertically;
 Support Web browsing, chat online, online video, online games and download
etc;
 Supporting multiple audio formats such as MP3, WMA, AAC, APE, FLAC etc;
 Support Video output function;
 Support Bluetooth, GPS;
 Front camera 0.3M, back 2M pixels, support network video call function;
 Support JPG BMP PNG formats such as picture browsing, rotating, automatic
playback;
 USB2.0 high rate transmission;
 Built-in microphone and longtime recording; Support e-book reading;
 Ultra-long standby;
 Supporting Micro SD Card; Support OTG function, can expand storage space；

Basic Operation
Power on
In the shutdown state, long press " " button.
Power off
In the power on state, press the " " key for 3 seconds then pop-up device options,
select "Power off” for shut down.
Sleep
The machine under normal operating conditions, short press the power button, into
hibernation, now screen will close. Short press the power button again and you are able
to resume normal mode. You can use this function to reduce power consumption.
Power reset
If the computer shutting down during the operation, you can turn off and restart it
by pressing "reset" key.
Screen time out
If you do not use computer for a while, without touching any buttons on the time,
the screen turns off automatically.
In any state, short press " " button for activation;
If it is necessary to deactivate the screen time out function, you can set the [Screen
time out] option under [display] function into "Never ".

Using the Micro SD card
After this unit is connected with the computer, you will find two moving disks. The
first one is the built-in memory disk for this unit and the other is the disk for the Micro
SD card. If no card is inserted, the second disk can not be opened. This unit supports the
extension of the Micro SD card from 128MB to 32GB.
Inserting Micro:
Put the Micro SD card face up (side with words), and slightly force the card into
the socket of the card, i.e. connecting the unit. Under this state, you can play the content
placed in the Micro SD card.
Pulling out the SD card:
Slightly push the Micro SD, it will bounce by a section, and then you can take it
out.
Battery:
This unit has High capacity Polymer battery.
Available duration of the battery power depends on volume, types of playing files
and operations. The player can be set up by the user as "user define power off time" or
"display setup" to save batteries.
Charging:
This unit can be recharged by USB port, you can also use DC Charger:
Take out the DC charger, plug it into the wall outlet with AC 220V(output current
2000mA，output voltage 5V~5.2V)), then plug in the DC jack into the device DC-in
jack.

Shapes and Keys
1. Front camera 2. Home key 3. Video socket
4. Reset 5. SD card socket 6. USB socket
7. MIC 8. earphone socket 9. Power switch
10. Loudspeaker 11. Back camera 12. SIM card
Settings. In the main menu,
select the option "settings" to be
able to access the System Set
folder.

Description of functions:
 WiFi
Wi-Fi: ON/OFF the wireless connection
Wi-Fi setting: touch the " " icon, can enter WIFI senior set items
 Date usage
Display Date usage
 Sound settings
Volume: set the notice, media and alarm clock volume.
Default notification: Click to open notification bell menu, select the item is set to
default notification bell.
Touch sounds: after touching, Touch screen will make a sound
Screen lock sound: after locking, Touch screen will make a sound
 Display settings
Brightness: Set adjust brightness of the screen
Wallpaper: you can choose wallpaper from Super-HD player and wallpaper
Sleep: Set the screen saver standby time. When the player is in the standby screen saver,
WIFI function Turns OFF to save electricity purpose; when you cancel this operation,
WIFI function turns ON automatic in 10 seconds.
Accelerometer coordinate system: you can set Accelerometer coordinate system
Screen adaption: Used to adjust size of some games display screen

 Storage
Check the PMP memory and available storage
 Apps
Here you can view, install and managing applications
 Security
Screen lock, slide, pattern, PIN, password etc. settings
Make password visible: View the password typed in the field
Unknown source: allow install of non-Google Market applications, the default setting is
open
 Language & input
Language and area Setting, input method etc. Function Storage
 Backup & reset
Here you can backup, restore the machine Settings and data
 Date & time
Set the date, time, time zone and time display format
 About device
Check the machine software version and other information

Connect the computer
This machine can be connected through the USB cable to personal computer; you
can copy or delete data. Steps:
1. Connect the machine through the USB cable to the PC's USB port, then on screen
appears notification "USB already connected" notice options
2. Click "USB already connected" notice options, choose "open USB storage devices",
and now you can use tablet as USB storage.

Common troubleshooting
 What is the APK file? Does it have any relation with Android PMP?
A: APK is the abbreviation of Android Package, that Android installation Package. Through the APK files
directly to Android system can be installed in execution PMP players.
 How to get the APK application
A: You can download via PC-side installation, you can also choose “Android market” online to download and
install app.
 Why WIFI connection is no working
A: When the player is in the standby screen saver, WIFI function Turns OFF to save electricity purpose; when
you cancel this operation, WIFI function turns ON automatic in 10 seconds.
 Why some downloaded APK program, not working properly
A: APK software, downloaded mostly by the user to development, without the platform compatibility testing,
and part of the hardware and software for Android system version has a special requirements, so they could be
not compatible and you can`t perform normal operation.
 Why connected charger is not displayed on charging state
A: When the battery is extremely low, you need to use DC charger at least half an hour or more to show
charging status
 Why can't realize the gravity induction function
A: This machine support gravity feeling function, can be through the shaking to switch the screen machine, but
some of the application does not support the gravity induction function, it can't realize the screen of switching
function, this is the software support question, the functionality of the player.
 Players can't boot
1）Check the battery
2）Connect the ac adapter after inspection again
3）If after charging still unable to boot, please contact our customer service
 Can’t Hear the voice in the headset
1）Please check the volume is not set to 0
2）Please check whether the connection headphones
 Player charging abnormalities
1) Please confirm that the use of the equipment complies with the charger of the player charger requirements
2) Such as connection USB charging, please do not connect to computers lead USB interface
 Why some download video can't normally broadcast
This player can be compatible with the Internet video files of the play, but because of the Internet provide
video format, coding method, the resolution, code flow rate in the parameters are different, it may result that
some video file cannot be played or play anomaly, it is recommended to use a third part video conversion
software, convert file format and then copy to the player to play.
For more information, please visit www.estar.eu

Vartotojo instrukcija
7" Planšetinis kompiuteris Android 4.1
Modelio Nr: eSTAR MID7138G
www.estar.eu

Gerbiami vartotojai,
Dėkojame, kad įsigijote šį gaminį.
Jis suteiks daugiau patogumo Jūsų verslui (dirba su programomis Word,
Excel, galėsite siųsti ir gauti el. laiškus...) galėsite pramogauti (žaisti 3D
žaidimus, bendrauti socialiniuose tinklalapiuose, peržiūrėti kinus ir el.
Knygas.....).
Nauodamiesi Android 4.1, su 1.2 GHz procesioriumi ir aukštos raiškos
jautriu ir talpiu liečiamuoju ekranu, įgysite nuostabios patirties.
Prieš pradedant naudotis planšetiniu kompiuteriu, prašome atidžiai
perskaityti šią vartojimo instrukciją.
Svarbi informacija
 Baterija tinkamai veiks ir bus geriausios būklės pilnai įkrovus ir iškrovus ją
2-3 kartus.
 Naudojantis ausinėmis pernelyg didelis garsas gali padaryti žalos jūsų
klausai. Todėl prašome atitinkamai sureguliuoti grotuvo garsą ir pasirinkti
tam tinkamą naudojimosi trukmę.
 Neatjunkite planšetinio kompiuterio staigiai, formuojant ar įkeliant ar
atsisiunčiant dokumentus ar programas, dėl to gali atsirasti gedimų
programose.
 Neardykite patys planšetinio kompiuterio, valydami planšetinio kompiuterio
paviršių nenaudokite alkoholio, skiediklio ar benzolo.
 Nenaudokite planšetinio kompiuterio vairuodami ar vaikščiodami.
 Planšetinis kompiuteris nėra atsparus drėgmei ir vandeniui.
 Prietaiso negalima pamesti arba per stipriai spausti ekrano, nes taip jį galima
sugadinti.
 Patys negalite atnaujinti mikroprogramos. Dėl to gali sugesti jūsų planšetinis
kompiuteris.

Saugos užtikrinimo priemonės
Kad nesusižalotumėte ir nesužalotumėte kitų ar nesugadintumėte prietaiso,
prieš naudodami prietaisą perskaitykite visą šią informaciją.
Perspėjimas: saugokitės, kad nesukeltumėte elektros iškrovos, gaisro ir
sprogimo.
Nenaudokite pažeistų maitinimo laidų ar kabelių ir atsilaisvinusių elektros
lizdų.
Nelieskite maitinimo laido drėgnomis rankomis ir nejunkite įkroviklio už
laido.
Nelankstykite ar negadinkite maitinimo laido.
Nenaudokite prietaiso jį kraudami arba nelieskite prietaiso šlapiomis
rankomis.
Nepadarykite įkroviklio trumpojo jungimo.
Nenumeskite ir nesudaužykite įkroviklio arba prietaiso.
Nekraukite akumuliatoriaus gamintojo neaprobuotais įkrovikliais.
Nenaudokite prietaiso perkūnijos metu.
Gali sutrikti Jūsų prietaiso veikimas ir padidėja elektros šoko rizika.
Naudokite „eSTAR“ patvirtintus akumuliatorius ir įkroviklius, specialiai
sukurtus jūsų prietaisui. Naudodami nesuderinamus įkroviklius, galite
stipriai pažeisti arba apgadinti savo prietaisą.Jokiu būdu nedeginkite
prietaisų. Šalindami prietaisus, vadovaukitės vietos taisyklėmis ir
reikalavimais. Jokiu būdu nepadėkite prietaisų į šildymo įrenginius,
pavyzdžiui, mikrobangų krosneles arba ant viryklių ir radiatorių. Perkaitę
akumuliatoriai gali sprogti. Jokiu būdu nesuspauskite ir nepradurkite
prietaiso. Pasirūpinkite, kad prietaisas nebūtų slegiamas iš išorės, nes dėl to
gali įvykti prietaiso vidinis trumpasis jungimas arba įrenginys gali perkaisti.

Šis simbolis ant produkto ar vartojimo vadove rodo, kad jūsų elektros
ar elektroninė įranga pasibaigus vartojimo laikotarpiui turi būti išmetama
atskirai nuo kitų buitinių atliekų. Jai skirta atskira surinkimo ir perdirbimo
sistema. VARTOTOJAU- saugok save ir mus supančią aplinką, pasinaudok
galimybe prisidėti prie gamtos išsaugojimo ateinančioms kartoms.
Neaktyvios netinkamos naudoti baterijos ir akumuliatoriai priimamos
nemokamai jų pardavimo vietose.
Netinkamas baterijas ir akumuliatorius meskite į tam skirtas specialias talpas,
kurios yra paženklintos baterijų ir/ar/akumuliatorių /surinkimo ženklu.
Nemeskite baterijų ir akumuliatorių atliekų į bendrą komunalinių atliekų
srautą.
Informaciją apie atliekų surinkimo galimybes bei perdirbimą galite sužinoti
pardavimo vietose, Aplinkos ministerijos tinklalapyje bei kitose informacijos
pateikimo leidiniuose.
Tel. [phone] (nemokamas tel.) visoje Lietuvoje
[phone] didžiuosiuose miestuose/perdirbėjas/;
[phone] didžiuosiuose miestuose/EPA/
[phone] (nemokamas tel.) visoje Lietuvoje
Rūpestingai tvarkykite ir utilizuokite prietaisą ir įkroviklius
CE ženklinimas (ang. "CE Marking") ant produkto (arba
jo pakuotės) rodo, kad šis Europoje ar kur kitur pagamintas
produktas atitinka Europos Sąjungos saugumo, sveikatos ir
aplinkos apsaugos reikalavimus.
RoHS ženklas užtikrina, kad detalės yra pagamintos iš perdirbtų
žaliavų.
