E-Z UP Eclipse II Professional User manual

“Sets Up in Seconds!”™
10’ x 20’
OWNER’S MANUAL
Care and MaintenanCe
IMPORTANT! Read this information before proceeding.
It is the user’s responsibility to take the following
precautions at all times.
• Always stake or weigh down your shelter. Do not use in any
potentially windy or rainy weather.
Wind and rain can damage the E-Z UP® Instant Shelter® product
and may also result in injury to you or others. Therefore, do not
rely on shelter for protection in heavy or prolonged rain storms.
• The E-Z UP® Instant Shelter® product is designed as a temporary
shelter. Do not leave up for extended periods.
• Use caution when handling the E-Z UP® folding frame.
Avoid pinching hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP® Instant Shelter® product unattended.
• Do not build fires within shelter enclosure.
For long lasting durability and the best possible protection
for your E-Z UP® Instant Shelter® products, follow these
E-Z care and maintenance instructions:
• Use a mild soap (not detergent) and plenty of water for top
cleaning.
• Let the E-Z UP® top and frame dry completely before closing
or storing to avoid mildew.
• Frame will operate and look better if occasionally wiped with
silicone spray, especially before and after use in damp conditions.
Remove excess silicone residue before applying top.
• Use a seam sealer if top leaks or drips water. Available at most
sporting goods and hardware stores.
• Slightly tighten bolts if frame becomes loose.
iMportant inforMation
WARNING: Keep all flame and heat sources away from all
shelter fabrics. These fabrics meet the flammability requirements
of CPAI-84. The fabric may burn if left in continuous contact with
any flame source. The application of any foreign substance to
the fabric may render the flame-resistant properties ineffective.
PRODUCT WARRANTY
We Make Life E-Z!™
INTERNATIONAL E-Z UP, INC.
1601 Iowa Avenue, Riverside, California 92507
[phone] • Fax [phone]
ezup.com
Customer Service Hot Line
800-45 SHADE
800-457-4233
INTERNATIONAL E-Z UP, INC., manufacturer of
E-Z UP® Instant Shelter®
products, warrants to the
original purchaser who provides a dated sales
receipt, from an Authorized Dealer, each part of the
E-Z UP® Instant Shelter® product to be free from
defects in material or workmanship for a period
of FIVE YEARS after the date of original purchase.
This warranty applies only for normal and expected
uses, as determined by the manufacturer.
INTERNATIONAL E-Z UP, INC.’s obligation and liability
under this warranty is limited to the repair or replace-
ment (at its option) of the product or its parts, after its
own review and examination.
RETURN ADVISORY - Before returning any part or
product to INTERNATIONAL E-Z UP, INC. or its desig-
nated representative, please phone or write to obtain
specific return shipping instructions. All shipping costs
must be prepaid, and INTERNATIONAL E-Z UP, INC. is
not responsible for products damaged in transit.
CONDITIONS - This warranty shall be void as to any prod-
uct which has been altered or modified in any manner.
This warranty does not apply to damages caused by
wind, rain, or other forces of nature, not to accidental
or deliberate damage of the product, nor to use of
the product that does not conform with the product
instructions.
This warranty is provided in lieu of all other warranties,
expressed or implied.
E-Z UP
®
INSTANT SHELTER
®
With proper care, this shelter will deliver
years of trouble free service. Please take a
few minutes to read the following use and
care instructions. If you have any questions
or require assistance, please call.
Customer Service Hot Line
800-45 SHADE
800-457-4233
ezup.com
© Copyright 2010 International E-Z UP, Inc. USA. All rights reserved. OM.EC2.20.0620 10942 B

Note: Once top is permanently attached, only perform
steps 3 and 8 - 11 to set up.
Trusses
Fabric Top
Top Attachment Nut
Coin
Spacers
instruCtions
*Note: First Time Attachment Is Required.
Top and frame are shipped separately to avoid damage.
A first time set up requires that top be bolted on to the frame.
This first time set up takes longer than future set ups. Once
top is permanently attached to frame, set up and take down
are easily accomplished within seconds.
Please read each step before you attempt to set up.
Save these instructions for future reference.
*1. With a partner, gently expand
the main frame part “A” and sub-
frame part “B” to approximately half
of its fully opened position. Face
open ends of trusses toward each
other.
*2. Attach the main frame to the
sub-frame at six points. The outside
end of each truss is marked with
either an “A” or “B” label. Locate
these labels as well as the “A” “B”
labels on the main frame angle brack-
ets. Attach each “B” truss to the
adjoining “B” bracket with the bolts
provided. Ensure that the “B” label
on the truss touches the “B” label
on the bracket and tighten the bolts
securely by inserting the allen wrench
into the bolt and securing the washer
with the open end wrench. Do not
overtighten bolts - make sure that
they can still rotate easily. Complete
by attaching the remaining “A” truss-
es to the adjoining “A” brackets.
3. Place your E-Z UP® Instant
Shelter® frame in the center of area
to be shaded. With partner on
opposite 10’ sides of shelter, grasp
outer legs, lift off the ground, and
step backwards stopping at full
arms’ length - approximately 3/4 its
total size.
*4. Gently unfold the fabric top
and place it over the open shelter.
Align the four corners of the top
over the four corners of the frame.
*5. Attach each corner of the
top to the frame by matching
the quick attachment strips on
the top with the quick attach-
ment strips on the frame. Pull
the corners down fully. Push
the strips firmly together at each
corner.
*6. To secure the top to
frame, align each of the 6 grom-
met holes on valance with the
bolts in frame.
8. With two hands grasp the
bottom of the diamond shaped
area of trusses on the opposite
10’ sides of shelter. Lift up and
continue stepping backward until
shelter is fully opened shaking
slightly. Be careful not to pinch
fingers.
9. Engage the Auto-Slider® at
each corner by pushing up with
one hand while holding down
the top of the leg with the other
hand. The quick pin will engage
the hole. Then pull down the
hem of the top. Repeat at all
four corners and at the middle
leg.
*7. Unscrew top attachment
nut from bolt. Place grommeted
fabric top over the bolt, screw on
top attachment nut and tighten
until snug. Top should rotate
easily - do not overtighten.
Repeat this procedure on the
remaining grommets.
first tiMe top attaChMent
2. With partner on opposite
10’ sides of shelter, lift outer
leg up 1”, depress toggle
button and telescope inner
leg up into outer leg. Repeat
steps 1 and 2 on remaining
legs.
4. Grasp the top of the dia-
mond shaped area of trusses,
on the opposite 10’ sides of
shelter, lift shelter up slightly
and shake while stepping
toward one another.
5. Grasp adjacent outer
legs and gently push shelter
together until fully closed. Be
careful not to pinch fingers!
Store shelter in cover bag in
upright position.
10. With partner, lift up
two outer legs as shown 1”
and lower the inner legs until
toggle button locks. Repeat
on middle leg on same side.
Repeat on opposite legs.
Be sure to adjust two legs
at one time to avoid frame
damage.
11. Lower adjacent
center legs until toggle but-
ton locks.
1. Depress toggle button
on one center leg and tele-
scope inner leg into outer
leg.
3. Release the Auto-Slider®
at each corner and center by
first lifting hem of top. With
one hand, push up on truss
near slider, release quick pin
by pulling ring.
how to take down
Main Frame (A) Sub Frame (B)
