OWNER'S MANUAL
Take time to learn how to provide
years of durable and safe use from
your E-Z UP®Instant Shelter® . After
reading these instructions carefully, if
you have any need of assistance, call
our Customer Service Department.
E-Z UP®
INSTANT SHELTER®
“Sets Up in Seconds!”™
8' x 8', 10' x 10' and 10' x 15'
5 YEAR WARRANTY
Ask about our other E-Z UP®Instant Products™
For online warranty, service, parts
and accessories as E-Z as 1-2-click,
contact us at
Customer Service Hot Line
(800) SHADE ME
www.ezup.com
74233 63
IMPORTANT INFORMATION
CARE AND MAINTENANCE
For long lasting durability and the best possible protection for your
E-Z UP®Instant Shelter®, follow these E-Z care and maintenance
instructions:
•Use a mild soap (not detergent) and plenty of water for top cleaning.
• Let the E-Z UP®top and frame dry completely before closing or storing to
avoid mildew.
• Frame will operate and look better if occasionally wiped with silicone spray,
especially before and after use in damp conditions. Remove excess silicone
residue before applying top.
• Use a seam sealer if top leaks or drips water. Available at most sporting
goods and hardware stores.
• Slightly tighten bolts if frame becomes loose.
IMPORTANT! Read this information before proceeding. It is the
user’s responsibility to take the following precautions at all times.
• Always stake or weight down your E-Z UP®. Do not use in any
potentially windy or rainy weather. Wind and rain can damage
the E-Z UP®Instant Shelter®and may also result in injury to you
or others. Therefore, do not rely on shelter for protection in
heavy or prolonged rain storms.
• The E-Z UP®Instant Shelter®is designed as a temporary shelter.
Do not leave up for extended periods.
• Use caution when handling the E-Z UP®folding frame. Avoid pinching
hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP®Instant Shelter®unattended.
• Keep all flame and heat sources away from fabric top. Do not build fires
within shelter enclosure.
Fire resistant - meets CPAI-84 requirements.
Covered under one or more of the following patents: 4,607,656; 4,924,896; 5,244,001; 5,421,356; 5,485,863;
5,490,533; 5,511,572; 5,632,292; 5,632,293; 5,794,546; 5,797,412; 5,813,425; 5,865,127; 5,921,260; 5,934,301; 6,041,800;
6,070,604; 6,076,312; 6,129,102; 6,138,702; 6,192,910; 6,230,729; 6,240,940; 6,361,057; 6,363,956; 6,374,842; 6,382,224;
6,397,872; 6,412,507; 6,431,193; 6,439,251; 6,470,902; 6,502,597; 6,520,196; 6,601,599; 95704390; 94/2354; 91461;
132167; 95/0693; 95/6140; 95/6141; 84107895; 684,978; 2123096; 190486; 289754; 215344; 701077; 2128935; 2949648;
48648; DE 695 10 919 T2; WO96/03561. International Design Registration No. DM/009515 Benelux Design Registration No. 16959-04.
Other US and foreign patents pending. © Copyright 2005 International E-Z UP, Inc. USA. All rights reserved. OV022-0105
We Make Life E-Z!™
INTERNATIONAL E-Z UP, INC.
1601 Iowa Avenue, Riverside, California 92507
[phone] • Fax [phone]
www.ezup.com
Toll-Free Sales
800-45 SHADE
INTERNATIONAL E-Z UP, INC., manufacturer of
the E-Z UP®Instant Shelter® , warrants to the original
purchaser who provides a dated sales receipt, each
part of the E-Z UP®Instant Shelter®to be free from
defects in material or workmanship for a period
of five years after the date of original purchase. This
warranty applies only for normal and expected
uses, as determined by the manufacturer.
INTERNATIONAL E-Z UP, INC.’s obligation and
liability under this warranty is limited to the repair or
replacement (at its option) of the product or its parts,
after its own review and examination.
RETURN ADVISORY - Before returning any part or
product to INTERNATIONAL E-Z UP, INC. or its
designated representative, please phone or write to
obtain specific return shipping instructions. All
shipping costs must be prepaid,and
INTERNATIONAL E-Z UP, INC. is not responsible
for products damaged in transit.
CONDITIONS - This warranty shall be void as to
any product which has been altered or modified in
any manner. This warranty does not apply to
damages caused by wind, rain, or other forces of
nature, not to accidental or deliberated damage of the
product, nor to use of the product that does not
conform with the product instructions.
This warranty is provided in lieu of all other war-
ranties, expressed or implied.

HOW TOSET UP
INSTRUCTIONS
1. With partner, slightly lift
up two adjacent outer legs 1",
depress snap button and
telescope inner legs into outer
legs. Repeat on the opposite
legs - making sure to do two
legs at a time.
9. Lift two adjacent outer
legs up 1" and slide out the
inner legs until the snap button
locks. Repeat on the opposite
legs - make sure to do two legs
at a time.
3. Grasp the top diamond on
opposite sides by “close“ sticker.
Lift the shelter up slightly and
shake it while stepping towards
your partner until the unit is
3/4 closed. With each partner
grasping two outer legs, push
frame together to fully close it -
Be careful not to pinch fingers.
Store shelter in cover bag.
7. Engage the auto slider®at
each corner by pushing up with
one hand while holding down the
top of the leg with the other hand.
The quick pin will engage the hole.
Then pull down the hem of the top.
Repeat at all four corners.
8. Adjust fabric tension to
desired tightness by turning center
peak poles. Twist clockwise to
lower center peak pole; twist
counter-clockwise to raise center
peak pole. Do not twist more than
three revolutions.
1. Place your E-Z UP®frame
in the center of area to be shel-
tered. With partner on opposite
side, grasp two outer legs, slightly
lift off ground and step back-
wards, stopping at full arms'
length - approximately 3/4 it's
total size.
*2. Gently unfold the fabric
top and place it over the open
frame.
*3. Attach the top to the
E-Z UP®frame by matching hook
and loop strips on the top with the
hook and loop strips on the frame.
Pull the corners down fully. Push
the strips firmly together at each
corner.
*4. To secure the top to
frame, line up grommet holes on
valance with the bolts on frame.
*5. Unscrew top attachment
nut from bolt. Place grommeted
fabric top over the bolt, screw on
top attachment nut and tighten
until snug. Top should rotate easi-
ly - do not overtighten. Repeat
this procedure on the remaining
grommets.
*Note: First Time Attachment Is Required.
Top and frame are shipped separately to avoid damage. A first time set up
requires that top be bolted on to the frame. This first time set up takes
longer than future set ups. Once top is permanently attached to frame, set
up and take down are easily accomplished within seconds.
HOW TO
TAKE DOWN
6. Grasp the bottom of the
diamond shaped area of trusses on
opposite sides. Lift up and step
backwards until shelter is fully
opened, being careful not to pinch
fingers. 2. Release the auto slider®
at each corner by first lifting
hem of top. With one hand, push
up on truss near slider, release
quick pin by pulling ring.
Note: Once top is permanently attached, only perform steps 1
and 6 - 9 to set up.
Please read each step before you attempt to set up.
Save these instructions for future reference.
Lower
Raise
Fabric Top
Top Attachment Nut
Coin
Spacers
Trusses
