IMPORTANT INFORMATION
CARE AND MAINTENANCE
For long lasting durability and the best possible protection for your
E-Z UP®Instant Shelter®product, follow these E-Z care and
maintenance instructions:
• Use a mild soap (not detergent) and plenty of water for top cleaning.
• Let the E-Z UP®top and frame dry completely before closing or storing to
avoid mildew.
• Frame will operate and look better if occasionally wiped with silicone spray,
especially before and after use in damp conditions. Remove excess silicone
residue before attaching top.
• Use a seam sealer if top leaks or drips water. Available at most sporting
goods and hardware stores.
• Slightly tighten bolts if frame becomes loose.
IMPORTANT! Read this information before proceeding. It is the
user’s responsibility to take the following precautions at all times.
•Always stake or weigh down your E-Z UP® shelter. Do not use in any
potentially windy or rainy weather. Wind and rain can damage your E-Z
UP®shelter and may also result in injury to you or others. Therefore, do
not rely on shelter for protection in heavy or prolonged rain storms.
•The E-Z UP®shelter is designed as a temporary sun shelter. Do not leave up
for extended periods.
• Use caution when handling the E-Z UP®frame. Avoid pinching
hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP®Instant Shelter®product unattended.
• Do not build fires under shelter.
WARNING: Keep all flame and heat sources away from
the top, awning and sidewall fabrics. These fabrics meet the
flammability requirements of CPAI-84. The fabric may burn
if left in continuous contact with any flame source. The
application of any foreign substance to the fabric may
render the flame-resistant properties ineffective.
022A-10-R01
INTERNATIONAL E-Z UP, INC., manufacturer of the E-Z UP®
Instant Shelter®product, warrants to the original purchaser
who provides a dated sales receipt from an Authorized
Dealer, each part of the E-Z UP®shelter to be free from
defects in material or workmanship for a period of two
years after the date of original purchase. The E-Z UP®
Instant Shelter®frame is covered under a limited two year
warranty and guarantees the frame to be free from defects
in material or workmanship. This warranty applies only for
normal and expected uses, as determined by the
manufacturer.
INTERNATIONAL E-Z UP, INC.’s obligation and liability
under this warranty is limited to the repair or replacement
(at its option) of the product or its parts, after its own review
and examination.
RETURN ADVISORY - Before returning any part or product
to INTERNATIONAL E-Z UP, INC. or its designated
representative, please phone or write to obtain specific
return shipping instructions. All shipping costs must be
prepaid, and INTERNATIONAL E-Z UP, INC. is not
responsible for products damaged in transit.
CONDITIONS - This warranty shall be void as to any
product which has been altered or modified in any manner.
This warranty does not apply to damages caused by wind,
rain, or other forces of nature, not to accidental or
deliberate damage of the product, nor to use of the product
that does not conform with the product instructions.
This warranty is provided in lieu of all other warranties,
expressed or implied.
2 YEAR LIMITED WARRANTY
We Make Life E-Z!™
INTERNATIONAL E-Z UP, INC.
1601 Iowa Avenue, Riverside, California 92507
[phone] • Fax [phone]
ezupdirect.com
Customer Service Hot Line
1 (800) SHADE ME
74233 63
Customer Service Hot Line
1 (800) SHADE ME
ezupdirect.com
74233 6 3
Take time to learn how to provide
years of durable and safe use from
your E-Z UP®Instant Shelter®product.
After reading these instructions
carefully, if you have any need of
assistance, call our Customer Service
Department.
9ft x 11ft (2.7m x 3.4m)
12ft x 14ft (3.7m x 4.3m)
OM_911_1214 Escort 2010.qxd 10/26/10 9:25 AM Page 1

WHAT'S
INTHE BOX
• Escort®Frame • Roller Bag
• Polyester Top • 4 Piece Stake Kit
4. Release the Pull Pin at each
corner by first lifting fabric top corner.
With one hand, push up on truss near
slider to remove the weight of the
shelter from Pull Pin. Pull the Pull Pin
out to release the Pull Pin slider.
5. With partner on opposite side,
grasp top and bottom of diamond-
shaped area of trusses and slightly lift
up. Shake shelter slightly, pulling
hands apart, while stepping towards
partner until shelter is 3/4 closed.
6. Grasp adjacent outer legs and
push shelter together until fully closed.
Be careful not to pinch fingers!
Store shelter in roller bag. (See Roller
Bag Instruction enclosed within your
Warranty Kit).
1. Place your E-Z UP®frame in
the center of area to be sheltered.
With partner standing on opposite
side of frame, the tallest trusses
should be in front of you. Grasping
two outer legs, slightly lift frame off
ground and step backwards,
stopping at full arms' length.
2. Unfold the top and drape over
partially opened frame. Place the
peaked side of the top’s valance on the
side of the frame with the tallest
trusses. Match hook and loop strips on
the top with the strips located just
below the corner caps on each leg (see
photo). Push the strips firmly together
1. Grasp the top and bottom of
diamond-shaped area of trusses.
Slightly lift shelter up and push
hands together while stepping
backwards until shelter is fully
opened. Be careful not to pinch
fingers or pull backwards too
hard as trusses will bend.
2. Check Pull Pin at each corner to
make sure Pull Pin has engaged. If Pull
Pin slider is not engaged push slider
with one hand while pushing down on
the top of the leg with the other hand.
Pull Pin will engage in hole. Repeat step
on remaining legs.
HOW TO
TAKE DOWN
4. Lift two adjacent outer legs and slide out
inner legs until the snap button locks into place.
2. Lower remaining legs, by
telescoping inner legs into outer legs.
5. Lift up the remaining two outer legs and
slide inner legs until snap button locks.
Use stakes to secure in windy conditions.
3. Important: Remove the
support arms by lifting the mounting
brackets from between the two
washers and let it hang freely from
the peak truss.
3. Support arms should be engaged
by seating the mounting brackets firmly
between the two sidewall washers.
Note: Size 12’ x 14’ model will have
2 sets of support arms.
1.With a partner, lift adjacent outer
legs up 1”, depress snap button and
telescope inner legs into outer legs.
Pull Pin
Please read each step before you attempt to set up.
Save these instructions for future reference.
FIRST TIME TOP
ATTACHMENT
HOW TOSET UP
First: Repeat Step 1, in ‘First Time Top Attachment’
