Instruction Manual
S1DC8–M3
COMBINATION TIMER WITH 8 CHANNELS
EAPL
Intro uction
On power application and shorting of S1 & S2 terminals, the timing starts,
each of the relays comes ON after the preset delay timing and remain
ON till the Preset ON timing. All 8 relays switches ON & OFF in different
com inations as per the program. After completion of all com inations
clock resets to zero and depending on the status of C1-C2, timer
continues to execute the same program or waits for fresh start signal. If
Run/Prog switch is slided from program mode to run mode, timer waits
for fresh start signal.
Box Accessories
One (1) S1DC8–M3COMBINATION TIMER WITH 8 CHANNELS
One (1) Instruction manual
Safety Precautions
Read and follow all the safety precautions and instructions efore
installing and working with the equipment.
• Shorting of C1-C2, S1-S2, and I1-I2 & R1-R2 shall e potential free;
applying power to these terminals will damage the timer permanently.
• Timing not initiated.
• S1- S2 signal shall e applied.
• I1- I2 shall e open.-
! DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
• Apply appropriate personal protective equipment(PPE) and follow
safety work practices
• Only qualified electrical workers should install this equipment. Such work
should e performed only after reading this entire set of instructions.
• If the equipment is not used in the manner specified y the
manufacturer, the protection provided y the equipment may e
impaired.
• NEVER work alone.
• The successful operation of this equipment depends upon proper
handling, installation and operation. Neglecting fundamental installation
requirements may lead to personal injury as well as damage to
electrical equipment or other property.
• NEVER ypass external fusing.
Failure to follow these instructions will result in eath or serious injury.
• EAPL is not responsi le for any consequential damages arising out of use
of our products, though the technology is cautiously chosen and
implemented like any other well designed good electric device.
Tools an Fasteners
Kindly use star – type screw driver for tightening the screws.
NOTE: Installation should include a disconnecting device, like switch or
circuit reaker, with clear ON/OFF markings, to turn-off the auxiliary
supply (control power).The disconnecting device should e within the
reach of the equipment and the operator.
Dimension
Note: All Dimensions are in mm.
Front Panel
Terminal Details
A1,A2 : Source
S1-S2 : Start signal for a minimum of 150mS.
C1-C2 : SHORT – Single cycle operation
(i.e. timer stops at the end of first cycle)
OPEN – Cyclic operation
(i.e. timer continues to operate).
I1-I2 : Time Pause Input. By shorting these terminals timing is
temporarily stopped and relay status is maintained,
again y opening timing continues.
R1– R2 : PROGRAM RESET:
After shorting these terminals slide PROG/RUN switch to
PROG mode. This will erase all previously programmed
On time & delay time settings.
HOLD MODE: Continue the timing after resumption of interrupted
power & alance time is executed.
RESTART MODE: After the resumption of interrupted power,
timer waits for fresh start signal.
Page 1 of 2
OD RS AN 210001 REV 01/18-05-17

CREATED ON: May 18, 2017
How to program:
Timing Example:-
RELAY :1 COMBINATION 1 :
DLY : 00.12.30
ON : 03.25.00
A ove format is in HRS/MIN/SEC.
 Slide RUN/PROG switch to PROG mode; Relay &
com ination shows “1” and “DLY” & “MIN SEC” LED glows.
 Press “RELAY” utton till display shows “1”.
 Press “com ination” utton till display shows ‘1’.
 Press “DLY/ON” utton to select Delay time
(DLY led glows).
 Press “RANGE” utton to select range as MIN SEC
(MIN SEC led glows).
 Press “SELECT” MSD starts flashing.
 Press “ADVANCE” till display shows 1.
 Press “SELECT” again; 2
nd
digit starts flashing.
 Press “ADVANCE” till display shows 2.
 Press “SELECT” again; 3
rd
digit starts flashing.
 Press “ADVANCE” till display shows 3.
 Press “SELECT” again; 4
th
(LSD) digit starts flashing.
 Press “ADVANCE” till display shows 0.
 Press “SELECT” again; the SET value is saved in memory &
same SET value is copied to ON time of same
com ination.
 Press “DLY ON” utton to select ON time (ON led glows).
 Press “RANGE” utton to select range as HRS MIN
(HRS MIN led glows).
 Press “SELECT” MSD starts flashing.
 Press “ADVANCE” till display shows 0.
 Press “SELECT” again; 2
nd
digit starts flashing.
 Press “ADVANCE” till display shows 3.
 Press “SELECT” again; 3
rd
digit starts flashing.
 Press “ADVANCE” till display shows 2.
 Press “SELECT” again; 4
th
digit (LSD) starts flashing.
 Press “ADVANCE” till display shows 5.
 Press “SELECT” again, SET ON time is saved in memory.
 Same procedure shall e followed for different ranges
and different com inations.
NOTE: ON time setting shall e always more than DLY time
in all ranges.
OPERATING
CONDITION/
MODE
STATUS
TIMING
SEQUENCE
TIMING IN
PROGRESS
(TIP)
TIMING
COMPLETION
(TC)
RELAY LED RELAY LED
CHANNEL
“0”
DELAY TIME OFF OFF ON ON
ON TIME ON ON OFF OFF
CHANNEL”1
” & So on
DELAY TIME OFF OFF ON ON
ON TIME ON ON OFF OFF
Function Com ination Switching of
Outputs.
Rated supply Voltage 85V TO 270V AC/DC
Rated frequency 50 / 60Hz ± 5%
Power consumption AC Approx. 20VA
DC Approx. 10W
Control output 8 (8 NO contacts rated for 5A @
250V AC/28VDC resistive load)
Start Signal Potential free closure for a
minimum of 250mSec.
Reset Signal Potential free closure
Time range 1Sec to 99Hrs 59Min 59Sec For
Delay & ON
Setting accuracy ± 0.2% ± 50mSec.
Repeat accuracy ± 0.2% ± 50mSec.
Recovery time 2Sec minimum
Variation due to voltage
change ± 1% max. ± 50mSec.
Variation due to
temperature change ± 2% max. ± 50mSec.
Variation due to
frequency change ± 1% max. ± 50mSec.
Am ient temperature Operation:-10º C to + 55º C
Storage :-25º C to +80º C
Humidity MAX 85% RH @ 40ºC
Technical Specification
Disposition
Once the product life is over, you may send ack the
unit to EAPL for disposition
