Earmor C51 User manual

C51

Thanks for your choosing EARMOR®
EARMOR®Hearing Protectors designed to protect users from harmful noise.
1. Headband
2. Slider
3. Microphone
4. Microphone Pickup
5. Bluetooth Mode
6. ON/ OFF
7. Volume buttons
PARTS
1
2
3
4
5
6
7

EARMOR® C51 electronic Hearing Protector are tested and certified according to the following
standards:
ANSI S3.19-1974
EN 352-1：2020
EN 352-6：2020
Noise Reduction Rating - 24dB
EARMOR® C51 Attenuation data, American National Standards Institute specifications ANSI
S3.19-1974
EARMOR® C51 electronic noise reduction headsets can provide hearing protection in noisy
environments, and can sense the environment through the sound pickup function. With the
Bluetooth function, you can connect to Bluetooth devices for telephone communication, send
voice messages or listen to music during work. Suitable for many industries: oil and gas
industry, mining industry, automobile manufacturing, building construction, design, food and
beverage manufacturing, forestry, industrial maintenance, metal manufacturing, military
maintenance, equipment maintenance, pharmaceuticals, racing, transportation.
For the best protection, ear cushion sealing ring should seal firmly against head, Anything that
interferes with the seal --- such as long hair(pull back to the extent possible), thick or poorly
fitting eyeglass temples, pencils or caps will lessen the protection.
- Earmuffs must be regularly inspected for cracks or worm parts and replaced as needed.
Typical life for foam cushion sealing rings is 12 months.
- Clean the exterior of the hearing protector regularly with soap and warm water. Do not
immerse the whole headset in water.
- Do not store the hearing protector behind a windshield or at temperatures above 131°F(55°C).
- Certain chemical substances may damage this product. Contact the manufacturer for more
information.
APPROVED
DESCRIPTION
INFORMATIONS
TEST FREQ.(HZ) 125 250 500 1000 2000 3150 4000 6300 8000 NRR
MEAN
ATTENUATION
(DB) 12.3 24.7 37.3 35.7 35.2 40.5 34.8 27.0 13.9 26
STANDARD
DEVEATION(DB) 1.1 0.3 1.0 1.7 3.1 2.4 4.4 2.8 1.3

If instructions are not followed, bodily injury may result or protection may be severely
These hearing protectors help reduce exposure to hazardous noise and other loud sounds.
Misuse or failure to wear hearing protectors at all times when you are exposed to noise may
result in hearing loss or injury.
If there is any drainage from your ear or if you have an ear infection, consult with your
physician before wearing hearing protection. Failure to do so may result in hearing loss or
injury.
For proper use, see user instructions or contact EARMOR customer service Email:
[email protected]
• Only use the specified type of battery provided by OPSMEN.
• When using lithium ion batteries, there is a risk of fire and burning. Do not open, squeeze,
heat above 50°C (122°F) or incinerate.
• If there is any damage or malfunction of the headset or accessories, stop using it.
• Contact OPSMEN official after-sales mailbox [email protected] for maintenance service.
• Only use the specified type of battery provided by OPSMEN.
• When using lithium ion batteries, there is a risk of fire and burning. Do not open, squeeze,
heat above 50°C (122°F) or incinerate.
• If there is any damage or malfunction of the headset or accessories, stop using it.
• Contact OPSMEN official after-sales mailbox [email protected] for maintenance service.
CAUTION
TO REDUCE THE SAFETY RISK WHEN USING THE PRODUCT
TO REDUCE THE SAFETY RISK WHEN USING THE PRODUCT
1. Press and hold two seconds to turn on the device for two seconds and enter the noise
reduction mode when you hear "Ambient listening Mode".
*After power on, the volume is the volume used last time.
2. Press Increase the ambient volume, keep pressing the volume will increase to the
maximum.
Press Reduce the ambient volume, keep pressing the volume will reduce to mute.
* Total of 5 levels of ambient volume to adjust.
3. Press and hold for two second to turn off, you will hear“power off”.
NOISE REDUCTION MODE

• Listening to music or audio communication may reduce situational awareness and the ability
to hear warning signals. Stay alert and adjust the volume to the lowest acceptable level.
• Use and maintain the hearing protector properly. Check the hearing protector before
each use. If it is damaged, please choose an undamaged hearing protector or avoid a noisy
environment.
• Do not bend or reshape the headband, and ensure that there is enough clamping force to fix
the earmuffs
• Earmuffs must be regularly inspected for cracks and leaks to be worn properly,replaced as
needed.
• The output of the electronic audio circuit of this hearing protector may exceed the daily limit
sound level. Please adjust the audio volume to the lowest acceptable level
TO REDUCE THE RISKS ASSOCIATED WITH HARMFUL NOISE
•The output of the level-dependent circuit of the hearing protector may exceed the external
sound level.
• Installing the sanitary cover on the cushion may affect the acoustic performance of the
earmuffs.
• Performance will decrease with battery consumption. The expected continuous use time of
the battery is approximately 8-13 hours.
• Maybe adversely affected by certain chemical substances. More information can be get from
the manufacturer.
This product contains electrical and electronic components and must not be disposed
of using standard garbage collection. Please consult your local electrical and electronic
equipment disposal instructions.
EN 352 SAFETY INFORMATION：

1. Press and hold for two seconds after turn on, you will hear “Bluetooth mode”, and LED
will blink blue light is Bluetooth mode.
2. After switching the mode, the indicator light flashes in red and blue to be a connectable
mode, and the prompt sound when the device is paired is“Bluetooth mode, Pairing On”, this
device is C51, After the selected device is successfully paired, you will hear “connected”.
*If the device is not connected to the mobile phone for more than five minutes, it will
automatically exit the Bluetooth mode and hear “Ambient listening Mode”.
3. After entering the Bluetooth" "mode, the sound pickup and noise reduction effect
will still be retained, press buttons to adjust the ambient volume.
*The volume of the Bluetooth needs to be adjusted by the mobile phone, and the C51
adjustment is only for the sound effect of pickup and noise reduction
4. Click the button to answer when a call comes in, long press the button for 2 seconds
to reject the call, and click the button to hang up during a call.
5. Click the button to play the music in the connected state, and then click the music to
pause.
6. Press and hold for two seconds, you will hear“Ambient listening Mode”, Exit the
Bluetooth mode and enter the noise reduction mode.
*In Bluetooth mode, the microphone can be used to make calls or send voice messages.
* Connect the TYPE-C interface through the charging cable for charging. When the headset is in
the charging state, the indicator light is red; and when the headset is fully charged, it is green.
*Do not open the battery compartment or replace the battery by yourself
* Low Battery Warning
BLUETOOTH MODE
CHARGING INSTRUCTION

FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modifications not
expressly approved by the party responsible for compliance. such
modifications could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement.
This equipment complies with FCC's RF radiation exposure limits set forth for
an uncontrolled environment. This device and its antenna(s) must not be co-
located or conjunction with any other antenna or transmitter.

Life time: 32 hours
Battery capacity: 800mAh
Charging current: 280mA
Use current: 15mA (70% volume Bluetooth music playback operating current)
Working temperature: -20 C° to 50C°
Storage temperature (full set): -20C° to 50 C°
Charging temperature: 0 C° to 50 C°
Protection level: IP42
The audio level in the hearing protector is dependent on the audio input level.
To prevent harmful noise levels, the hearing protector audio levels is limited to 82dB when
connected to a Personal Music Player (PMP). If the hearing protector is connected to a PMP
or other device with very high output level ,it is the user’s responsibility to set the audio input
level to a safe level.
EARMOR® C51 hearing protector is warranted to be free of defects in material and
workmanship for a period of 1 year from the date of original purchase.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
SPECIFICATIONS:
AUDIO INPUT LEVEL
WARRANTY
For the latest information on OPSMEN/EARMOR products and services
Please contact a local distributor or email OPSMEN distributor ：[email protected] / cs@
opsmen.com
OPSMEN official website http://www.opsmen.com/ shall prevail in case of any product data
changes.
CONTACT
